Netech UPM 2000 User manual

UPM 2000
Ultrasound Power Meter
User Manual
Manual P/N 1200-User-Manual
Initial Release-3/12/2008

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
2
1-800-547-6547

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
3
1-800-547-6547
Contents
Warranty...........................................................................................................................................4
Notices .............................................................................................................................................5
Safety Considerations......................................................................................................................8
Hazard Warnings .............................................................................................................................9
Precautions ......................................................................................................................................9
Electromagnetic Interference and Susceptibility............................................................................10
EC Directives .................................................................................................................................11
Chapter 1 General Information................................................................................13
Summary of Features.....................................................................................................................14
Ultrasound and Its Application .......................................................................................................15
Patient Treatment with Therapeutic Ultrasound. ...........................................................................16
Chapter 2 Description................................................................................................17
UPM 2000 Specifications...............................................................................................................18
Overall Unit Layout.........................................................................................................................19
Front Panel Description..................................................................................................................20
Back Panel Description..................................................................................................................21
Bottom Panel Description ..............................................................................................................22
Standard Accessories....................................................................................................................23
Optional Accessories .....................................................................................................................24
Chapter 3 Installation and the Operating Environment........................................25
Unpacking and Inspection..............................................................................................................26
Operation .......................................................................................................................................28
UPM 2000 Systems Check............................................................................................................30
Beginning Ultrasound Power Measurements ................................................................................32
Using the Universal Transducer Clamp Assembly and Centering Rings ......................................34
Ultrasound Unit Testing..................................................................................................................36
Using the RS232 Port ....................................................................................................................37
Chapter 4 Safety, Maintenance, and Storage..........................................................39
Recommended Procedures and Precautions................................................................................40
Calibration Check Procedures .......................................................................................................40
Maintenance...................................................................................................................................41
Service ...........................................................................................................................................41
Returning the UPM 2000 for Calibration........................................................................................42
Battery Replacement......................................................................................................................42
Storage...........................................................................................................................................42
Repackaging and Shipping....................................................................................................43
Appendix Troubleshooting..................................................................................................................47

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
4
1-800-547-6547
Warranty

Netech warrants the UPM 2000 against defects in materials and workmanship for one
year from the date of original purchase. The standard warranty is extended for a second
year if the instrument is returned to Netech for its recommended yearly recalibration.
During the warranty period, we will repair or, at our option, replace at no charge a
product that proves to be defective, provided you return the product shipping prepaid to
Netech Corporation. Only serialized products are covered under this warranty.
This warranty does not apply if the product has been damaged by accident or misuse or as
the result of service or modification by other than Netech Corporation, or if its serial
number is defaced or removed.
Netech reserves the right to discontinue the UPM 2000 at any time, and change its
specifications, price, or design without notice and without incurring any obligation.
Netech guarantees availability of service parts for 5 years after the manufacture of the
unit is discontinued.
The warranty is void if you elect to have the unit serviced and/or calibrated by someone
other than Netech Corporation.
The warranty covering your product becomes void when the tamper-resistant
Quality Seal is removed or broken without proper factory authorization.
We strongly recommend, therefore, that you send your instrument to Netech Corporation
for factory service and calibration, especially during the original warranty period.
The purchaser assumes all liability for any damages or bodily injury, which may result
from the use or misuse of the unit by the purchaser, his employees, agents, or customers.
Warranty may be void if shipping procedures are not adhered to.
In no event shall Netech Corporation be liable for consequential damages

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
5
1-800-547-6547
Notices
Copyright
Copyright © 2008 by Netech Corporation. All rights reserved. No part of this
publication may be reproduced or transmitted in any form other than for the
purchaser’s personal use without written permission from Netech Corporation.
Quality Assurance
Netech is ISO 9001-2000 Certified. This instrument was thoroughly tested and
inspected according to Netech’s ISO 9001-2000 quality standards and test
procedures and found to meet those specifications when it was shipped from the
factory.
Certification
Calibration measurements are traceable to the National Institute of Standards
and Technology (NIST). Devices for which there are no NIST calibration
standards are measured against in-house performance standards using accepted
test procedures.
Trademarks
Netech and UPM 2000 are trademarks of Netech Corporation. Any other
trademark names used in this manual are only for editorial purposes and the
benefit of the respective trademark owner with no intention of improperly using
that trademark.
Refunds and Credits
Please note that only serialized products and their accessory items (i.e., products
and items bearing a distinct serial number tag) are eligible for partial refund
and/or credit. Non-serialized parts and accessory items (e.g., cables, carrying
cases, auxiliary modules, etc.) are not eligible for return or refund. Only products
returned within 90 days from the date of original purchase are eligible for
refund/credit.

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
6
1-800-547-6547
In order to receive a partial refund/credit of a product purchase price on a serialized
product, the product must not have been damaged by the customer or by the carrier
chosen by the customer to return the goods, and the product must be returned
complete (meaning with all manuals, cables, accessories, etc.) and in “as new” and
resalable condition.
Products not returned within 90 days of purchase, or products, which are not in “as
new”, and resalable condition, are not eligible for credit return and will be returned
to the customer. The Return Procedure (see below) must be followed to assure
prompt refund/credit.
Restocking Charges
Products returned within 30 days of original purchase are subject to a minimum
restocking fee of 15 %. Products returned in excess of 30 days after purchase, but
prior to 90 days, are subject to a minimum restocking fee of 20 %. Additional
charges for damage and/or missing parts and accessories will be applied to all
returns.
Return Procedure
All items being returned (including all warranty-claim shipments) must be sent
freight-prepaid to our factory location. When you return an instrument to
Netech Corporation, we recommend using United Parcel Service, Federal
Express, or Air Parcel Post. We also recommend that you insure your shipment
for its actual replacement cost. Netech Corporation will not be responsible for
lost shipments or instruments that are received in damaged condition due to
improper packaging or handling. Use the original carton and packaging material
for shipment. If they are not available, contact Netech for replacement packing.
Returns for Refund / Credit
A Return Material Authorization (RMA) number must be obtained from our
service or customer service dept, before a product is returned for refund or
credit. The RMA number should be clearly marked on the package along with a
statement indicating the reason for return.

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
7
1-800-547-6547
Repair and Calibration
Products returned for repair or recalibration must obtain the service form which
can be down loaded from our website www.Netech.org/service or contact:
Netech Corporation
Service Dept.
110 Toledo Street
New York, 11735
Tel: [phone]
Email: [email protected]
WARNING
Unauthorizedusermodificationsorapplicationbeyondthe
publishedspecificationsmayresultinelectricalshock
hazardsorimproperoperation.NetechBiomedical
Corporationwillnotberesponsibleforanyinjuriessustained
duetounauthorizedequipmentmodifications.

Changesormodificationstothisunitnotexpresslyapproved
bythemanufacturercouldvoidtheuserʹsauthoritytooperate
theequipment.

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
8
Safety Considerations
Use of this instrument is restricted to qualified personnel who recognize shock
hazards and are familiar with safety precautions used when operating electrical
equipment. Read the manual carefully before operating the UPM2000.
The following warning symbols may be found on the UPM2000:
Symbol
Description
Caution: Risk of electric shock
Caution: Refer to documentation
Power Off (Mains)
Power On (Mains)
DC/AC
DC
AC
Earth (Ground)
1-800-547-6547

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
9
Hazard Warnings
∗ Warning! Power Rating. The UPM 2000’s mains power input must be connected
to an external power transformer that provides voltage and current within the
specified rating for the system.
Use of an incompatible power transformer may produce electrical shock and
fire hazards. See Specifications and Optional Accessories in Chapter 2.
∗ Warning! Internal Voltage. Always turn off the power switch and unplug the
power cord before cleaning the UPM 2000’s outer surface.
∗ Warning! Liquids. Avoid spilling liquids on the analyzer; fluid seepage into
internal components creates a potential shock hazard. Do not operate the
instrument if internal components are exposed to fluid.
Precautions
The following precautions are provided to help you avoid damaging the system:
∗ Caution: Service. Authorized service personnel should service the UPM 2000.
Only qualified technical personnel should perform troubleshooting and service
procedures on internal components.
∗ Caution: Environmental Conditions. Do not expose the system to temperature
extremes. Ambient temperatures should remain between 10-30°C operating or
5-40°C storage. System performance may be adversely affected if temperatures
fluctuate above or below this range.
∗ Caution: Do Not Immerse. Clean only with a mild detergent, and wipe down
with a gentle cloth.
1-800-547-6547

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
10
Based on the testing standards below,
this device bears the
mark.
Electromagnetic Interference and Susceptibility
USA FCC CLASS A
Warning: Changes or modifications to this unit not expressly approved by the
manufacturer could void the user's authority to operate the equipment. This
equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. Like all similar equipment, this
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause interference, in which case the user will be
required to correct the interference at his/her own expense.
Canadian Department of Communications Class A
ThisdigitalapparatusdoesnotexceedClassAlimitsforradioemissionsfrom
digitalapparatussetoutintheRadioInterferenceRegulationsoftheCanadian
DepartmentofCommunications.
Emissions - CLASS A
The system has been type tested by an independent, accredited testing laboratory
and found to meet the requirements of EN 61326-1:1998 for Radiated Emissions
and Line Conducted emissions. Verification of compliance was conducted to the
limits and methods of the following:
CISPR 16-1:1993 and CISPR 16-2:1996
1-800-547-6547

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
11
1-800-547-6547
Immunity
The system has been type tested by an independent, accredited testing laboratory
and found to meet the latest harmonized European emissions and immunity
standard requirements of EN 61326 for commercial measurement equipment.
Verification of compliance was conducted to the limits and methods of the
following:
EN 61326-1 IAW EN 61000-4-2 Electrostatic Discharge
EN 61326-1 IAW EN 61000-4-3 Annex D Radiated & Conducted EM
EN 61326-1 IAW EN 61000-4-4 Electrical Fast Transient/Burst
EN 61326-1 IAW EN 61000-4-5 Surge Immunity
EN 61326-1 IAW EN 61000-4-6 Conducted Disturbances
EN 61326-1 IAW EN 61000-4-11 Voltage Interrupts
EC Directive 73/23/EEC Low Voltage (User Safety)
The system has been type tested by an independent testing laboratory and found
to meet the requirements of EC Directive 73/23/EEC for Low Voltage.
Verification of compliance was conducted to the limits and methods of the
following:
EN 61010-1
“Safety Requirements for Electrical Equipment for Measurement, Control and
Laboratory Use, Part 1: General requirements” (including amendments 1 & 2).

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
12
1-800-547-6547

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
13
Chapter 1: General Information
Inside This Chapter
• Summary of Features
• Ultrasound and its Applications
• Patient Treatment with Therapeutic Ultrasound
1-800-547-6547
1

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
14
1-800-547-6547
Summary of Features
Netech’s UPM 2000 digital ultrasound power meter provides an accurate means of
verifying and calibrating the output of therapeutic ultrasound devices. The
instrument measures output through a strain gauge bridge transducer.
After the initial output is verified, the UPM 2000 is used to accurately calibrate the
ultrasound unit under test.
In addition, the UPM 2000:
• Has a resolution of 0.1 W and a repeatability of ±-3% of
readings ±.2 watts from 0 - 30 W;
• Maintains electrical accuracy of .01 grams throughout
range;
• Features a large, backlit, easy to read display that enables
the user to quickly and accurately make power
measurements;
• Can accommodate a variety of transducer shapes and sizes
without interfering with the measurement;
• Has a drain hose and stopper for convenient and
controlled drainage of the tank.
• Has a built in draft shield for improved stability in
readings.
• Measures total-pulsed or continuous-average power.
• Has a selectable readout in grams or watts.
• Can be battery operated or line-powered 120 VAC for
long-term sessions.
• Has an RS232 interface.
• Has a field calibration check.
• Is housed in a sturdy Kydex®case.
• Is portable to meet the needs of service groups and
biomedical engineers.
• Comes with a soft carrying case as a standard accessory for
ease of transporting and storage.

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
15
1-800-547-6547
Ultrasound and Its Applications
Human perception of sound waves is limited to frequencies of fewer than 20,000
vibrations per second. Higher frequency vibrations — between 0.7 and 3.3 MHz —
are used for ultrasound therapy. (Most ultrasound equipment produces an output of
between 1 and 3.3 MHz.)
An ultrasound unit produces electrical oscillations at a specified frequency that cause
the transducer in the ultrasound applicator to generate sound waves. The resulting
ultrasonic radiation is transmitted from the ultrasound applicator, or treatment head,
through a coupling medium, to the patient’s tissue.
Therapeutic Use of Ultrasound
The therapeutic use of ultrasonic energy is accepted worldwide, and most
modern hospitals and clinics have ultrasound devices in their physical therapy
departments.
Ultrasound therapy is primarily used in the treatment of sports-related injuries.
Another common use is the treatment of circulatory disorders and rheumatic
diseases of the musculoskeletal system and peripheral nerves. Ultrasound has
been found to be extremely effective in treating body areas with a great deal of
scar tissue.
Physiological Effects of Ultrasound Therapy
It is well documented that ultrasound therapy heals because of thermal,
mechanical, and chemical effects. *
Thermal effects include deep tissue heating at depths to 5 cm or more. The thermal
effects of ultrasound differ from diathermy (the use of electrical impulses to
produce generalized vasodilation) in that the ultrasound beam heats only a small
tissue area that approximates the cross-section of the beam. This heating effect is
concentrated in muscles, ligaments, nerves, bones, and where the ultrasound
beam crosses from one type of tissue to another.
The mechanical effects are best described as micro massage, a deep stirring action
within the tissue. The benefit of this action is an increased circulation to the
damaged tissue. In addition, ultrasound is capable of separating collagen fibers
from one another and of changing the tensile strength of tendons, thereby
increasing their extensibility.

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
16
1-800-547-6547
The physiological benefits from ultrasound therapy are numerous. Ultrasound
therapy affects the peripheral nerves by chemically changing the conduction
velocity (this has been shown clinically in situ). Ultrasound alters the diffusion of
Na+ and K+ (sodium and potassium) across red blood cell membranes.
Ultrasound can also remove some salt deposits from irritated tissues.
* Physical Agents for Physical Therapists, Second Edition, James E. Griffin and Terence Karselis, Charles C. Thomas
Publishing Co., 1992.
Patient Treatment with Therapeutic Ultrasound
The clinician working with ultrasound can ensure successful ultrasound treatment by
assessing:
λthe physical condition of the patient,
λthe absorption coefficient of the tissue(s),
λthe energy output of the ultrasound unit (continuous and pulsed),
λthe massivity and location of the affected tissue, and
λthe spread pattern of the beam.
The most essential assurance that the clinician can have is the verification that the
ultrasound unit is producing the ultrasound energy for which it was designed. The
Netech UPM 2000 digital power meter enables the clinician to accurately measure this
output energy.

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
17
Chapter 2: Description
Inside This Chapter
• Specifications
• Overall Unit Layout
• Front Panel Description
• Back Panel Description
• Standard Accessories
• Optional Accessories
1-800-547-6547
2

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
18
1-800-547-6547
UPM 2000 Specifications
• Measurement range 0.1 to 30 Watts
• Input Power Level 0 - 30 W
• Input Frequency 0.5 - 10 MHz
• Resolution 0.1 W
• Accuracy, electrical +/- .15 W (+/-.01 grams)
throughout range
• Repeatability ±3% of reading ±.2 watts
• Zero Shift Auto Zero button
• Acceptable Transducer Size up to 6.7 cm (2.65") diameter
• Operating Temperature 100- 300C (500- 860F)
• Power Requirements 9 V alkaline battery
(Duracell
®MN1604 or
equivalent)
• Battery Life Maximum of 10 hours
Note: Unit will auto shut down after approximately 10 minutes of
inactivity when on battery power. (A 12-volt DC 300 mA transformer unit
is a standard accessory for longer-term test sessions) Refer to page 26.
λ Dimensions 9” wide x 14 ½” deep
λHeight 7 ½” (10 ¾” with Clamp Post)
λCase Kydex
®Unit Layout

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
19
Overall Unit Layout
1-800-547-6547
Figure 2-1: UPM 2000 General Layout
The top of the UPM 2000 Ultrasound Power meter is shown in Figure 2-1. It
includes the following components.
• Front Panel: Includes LCD readout and keyboard.
• Rear Panel: Includes Battery compartment, RS-232 Connector and
Power Transformer Jack.
• Sound Tank: To be filled with 600ml ±50 ml of degassed and de-
ionized water for each use.
• Transducer Cone: The cone is removable for safe transporting.
• Leveling Bubble: Used to help level the unit before turning it on.
Leveling Jacks: Used to adjust the unit to a level position. (Figure 2-4)
• Universal Transducer Clamp Support Post: A removable vertically
mounted bar that the transducer clamp is attached.
Leveling
Bubble
Clamp
Support Post
Rear panel Sound Tank Transducer Cone
Front Panel
Cone Hanger

UPM 2000
Netech Corporation
110 Toledo St, Farmingdale, NY 11735
http://www.Netech.org
20
Front Panel Description
Figure 2-2: UPM 2000 Front Panel Layout
The front panel of the UPM 2000 ultrasound power meter is shown in Figure 2-2.
It includes the following components:
• LCD Display: Indicates the meter reading in watts or grams.
• Power On/Off Switch: Turns the power provided by an alkaline
battery (or transformer) on and off.
• Auto Zero Button: Adjusts the LCD display to 00.0 watts or 0.00
grams depending on the mode selected.
• Mode button: Switches the mode from watts to grams and back.
• Print Button: Sends the text on screen to the RS-232 port for
printing or recording
1-800-547-6547
