ProSafe™ Wireless ADSL Modem VPN
Firewall Router Data Sheet
DGFV338
Six-in-one Wireless and Wired VPN Solution
VPN, Wireless Access Point, Firewall, Router, Switch and ADSL2+ modem
This comprehensive and affordable solution offers wired, wireless connectivity with business-
class protection for small office and remote/branch office users. It combines six functions in
a single, compact package – Stateful Packet Inspection (SPI) firewall, 802.11g wireless access
point, IPSec Virtual Private Network (VPN), NAT router, an eight port 10/100 fast ethernet switch
and built-in ADSL2+ modem support.
Easy and relliable, the DGFV338 delivers both 10 and 100 Mbps connections for wired devices,
plus wireless support at 2.4 Ghz frequency at 54 Mbps radio transmission with up to 108 Mbps
in 802.11g (region specific).
More than just a simple NAT router, the ProSafe DGFV338 SPI firewall provides business-
class protection, blocking unwanted users from accessing the network. Support for Wi-Fi
Protected Access 2 Enterprise (WPA2) shields wireless communication with the highest available
level of industry-standard encryption and authentication. Comprehensive controls block or
filter unwanted addresses, services, protocols, and URLs, fortifying your network. Up to fifty
simultaneous IPSec VPN connections protect links between business locations, encrypting all
traffic as it traverses the Internet.
Ideal Solution for Telecommuters
and Remote Offices
The DGFV338 is easy to set up. It delivers all the advantages of centralized administration for
remote offices, teleworkers and small businesses, including dynamic DNS capabilities. Providing
support for ADSL2+, the DGFV338 also supports an Ethernet WAN port for failover on non-
ADSL connections.
ProSafe DGFV338 is the all-in-one solution for all your small to mid-sized business needs.
ProSafe
VPN Client Software
VPN01L/05L
Internet
Notebook PC with
Dual 108 Mbps
Wireless Adapter
PC Card (WAG511)
Desktop PC
with 10/100
NIC (FA311)
Desktop PC
with 10/100
NIC (FA311)
Notebook PC with
Dual 108 Mbps
Wireless Adapter
PC Card (WAG511)
ProSafe™ Wireless
ADSL Modem VPN
Firewall Router (DGFV338)

4500 Great America Parkway
Santa Clara, CA 95054 USA
1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
Technical Specifications
Wireless
Standards: IEEE, 802.11g, 54 Mbps,
Super G technology up to 108 Mbps
Antenna: (2) 5dBi, detachable
Physical Interfaces
LAN ports: Eight (8) 10/100Mbps auto-
sensing, Auto Uplink™ RJ-45 ports
WAN port: 10/100BASE-T
Ethernet RJ-45
ADSL WAN port: One (1) RJ-11
supporting annex A or Annex B
(Region Specific)
Security
SPI firewall: Stateful packet inspection
(SPI) Intrusion Detection System (IDS)
including logging, reporting and email
alerts, address, service and protocol,
Web URL keyword filtering, port/
service blocking. Advanced features
include block Java/URL/ActiveX
based on extension, FTP/SMTP/RPC
program filtering
VPN Functionality: Fifty (50) dedicated
VPN tunnels, Manual Key and Internet
Key Exchange Security Association (IKE
SA) assignment with pre-shared key
and RSA/DSA signatures, key life and
IKE lifetime settings, perfect forward
secrecy (Diffie-Hellman groups 1 and
2 and Oakley support), operating
modes (Main, Aggressive, Quick),
fully qualified domain name (FQDN)
support for dynamic IP address
VPN connections
IPSec Support: IPSec-based 56-bit
(DES), 168-bit (3DES), or 256-bit
(AES) encryption algorithm, MD5 or
SHA-1 hashing algorithm, AH/AH-ESP
support, PKI features with X.509 v.3
certificate support, remote access VPN
(client-to-site), site-to-site VPN, IPSec
NAT traversal (VPN pass-through)
Mode of operation: One-to-one/
many-to-one multi-network address
translation (NAT), classical routing,
unrestricted users per port
IP address assignment: Static IP
address assignment, DHCP replay,
DHCP address reservation
Wireless Security: Wi-Fi Protected
Access 2 Enterprise (WPA2), 802.1x
•
–
–
•
–
–
–
•
–
–
–
–
–
–
Performance Features:
Throughput: Up to 50 Mbps
WAN-to-LAN, up to 20 Mbps for
3DES throughput
Management Features
Administration interface: SNMP
(v2c) support, Web graphic user
interface, Secure Sockets Layer (SSL)
remote management, user name and
password protected; Secure Remote
Management support authenticated
through IP address or IP address range
and password; configuration changes/
upgrades through web GUI
Configuration and upgrades: Upload
and download configuration settings,
firmware upgradeable flash memory
Secure HTTPS remote management
support: Authenticated through IP
address or IP range and password
Functions
VPN Wizard to simplify configuration
of the VPN, port range forwarding,
port triggering, exposed host (DMZ),
enable/disable WAN ping, DNS
proxy, MAC address cloning/spoofing,
Network Time Protocol support,
keyword content filtering, email alerts,
DHCP server (info and display table),
WAN DHCP client, diagnostic tools
(ping, trace route, other), port/service/
MAC address blocking
Protocol Support
Network: IP routing, TCP/IP, UDP,
ICMP, PPPoE
IP Addressing: DHCP (client and server)
Routing: Static, RIPv1, RIPv2
VPN/Security: IPSec (ESP, AH), MD5,
SHA-1, DES, 3DES, IKE, PKI, AES
User Support
LAN: Up to 253 users
WLAN: Up to 20 users
Hardware
Processor: 266 Mhz 32-bit RISC
ADSL Processor: T. I. AR7
Memory: 8 MB flash, 32 MB SDRAM
Power requirements: 100-240V AC,
50-60Hz
•
–
•
–
–
–
•
–
•
–
–
–
–
•
–
–
•
–
–
–
–
Power adapter: 12V DC, 1.2A Plug is
localized to country of sale
Dimensions: 280 x 245 x 106 mm
(11.02 x 9.65 x 4.17 in)
Weight: 2.19 kg/4.83 lb
MTBF: 35141.413 hours =
4.012 years
Acoustic noise: 0 dB
Environmental Specifications
Operating temperature: 0° to 40°C
(32° to 104ºF)
Operating humidity: 90% maximum
relative humidity, non-condensing
System Requirements
Cable, DSL, and Internet service
Ethernet connectivity from
broadband modem
Wired or wireless capability for each PC
Network software (e.g. Windows®)
Internet Explorer 6.0 or higher,
Netscape Navigator 7.2 or higher,
Mozilla Firefox®1.5 or higher
Warranty
NETGEAR Lifetime Warranty†
ProSupport™ Service Packs
Available
On Call 24 x 7
PMB0331-100 (US)
PMB0331 (non-US)
Xpress HW
PRR0331
Package Contents
ProSafe Wireless ADSL Modem VPN
Firewall Router (DGFV338)
Ethernet cable
Two (2) detachable 5 dBi antenna
Installation guide
Resource CD with single user ProSafe
VPN Client Software license
Warranty/support information card
Ordering Information
Europe - General: DGFV338 - 100ISS
United Kingdom: DGFV338 - 100UKS
Germany: DGFV338 - 100GRS
Australia: DGFV338 - 100AUS
–
–
–
–
–
•
–
–
•
–
–
–
–
–
–
•
–
–
•
–
–
–
–
–
–
–
–
–
–
–
