NETGEAR FVX538v1 - ProSafe VPN Firewall Dual WAN Technical manual

October 2004
202-10066-01 (Beta Draft)
October 2004
NETGEAR, Inc.
4500 Great America Parkway
Santa Clara, CA 95054 USA
Network Planning Guide
for ProSafe VPN Firewall
Router FVX538

ii
October 2004
© 2004 by NETGEAR, Inc. All rights reserved. FullManual.
Trademarks
NETGEAR and Auto Uplink are trademarks or registered trademarks of NETGEAR, Inc..
Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Other brand and product names are registered trademarks or trademarks of their respective holders.
October 2004
Statement of Conditions
In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to
make changes to the products described in this document without notice.
NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit
layout(s) described herein.
Export Restrictions
The NETGEAR VPN Client (the “software”) is subject to United States Export Controls. The software may not be
exported or transmitted 1) into (or to a national or resident of) Cuba, Iran, Iraq, Libya, North Korea, Syria, Sudan or any
other country to which the United States has embargoed goods; or 2) to anyone on the United States Treasury
Department's list of Specially Designated Nationals or the U.S. Commerce Department's Table of Deny Orders. By using
this software, you agree to abide by the laws, rules and regulations - including, but not limited to the Export
Administration Act and the Arms Export Control Act - applicable to such use and not to transfer, by electronic
transmission or otherwise, the software to either a foreign national or a foreign destination in violation of any such laws.

Contents iii
October 2004
Contents
Chapter 1
Introducing the FVX538
The Router’s Front Panel ...............................................................................................1-1
The Router’s Rear Panel ................................................................................................1-3
Rack Mounting the Router ..............................................................................................1-3
The Router’s IP Address, Login Name, and Password ..................................................1-4
Default Factory Settings .................................................................................................1-4
Chapter 2
Network Planning
Overview of the Planning Process ..................................................................................2-1
Single or Multiple Exposed Hosts ............................................................................2-1
Virtual Private Networks (VPNs) ..............................................................................2-2
The Fail-over Case for Routers With Dual WAN Ports .............................................2-2
The Load Balancing Case for Routers With Dual WAN Ports ..................................2-2
Single or Multiple Exposed Hosts ...................................................................................2-3
Single Exposed Host ................................................................................................2-3
Multiple Exposed Hosts ............................................................................................2-5
Virtual Private Networks (VPNs) .....................................................................................2-6
VPN Road Warrior (Client-to-Gateway) ...................................................................2-8
VPN Gateway-to-Gateway .....................................................................................2-10
VPN Telecommuter (Client-to-Gateway Through a NAT Router) ...........................2-13

October 2004
iv Contents

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Introducing the FVX538 1-1
October 2004
Chapter 1
Introducing the FVX538
This chapter introduces the FVX538 ProSafe VPN Firewall Router.
The Router’s Front Panel
The FVX538 ProSafe VPN Firewall Router front panel shown below contains the port
connections, status LEDs, and the factory defaults reset button.
Figure 1-1: FVX538 Front Panel
You can use the LEDs to verify various conditions. Table 1-1 lists and describes each object on the
front panel of the router and its operation.
Table 1-1. Object Descriptions
Object Activity Description
Power LED On (Green)
Off Power is supplied to the router. Power is not supplied to the router.
Test LED On (Amber)
Blinking (Amber)
Off
Test mode: The system is initializing or the initialization has failed.
Writing to Flash memory (during upgrading or resetting to defaults).
The system has booted successfully.
Tes t
Power
Factory
Defaults
WAN1 WAN2
Gigabit
ProSafe VPN Firewall
14
58
MODEL FVX538
LAN
DMZ
Link/Act
Link/Act Speed
100
Active Active
Link/Act 100Link/Act 100
CONSOLE
Power Test
LED LED WAN1 Port
and LEDs WAN2 Port and LEDs
LAN Ports
and LEDs Console
Port
Factory
Defaults
Gigabit Port
and LEDs
DMZ Port
and LEDs Button

Network Planning Guide for ProSafe VPN Firewall Router FVX538
1-2 Introducing the FVX538
October 2004
WAN Ports
and LEDs Two RJ-45 WAN ports N-way automatic speed negotiation, Auto MDI/MDIX.
Link/Act LED
On (Green)
Blinking (Green)
Off
The WAN port has detected a link with a connected Ethernet device.
Data is being transmitted or received by the WAN port.
The WAN port has no link.
100 LED
On (Green)
Off The WAN port is operating at 100 Mbps. The WAN port is operating at 10 Mbps.
Active LED
On (Green)
On (Amber)
Off
The WAN port has a valid Internet connection.
The Internet connection is down.
The WAN port is either not enabled or has no link.
LAN Ports
and LEDs 8-port RJ-45 10/100 Mbps Fast Ethernet
Switch
N-way automatic speed negotiation, auto MDI/MDIX.
Link/Act LED
On (Green)
Blinking (Green)
Off
The LAN port has detected a link with a connected Ethernet device.
Data is being transmitted or received by the LAN port.
The LAN port has no link.
100 LED
On (Green)
Off The LAN port is operating at 100 Mbps. The LAN port is operating at 10 Mbps.
DMZ (port 8)
On (Green)
Off Port 8 is operating as a dedicated hardware DMZ port. Port 8 is operating as a normal LAN port.
Gigabit Port
and LEDs Gbit RJ-45 connector Port for connecting to a gigabit Ethernet device.
Link/Act LED
On (Green)
Blinking (Green)
Off
The LAN port has detected a link with a connected Ethernet device.
Data is being transmitted or received by the LAN port.
The LAN port has no link.
Speed LED
On (Green)
On (Amber)
Off
The LAN port is operating at 1,000 Mbps.
The LAN port is operating at 100 Mbps.
The LAN port is operating at 10 Mbps.
Console
Port DB9 male connector Port for connecting to an optional console terminal. Default baud rate is 9,600; pinouts: (2) Tx, (3) Rx, (5) and (7) Gnd.
Factory
Defaults — Factory Defaults reset push button (see “Default Factory Settings” on page 1-4 for the factory defaults).
Table 1-1. Object Descriptions (continued)
Object Activity Description

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Introducing the FVX538 1-3
October 2004
The Router’s Rear Panel
The rear panel of the FVX538 ProSafe VPN Firewall Router (Figure 1-2) contains the On/Off
switch and AC power connection.
Figure 1-2: FVX538 Rear Panel
Viewed from left to right, the rear panel contains the following elements:
•ACpowerin
•On/Offswitch
Rack Mounting the Router
The FVX538 can be mounted either on a desktop (using included rubber feet) or in a 19-inch rack
(using the included rack mounting hardware illustrated in Figure 1-3).
Figure 1-3: Attaching Mounting Brackets
100-240 VAC, 50-60Hz, 0.7A max.
On/Off
Switch
AC Power
Connection

Network Planning Guide for ProSafe VPN Firewall Router FVX538
1-4 Introducing the FVX538
October 2004
The Router’s IP Address, Login Name, and Password
Check the label on the bottom of the FVX538’s enclosure if you forget the following factory
default information:
• IP Address: http://192.168.1.1 to reach the Web-based GUI from the LAN
•Username:admin
• Password: password
Figure 1-4: FVX538 Bottom Label
Default Factory Settings
When you first receive your FVX538, the default factory settings will be set as shown in Table 1-2
below. You can restore these defaults with the Factory Defaults restore switch on the front panel —
see “The Router’s Front Panel” on page 1-1.
• Pressing this switch for a prolonged period (>5 seconds) causes the router to restore all factory
default settings and reboot.
• A shorter press and release causes the router to merely reboot.
ProSafe VPN Firewall FVX538
MAC
(internet)
http://192.168.1.1
user name: admin
password: password
DEFAULT ACCESS
MAC
(internet)
272-10134-01
SERIALMAC
(local)
N10947
E-E011-02-4749 (B)
IP Address
User Name
Password

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Introducing the FVX538 1-5
October 2004
Table 1-2. Factory Default Settings
Feature Default
User Name (case sensitive) admin
Password (case sensitive) password
Built-in DHCP server DHCP server is enabled, issues addresses in the
default subnet
IP Configuration IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
Gateway: 0.0.0.0
Time Zone GMT
Time Zone Adjust for Daylight Saving TIme Disabled
SNMP Disabled

Network Planning Guide for ProSafe VPN Firewall Router FVX538
1-6 Introducing the FVX538
October 2004

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Network Planning 2-1
October 2004
Chapter 2
Network Planning
This chapter describes the factors to consider when planning a network using a router that has dual
WAN ports.
Overview of the Planning Process
The areas that require planning when using a router that has dual WAN ports include:
• Single or multiple exposed hosts
• Virtual private networks (VPNs)
The two WAN ports can be configured on a mutually-exclusive basis to either:
• Fail over for increased system reliability, or
• Balance the load for outgoing traffic
These two categories of considerations interact to make the planning process more challenging.
Single or Multiple Exposed Hosts
Unrequested incoming traffic can be directed to one or more exposed hosts rather than being
discarded. As a result, the IP address of at least one WAN port must always be public.
The mechanism for making the IP address public depends on whether there are single or multiple
exposed hosts and whether the dual WAN ports are configured to either fail over or balance the
loads. See “Single or Multiple Exposed Hosts” on page 2-3 for further discussion.
Note: Exposed hosts are sometimes referred to as DMZ hosts. Unlike hardware-based
DMZ ports, however, exposed hosts are implemented in software and do not enjoy the
same level of firewall protection that hardware-based DMZ ports do. Use the exposed
host feature at your own risk.

Network Planning Guide for ProSafe VPN Firewall Router FVX538
2-2 Network Planning
October 2004
Virtual Private Networks (VPNs)
A virtual private network (VPN) tunnel provides a secure communication channel between either
two gateway VPN routers or between a remote PC client and gateway VPN router. As a result, the
IP address of at least one of the tunnel end points must be known in advance in order for the other
tunnel end point to establish (or re-establish) the VPN tunnel. See “Virtual Private Networks
(VPNs)” on page 2-6 for further discussion.
The Fail-over Case for Routers With Dual WAN Ports
Failover (Figure 2-1) for the dual WAN port case is different from the single gateway WAN port
case when specifying the IP address. Only one WAN port is active at a time and when it fails over,
the IP address of the active WAN port always changes. Hence, the use of a fully-qualified domain
name is always required, even when the IP address of each WAN port is fixed.
Figure 2-1: Dual WAN ports before and after failover
Features such as multiple exposed hosts are not supported when using dual WAN port failover
because the IP addresses of each WAN port must be in the identical range of fixed addresses.
The Load Balancing Case for Routers With Dual WAN Ports
Load balancing (Figure 2-2) for the dual WAN port case is similar to the single WAN port case
when specifying the IP address. Each IP address is either fixed or dynamic based on the ISP:
fully-qualified domain names must be used when the IP address is dynamic and are optional when
the IP address is static.
Note: Once the gateway router WAN port fails over, the VPN tunnel collapses and must
be re-established using the new WAN IP address.
Router
WAN1 port active
WAN1 IP
Dual WAN Ports (Before Failover)
WAN2 IP (N/A)
WAN2 port inactive
Router
WAN1 port inactive
WAN1 IP (N/A)
Dual WAN Ports (After Failover)
WAN2 IP
WAN2 port active
IP address of active WAN port changes after a failover:
o use of fully-qualified domain names always required
o features requiring fixed IP address blocks not supported
XX
XX

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Network Planning 2-3
October 2004
Figure 2-2: Dual WAN ports for load balancing
Single or Multiple Exposed Hosts
Incoming traffic from the Internet is normally discarded by the firewall unless the traffic is a
response to one of your local computers or a service that you have configured in the Inbound Rules
menu. Instead of discarding this traffic, you can have it forwarded to one or more LAN hosts on
your network. These LAN hosts are called exposed hosts.
The addressing of the router’s dual WAN port depends on the configuration being implemented:
Single Exposed Host
The Internet IP address of the router’s WAN port must be known to the public so that the public
can send incoming traffic to the exposed host when this feature is supported and enabled.
Table 2-1. IP addressing requirements for exposed hosts in dual WAN port systems
Configuration and
WAN IP address Single WAN Port (reference case)
Dual WAN Port Cases
Failover Load Balancing
Single exposed host Fixed Allowed
(FQDN optional) FQDN required Allowed (FQDN optional)
Dynamic FQDN required FQDN required FQDN required
Multiple exposed
hosts Fixed Address block required
(FQDN optional)
Not alloweda
a. Not allowed because to do so, the IP addresses of each WAN port would have to be the identical range of
fixed addresses.
Address block
required
(FQDN optional)
Dynamic Not allowed Not allowed Not allowed
Router
netgear1.dyndns.org
WAN1 IP
Dual WAN Ports (Load Balancing)
WAN2 IP
netgear2.dyndns.org
Use of fully-qualified domain names for IP addresses of WAN ports:
o required for dynamic IP addresses
o optional for fixed IP addresses

Network Planning Guide for ProSafe VPN Firewall Router FVX538
2-4 Network Planning
October 2004
Single Exposed Host: Single WAN Port (Reference Case)
In the single WAN case (Figure 2-3), the WAN’s Internet address is either fixed IP or a
fully-qualified domain name if the IP address is dynamic.
Figure 2-3: Single WAN port case with exposed host
Single Exposed Host: Dual WAN Ports for Improved System Reliability
In the dual WAN port case with failover (Figure 2-4), the WAN’s IP address will always change at
failover. A fully-qualified domain name must be used that toggles between the IP addresses of the
WAN ports (i.e., WAN1 or WAN2).
Figure 2-4: Dual WAN port case with exposed host, before and after failover
Single Exposed Host: Dual WAN Ports for Load Balancing
In the dual WAN port case for load balancing (Figure 2-5), the Internet address of each WAN port
is either fixed if the IP address is fixed or a fully-qualified domain name if the IP address is
dynamic.
Note: Load balancing is implemented for outgoing traffic and not for incoming traffic.
Consider making one of the WAN port Internet addresses public and keeping the other
one private in order to maintain better control of WAN port traffic.
Router
netgear.dyndns.org
WAN IP
IP address of WAN port:
FQDN is required for dynamic IP address and is optional for fixed IP address
exposed host
Router
netgear.dyndns.org
WAN1 IP
Dual WAN Ports (Before Failover)
WAN2 IP (N/A)
WAN2 port inactive
Router
WAN1 port inactive
WAN1 IP (N/A)
Dual WAN Ports (After Failover)
WAN2 IP
netgear.dyndns.org
IP address of active WAN port changes after a failover (use of fully-qualified domain names always required)
exposed host exposed host
XX
XX

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Network Planning 2-5
October 2004
Figure 2-5: Dual WAN port case for exposed host with load balancing
Multiple Exposed Hosts
The IP address range of the router’s WAN port must be both fixed and public so that the public can
send incoming traffic to the multiple exposed hosts when this feature is supported and enabled.
Multiple Exposed Hosts: Single WAN Port (Reference Case)
In the single WAN case (Figure 2-6), the WAN port’s IP address range must be fixed.
Figure 2-6: Single WAN port case with multiple exposed hosts
Multiple Exposed Hosts: Dual WAN Ports for Improved System Reliability
Using multiple exposed hosts with routers that have dual WAN ports for improved system
reliability is a disallowed combination because to do so, the IP addresses of each WAN port would
have to be the identical range of fixed addresses. Instead, use additional routers that have dual
WAN ports with a single exposed host for improved system reliability.
Multiple Exposed Hosts: Dual WAN Ports for Load Balancing
In the dual WAN port case for load balancing (Figure 2-7), the IP address range of each WAN port
must be fixed.
Router
netgear1.dyndns.org
WAN1 IP
Dual WAN Ports (Load Balancing)
WAN2 IP
netgear2.dyndns.org
IP addresses of WAN ports:
use of fully-qualified domain names
required for dynamic IP addresses
and optional for fixed IP addresses
exposed host
Router
22.23.24.25
22.23.24.26
...
WAN IPs
Single WAN Port
IP addresses of WAN port must be a fixed block
exposed hosts

Network Planning Guide for ProSafe VPN Firewall Router FVX538
2-6 Network Planning
October 2004
Figure 2-7: Dual WAN port case for multiple exposed hosts with load balancing
Virtual Private Networks (VPNs)
When implementing virtual private network (VPN) tunnels, a mechanism must be used for
determining the IP addresses of the tunnel end points. The addressing of the router’s dual WAN
port depends on the configuration being implemented:
Note: Load balancing is implemented for outgoing traffic and not for incoming traffic.
Consider publicizing one of the WAN port Internet addresses and keeping the other one
unpublicized in order to maintain better control of WAN port traffic.
Table 2-1. IP addressing requirements for VPNs in dual WAN port systems
Configuration and WAM IP address Single WAN Port
(reference case)
Dual WAN Port Cases
Failovera
a. All tunnels must be re-established after a failover using the new WAN IP adress.
Load Balancing
VPN Road Warrior
(client-to-gateway) Fixed Allowed (FQDN optional) FQDN required Allowed (FQDN optional)
Dynamic FQDN required FQDN required FQDN required
VPN Gateway-to-Gateway Fixed Allowed
(FQDN optional) FQDN required Allowed (FQDN optional)
Dynamic FQDN required FQDN required FQDN required
VPN Telecommuter
(client-to-gateway through
a NAT router)
Fixed Allowed
(FQDN optional) FQDN required Allowed (FQDN optional)
Dynamic FQDN required FQDN required FQDN required
Router
22.23.24.25, 22.23.24.26,...
WAN2 IP Addresses
Dual WAN Ports
IP addresses of WAN ports must be fixed blocks
exposed hosts
14.15.16.17, 14,15,16,18,...
WAN1 IP Addresses

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Network Planning 2-7
October 2004
For the single gateway WAN port case, the mechanism is to use a fully-qualified domain name
(FQDN) when the IP address is dynamic and to use either an FQDN or the IP address itself when
the IP address is fixed. The situation is different when dual gateway WAN ports are used in a
failover-based system.
• Failover Case for Dual Gateway WAN Ports
Failover (Figure 2-8) for the dual gateway WAN port case is different from the single gateway
WAN port case when specifying the IP address of the VPN tunnel end point. Only one WAN
port is active at a time and when it fails over, the IP address of the active WAN port always
changes. Hence, the use of a fully-qualified domain name is always required, even when the IP
address of each WAN port is fixed.
Figure 2-8: Dual gateway WAN ports before and after failover
• Load Balancing Case for Dual Gateway WAN Ports
Load balancing (Figure 2-9) for the dual gateway WAN port case is the same as the single
gateway WAN port case when specifying the IP address of the VPN tunnel end point. Each IP
address is either fixed or dynamic based on the ISP: fully-qualified domain names must be
used when the IP address is dynamic and are optional when the IP address is static.
Figure 2-9: Dual gateway WAN ports for load balancing
Note: Once the gateway router WAN port fails over, the VPN tunnel collapses and must
be re-established using the new WAN IP address.
Gateway
netgear.dyndns.org
WAN1 IP
Dual WAN Ports (Before Failover)
VPN Router WAN2 IP (N/A)
WAN2 port inactive
Gateway
WAN1 port inactive
WAN1 IP (N/A)
Dual WAN Ports (After Failover)
VPN Router WAN2 IP
netgear.dyndns.org
IP address of active WAN port changes after a failover (use of fully-qualified domain names always required)
XX
XX
Gateway
netgear1.dyndns.org
WAN1 IP
Dual WAN Ports (Load Balancing)
VPN Router WAN2 IP
netgear2.dyndns.org
IP addresses of WAN ports same as single
WAN port case (use of fully-qualified domain
names required for dynamic IP addresses
and optional for fixed IP addresses)

Network Planning Guide for ProSafe VPN Firewall Router FVX538
2-8 Network Planning
October 2004
VPN Road Warrior (Client-to-Gateway)
The following situations exemplify the requirements for a remote PC client with no router to
establish a VPN tunnel with a gateway VPN router:
• Single gateway WAN port
• Redundant dual gateway WAN ports for increased system reliability (before and after failover)
• Dual gateway WAN ports used for load balancing
VPN Road Warrior: Single Gateway WAN Port (Reference Case)
In the case of the single WAN port on the gateway VPN router (Figure 2-10), the remote PC client
initiates the VPN tunnel because the IP address of the remote PC client is not known in advance.
The gateway WAN port must act as the responder.
Figure 2-10: Single gateway WAN port case for VPN road warrior
The IP address of the gateway WAN port can be either fixed or dynamic. If the IP address is
dynamic, a fully-qualified domain name must be used. If the IP address is fixed, a fully-qualified
domain name is optional.
VPN Road Warrior: Dual Gateway WAN Ports for Improved System Reliability
In the case of the dual WAN ports on the gateway VPN router (Figure 2-11), the remote PC client
initiates the VPN tunnel with the active gateway WAN port (port WAN1 in this example) because
the IP address of the remote PC client is not known in advance. The gateway WAN port must act
as a responder.
Gateway A
bzrouter.dyndns.org
10.5.6.0/24
10.5.6.1
WAN IP WAN IP
LAN IP
Client B
FQDN 0.0.0.0
VPN Router
(at employer's
main office)
Road Warrior Example (Single WAN Port)
Remote PC
(running NETGEAR
ProSafe VPN Client)
Fully-Qualified Domain Names (FQDN)
- optional for Fixed IP addresses
- required for Dynamic IP addresses

Network Planning Guide for ProSafe VPN Firewall Router FVX538
Network Planning 2-9
October 2004
Figure 2-11: Dual gateway WAN ports, before failover, for VPN road warrior
The IP addresses of the gateway WAN ports can be either fixed or dynamic, but a fully-qualified
domain name must always be used because the active WAN port could be either WAN1 or WAN2
(i.e., the IP address of the active WAN port is not known in advance).
After a failover of the gateway WAN port (Figure 2-12), the previously inactive gateway WAN
port becomes the active port (port WAN2 in this example) and the remote PC client must
re-establish the VPN tunnel. The gateway WAN port must act as the responder.
Figure 2-12: Dual gateway WAN ports, after failover, for VPN road warrior
The purpose of the fully-qualified domain name is this case is to toggle the domain name of the
gateway router between the IP addresses of the active WAN port (i.e., WAN1 and WAN2) so that
the remote PC client can determine the gateway IP address to establish or re-establish a VPN
tunnel.
Gateway A
bzrouter.dyndns.org
10.5.6.0/24
10.5.6.1
WAN1 IP
WAN IP
LAN IP
Client B
0.0.0.0
VPN Router
(at employer's
main office)
Road Warrior Example
(Dual WAN Ports, Before Failover)
Remote PC
(running NETGEAR
ProSafe VPN Client)
Fully-Qualified Domain Names (FQDN)
- required for Fixed IP addresses
- required for Dynamic IP addresses
WAN2 port inactive
WAN2 IP (N/A)
XX
Gateway A
WAN1 port inactive
10.5.6.0/24
10.5.6.1
WAN1 IP (N/A)
WAN IP
LAN IP
Client B
0.0.0.0
VPN Router
(at employer's
main office)
Road Warrior Example
(Dual WAN Ports, After Failover)
Remote PC
(running NETGEAR
ProSafe VPN Client)
Fully-Qualified Domain Names (FQDN)
- required for Fixed IP addresses
- required for Dynamic IP addresses
bzrouter.dyndns.org
WAN2 IP
Remote PC must re-establish VPN tunnel after a failover
XX

Network Planning Guide for ProSafe VPN Firewall Router FVX538
2-10 Network Planning
October 2004
VPN Road Warrior: Dual Gateway WAN Ports for Load Balancing
In the case of the dual WAN ports on the gateway VPN router (Figure 2-13), the remote PC
initiates the VPN tunnel with the appropriate gateway WAN port (i.e., port WAN1 or WAN2 as
necessary to balance the loads of the two gateway WAN ports) because the IP address of the
remote PC is not known in advance. The chosen gateway WAN port must act as the responder.
Figure 2-13: Dual gateway WAN ports (load balancing case) for VPN road warrior
The IP addresses of the gateway WAN ports can be either fixed or dynamic. If an IP address is
dynamic, a fully-qualified domain name must be used. If an IP address is fixed, a fully-qualified
domain name is optional.
VPN Gateway-to-Gateway
The following situations exemplify the requirements for a gateway VPN router to establish a VPN
tunnel with another gateway VPN router:
• Single gateway WAN ports
• Redundant dual gateway WAN ports for increased system reliability (before and after failover)
• Dual gateway WAN ports used for load balancing
VPN Gateway-to-Gateway: Single Gateway WAN Ports (Reference Case)
In the case of single WAN ports on the gateway VPN routers (Figure 2-14), either gateway WAN
port can initiate the VPN tunnel with the other gateway WAN port because the IP addresses are
known in advance.
Gateway A
bzrouter1.dyndns.org
10.5.6.0/24
10.5.6.1
WAN1 IP
WAN IP
LAN IP
Client B
0.0.0.0
VPN Router
(at employer's
main office)
Road Warrior Example
(Dual WAN Ports, Load Balancing)
Remote PC
(running NETGEAR
ProSafe VPN Client)
Fully-Qualified Domain Names (FQDN)
- optional for Fixed IP addresses
- required for Dynamic IP addresses
bzrouter2.dyndns.org
WAN2 IP
