NETGEAR GS316 User manual

Installation
Step 1. Connect the equipment.
GS316 switch
16-Port Gigabit Ethernet
Unmanaged Switch
GS316
Step 2. Connect to power. Step 3. Check the status.
Power LED Port LEDs
On 1000 Mbps link (both LEDs)
O 100 Mbps link (le LED)
10 Mbps link (right LED)
Activity (blinking)
No link (o)
Optional wireless access point
Server Internet Computer

November 2015
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo are trademarks of NETGEAR, Inc. Any non‑NETGEAR
trademarks are used for reference purposes only.
Specifications
Specification Description
Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or
1000BASE-T
Network cable Category 5 (Cat 5) or better Ethernet cable
Ports 16
Power 12V/1.0A DC input
Power consumption 8.4W
Weight 0.84 kg (1.86 lb)
Dimensions (W x D x H) 286 x 101 x 26 mm (11.3 x 4.0 x 1.0 in.)
Operating temperature 0°–40°C (32°–104°F)
Operating humidity 10%–90% relative humidity, noncondensing
Support
Thank you for purchasing this NETGEAR product. You can visit
www.netgear.com/support to register your product, get help, access the latest
downloads and user manuals, and join our community. We recommend that you
use only ocial NETGEAR support resources.
For the current EU Declaration of Conformity, visit
http://support.netgear.com/app/answers/detail/a_id/11621/.
For regulatory compliance information, visit
http://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
