NETGEAR FS605 v3 User manual

Installation Guide
Optional
modem
Step 1. Position switch
Step 3. Connect power
Step 4. Check status
Step 2. Connect equipment
FS605v3
10/100 Mbps Ethernet Switch FS605v3/FS608v3
Optional router
Internet
Computer Server
On
Off
Power indicator
Activity (blinking)
No link (off)
Ethernet link
Port number indicator
FS605_608_v3 IG_23sept2012.fm Page 1 Sunday, September 23, 2012 6:00 PM

September 2012
This symbol appears in accordance with the European Union Directive 2002/96 on the Waste
Electrical and Electronic Equipment (the WEEE directive). If you dispose of this product in the
European Union, treat and recycle it in accordance with your jurisdiction’s laws that implement the
WEEE directive.
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to
change without notice. Other brand and product names are registered trademarks or trademarks of their
respective holders. © NETGEAR, Inc. All rights reserved.
For indoor use only in all EU countries and Switzerland.
For the complete EU Declaration of Conformity, visit
http://support.netgear.com/app/answers/detail/a_id/11621/.
Statement of Conditions: In the interest of improving internal design, operational function, and/or reliability,
NETGEAR reserves the right to make changes to the products described in this document without notice.
NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit
layout(s) described herein.
Specifications
Specification Description
Network interface RJ-45 connector for 10BASE-T or 100BASE-TX
Network cable Category 5 (Cat 5) or better Ethernet cable
Ports FS605v3: 5
FS608v3: 8
Power adapter 7.5V @ 1.0A DC input
Power consumption FS605v3: 2.1W max
FS608v3: 2.3W max
Weight FS605v3: 0.1.92 Kg (0.424 lbs)
FS608v3: 0.278 Kg (0.614 lbs)
Dimensions
(W x D x H)
FS605v3: 147 mm x 97 mm x 28 mm
(5.8 in. x 3.8 in. x 1.1 in.)
FS608v3: 171 mm x 113.2 mm x 28.5 mm
(6.73 in. x 4.46 in. x 1.12 in.)
Operating
temperature
0–40° C (32–104° F)
Operating humidity 10%–90% relative humidity, noncondensing
Electromagnetic
compliance
CE Class B, FCC Class B, VCCI Class B, C-Tick Class B
Safety agency
approvals
CE mark
Technical Support
After installing your device, locate the serial number on the label of your product and
use it to register your product at https://my.netgear.com.
You must register your product before you can use NETGEAR telephone support.
NETGEAR recommends registering your product through the NETGEAR web site.
For product updates and web support, visit http://support.netgear.com.
