NETGEAR GC110 Manual

Hardware Installation Guide
Insight Managed 8-Port Gigabit Ethernet
Smart Cloud Switch with 2 SFP Fiber Ports
(and PoE on Model GC110P Only)
Models GC110 and GC110P
NETGEAR, Inc.
350 E. Plumeria DriveApril 2020
San Jose, CA 95134, USA202-11953-02

Support and Community
Visit netgear.com/support to get your questions answered and access the latest
downloads.
You can also check out our NETGEAR Community for helpful advice at
community.netgear.com.
Regulatory and Legal
Si ce produit est vendu au Canada, vous pouvez accéder à ce document en français
canadien à https://www.netgear.com/support/download/.
(If this product is sold in Canada, you can access this document in Canadian French at
https://www.netgear.com/support/download/.)
For regulatory compliance information including the EU Declaration of Conformity, visit
https://www.netgear.com/about/regulatory/.
See the regulatory compliance document before connecting the power supply.
For NETGEAR’s Privacy Policy, visit https://www.netgear.com/about/privacy-policy.
By using this device, you are agreeing to NETGEAR’s Terms and Conditions at
https://www.netgear.com/about/terms-and-conditions. If you do not agree, return the
device to your place of purchase within your return period.
Do not use this device outdoors. The PoE source is intended for intra building connection
only.
Trademarks
©NETGEAR, Inc. NETGEAR, and the NETGEAR Logo are trademarks of NETGEAR, Inc.
Any non-NETGEAR trademarks are used for reference purposes only.
Revision History
CommentsPublish DatePublication Part
Number
We revised Overview on page 6.
We revised Safety instructions and warnings on page 9.
We changed the Ethernet cable to a flat Ethernet cable in Step 3: Unpack
the switch on page 25.
We made other minor changes.
April 2020202-11953-02
First publication.October 2018202-11953-01
2
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Contents
Chapter 1 Introduction
Overview................................................................................................6
Features.................................................................................................8
Safety instructions and warnings........................................................9
Chapter 2 Hardware Overview
Hardware description........................................................................13
Front panel......................................................................................13
Back panel.......................................................................................13
LEDs.................................................................................................15
Switch hardware interfaces...............................................................16
RJ-45 ports for 10/100/1000M BASE-T Ethernet connectivity..16
SFP ports for fiber connectivity....................................................16
Multi-function Reset button..........................................................17
Chapter 3 Applications
PoE applications.................................................................................19
PoE overview..................................................................................19
Connect PoE equipment in a business environment................19
Connect PoE equipment for surveillance and security.............20
Desktop switching..............................................................................21
Chapter 4 Installation
Step 1: Prepare the site......................................................................24
Step 2: Protect against electrostatic discharge..............................24
Step 3: Unpack the switch.................................................................25
Step 4: Install the switch....................................................................27
Install the switch on a flat surface.................................................27
Wall-mount the switch...................................................................27
Wall-mount the switch vertically..............................................28
Wall-mount the switch horizontally.........................................30
Mount the switch to a pole or another surface..........................31
Optional Step 5: Install SFP transceiver modules...........................32
Step 6: Connect devices to the switch.............................................32
Step 7: Check the installation...........................................................33
Step 8: Apply power and check the LEDs.......................................33
3

Step 9: Manage the switch................................................................34
Chapter 5 Troubleshooting
Troubleshooting chart.......................................................................36
PoE troubleshooting suggestions....................................................37
Additional troubleshooting suggestions.........................................37
4
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

1
Introduction
This hardware installation guide is for the following NETGEAR Insight Managed switch
models:
•8-Port Gigabit Ethernet Insight Managed Smart Cloud Switch with 2 SFP Fiber Ports,
Model GC110
•8-Port Gigabit Ethernet PoE Insight Managed Smart Cloud Switch with 2 SFP Fiber
Ports, 62W PoE, Model GC110P
The switch provides eight Gigabit Ethernet RJ-45 copper ports and two dedicated
Gigabit SFP fiber ports.
Model GC110P supports Power over Ethernet (PoE) on all eight RJ-45 copper ports so
that you can let the switch provide power to PoE-capable devices such as WiFi access
points, VoIP phones, and IP security cameras. Model GC110P can supply up to 15.4W
PoE (IEEE 802.3af) to each port, with a maximum PoE power budget of 62W across all
active PoE ports.
This hardware installation guide complements the installation guide that came with your
switch.
The chapter serves as an introduction to the switch and includes the following sections:
• Overview
• Features
• Safety instructions and warnings
Note: For more information about the topics that are covered in this manual, visit the
support website at netgear.com/support.
Note: For technical specifications on the Models GC110 and GC110P, visit
https://www.netgear.com/GC110 and see the data sheet under the Resources tab. For
switch documentation, visit netgear.com/support/download.
5

Overview
The switch provides eight Gigabit Ethernet copper ports and two dedicated Gigabit
SFP fiber ports. All copper ports use RJ-45 connectors. The SFP ports require a standard
small form-factor pluggable (SFP) gigabit interface converter (GBIC, also referred to as
transceiver module), which is sold separately from the switch. The switch integrates
full-duplex, nonblocking switch fabric that provides full-wire speed for all packet sizes.
The PoE model supports PoE on all copper ports with a maximum PoE power budget
of 62W across all active PoE ports.
Note: For information about application examples, see Applications on page 18.
The switch provides management options that let you discover the switch on the network
and configure, monitor, and control the switch:
•NETGEAR Insight app. Using the NETGEAR Insight app, you can discover the switch
on the network and add the switch to the NETGEAR Insight app so that you can set
up the switch in the network and manage and monitor the switch remotely from your
mobile device. You can choose from four methods to add the switch to the NETGEAR
Insight app: You can scan your network for the switch, scan the QR code or the
barcode of the switch, or type in the serial number of the switch. For more information,
see the NETGEAR knowledge base articles at netgear.com/support.
•Insight Cloud portal. Using the NETGEAR Insight Cloud portal, you can set up the
switch in the network, perform advanced remote management, monitor the switch,
analyze the switch and network usage, and, if necessary, troubleshoot the switch
and the network. The Insight Cloud portal is available to Insight Premium and Insight
Pro subscribers. A free trial of Insight Premium is available for new customers.
•Local browser user interface (UI). By default, the management mode of the switch
is set to NETGEAR Insight. With this setting you can manage the switch using the
Insight app or the Insight Cloud portal. For complex tasks such as integrating with
an existing network of devices that are not managed through Insight, and for
debugging purposes, you can use the local browser UI to change the management
mode of the switch to Direct Connect Web-browser Interface (Local LAN Only). In
this mode, you can change the settings of the specific switch, but we recommend
that you do not use this mode to change settings that are Insight manageable because
they will not be synchronized with Insight or to the network location and other devices
to which you assigned the switch.
Hardware Installation Guide6Introduction
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Note: Changes to Insight-manageable settings from the local browser UI might also
create conflicts with the rest of the Insight-managed network to which the device is
connected. While you manage the switch with the local browser UI, you cannot use
the Insight app or Insight Cloud portal. To reenable management of the device
remotely or through the cloud, you can return the management mode to NETGEAR
Insight at any time so that you can manage the switch with the Insight app or Insight
Cloud portal.
For more information about the local browser UI, see the user manual, which you
can download from netgear.com/support/download.
Note: The switch is designed for management by NETGEAR Insight: You can use
the NETGEAR Insight app on your mobile device or the Insight Cloud portal from a
web browser on your Windows-based computer, Mac, or tablet. By default, the local
browser UI is disabled and you cannot use it while the switch is managed by NETGEAR
Insight.
You can install the switch freestanding (on a desktop) or wall-mounted, using the
VESA-standard mounting holes and supplied wall-mount kit. The switch is IEEE compliant
and offers low latency. All ports can automatically negotiate to the highest speed, which
makes the switch very suitable for a mixed environment with Gigabit Ethernet and Fast
Ethernet.
For Gigabit Ethernet connections, use Category 5e (Cat 5e) or higher-rated Ethernet
cables terminated with RJ-45 connectors.
Hardware Installation Guide7Introduction
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Features
The switch includes the following key hardware features:
•Eight Gigabit Ethernet ports.
•Two dedicated Gigabit SFP fiber ports.
•PoE on copper ports (model GC110P):
-Eight ports PoE (IEEE 802.3af)
-Total PoE power budget of 62W
•MAC table size of 16K entries.
•Switch fabric full duplex nonblocking.
•Includes the following mounting hardware:
-Four rubber footpads for tabletop installation
-Wall-mount screw kit for wall installation
•Full compatibility with IEEE standards:
- IEEE 802.3 Ethernet
- IEEE 802.3u 100BASE-T
- IEEE 802.3ab 1000BASE-T
- IEEE 802.3z Gigabit Ethernet 1000BASE-SX/LX
- IEEE 802.1Q VLAN tagging
-IEEE 802.3x Full-duplex flow control
- IEEE 802.3ad Link aggregation (LAG with LACP)
- IEEE 802.1ab LLDP
-IEEE 802.1p Class of Service (QoS)
- IEEE 802.1D Spanning Tree Protocol (STP)
- IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
- IEEE 802.1x RADIUS network access control
-IEEE 802.3az Energy Efficient Ethernet (EEE)
-IEEE 802.3af (PoE)
Hardware Installation Guide8Introduction
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

•AutoSensing and autonegotiating capabilities for all ports.
•Auto Uplink™ technology is supported on all ports.
•Automatic address learning function to build the packet-forwarding information
table. The table contains up to 16K Media Access Control (MAC) addresses.
•Store-and-forward transmission to remove bad packets from the network.
•Active flow control to minimize packet loss and frame drops.
•Half-duplex backpressure control.
•Per-port status LEDs and system status LEDs:
-System Power LED (front and back panels)
-Cloud Connection LED (front and back panels)
- PoE Max or Fault LED (model GC110P only)
-Per-port link, speed, and activity LED for copper ports
-Per-port PoE status LED for copper ports (model GC110P only)
-Per-port link and activity LED for SFP fiber ports
•NETGEAR green power-saving features:
-Energy efficiency mode that fully conforms to the IEEE 802.3az standard
- Per-port automatic change to a lower power mode when the port link is down
Safety instructions and warnings
Use the following safety guidelines to ensure your own personal safety and to help
protect your system from potential damage.
To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment,
observe the following precautions:
•This product is designed for indoor use only in a temperature-controlled and
humidity-controlled environment. For more information, see the environmental
specifications in the appendix or the data sheet.
Any device that is located outdoors and connected to this product must be properly
grounded and surge protected.
Failure to follow these guidelines can result in damage to your NETGEAR product,
which might not be covered by NETGEAR’s warranty, to the extent permissible by
applicable law.
Hardware Installation Guide9Introduction
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

•Observe and follow service markings:
- Do not service any product except as explained in your system documentation.
Some devices should never be opened.
-If applicable to your device, opening or removing covers that are marked with
the triangular symbol with a lightning bolt can expose you to electrical shock.
We recommend that only a trained technician services components inside these
compartments.
•If any of the following conditions occur, unplug the product from the electrical outlet
and replace the part or contact your trained service provider:
- Depending on your device, the power adapter, power adapter cable, power
cable, extension cable, or plug is damaged.
-An object fell into the product.
- The product was exposed to water.
- The product was dropped or damaged.
-The product does not operate correctly when you follow the operating
instructions.
•Keep your system away from radiators and heat sources. Also, do not block cooling
vents.
•Do not spill food or liquids on your system components, and never operate the
product in a wet environment. If the system gets wet, see the appropriate section in
your troubleshooting guide, or contact your trained service provider.
•Do not push any objects into the openings of your system. Doing so can cause fire
or electric shock by shorting out interior components.
•Use the product only with approved equipment.
•If applicable to your device, allow the product to cool before removing covers or
touching internal components.
•Operate the product only from the type of external power source indicated on the
electrical ratings label. If you are not sure of the type of power source required,
consult your service provider or local power company.
•To avoid damaging your system, if your device uses a power supply with a voltage
selector, be sure that the selector is set to match the power at your location:
-115V, 60 Hz in most of North and South America and some Far Eastern countries
such as South Korea and Taiwan
- 100V, 50 Hz in eastern Japan and 100V, 60 Hz in western Japan
-230V, 50 Hz in most of Europe, the Middle East, and the Far East
Hardware Installation Guide10Introduction
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

•Be sure that attached devices are electrically rated to operate with the power available
in your location.
•Depending on your device, use only a supplied power adapter or approved power
cable:
If your device uses a power adapter:
-If you were not provided with a power adapter, contact your local NETGEAR
reseller.
-The power adapter must be rated for the product and for the voltage and current
marked on the product electrical ratings label.
If your device uses a power cable:
-If you were not provided with a power cable for your system or for any
AC-powered option intended for your system, purchase a power cable approved
for your country.
-The power cable must be rated for the product and for the voltage and current
marked on the product electrical ratings label. The voltage and current rating of
the cable must be greater than the ratings marked on the product.
•To help prevent electric shock, plug the system and peripheral power cables into
properly grounded electrical outlets.
•If applicable to your device, the peripheral power cables are equipped with
three-prong plugs to help ensure proper grounding. Do not use adapter plugs or
remove the grounding prong from a cable. If you must use an extension cable, use
a three-wire cable with properly grounded plugs.
•Observe extension cable and power strip ratings. Make sure that the total ampere
rating of all products plugged into the extension cable or power strip does not
exceed 80 percent of the ampere ratings limit for the extension cable or power strip.
•To help protect your system from sudden, transient increases and decreases in
electrical power, use a surge suppressor, line conditioner, or uninterruptible power
supply (UPS).
•Position system cables, power adapter cables, or power cables carefully. Route
cables so that they cannot be stepped on or tripped over. Be sure that nothing rests
on any cables.
•Do not modify power adapters, power adapter cables, power cables or plugs. Consult
a licensed electrician or your power company for site modifications.
•Always follow your local and national wiring rules.
Hardware Installation Guide11Introduction
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

2
Hardware Overview
This chapter describes the switch hardware features.
The chapter includes the following sections:
• Hardware description
• Switch hardware interfaces
12

Hardware description
The following sections describe the switch hardware features.
Front panel
The front panel does not contain any components other than two LEDs: The upper LED
is the Cloud Connection LED and the lower LED is the Power LED (see LEDs on page
15).
Figure 1. Front panel
Back panel
Model GC110 provides eight 10/100/1000BASE-T RJ-45 ports and two dedicated
Gigabit SFP fiber ports.
Model GC110P provides eight 10/100/1000BASE-T RJ-45 PoE ports and two dedicated
Gigabit SFP fiber ports.
Both models require DC power and come with an external power adapter.
The following figures show the back panels.
Figure 2. Back panel model GC110
Hardware Installation Guide13Hardware Overview
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Figure 3. Back panel model GC110P
Table 1. Back panel components
DescriptionNumber
Cloud Connection LED (see LEDs on page 15).1a
Power LED (see LEDs on page 15).1b
PoE Max or Fault LED (see LEDs on page 15) for model GC110P only.1c
Recessed multi-function Reset button (see Multi-function Reset button on page 17).2
Model GC110. Eight independent 10/100/1000BASE-T RJ-45 ports, each with a left LED that
functions as the combined speed and activity LED (see LEDs on page 15). The right LED is
nonfunctioning.
Model GC110P. Eight independent 10/100/1000BASE-T RJ-45 PoE ports, each with a left LED
that functions as the combined speed and activity LED and a right LED that indicates the PoE status
(see LEDs on page 15).
3
Two dedicated Gigabit SFP fiber ports that can accept optional transceiver modules (see SFP
ports for fiber connectivity on page 16) with a single LED that functions as the combined link and
activity LED (see LEDs on page 15).
4
DC power receptacle for the DC power adapter that came in the switch package.5
Kensington lock for an optional security cable.6
Hardware Installation Guide14Hardware Overview
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

LEDs
This section describes the LED designations of the switch.
Table 2. LEDs on the back panel
DescriptionLED
Solid blue. The switch is connected to the cloud server and is set up to be managed
by the NETGEAR Insight app.
Off. The switch is not connected to the cloud server or is set up to be managed by
the local browser UI.
Cloud Connection LED
Solid green. The switch is powered on.
Solid amber. The switch is booting.
Off. Power is not supplied to the switch.
Power LED
Off. Sufficient (more than 7W of) PoE power is available.
Solid amber. Less than 7W of PoE power is available.
Blinking amber. At least once during the previous two minutes, less than 7W of PoE
power was available.
PoE Max/Fault LED
Model GC110P only
Off. No link is established.
Solid green. A valid 1 Gbps link is established.
Blinking green. The port is transmitting or receiving packets at 1 Gbps.
Solid amber. A valid 10 Mbps or 100 Mbps link is established.
Blinking amber. The port is transmitting or receiving packets at 10 Mbps or 100
Mbps.
RJ-45 left LED
Link, speed, and activity for
Ethernet ports 1 to 8
Off. The port is not delivering PoE power.
Solid green. The port is delivering PoE power.
Solid amber. A PoE fault occurred.
RJ-45 right LED
PoE status for Ethernet ports
1 to 8 for model GC110P
only
Off. No SFP module link is established.
Solid green. A valid 1 Gbps link is established.
Blinking green. The SFP fiber port is transmitting or receiving packets at 1 Gbps.
Link/ACT LED
Link and activity for SFP fiber
ports 9 and 10
Table 3. LEDs on the front panel
DescriptionLED
Solid blue. The switch is connected to the cloud server and is set up to be managed
by the NETGEAR Insight app.
Off. The switch is not connected to the cloud server or is set up to be managed by
the local browser UI.
Cloud Connection LED
Solid green. The switch is powered on.
Solid amber. The switch is booting.
Off. Power is not supplied to the switch.
Power LED
Hardware Installation Guide15Hardware Overview
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Switch hardware interfaces
The following sections describe the hardware interfaces on the switch.
RJ-45 ports for 10/100/1000M BASE-T Ethernet connectivity
All RJ-45 copper ports support autosensing. When you insert a cable into an RJ-45 port,
the switch automatically ascertains the maximum speed (10 Mbps, 100 Mbps, or 1 Gbps)
and duplex mode (half-duplex or full-duplex) of the attached device. All ports support
a Category 5e (Cat 5e) cable (or higher-rated Ethernet cable) terminated with an 8-pin
RJ-45 connector.
To simplify the procedure for attaching devices, all RJ-45 ports support Auto Uplink
technology. This technology allows attaching devices to the RJ-45 ports with either
straight-through or crossover cables.
When you insert a cable into the switch’s RJ-45 port, the switch automatically performs
the following actions:
•Senses whether the cable is a straight-through or crossover cable.
•Determines whether the link to the attached device requires a normal connection
(such as when you are connecting the port to a computer) or an uplink connection
(such as when you are connecting the port to a router, switch, or hub).
•Automatically configures the RJ-45 port to enable communications with the attached
device. The Auto Uplink technology compensates for setting uplink connections
while eliminating concern about whether to use crossover or straight-through cables
when you attach devices.
All RJ-45 copper ports on model GC110P support Power over Ethernet (PoE).
SFP ports for fiber connectivity
To enable fiber connections on the switch, SFP fiber ports accommodate standard small
form-factor pluggable (SFP) gigabit interface converters (GBICs, also referred to as
transceiver modules). GBICs are sold separately from the switch.
The switch supports the NETGEAR SFP transceiver modules that are listed in the following
table.
Hardware Installation Guide16Hardware Overview
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Table 4. Supported SFP transceiver modules
DescriptionModelSpeed and Medium
SFP transceiver 1000BASE-SXAGM731F1G Ethernet short-reach fiber
SFP transceiver 1000BASE-LXAGM732F1G Ethernet long-reach fiber
SFP transceiver 1000BASE-TAGM7341G Ethernet copper
For more information about NETGEAR SFP transceiver modules, visit
netgear.com/business/products/switches/modules-accessories.
Note: If you use a third-party passive direct-attach cable (DAC), the length of the cable
must not exceed 5 meters (16.4 feet).
Multi-function Reset button
The switch provides a recessed multi-function Reset button on the back panel so that
you can either restart (power-cycle) the switch, reset the switch to the most recently
saved cloud-managed configuration, or return the switch to its factory default settings,
causing all custom settings to be erased. The factory default settings function of the
Reset button is available only after you use the NETGEAR Insight app to remove the
switch from your network.
To restart or reset the switch or return the switch to its factory default settings:
1. Insert a device such as a straightened paper clip into the opening.
2. Do one of the following:
•Restart the switch. Press the Reset button for about two seconds. (Do not press
the button for more than five seconds!)
The switch restarts but retains its custom settings. During this process, the Power
LED lights amber.
•Reset the switch to the most recently saved cloud-managed configuration.
Press the Reset button for at least five seconds.
The switch restarts and returns to the most recently saved cloud-managed
configuration. During this process, the Power LED lights amber.
•Return the switch to its factory default settings. After you use the NETGEAR
Insight app to remove the switch from your network, press the Reset button for
at least five seconds.
The switch restarts and returns to its factory default settings. During this process,
the Power LED lights amber.
Hardware Installation Guide17Hardware Overview
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

3
Applications
The switch is designed to provide flexibility in configuring network connections. The
switch can be used as your only network traffic–distribution device for PoE (on model
GC110P) and non-PoE devices or with 10 Mbps, 100 Mbps, and 1 Gbps Ethernet and
fiber hubs, routers, and switches.
This chapter includes the following sections:
• PoE applications
• Desktop switching
18

PoE applications
This section covers the following topics:
• PoE overview
• Connect PoE equipment in a business environment
• Connect PoE equipment for surveillance and security
PoE overview
Model GC110P supports eight Power over Ethernet (PoE) ports. The switch can supply
up to 15.4W PoE (IEEE 802.3af) to each port up to its total maximum PoE power budget
of 62W across all active PoE ports.
Supplied power is prioritized according to the port order, up to the total power budget
of the device. Port 1 receives the highest PoE priority, while port 8 is relegated to the
lowest PoE priority.
If the power requirements for attached devices exceed the total power budget of the
switch, the PoE power to the device on the highest-numbered active PoE port is disabled
to make sure that the devices connected to the higher-priority, lower-numbered PoE
ports are supported first.
Although a device is listed as an 802.3af PoE-powered device, it might not require the
maximum power limit that is specified by its IEEE standard. Many devices require less
power, allowing all eight PoE ports to be active simultaneously when the devices correctly
report their PoE class to the switch.
Connect PoE equipment in a business environment
The following figure shows an example of how you can connect PoE wireless access
points that require 802.3af only, PoE VoIP phones, and PoE surveillance equipment to
the switch in a business environment.
In a small office or home office network, the blue network icon represents a router that
is connected to an Internet modem. In such a setup, you must connect one port on the
switch to a LAN port on the router.
Hardware Installation Guide19Applications
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports

Figure 4. Sample PoE business use case
ConnectionLine Color
Internet router or gatewayPurple
PoE devices such as Insight managed (or other) WiFi access points, Arlo (or
other) security cameras, and VoIP phones
Blue
Network devices such as a desktop computerBlack
Connect PoE equipment for surveillance and security
The following figure shows an example of how you can connect PoE and non-PoE
equipment to the switch for surveillance and security purposes.
In a small office or home office network, the blue network icon represents a router that
is connected to an Internet modem. In such a setup, you must connect one port on the
switch to a LAN port on the router.
Hardware Installation Guide20Applications
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
