ProSafe®16-port Gigabit Desktop Switch Data Sheet
GS116
Power up Your Small Network to Gigabit Speeds
Now you can have a powerful, high-speed network on a small scale. NETGEAR’s ProSafe
GS116 Gigabit Ethernet Switch lets you build a system that provides full, dedicated 1000 Mbps
connections so you can move very large files across your network instantly. The standards-based
GS116 helps to protect your existing and future network infrastructure investments by painlessly
integrating other 10, 100, and 1000 Mbps devices. This potent switch is ideal for workgroups or
quickly upgrading workstations to full Gigabit speed, plus it’s packed with ease-of-use features
to simplify your workday experience. It’s compact design fits neatly into small work spaces and,
since it’s self-cooling without a fan, it runs silently and unobtrusively.
Power-Packed Moves huge files fast! Features 16 high-speed, auto-switching 10/100/1000 Mbps Ethernet
connections. And because copper Gigabit Ethernet is a full duplex standard, you can get up
to 2000 Mbps on each port. The GS116 supports jumbo frames up to 9,000 Bytes for extra
large transfers.
Versatile Integrates 10, 100, and 1000 Mbps devices on the same network and will honor Layer 2
802.1p and Layer 3 DSCP traffic priority tags. Every port automatically senses the right speed
and full/ half duplex mode, while Auto UplinkTM technology automatically adjusts for straight-
through or crossover cables.
Accommodating LEDs embedded in each of the 16 RJ-45 jacks make for easy monitoring. Space-saving
dimensions are ideal for desktop or wall-mounting in home, small office, workgroups,
departments and conference room environments. Its durable metal case has no fan for silent
operation. Compatible with PC, Macintosh, Unix, or Linux operating systems.
Solid Providing plug-and-play simplicity with exceptional performance and reliability, the GS116 is a
cost-effective solution for your growing network. This switch is made to last and NETGEAR backs
it with a lifetime warranty.
*
Internet
Macintosh computer
with Ethernet connection
Desktop PCs with
GA311 Gigabit PCI Adapters
Servers with GA311
Gigabit PCI Adapters
Modem
10/100 Mbps
1000 Mbps
1000 Mbps
GS116 16-port
Gigabit Switch
Notebook
FVS338 ProSafe VPN Firewall
with 8-port 10/100 Switch

4500 Great America Parkway
Santa Clara, CA 95054 USA
1-888-NETGEAR (638-4327)
E-mail: [email protected]
www.NETGEAR.com
© 2008 NETGEAR, Inc. NETGEAR, the NETGEAR Logo, NETGEAR Digital Entertainer Logo, Connect with Innovation, FrontView, IntelliFi,
PowerShift, ProSafe, RAIDar, RAIDiator, X-RAID, RangeMax, ReadyNAS and Smart Wizard are trademarks of NETGEAR, Inc. in the United
States and/or other countries. Other brand names mentioned herein are for identification purposes only and may be trademarks of their
respective holder(s). Information is subject to change without notice. All rights reserved.
*Free basic installation support provided for 90 days from date of purchase. Advanced product features and configurations are not included
in free basic installation support; optional premium support available.
†Lifetime warranty for product purchased after 05/01/2007. For product purchased before 05/01/2007, warranty is 5 years for switch,
2 years for power supply.
D-GS116-3
ProSafe®16-port Gigabit Desktop Switch GS116
Technical Specifications
Network Ports•
16 RJ-45 auto-sensing 10/100/1000–
Mbps UTP ports
Forwarding Mode•
Store-and-forward–
Performance•
Bandwidth: 32 Gbps (non-blocking)–
Forward rate (10 Mbps port):–
14,800 packets/sec
Forward rate (100 Mbps port):–
148,000 packets/sec
Forward rate (1000 Mbps port):–
1,488,000 packets/sec
Latency (100 to 100 Mbps): 40 μ (max)–
Latency (1000 to 1000 Mbps): 10 μ (max)–
Queue buffer memory:–
512 Kbytes per port
MAC address database: 8,000–
Acoustic noise: 0 dB–
Heat dissipation: 38.8 Btu/hr–
Mean time between failures (MTBF):–
393,000 hours (~45 years)
AC Power•
18W max and 12V @ 1.5A DC input–
Status LEDs•
Power, activity and link indicators for–
each port
Link and speed indicators built–
into each RJ-45 port
Physical Specifications•
Dimensions: (w x d x h)–
285 x 103 x 27 mm
(11.22 x 4.06 x 1.06 in)
Weight: 0.99 kg (2.2 lb)–
Environmental Specifications•
Operating temperature:–
0º to 50º C (32º to 122° F)
Operating humidity: 10% to 90%–
non-condensing
Safety Agency Approvals•
CE mark, commercial–
UL listed (UL 1950)–
C-Tick–
Electromagnetic Compliance•
CE mark, commercial–
FCC Part 15 Class A–
EN 55 022 (CISPR 22)–
Class A VCCI–
Class A C-Tick–
Standards Compliance•
IEEE 802.3i 10BASE-T Ethernet–
IEEE 802.3u 100BASE-TX Fast Ethernet–
IEEE 802.3ab 1000BASE-T–
Gigabit Ethernet
Honors 802.1p priority tags–
Honors DSCP priority tags–
System Requirements
UTP Category 5 or better cables–
Network card for each PC or server–
Network software (e.g., Windows– ®,
Linux®, Mac OS)
Warranty
Switch: NETGEAR Lifetime Warranty– †
Power adapter: NETGEAR–
2-year Warranty
ProSupport™ Service Packs
Available
OnCall 24x7•
PMB0331-100 (US)–
PMB0331 (non-US)–
XPressHW•
PRR0331–
Package Contents
ProSafe 6-port Gigabit Desktop–
Switch (GS116)
Wall-mount kit–
AC adapter–
Installation guide–
Warranty/support information card–
NETGEAR Related Products
Accessories•
32-bit Gigabit PCI Adapter (GA311)–
Gigabit PC Card Adapter (GA511)–
Switches•
ProSafe 5-port Gigabit Desktop Switch–
(GS105)
ProSafe 8-port Gigabit Desktop Switch–
(GS108)
Ordering Information
North America: GS116NA–
Europe - General: GS116GE–
Europe - UK: GS116UK–
Asia: GS116AU–
Japan: GS116JP–
