netvox R718PA Series User manual

Model: R718PA10
Wireless Turbidity Sensor
Wireless Turbidity Sensor
R718PA10
User Manual
Copyright© Netvox Technology Co., Ltd.
This document contains proprietary technical information which is the property of NETVOX Technology. It shall
be maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written
permission of NETVOX Technology. The specifications are subject to change without prior notice.

1
Table of Content
1. Introduction .........................................................................................2
2. Appearance..........................................................................................3
3. Main Feature........................................................................................3
4. Set Up Instruction................................................................................4
5. Data Report..........................................................................................5
6. Installation...........................................................................................7
7. Important Maintenance Instruction.....................................................9

2
1.Introduction
R718PA10 is a Class A device based on the LoRaWANTM protocol of Netvox and is compatible with LoRaWAN protocol.
R718PA10 can be connected with a turbidity sensor (RS485) externally and report the turbidity value and the temperature of the
solution collected by the device to the corresponding gateway.
LoRa Wireless Technology:
LoRa is a wireless communication technology dedicated to long distance and low power consumption. Compared with other
communication methods, LoRa spread spectrum modulation method greatly increases to expand the communication distance.
Widely used in long-distance, low-data wireless communications. For example, automatic meter reading, building automation
equipment, wireless security systems, industrial monitoring. Main features include small size, low power consumption,
transmission distance, anti-interference ability and so on.
LoRaWAN:
LoRaWAN uses LoRa technology to define end-to-end standard specifications to ensure interoperability between devices and
gateways from different manufacturers.

3
2.Appearance
3.Main Feature
⚫Adopt SX1276 wireless communication module
⚫RS485 communication
⚫12V DC power supply
⚫Detecting the turbidity value and the temperature of the solution
⚫The base is attached with a magnet that can be attached to a ferromagnetic material object
⚫Main body protection level IP65 / IP67 (Optional)
⚫Compatible with LoRaWANTM Class A
⚫Frequency hopping spread spectrum technology
⚫Configuring parameters and reading data via the third-party software platforms, and set alarms via SMS text and email
(optional)
⚫Applicable to the third-party platforms: Actility/ ThingPark/ TTN/ MyDevices/ Cayenn
Note:
Battery life is determined by the sensor reporting frequency and other variables, please refer to
http://www.netvox.com.tw/electric/electric_calc.html
On this website, users can find battery lifetime for varied models at different configurations.
Turbidity Sensor
Indicator
Function Key

4
4.Set Up Instruction
On/Off
Power On
DC12V adapter
Turn On
DC12V power supply, the green indicator flashing once means turn on successfully.
Restore To Factory Setting
Press and hold the function key for 5 seconds, and the green indicator flashes 20 times.
Power Off
Remove DC12V adapter
Note
1. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor
inductance and other energy storage components.
2. The first 5 seconds after power on, the device will be in engineering test mode.
Network Joining
Never Join the Network
Turn on the device to search the network.
The green indicator keeps on for 5 seconds: success.
The green indicator remains off: fail
Had Joined the Network
(Not restore to the factory setting)
Turn on the device to search the previous network.
The green indicator keeps on for 5 seconds: success.
The green indicator remains off: fail.
Fail to Join the Network
Suggest checking the device registration information on the gateway or consulting your
platform server provider if the device fails to join the network.
Function Key
Press and Hold for 5 Seconds
Restore to the original setting
The green indicator flashes 20 times: success
The green indicator remains off: fail
Press once
The device is in the network: the green indicator flashes once and the device sends a data
report
The device is not in the network: the green indicator remains off

5
5.Data Report
After power on, the device will immediately send a version packet report. Then, it will send another report with the data of the turbidity
value and the temperature of the solution after it is powered on for 20s.
The device sends data according to the default configuration before any other configuring.
Default setting:
MaxTime: Max Interval = 3min = 180s
MinTime: The MinTime configuration is not available.
* But the software has restriction, MinTime must be configured a number greater than 0.
Note:
1. Report interval is based on the factory default.
2. R718PA10 reports the turbidity value and the temperature of the solution.
3. The device reported data parsing please refer to Netvox LoRaWAN Application Command document and
Netvox LoRa Command Resolver http://loraresolver.netvoxcloud.com:8888/page/index
Example of ReportDataCmd
FPort：0x06
Bytes
1
1
1
Var(Fix=8 Bytes)
Version
DeviceType
ReportType
NetvoxPayLoadData
Version–1 byte –0x01——the Version of NetvoxLoRaWAN Application Command Version
DeviceType–1 byte –Device Type of Device
ReportType –1 byte –the presentation of the NetvoxPayLoadData，according the devicetype
NetvoxPayLoadData–Fixed bytes (Fixed =8bytes)
Device
Device
Type
Report
Type
NetvoxPayLoadData
R718PA series
(R718PA10)
0x57
0x09
Battery
(1Byte, unit:0.1V)
NTU
(2Byte ,0.1ntu)
TemperaturewithNTU
(Signed 2Bytes,unit:0.01°C)
EC5SoildHumidtiy
(2Bytes,unit:0.01%)
Reserved
(1Bytes,fixed 0x00)
Uplink: 0157090007D009E2FFFF00
1st byte (01): Version
2nd byte (57): DeviceType－R718PA Series
3rd byte (09): Report Type
4th byte (00): Battery; When Battery is 0x00, it represents is powered by DC/AC power source
5th 6th byte(07D0): NTU(Turbidity), 7D0 Hex = 2000 Dec, 2000*0.1 ntu = 200 ntu
7th 8th byte (09E2): Temperature with NTU, 9E2 Hex = 2530 Dec, 2530*0.01°C= 25.3°C
9th 10th byte (FFFF): Soil Humidity, please ignore.
11th byte (00): Reserved

6
Example of ConfigureCmd
FPort：0x07
Bytes
1
1
Var (Fix =9 Bytes)
CmdID
DeviceType
NetvoxPayLoadData
CmdID–1 byte
DeviceType–1 byte –Device Type of Device
NetvoxPayLoadData–var bytes (Max=9bytes)
(1)Configure R718PA10 device parameter MaxTime = 1min
(The MinTime configuration is useless, but it needs to be set greater than 0 because of the software limitation.)
Downlink: 0157000A003C0000000000
Device Return:
8157000000000000000000 (configuration success)
8157010000000000000000 (configuration failure)
(1)Read R718PA10 device parameter
Downlink: 0257000000000000000000
Device Return:
8257000A003C0000000000 (device current parameter)
Description
Device
Cmd
ID
Device
Type
NetvoxPayLoadData
ConfigReport
Req
R718PA10
0x01
0x57
MinTime
(2bytes Unit: s)
MaxTime
(2bytes Unit: s)
Reserved
(5Bytes,Fixed 0x00)
ConfigReport
Rsp
0x81
Status
(0x00_success)
Reserved
(8Bytes, Fixed 0x00)
ReadConfig
ReportReq
0x02
Reserved
(9Bytes, Fixed 0x00)
ReadConfig
ReportRsp
0x82
MinTime
(2bytes Unit: s)
MaxTime
(2bytes Unit: s)
Reserved
(5Bytes,Fixed 0x00)

7
6.Installation
1. R718PA10 has the built-in magnet (as the figure below)
which can be attached to the surface of an iron object
during installation, which is convenient and quick.
In order to make the installation firmer, please use screws
(purchased separately) to fix the device to the wall or other
surface (as Figure below).
Note:
Do not install the device in a metal shielded box or in an
environment surrounded by other electrical equipment to
avoid affecting the wireless transmission of the device.
2. R718PA10 regularly reports the data of the turbidity value
and the temperature of the solution according to MaxTime.
The default Max Time is 3 minutes.
Note:
MaxTime can be modified by the downlink command, but it
is recommended not to set the interval too short.
R718PA10 can be applied to detecting the turbidity and the
temperature of the solution.
Example:
⚫Water Quality Monitor
Screw
Fixation
Screw
Fixation
Turbidity Sensor
R718PA10
Socket
Adapter 12V

8
Note:
1. The probe contains sensitive optical and electronic components. Make sure that the probe is not subject to severe mechanical
shocks. There are no parts inside the probe that need users’ maintenance.
2. The black plastic cap on the head of the turbidity sensor should be removed during the test; otherwise, it will affect the
measurement.
Maintenance Method
1. External Surface of The Sensor:
Use tap water to clean the external surface of the sensor. If there are still debris remaining, wipe it with a moistened soft cloth.
For some stubborn dirt, users can add some household detergent to the tap water to clean it.
2. Check the Cable of The Sensor:
The cable should not be taut during normal operation; otherwise, the internal wires of the cable may break and the sensor
cannot work normally.
3. Check whether the measuring part of the sensor is dirty, and whether the cleaning brush is normal.

9
7.Important Maintenance Instruction
Kindly pay attention to the following in order to achieve the best maintenance of the product:
• Keep the device dry. Rain, moisture, or any liquid, might contain minerals and thus corrode electronic circuits. If the device gets
wet, please dry it completely.
• Do not use or store the device in dusty or dirty environment. It might damage its detachable parts and electronic components.
• Do not store the device under excessive heat condition. High temperature can shorten the life of electronic devices, destroy
batteries, and deform or melt some plastic parts.
• Do not store the device in places that are too cold. Otherwise, when the temperature rises to normal temperature, moisture will
form inside, which will destroy the board.
• Do not throw, knock or shake the device. Rough handling of equipment can destroy internal circuit boards and delicate
structures.
• Do not clean the device with strong chemicals, detergents or strong detergents.
• Do not apply the device with paint. Smudges might block in the device and affect the operation.
• Do not throw the battery into the fire, or the battery will explode. Damaged batteries may also explode.
All of the above applies to your device, battery and accessories. If any device is not working properly, please take it to the
nearest authorized service facility for repair.
