New Holland W130 Instruction manual

THIS ALERT SYMBOL SIGNALS IMPORTANT MESSAGES INVOLVING YOUR SAFETY.
Read and heed carefully the safety instructions listed and follow the precautions recommended to
avoid potential risks and to safeguard your health and your safety.
You will find this symbol in the text of this Manual referred to the following key words:
W130/W130TC
WHEEL LOADER
Workshop Manual
Print N° 604.13.492.00 English
II - 2005
WARNING
Cautions directed to avoid improper repair interventions involving potential consequences for the
operator’s safety.
DANGER
These warnings qualify specifically potential dangers for the safety of the operator or other per-
sons directly or indirectly involved.
IMPORTANTNOTICE
All maintenance and repair interventions explained in this Manual must be performed exclusively by the Service
Organization of the Manufacturer, observing strictly the instructions explained using, whenever necessary, the
recommended specific tools.
Whoever performs the operations reported without following exactly the precautions is responsible on his own, for
the damages that may result.
Neither the Factory nor any Organizations in its Distribution Network, including but not limited to national, regional
or local distributors, are responsible for any liability arising from any damage resulting from defects caused by parts
and/or components not approved by the Factory for use in maintaining and/or repairing products manufactured or
merchandized by the Factory.
In any case, no warranty of any kind is made or shall be imposed with respect to products manufactured or mer-
chandized by the Factory, when failures are caused by the use of parts and/or components not approved by the
Factory.

Most accidents and injuries occurring in industry, on
the farm, at home or on the road, are caused by the
failure of some individual to follow simple and funda-
mental safety rules or precautions. For this reason,
MOST ACCIDENTS CAN BE PREVENTED by recog-
nizing the real cause and taking the necessary pre-
cautions, before the accident occurs.
Regardless of the care used in design and construc-
tion of any type of equipment, there may be conditions
that cannot be completely safeguarded against with-
out interfering with reasonable accessibility and effi-
cient operation.
A careful operator is the best insurance against acci-
dents. The complete observance of one simple rule
would prevent many thousands serious injuries each
year.
This rule is: Never attempt to clean, lubricate or adjust
a machine while it is in motion.
AVOID ACCIDENTS
WARNING
On machines having hydraulically, mechanically and/or cable
controlled equipment (such as showels, loaders, dozers,
scrapers etc.) be certain the equipment is lowered to the
ground before servicing, adjusting and/or repairing.
If it is necessary to have the equipment partially or fully raised
to gain access to certain items, be sure the equipment is suit-
ably supported by means other than the hydraulic lift cylin-
ders, cable and/or mechanical device used for controlling the
equipment.
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

SUMMARY
GENERALITIES.................................................... Section 0
ENGINE ................................................................ Section 1
TRANSMISSION................................................... Section 2
BRAKE SYSTEM.................................................. Section 3
STEERING SYSTEM ............................................ Section 4
BUCKET BOOMS AND FRAME .......................... Section 5
EQUIPMENT HYDRAULIC SYSTEM ................... Section 6
ELECTRICAL SYSTEM........................................ Section 7
CAB ...................................................................... Section 8
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

SECTION 0
GENERALITIES
INDEX
SUBJECT PAGE
SAFETY RULES ........................................................................................................................................... 0-1
SPECIFICATIONS........................................................................................................................................ 0-8
DIMENSIONSANDWEIGHT .......................................................................................................................0-19
TABLE OFFLUID CAPACITIES ...................................................................................................................0-20
UNITS OF MEASURE .................................................................................................................................0-21
STANDARDTORQUESPECIFICATION .......................................................................................................0-23
LOCTITEPRODUCT CHART.......................................................................................................................0-27
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 1W130/W130TC
SAFETY RULES
GENERALITIES
Read this Manual carefully before starting, operating,
maintaining, fuelling or servicing the machine.
Read and comply with all safety precautions before any
intervention.
Do not allow unauthorised personnel to operate or serv-
ice this machine.
Do not wear rings, wrist watches, jewellery, loose or hang-
ing garments, such as ties, torn clothing, scarves, unbut-
toned or unzipped jackets that can get caught in moving
parts. Wear certified safety clothes such as: hard hat, no-
slipfootwear, heavygloves, earprotection, safety glasses,
reflector vests, respirators. Ask your employer about spe-
cific safety equipment requirements.
Keep the operator’s compartment, step plates, grab-rails
andhandles clean and clear offoreign objects, oil,grease,
mud or snow to minimize the danger of slipping or stum-
bling. Remove mud or grease from your shoes before
attempting to mount or operate the machine.
Donotjumponoroffthemachine.Alwayskeepbothhands
and one foot, or both feet and one hand in contact with
steps and grab rails.
Do not use controls or hoses as hand holds when climbing
on or off the machine. Hoses and controls are movable
parts and do not provide solid support. Besides, controls
may be inadvertently moved and cause unexpected
movement of the machine or its attachments.
Never operate the machine or its attachments from any
position other than sitting in the driver’s seat.
Keep head, body, limbs, hands and feet inside the opera-
tor’s compartment at all times to reduce exposure to
external hazards .
Be careful of possible slippery conditions of the steps and
hand rails as well as of the ground around the machine.
Donot leave themachine until itis hascome to acomplete
stop.
Check the seat safety belt at least twice per year and
replace it if it shows signs of wear, fraying or other
weakness that could lead to failure.
STARTING
NEVER START OR OPERATE A FAILED MACHINE. Be-
foreoperatingthemachine,alwaysensurethatanyunsafe
condition has been satisfactorily corrected.
Check brakes, steering and attachment controls before
movingoff.Report any malfuctioningpartorsystemtothe
maintenance managers for proper action.
Ensure all protective guards and panels as well as all
safetydevices providedare in place and ingood operating
condition.
Ensure that nobody is in the machine operating range
before moving off or operating the attachment. WALK
COMPLETELY AROUND the machine before mounting.
Sound the horn.
Beforestartingmachine,check,adjustandlockthedriver's
seat for maximum comfort and control of the machine.
Fasten your seat belts(when fitted).
Obey all flag signals and signs.
Due to the presence of flammable fluids on the machine,
never check or fill fuel tanks or accumulator batteries near
fires, open flames, or sparks.
REMEMBER THAT SPECIAL STARTING FLUIDS ARE
FLAMMABLE. Scrupolously follow recommendations
printed on the containers and in this Manual.
DO NOT PUNCTURE OR BURN CONTAINERS.
Containers must be stored in fresh, well ventilated places
and out of the reach of unauthorised persons. Strictly
follow the instructions provided by the Manufacturer.
Never use these products near fires, open flames, or
sparks.
OPERATING
Check wheel and rim retainers before each working shift.
If necessary, tighten to the torque specified.
Do not run the engine of this machine in closed buildings
without proper ventilation capable to remove harmful
exhaust gases.
Roll Over Protective Structures (ROPS) are required on
wheel or crawler loaders, dozers, or graders. NEVER
OPERATE the machine if such protective structure is
removed.
Keep the operator’s compartment free of foreign objects,
especially if not firmly secured. Never use the machine to
transport objects, unless proper securing points are pro-
vided.
DO NOT CARRY RIDERS ON THE MACHINE
Study and familiarize with escape routes alternate to
normal exit routes.
According to law provisions, seat belts must be fitted with
Roll Over Protection Structures or cabs. Keep safety belts
fastened during operation.
Foryourpersonalsafety,donotclimbonoroffthemachine
while it is in motion.
Make sure that bystanders are clear of the machine oper-
ating range before starting the engine and operating the
attachment.Sound the horn. Obey all indications provided
by flags, signs and signals.
DO NOT COAST OR FREEWHEEL down hills. Engage the
mostsuitablegearspeedtokeepthemachineundercontrol.
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 2 W130/W130TC
When working on slopes or near sudden level drops in the
terrain, avoid areas where ground is loose or soft since
overturn or loss of machine control could result.
If noise levelishighandcontinuoslyexceeds90 dBA over
8hoursattheoperator'sear,wearapprovedearprotection
in compliance with local regulations.
Where counterweights are provided, do not operate the
machine if they have been removed.
When transportingaloadedbucket,keeptitasrolled-back
and low as possible for maximum visibility, stability and
safety of there machine. Ground speed should be ad-
equate to the load and ground conditions.
The load must always be properly arranged in the bucket;
movewithextremecarewhen transporting oversizeloads.
Useonly the typeof bucket recommendedfor themachine
and the materials to be handled. Follow the recommenda-
tions concerning loading capacity, arrangement of the
materials, characteristics of the ground and job to be
performed.
Do not lift and move loads overhead where persons are
standing or working, nor downhill when working crosswise
on slopes. In this case, the bucket should be unloaded on
the uphill side, whenever possible.
Startandstopthemachinecarefullywhenthebucketisfull.
Do not move off without first reducing engine speed.
Overtaking manoeuvres should be performed only when
absolutely necessary and unavoidable. Beware possible
uneven terrains, poor visibility, presence of other machin-
ery or persons out of sight.
Operate the machine at a speed adequate to the working
site conditions and in any case slow enough to ensure
complete control at all times.
Check instruments at start-up and frequently during
operation. Stop the machine immediately should any
malfunction be signalled.
Never use the bucket as a man lift or to carry riders.
Never use the machine as a work platform or scaffolding,
nor for other improper use (such as pushing railway cars,
trucks or other machines).
Payattetion topeople withinthe machineoperating range.
Load trucks from the driver’s side whenever possible.
Prior to operating the machine, check which obstacles
and/or difficulties you will encounter, such as narrow
streets,overhead doors,cables, piping,as wellas ground,
bridges, paving and ramps bearing load limitations.
In case of road transfers, find out beforehand what condi-
tionsarelikelytobeencountered,suchassizerestrictions,
heavy traffic, paving type, etc.. Beware fog, smoke or dust
that obscure visibility.
When crossing gullies or ditches, move at an angle with
reduced speed after ensuring ground conditions will per-
mit a safe traverse.
Donotoperatethemachineif youareextremelytiredorfeel
ill.Beespecially carefultowardsthe endofthe workingshift.
Do not operate a machine with misadjusted brakes.
Operate the machine at low speed which can ensure
complete control at all times.
Travelslowly over very rough terrain, slopes or near drop-
offs, in congested areas or on frozen or slippery surfaces.
When backing, always look to where the machine is to be
moved. Be alert of the position of bystanders. Should
someone enter the work area, STOP THE MACHINE.
Maintainasafe distance fromother machines orobstacles
toensurerequired visibilityconditions.Give way toloaded
machines.
Maintain a clear vision of the surroundings of the travel or
work area at all times. Keep cab windows clean and
repaired.
Whenmachinesareoperatingintandem,thepusher(rear)
mustbeequippedwiththeappropriatedeflectorstoprotect
the front unit driver against the air stream coming from the
blower fan.
When pulling or towing through a cable or chain, do not
start suddenly at full throttle. Take-up slack carefully.
Carefuly inspect the towing items for flaws or problems
before proceedig.
Avoid kinking or twisting chains or cables. Do not pull
through a kinked chain or cable as the high stresses
existing in this condition may induce failures. Always wear
heavy gloves when handling chains or cables.
Chains and cables should be securely anchored. Anchor
points should be strong enough to withstand the expected
load. Keep anyone clear of anchor points and cables or
chains.
DONOT PULL UNLESSTHE OPERATOR’S COMPART-
MENTS OF THE MACHINES INVOLVED ARE PROP-
ERLY PROTECTED AGAINST POSSIBLE BACKLAS IN
CASE OF CABLE OR CHAIN FAILURE OR DETACH-
MENT.
Be alert of soft ground conditions close to newly con-
structed walls. The fill material and machine weight may
cause the wall to collapse.
In darkness, check area of operation carefully before
movingin with the machine. Use all lights provided.Do not
move into low visibility areas.
If the engine tends to stall for whatever reason under load
or at idle, immediately report this problem to the mainte-
nance managers for proper action. Do not operate the
machine until this condition has been corrected.
On machines fitted with suction radiator fans, regularly
check the engine exhaust system for leaks, as exhaust
fumes expelled towards the operator are toxic.
Operators must know thoroughly the performances of the
machine they are driving.
SAFETY RULES
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 3W130/W130TC
Always inspect the working area to identify potential risks
such as: inclines, overhangs, trees, demolition rubble,
fires,ravines,steepslopes,rough terrain, ditches,crowns,
ridge trenches, heavy traffic, crowded parking and service
areas, closed ambients. In such conditions, proceed with
extreme care.
Whenever possible, avoid going over obstacles such as
very rough terrain, rocks, logs, steps, ditches, railroad
tracks. When obstructions must be crossed, do so with
extreme care and at an angle, if possible. Slow down and
select a lower gear. Ease up to the break-over point, pass
the balance point slowly and ease down the other side.
In steep down-hill operation, do not allow the engine to
over-speed. Select the proper gear before starting down
grade.
Avoid crosswise hill travel, whenever possible. Drive up
and down the slope. Should the machine start slipping
sideways when going uphill, steer and turn machine front
immediately downhill.
The gradient you may attempt to overcome is limited by
factors such as ground conditions, load being handled,
machine type and speed, and visibility.
There is no substitute for good judgement and experience
when working on slopes.
Avoid operating the attachment too close to an overhang
or high wall, either above or below the machine. Beware
of caving edges, falling objects and landslips. Remember
that such hazards are likely to be concealed by bushes,
undergrowth and such.
When pushing-over trees, the machine must be equipped
with proper overhead guards. Never drive a machine up
the roots, particularly while the tree is being felled. Use
extreme care when pushing over any tree with dead
branches.
Avoid faggots, bushes, logs and rocks.
NEVER DRIVE OVER THEM, nor over any other surface
irregularities that discontinue adherence or traction with
the ground, especially near slopes or drop-offs.
Be alert to avoid changes in traction conditions that could
cause loss of control. AVOID driving on ice or frozen
ground when working on steep slopes or near drop-offs.
Working in virgin rough terrains is characterized by the
presence of all the perils and risks listed above. In these
conditions, it is emphasised the danger represented by
large tree limbs (possibly falling on the machine), large
roots (which may act as a leverage under the machine
when up-rooted and cause the unit to overturn), etc.
STOPPING
When the machine is to be stopped for whatever reason,
do so following the instructions given in chapters “Stop-
ping the machine” and “Shutting off the engine" in the
Operation and Maintenance Instruction Manual.
Alwaysremembertomovethegearshiftlevertothe neutral
position and engage the control lever lock for safety
purposes.
Apply the parking brake (if fitted).
NEVER LEAVE THE MACHINE UNATTENDED with the
engine running.
Prior to leaving the operator’s seat,and after making sure
that all people are clear of the machine, always slowly
lower the attachment until resting it safely to the ground
Park the machine in a non-operating and no-traffic area.
Parkonfirmlevelground.Ifthisisnotpossible,positionthe
machine at a right angle to the slope, making sure there is
nodangerofuncontrolledsliding.Applythe parkingbrake.
If parking in traffic lanes cannot be avoided, provide
appropriate flags, barriers, flares and signals as required
to adequately warn the oncoming drivers.
Keephead, body, limbs, hands and feet clear ofthe dozer,
arms, bucket or ripper when raised.
Always switch off the battery isolator switch before serv-
icing the machine in whatever manner (i.e., cleaning,
repairing, maintaining, etc.). Do the same when the
machine is to remain parked for prolonged periods of time
to avoid accidental or unauthorized starting.
Never lower the attachments other than sitting in the
operator’s seat. Sound the horn. Make sure that nobody is
withinthe machine operating range. Lowerthe attachment
slowly.DONOTUSEFLOATPOSITIONincaseofhydrau-
lic controls.
Securely block the machine and lock it every time you
leave it unattended. Return keys to authorized security.
Performallnecessary operations asdetailed in theOpera-
tion and Maintenance Instruction Manual. Apply the park-
ing brake (if fitted) every time you leave the machine.
MAINTENANCE
GENERALITIES
Before operating or performing any intervention on the
machine:
- carefully read all the norms contained in this Manual;
- read and observe all safety plates and instructions
located on the machine.
Do not allow unauthorized personnel to service the ma-
chine.Donotcarryoutanymaintenanceworkwithoutprior
authorization. Follow all recommended maintenance and
service procedures.
Keeptheoperator’scompartmentfreeof looseobjectsthat
are not properly secured.
Do not wear rings, wrist watches, jewellery, loose or
hanging garments, such as ties, torn clothing,
scarves,unbuttoned or unzipped jackets that can get
caught in moving parts.
SAFETY RULES
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 4 W130/W130TC
Wear certified safety clothes such as: hard hat, no-slip
footwear, heavy gloves, ear protection, safety glasses,
reflector vests, respirators. Ask your employer about spe-
cific safety equipment requirements.
Never service the machine with someone sitting in the
driver's seat, unless this person is an authorized operator
assisting in the maintenance being carried out.
Keep the operator’s compartment, step plates, grab rails
and handles clear of foreign objects, oil, grease, mud or
snow to minimize the danger of slipping or stumbling.
Clean mud or grease from your shoes before climbing on
the machine or driving it.
Never attempt to operate the machine or its attachments
from any position other than sitting in the operator’s seat.
Never stand under the boom.
Shoulditbenecessarytomovetheattachmentthroughthe
hydraulic controls for maintenance purposes, remember
thatthis should be done whilesitting inthe operator’sseat.
Before starting the machine or moving its attachment,
apply the brakes, sound the horn and call that you are
about to manoeuvre. Raise the attachment slowly.
Always lock machine arms or any other parts that must be
lifted for maintenance purposes using adequate external
means. Do not allow anyone to pass near or even below
araised yet unlocked attachment. If you arenot absolutely
sure about your safety, do not stay under a raised attach-
ment, even if it is locked.
Donotplacebody,limbs,orfingersneararticulatedcutting
edges of uncontrolled machine parts or deprived of the
necessary guards, unless they are suitably and safely
locked.
Never perform any work on the machine with the engine
running, except when this is specifically required. Do not
wear loose clothing, jewellery or such near moving parts.
Whenserviceor maintenance requireaccess to areasthat
cannot be reached from the ground, use a ladder or step
platform conforming to regulations in force. If such means
are not available, use machine grab rails and steps.
Always perform all service or maintenance work with the
greatest care and attention.
Shop and/or field service platforms or ladders should be
manufactured in accordance with safety regulations in
force.
Disconnect batteries and label all controls to warn that
service work is in progress. Block the machine and all
attachments to be raised.
Do not check or fill fuel tanks, batteries and accumulators,
nor use the starting liquid if you are smoking or near open
flames. These fluids are flammable!
BRAKESAREINOPERATIVEwhenmanuallyreleasedfor
servicing. Provisions must be made to maintain control of
the machine using suitable blocks or other means.
Thefuel fillerpipenozzlemustbeconstantlykeptincontact
with the filler neck. Keep this contact from the beginning to
the end of the fuelling operation to avoid possible genera-
tion of sparks due to static electricity.
Tow the machine only from the attaching points provided.
Use care in making connections and ensure pins and/or
bolt are firmly secured before pulling. Stay clear of draw-
bars, cables or chains under load.
To move a failed machine, use a trailer or a low platform
truck, if available. In case towing is needed, use all neces-
sary signals required by local regulations, and follow
directions provided in this Manual.
Load/unload the machine from transporter on firm level
ground providing safe support to the wheels of the truck or
trailer.Usestrongaccessramps,withadequateheightand
angle.Keeptheloadingplatformfreeofmud,oilorslippery
materials.
Tie the machine securely to the platform of the truck or
trailer and opportunely wedge machine wheels or tracks
as required.
Never align holes or slots using your fingers; always use
appropriate aligning tools.
Remove all sharp edges and burrs from re-worked parts.
Use only approved and effectively grounded auxiliary
power sources for heaters, battery chargers, pumps and
similar equipment to reduce electrical shock hazard.
Lift and handle heavy components using hoisting devices
of appropriate capacity. Ensure the sling has been cor-
rectly applied. Use lifting eyes if provided. Pay attention to
bystanders.
Never pour gasoline or diesel fuel into open, wide and low
containers. Never use gasoline, solvents or other flamma-
ble fluids to clean parts. Use proprietary certified non-
flammable, non-toxic solvents only.
When using compressed air to clean parts, wear safety
glasses with side shields. Limit pressure to max 2 bars, in
accordance with local safety regulations in force.
Do not run the engine in closed buildings without proper
ventilation capable to remove lethal fumes.
Donot smoke, use open flames orproduce sparksnearby
while refuelling the unit or handling highly flammable
materials.
Donotuseanyflameasalightsourceduringmaintenance
work or to look for leaks anywhere on the machine.
Make sure that all tools provided are in good condition at
all times. NEVER USE tools with mushroomed or dam-
aged heads. Always wear eye protections.
Movewithextreme care whenworking under themachine,
its attachments, and even on or near them. Always wear
protective safety equipment as required, such as hard hat,
goggles, safety shoes, and ear plugs.
SAFETY RULES
Find manuals at https://best-manuals.comFind manuals at https://best-manuals.com

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 5W130/W130TC
In case tests during which the engine should be kept
runinng, a qualified operator must sit in the driver’s seat
with the mechanic in sight at all times. Place the transmis-
sion in neutral, apply and lock the brakes. KEEP HANDS
OFFMOVINGPARTS.
In case of field service, move machine to level ground, if
possible, and block it. If work on an incline cannot be
advised, block the machine and its attachments securely.
Move damaged to level ground as soon as possible.
Do not trust worn and/or kinked chains and cables. Never
use them for lifting or pulling. Always wear heavy gloves
to handle chains or cables.
Be sure chains and cables are firmly fastened and that
anchorpointsarestrongenoughtowithstandtheexpected
load. Nobody should stay near the anchor points, cables
orchains.DONOTPULLORTOWUNLESSTHEOPERA-
TOR’S COMPARTMENTS OF THE MACHINES IN-
VOLVED ARE FITTED WITH THE PROPER GUARDS
AGAINST BACKLASH IN CASE OF CABLE OR CHAIN
FAILURE OR DETACHMENT.
Keep the area where maintenance is carried out CLEAN
and DRY at all times. Clean immediately all water and oil
spillages.
Donotpileupoilyorgreasyragsas they represent a major
fire hazard. Always store them in closed metal containers.
Beforestartingthemachineoritsattachment,check,adjust
and lock the operator’s seat. Also ensure that nobody is
within the machine operating range. Sound the horn.
Rust inhibitors are volatile and flammable. Use them only
inwellventilatedareas.Keep openflamesaway- DONOT
SMOKE - Store containers in a cool well ventilatedplace
where they could not be reached by unauthorised people.
Do not carry loose objects in your pockets that might fall
unnoticed into open compartments.
Wear safety glasses with side shields, hard hat, safety
shoes, heavy gloves when metal particles or similar may
be ejected and hit you.
Wear appropriate protective equipment such as dark
safety glasses, hard hat, protective clothing, special
gloves and footwear while welding. Nearby persons
should also wear dark safety glasses even if they are not
welding. DO NOT LOOK THE WELDING ARC WITHOUT
PROPER EYE PROTECTION.
Become acquainted with all your jacking equipment and
its capacity. Remember that the jacking point on the
machine should be appropriate for the load applied. Also,
be sure the support area of the jack at the machine and on
the ground is appropriate and stable.
Any load supported by a jack represents a possible haz-
ard. Always transfer the load onto appropriate support
means according to local or national safety requirements
before proceeding with service or maintenance work.
Metal cables get frayed after prolonged use. Always wear
appropriate protections (heavy gloves, goggles, etc.)
while handling them.
Handle all parts carefully. Keep hands and fingers away
from gaps, gears, and similar. Always use and wear the
appropriate protections.
Watercanbuildupinpneumaticsystems fromcondensate
moisture due to changes in atmospheric conditions. If
necessary, drain such deposits following instructions.
Before carrying out any maintenance work or service, lock
the machine articulated frame modules using the appro-
priate safety device. Remember to remove and store it
properly at the end of work.
If the machine is equipped with hydraulic brakes, make
surethatthereservoirisalwaysfilleduptothecorrectlevel.
Always block all wheels, front and rear, before bleeding
the braking system or disconnecting control hoses and/or
cylinders.
STARTING
Do not run the engine in closed buildings without proper
ventilation capable to remove lethal exhaust fumes.
Donot place head, body, limbs,feet, handsor fingersnear
rotating fans or belts.
Be especially careful near blower fans.
REMEMBER THAT THE STARTING FLUID IS HIGHLY
FLAMMABLE. Follow recommendations provided in this
Manual and printed on the containers. Containers must be
stored in a cool, well ventilated place out of the reach of
unauthorised persons.
DO NOT PUNCTURE OR BURN CONTAINERS.
ENGINE
Loosen the radiator cap very slowly to relieve system
pressure before removing it. Always top-up coolant level
with the engine off.
Avoid that flammable materials could touch exhaust parts.
If not possible, provide necessary protections.
Do not refuel with the engine running, especially if hot, as
this increases fire hazard.
Neverattempttocheckoradjustfanbelttensionswhenthe
engine is running.
Do not adjust the fuel pump when the machine is motion.
Do not lubricate the machine with the engine running.
Donotruntheenginewithairintakes,doororguards open.
SAFETY RULES

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 6 W130/W130TC
ELECTRICAL SYSTEM
Always disconnect the batteries prior to any intervention
on the machine or its electrical system (cleaning, repair,
maintenance).
Should booster batteries be used, remember to connect
ends of the booster cables in the proper manner: (+) to (+)
and (-) to (-). Do not short-circuit terminals. Thoroughly
follow instructions given in this Manual.
Beforeanyintervention,makesurethatthebatteryisolator
switch is off.
BATTERY GAS IS HIGHLY FLAMMABLE. Leave the bat-
tery compartment open during recharging to improve
ventilation. Never check battery charge by placing metal
objectsacrosstheposts.Keepsparksoropenflamesaway
from batteries. Do not smoke near the battery to prevent
explosion hazard.
Before any intervention, make sure that there are no fuel
or electrolyte leakages. If any, correct prior to proceeding
with further work. Do not recharge batteries in confined
spaces. Ensure proper ventilation is provided to avoid
accidental explosions due to build-up of gas released
during charging.
HYDRAULIC SYSTEM
Pressure fluid escaping from a very small hole can be
almost invisible and still have sufficient force to penetrate
the skin. Always check any suspected pressure leaks
usingapieceofcardboardorwood.DONOTUSEHANDS.
If injured by escaping fluid, obtain medical attention imme-
diately or serious infection or reaction may develop.
Stop the engine and relieve all system pressure before
removing panels, housings, caps, plugs or covers.
Always use gauges of adequate capacity (end-of-scale
reading) and follow recommended procedures.
TOOLS
Always keep head, body, limbs, feet, or hands away from
bucket, blade, or ripper when in the raised position. Prior
to any intervention, install all safety devices according to
current regulations. In case the attachment is to be oper-
ated through the machine hydraulic system for mainte-
nancepurposes,remembertodosoonlywhilesittinginthe
driver's seat. Make sure that nobody is within the machine
operating range. Before operating the attachment, alert
people by sounding the horn and by voice. Raise the
attachment slowly.
SAFETY RULES
Do not use the machine to transport loose objects, unless
proper devices to this purpose are provided.
Clutches and brakes of this machine as well as auxiliary
devices and attachments (such as drive cylinder or winch
control valves) should always be properly adjusted in
accordancewiththeinstructionsprovidedby theManufac-
turer. Never perform adjustments with the engine running,
except when this is specifically required by the relevant
procedures.
TYRES AND WHEELS
Make sure that the tyre inflation pressure corresponds to
specifications issued by the Manufacturer. Regularly
check inflation pressure.
Should pressure be changed, do this while staying on the
tyre side and at a safe distance.
Pressure checks should always be carried out with the
machine unloaded and cold tyres.
Never use reconditioned tyre rims, since possible
weldings, incorrect heat-treatments or repairs can
weaken the wheels and cause damages or failures.
Do not cut, nor weld rims with inflated tyres installed.
The spare tyre should be inflated only enough to keep the
rim components assembled. Remember that when not
installed on the disc, a tyre inflated to maximum pressure
can explode.
Therefore, maximum care must be taken when handling a
fully inflated tyre.
Beforeservicingtyres,blockallwheels,frontandrear.After
jackingupthe machine, blockitin the raisedpositionusing
suitable stands conforming to current safety regulations.
Deflatethetyrebeforeremovingobjectsfromthetyretread.
Never inflate tyres with flammable gas: explosions and
severe bodily injuries may result.
Whenstarting your work shift, check for loose wheel or rim
bolts and brackets and retighten to correct torque as
necessary.

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 7W130/W130TC
SAFETY RULES
DECOMMISSIONINGTHE MACHINE
Forthedecommissioningofthemachine,theavailability
ofparticulartooling(hoists,hydraulicpresses.contain-
ers for liquids etc.) is required as well as specific tools
listed in the Repair Manuals, available from FIAT
KOBELCODealers.
Thishasthepurposeofavoidingthatduringdisassem-
blyoperations,dangeroussituationsmayarisebothfor
thepersonnelinvolvedandtheenvironment.
Inthemachine are present:
• Fluids under pressure (hydraulic system, cooling
system etc.)
• Gases (air conditioning system and accumulator, if
installed)
• Mechanical devices mounted under pressure (track
tensioneretc.)
• Heavymachine components (frames,blades, buck-
ets etc.)
WARNING
• The decommissioning of the machine must be
performed exclusively by personnel trained,
qualified and authorised to perform such op-
eration.
• Startthe disassemblyof hydraulic components
only after the same, the hydraulic oil and lubri-
cantshave fully cooled-offand after all residual
pressureshave been released, asdescribed by
the Repair Instruction Manual.
• Prior to proceeding with disassembly opera-
tions, comply with the GENERAL SAFETY
RULES and drain each components of the ma-
chine filled with fluids, both in the reservoirs
and the relevant systems.
WARNING
Ensure that the attachment is safely resting on to the ground before repairing,adjusting, or servicing
machines fitted with hydraulically, mechanically or cable controlled attachments (such as excavators,
loaders, dozers, scrapers, etc.). Should it be necessary to partially or fully raise the hydraulically, me-
chanically, or cable controlled attachment to gain access to certain items, make sure the attachment is
adequately retained in the raised position by means other than the hydraulic lift cylinders, cable and/or
mechanical devices used for controlling it.

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 8 W130/W130TC
SPECIFICATIONS
ENGINE - EMISSION
Model F4GE0684F
Fuel #2 Diesel (#1 & 2 Mixture Permitted For Cold
Temperature)
NumberofCylinders 6
Bore andStroke 4.09" (104 mm) x 5.20" (132 mm)
Displacement 409in3(6.7 Liters)
Electrical System 24Volts
Batteries (2)12Volts
Alternator 70 Amp
CompressionRatio 17.5 to 1
FuelPump
AirCleaner Dry TypeElementsWithWarningRestriction Indicator
Oil Filter Full Flow ReplaceableCartridge
Lubrication PositivePressure
CoolingSystem Air/WaterwithLube Oil Cooler
Power
- Gross(per SAE J1995) 148hp (111 kW)@ 2000 RPM
- Net(per SAE J1349) 136hp (101 kW)@ 2000 RPM
- Gross(per SAE J1995) 149hp (111 kW)@ 1800 RPM
- Net(per SAE J1349) 139hp (103 kW)@ 1800 RPM
Torque,Max.
- Gross(per SAE J1195) 509lb-ft (690 Nm)@ 1200 RPM
- Net(per SAE J1349) 495lb-ft (671 Nm)@ 1200 RPM
Governor
Complieswith 1996 US EPAand CARB Heavy DutyNon-RoadEmissions for 100-750hp(75-560 kW) engines.

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 9W130/W130TC
POWER TRAIN
TRANSMISSION
Make ZF
Model 4WG160
Radio 1st 2nd 3rd 4th
Forward 4.012 2.024 1.088 0.619
Reverse 3.804 1.919 1.031 -
TORQUECONVERTER
Make ZF
Model 06.013.08
Stall Ratio 2.66:1
SPEEDS:mph (km/h) 1st 2nd 3rd 4th
(17.5x 25 L3Tires)
- Forward 4.0(6.4) 7.8(12.5) 13.8(22.3) 22.5(36.2)
- Reverse 4.2(6.8) 8.2(13.2) 14.5(23.4)
(20.5x 25 L3Tires)
- Forward 4.3(6.9) 8.4(13.5) 14.9(23.9) 24 (38.6)
- Reverse 4.5(7.3) 8.8(14.2) 15.6(25.0)
AXLES Front Rear
- Differential Ratio 3.18 3.18
- Planetary Ratio 6.40 6.40
- Final Axle Ratio 20.36 20.36
Make ZF
Model Front-MTL3075
Rear -MTL 3065

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 10 W130/W130TC
BRAKES
Hydraulic, wet four-wheel disc. One brake pedals, both pedals apply brakes and electrically neutralilzes power
flow to wheels with transmission disconnect switch activated. Both pedals apply brakes only when transmission
disconnectswitch is notactivated.Hydraulic brake valvefor front and rearsplit system. Springapplied/hydraulic
releaseddisc parking brakeon transmission outputshaftneutralizes power flowto wheels engaged.
Brake Area of Service Brakes 355.28in2(0.229m2)/Hub
Brake Areaof Parking Brake 9.0 in2(58 cm2)
BrakePressure Front:1305psi(8998kPa)
(@ 2 sec. Setting method) Rear:1275 psi (8791 kPa)
ACCUMULATOR DATA
Cut In 2275psi(15686kPa)
Cut Out 2800 psi(19305 kPa)
Low PressureWarning 1500 psi(10342kPa)
TransmissionDeclutch 350psi(2413 kPa)
ChargePressure (N2) 800 psi (5516 kPa)
TIRES
20.5 R 25 XTLA TL★50psiFront 40 psi Rear
(345kPa) (275kPa)
20.5 R 25 XHA TL★50 psi Front 40psiRear
(345kPa) (275kPa)
20.5 R 25 XLD-D2 ★50 psi Front 40psiRear
(345kPa) (275kPa)
20.5 R 25 GP-2B ★50psiFront 40 psi Rear
(345kPa) (275kPa)
550/65 R 25 XLD ★50psiFront 40 psi Rear
(345kPa) (275kPa)
17.5 R 25 XTLA TL★50psiFront 40 psi Rear
(345kPa) (275kPa)
17.5 R 25 XHA TL★50 psi Front 40psiRear
(345kPa) (275kPa)
17.5 R 25 GP-2B ★50psiFront 40 psi Rear
(345kPa) (275kPa)

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 11W130/W130TC
HYDRAULICS AND STEERING
Reservoir: Filtered vent with relief on hydraulic reservoir main-
tains 3-5 psi (20-34 kPa) on reservoir. Full time 10
micron return filters furnish only clean oil to all com-
ponents of the system.
Valves: Closed-center,loadsensingcircuit,positivelowpres-
sure regeneration for bucket dump. Remote control
hydraulicpower assit withelectromagnetdetents.
Inletsectiongivessteeringprioritywithmaximumpres-
sure of 3500 psi (24132 kPa). Bucket section gives
bucketpriority.Reliefvalve provides maximum loader
pressureof 3625 psi(25,000kPa).
Loader control valve section contains float circuitry.
Senses steering demand to control oil flow to loader
valve or steering valve as required by steering de-
mand.
System: A variable displacement piston pump is used to sup-
ply oil to the integrated loader and steering hydraulic
system.
Pump displacement 5.49 in3/rev (90 cc/rev).
45.2 GPM @ 2000 RPM @ 3600 psi
(171.0l/min @ 2000RPM @ 24822kPa)
SteeringSection
Centerpivotarticulatedsteering-frontandrearwheels
alwaystrack. Two hydrauliccylinderscontrolled by a
hydrostatic steering gear and a priority valve.
Thesteering Orbitrol provider3.8 turns lock-to-lock.
Lock-to-lock time at high idle is 2.2 sec.

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 12 W130/W130TC
HydraulicCylinder:
Dump: (Z-Bar,XR) 5.00 dia x 24.40 stroke x 3.00 rod
(127.0 mm dia x 619.7 mm stroke x 76.2 mm rod)
(TC) 4.13 dia x 37.57 stroke x 2.25 rod
(104.8 mm dia x 954.4 mm stroke x 57.2 mm rod)
Lift: 4.50 dia x 31.00 stroke x 2.50 rod
(114.3 mm dia x 787.6 mm stroke x 63.5 mm rod)
Steer: 2.75 dia x 18.21 stroke x 1.50 rod
(69.9 mm dia x 462.5 mm stroke x 38.1 mm rod)
Diameter of Hydraulic Inlet and Outlet Ports:
One Inlet 2" Split Flange (50.8 mm)
OneOutlet 1.25" ORB (31.7mm)
- Steering Section 1.0" ORB (25.4 mm)
Maximum Oil Velocity at Hydraulic Pump @ 2000 RPM:
Outlets - Implement Section 11.8 ft/sec (3.60 m/sec)

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 13W130/W130TC
CAPACITIES
Cooling System:
6.3 US/gal (24.0 liters) to fill system
GallonsEthyleneGlycol (Prestone) required:
2.2 US/gal (8.5 liters) for 0 °F
2.7 US/gal (10.4 liters) for -20 °F
3.4 US/gal (12.8 liters) for -40 °F
FuelTank: 50.0 US/gal (189liters) Usable Fuel
Engine:
Crankcase Only 16 quarts (15.1 liters)
Crankcase andFilter 17 quarts (16.1 liters)
Transmission: 6.87 US/gal (26 liters) initial capacity
5.0 US/gal (18.9 liters) service (w/filter)
Axles: Front/Rear
Total/Axle 23.2 quarts (22 liters)
HydraulicReservoir:
Reservoir,oilonly 15.0 US/gal (56.8liters)
Reservoir,oil plus air 23.8US/gal(90.1 liters)
TotalSystem 30.0 US/gal (113.6 liters)

GENERALITIES
Carefully read personal and machine SAFETY PRECAUTIONS (at the beginning of this manual)
0 - 14 W130/W130TC
SOUND LEVEL DATA
Emission Engine w/o Enhanced Sound Package SoundLevel (Arithmetic Average) dBA
CabClosed
Exterior Sound Level @ 15 meters
per SAE J88 SEP80
Stationary-Rated Speed 71.4
TestAverage 72.6
Operator'sStationSound Level
per SAE J919 JUN86
Stationary-Rated Speed 70.5
TestAverage 69.8
Soundlevels per (indB(A))
2000/14/EC
98/37/EC(ISO6395, 6396, 3744)
InteriorLpA ExteriorLwA
CombinedDynamic (Test Average) 71.2 106.2
DecalValue 71 107
The option w Enhanced Sound Package will be developed at the begin of March.
Thestandard machine will bew/oEnhanced Sound Package.
