NEW HOLLAND
El
I\EW HOLLAI\D
SERVICE

Please cutwhere indicated and insertthe label intothe plastic pocket on the spine of
the binder.
r---------7
I
I
I
I
I
I
I
SKID-STEER
LOADER
REPAIR
: L865, Lx865, Lx885,
I Lx985
I
I
I
I
I
Vol.1
86584316
r---------7
SKID-STEER
LOADER
REPAIR
L865,Lx865,Lx885,
Lx985
Vol.1
86584316
L _________ J L _________ J
86587273
Find manuals at https://best-manuals.com

 ¤ 1(: +2 $1' 1257+ $0(5,&$ ,1&
/ /[ /[ /[
6.,'67((5 /2$'(5
5(3$,5 0$18$/
&217(176
6(&7,21   *(1(5$/ ,1)250$7,21
6(&7,21   (1*,1(
6(&7,21   (/(&75,&$/ 6<67(0
6(&7,21   ),1$/ '5, ( $;/(6 %5$.(6 *($5%2;(6
6(&7,21   +<'5267$7,& 6<67(0 $1' 67((5,1* 6<67(0
6(&7,21   +<'5$8/,& 6<67(0
6(&7,21   6($7 &$% 5236 %220 /2&. %220
$77$&+0(17 02817,1* 3/$7(
6(&7,21   237,21$/ (48,30(17
Find manuals at https://best-manuals.com

SECTION 1
GENERAL INFORMATION
CONTENTS
INTRODUCTION .................................................................... 1-2
IMPROVEMENTS ...........•....•.•..•..•............•..•............•......•..•..• 1-2
PRECAUTIONARY STATEMENTS
...••...•..•..••.•.•..•.•...•..•...................• 1-3
PERSONAL SAFETY
............•.......•........•...•............................. 1-3
MACHINE SAFETY
...................................................•...•.......•. 1-3
SAFETY PRECAUTIONS
•....................•.....•..•............................. 1-4
SAFETY DECALS
.......................................................•.......... 1-7
GENERAL SAFETY INFORMATION
.••.....•.....•..•..................•..•.......... 1-11
MODELAND SERIAL NUMBER LOCATION ........................................... 1-14
MINIMUM HARDWARE TIGHTENING TORQUES, INCH
...............................• 1-15
MINIMUM HARDWARE TIGHTENING TORQUES, METRIC
............•.•........••.... 1-16
HYDRAULIC TUBE AND FITTING INFORMATION
....•..•............................. 1-17
PROPERLY SUPPORTING A RAISED MACHINE
.....•............................•..• 1-18
PROPERLY SUPPORT BOOM ON BOOM
LOCK PINS ...•.•........................... 1-18
MAJOR UNIT OVERHAUL
.............•..•.........................................• 1-18
CAB TILTING PROCEDURE ......................................................•.• 1-19
TILTING
CAB AND BOOM BACK ON FRAME ...........•..........•...••.....•..•.... 1-24
CRANING THE SKID-STEER LOADER
.................................•..........•.. 1-26
DRILLING HOLES IN OVERHEAD DASH
•........•..••.••.••..............•.........• 1-28
ADAPTING ATTACHMENTS REQUIRING
12V ELECTRICAL POWER ...•.••.....•..•..•• 1-29
HYDRAULIC SYSTEM COMPATIBILITY
•••••.••••••••.••.••••••.••..•......•.....•.... 1-31
ACCESSORY RELAYAND ENGINE FUSE
BLOCK ....•..•..........•...••.••.•••...••• 1-32
SPECIFICATIONS L865, Lx865, Lx885
.•..••..•.•••••..•...•..•...............•.....•. 1-33
SPECIFICATIONS Lx985
••••.•..••.•..•.••..••.•..•••.•..•..••...••.••..••..•••..••. 1-38
INDEX ............................................................................. 1-43
1-1
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
INTRODUCTION
This service manual provides the technical
information needed to properly service and
maintain the Models L865, Lx865, Lx885, and
Lx985 skid-steer loaders. Use it
in conjunction
with theoperator's manual which is supplied with
the loader. Keep both manuals available for
ready reference.
The L
___ designates a factory standard built
unit.
The Lx
___ designates a factory Deluxe built
unit. Factoryoptions installed includeworklights,
taillights, and auxiliary boom hydraulics.
The L865, Lx865, Lx885, and Lx985 have many
similaritieswith the major difference being atwo-
speed hydrostatic motor used
on the Lx885 and
Lx985.
The L865, Lx865, Lx885 loaders are equipped
with the 332T non-emissionized or the 332T/JF
emissionized three-cylinder 60 net horsepower
turbocharged engine.
The Lx985 is equipped with the 450/NC
emissionized four cylinder 75 net horsepower
naturally aspirated engine.
Whenever working on New Holland equipment,
leftand rightsidesofthemachinearedetermined
by standing behind the unit, looking
in the
direction oftravel.
The easiest and least time-consuming removal,
disassembly, and reassembly procedure are
detailed
in the manual. Modifying these
procedures is not recommended.
New Holland skid-steer loaders are designed
with emphasis on safety for operator protection.
However, careless and negligent operation can
still result
in serious injuryto persons orproperty.
Be sure to read and follow all safety instructions
in this manual.
Your New Holland dealer is interested
in your
obtaining the mostfrom your investment and will
be glad to answer any questions you may have
about your loader. When major service is
required, your dealer's staff of trained service
technicians is ready to serve you.
When
in need of parts, always order genuine
New Holland service parts from your New
Holland dealer. Be prepared to give your dealer
the model and serial number of the engine and
loader (the location of these numbers is
described later
in this section). Record the serial
numbers here.
Loader Model
------------
Loader Serial Number
---------
Engine Model
------------
Engine Serial Number ________ _
A
CAUTION: THIS SYMBOL IS USED
THROUGHOUT THIS BOOK WHENEVER
YOUR OWN PERSONAL SAFETY IS
INVOLVED. TAKE TIME TO
BE CAREFUL!
IMPROVEMENTS
NewHollandis continuallystrivingtoimproveitsproducts. Wemust, therefore, reservetherighttomake
improvements or changes when it becomes practical and possible to do so, without incurring any
obligation to make changes or additions to the equipment sold previously.
ALL SPECIFICATIONS ARE SUBJECT
TO CHANGE WITHOUT NOTICE.
1-2
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
PRECAUTIONARY
STATEMENTS
PERSONAL SAFETY
Throughout this manual and on machine decals, you will find precautionary statements ("CAUTION",
'WARNING", and "DANGER") followed byspecific instructions. These precautions are intended forthe
personal safety
of you and those working with you. Please take the time to read them.
A
CAUTION: THE WORD "CAUTION" IS USED WHERE A SAFE BEHAVIORAL PRACTICE AC-
CORDING TO OPERATING AND MAINTENANCE INSTRUCTIONS AND COMMON SAFETY
PRACTICES WILL PROTECTTHE OPERATOR AND OTHERS FROM ACCIDENT INVOLVEMENT.
A
WARNING: THEWORD "WARNING" DENOTESA POTENTIAL OR HIDDEN HAZARD WHICH HAS
A POTENTIALFORSERIOUS INJURY. ITIS USED TO WARN OPERATORS AND OTHERSTO EX-
ERCISE EVERYAPPROPRIATE MEANSTOAVOID A SURPRISE INVOLVEMENTWITH MACHIN-
ERY.
A
DANGER: THE WORD "DANGER" DENOTES A FORBIDDEN PRACTICE IN CONNECTION WITH
A SERIOUS HAZARD.
FAILURE TO FOLLOW THE "CAUTION", "WARNING", AND "DANGER" INSTRUCTIONS MAY
RESULT
IN SERIOUS BODILY INJURY OR DEATH.
MACHINE SAFETY
Additional precautionary statements ("ATTENTION" and "IMPORTANT") are followed by specific in-
structions. These statements are intended for machine safety.
ATTENTION: The word ''ATTENTION" is used to warn the operator
of potentialmachine damage if a
certain procedure is
not followed.
IMPORTANT: The word "IMPORTANT'is
used to inform the reader of something he needs to know to
preventminormachine damage
if a certain procedure is not followed.
1-3
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
A
SAFETY PRECAUTIONS
UNSAFE OPERATING PRACTICES AND IMPROPER USE OF THE SKID-STEER LOADER AND
ITS ATTACHMENTS ON THE PART OF THE OPERATOR CAN RESULT IN INJURIES. OBSERVE
THE FOLLOWING SAFETY PRECAUTIONS AT
ALL TIMES:
1. FOR SERVICING, THE LOADER SHOULD BE ON LEVELTERRAIN, ENGINE STOPPEDWITH
THE WHEELS BLOCKED OR THE ENTIRE LOADER SOLIDLY SUPPORTED WITH THE
WHEELSOFFTHE GROUND BEFORESERVICING ANY COMPONENTOFTHE DRIVETRAIN.
2. FOR SERVICING UNDER THE OPERATOR'S SEAT, RAISE THE SEATAND PAN ASSEMBLY
UP TO THE RAISED LATCHED POSITION AND SECURELY LATCH.
3. DO NOT OPERATE THE LOADER UNLESS THE SEAT IS LATCHED IN THE OPERATE
POSITION.
4. DO NOT SERVICE THE LOADER WITH A RAISED BOOM UNLESS THE BOOM IS RESTING
ON THE BOOM
LOCK PINS.
5. DO NOT SERVICE THE LOADER WITH THE ENGINE RUNNING UNLESS THE LOADER IS
PROPERLY AND SECURELY SUPPORTED WITH
ALL FOUR WHEELS OFFTHE GROUND.
6. USE CAUTION WHEN SERVICING THE UNIT AROUND MOVING PARTS.
7. DO NOT TILTTHE BOOM AND
CAB WITHOUT PROPER INSTRUCTION.
8. DO NOT TILT THE BOOM AND
CAB WITHOUT USING THE PROPER CAB TILTING TOOL.
9. REINSTALL ALL SHIELDS REMOVED FOR SERVICE.
10. NEVERLOOSEN
ANY HYDRAULICCONNECTIONSBEFORE RELIEVINGTHE PRESSUREIN
THE HYDRAULIC SYSTEM.
11. WEAR EYE PROTECTION SUCH
AS GOGGLES, ETC.
12. WEAREARPROTECTION SUCH
AS EARPLUGS, ETC. WHENYOU FEELTHENOISE LEVEL
IS UNCOMFORTABLE.
13. IF
ANY SERVICING OR ADJUSTMENTS REQUIRE THE BATTERYTO BE DISCONNECTED,
DISCONNECT THE (-) NEGATIVE GROUND CABLE.
14. WHEN SERVICING ELECTRICAL COMPONENTS, DISCONNECT THE (-) NEGATIVE
GROUND CABLE.
15. IFTHE ELECTRONICINSTRUMENTCLUSTER(EiC) REQUIRES REMOVALFROMTHE DASH
AREA OR THE SKID-STEER LOADER DISCONNECT THE(-) NEGATIVE GROUND BATTERY
CABLE. THIS
WILL SHUT OFF POWER TO THE EiC AND PREVENT DAMAGE TO THE EiC
BOARD OR BLOWING THE 5-AMP FUSES IFTHE BOARD IS ACCIDENTALLY GROUNDED.
16. IFWELDING IS REQUIREDONTHE SKID-STEER LOADER, DISCONNECTTHE (-) NEGATIVE
GROUND CABLE. FAILURE TO DISCONNECTTHE BATTERYMAY RESULT IN DAMAGE TO
THE EiC (ELECTRONIC INSTRUMENT CLUSTER) MONITORING SYSTEM AND OTHER
ELECTRICAL COMPONENTS.
17. IFWELDING IS REQUIRED ON
AN ATTACHMENT, REMOVE THE ATTACHMENT FROM THE
SKID-STEER LOADER.
1-4
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
18. GIVECOMPLETEAND UNDIVIDEDATTENTION TO THE JOB ATHANDSOTHATCOMPLETE
CONTROL OF THE LOADER IS MAINTAINED AT
ALL TIMES.
19. DRIVE SLOWLY OVER ROUGH GROUND AND ON SLOPES; KEEP
ALERT FOR HOLES,
DITCHES AND OTHER IRREGULARITIES THAT MAYCAUSE THE LOADER TO OVERTURN.
20. AVOIDSTEEP HILLSIDEOPERATION WHICH COULDCAUSETHE LOADERTO OVERTURN.
21. NEVER TRANSPORTA LOADED BUCKETAT FULLHEIGHT. OPERATE THE LOADER WITH
THE LOAD AS LOWAS POSSIBLE UNTILIT BECOMES NECESSARYTO RAISE THE BOOM
TO DISCHARGE THE LOAD INTO A TRUCK, CONTAINER, ETC.
22. REDUCE SPEED WHEN TURNING SO THERE IS NO DANGER OF THE LOADER
OVERTURNING.
23. NEVERDRIVE
UP OR BACK UP A HILLOR INCLINEWITH A RAISED BOOMOR THE LOADER
COULD OVER TURN.
24. ALWAYS LOOK BEHIND YOU BEFORE BACKING THE LOADER.
25. MAINTAIN PROPER TRANSMISSION OIL LEVEL TO PREVENT LOSS OF HYDROSTATIC
BRAKING.
26. DO NOT ALLOW PASSENGERS TO RIDE ON THE LOADER AT ANY TIME.
27.
DO NOT ALLOW CHILDREN TO OPERATETHE LOADER OR RIDE ON THE LOADERAT ANY
TIME.
28.
DO NOT ALLOW ANYONE TO OPERATE THE LOADER WITHOUT PROPER INSTRUCTION.
OSHA REQUIRES THAT
ALL OPERATORS BE INSTRUCTED ON THE PROPER OPERATION
OF THE MACHINE BEFORE THEY OPERATE THE UNIT.
29. DO NOT OPERATE THE LOADER
IN ANY POSITION OTHER THAN WHILE IN THE
OPERATOR'S SEAT WITH THE SEAT BELT SECURELY FASTENED.
30. BEFORE STARTING THE ENGINE, BE SURE THAT
ALL OPERATING CONTROLS ARE IN
NEUTRAL AND THE PARKING BRAKE IS ENGAGED.
31. NEVER OPERATE THE LOADER ENGINE
IN A CLOSED BUILDING WITHOUT ADEQUATE
VENTILATION.
32. REFUEL THE LOADER OUTDOORS WITH THE ENGINE SHUT
OFF. REPLACE THE FUEL
CAP SECURELY. USE AN APPROVED FUEL CONTAINER. DO NOT SMOKE WHEN
HANDLING FUEL. AVOID SPILLING FUEL.
33. AFTER OPERATING THE ENGINE, NEVER TOUCH THE MUFFLER, EXHAUSTPIPE, ENGINE
OR RADIATOR UNTIL THEY HAVE HAD TIME TO COOL.
34. DRESS APPROPRIATELY -WEAR RELATIVELY TIGHT-FITTING CLOTHING WHEN
OPERATING THE LOADER. LOOSE OR TORN CLOTHING CAN CATCH
IN MOVING PARTS
OR CONTROLS.
35. BEFORE SERVICING THE LOADER OR
ANY OF ITS ATTACHED EQUIPMENT, BE SURE
THAT THE ATTACHMENTS ARE LOWERED TO THE GROUND OR THAT THE BOOM ARMS
ARE SUPPORTED
BY THE BOOM LOCK PINS.
36. DO NOT WORK UNDER OVERHANGS, ELECTRIC WIRES, OR WHERE THERE IS DANGER
OF A SLIDE.
37. WEARAN APPROVED SAFETY HATWHEN OPERATING THE MACHINEANDWHILE
IN ANY
WORK AREA.
1-5
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
38. WHEN DRIVING THE LOADER ON A ROAD OR HIGHWAY, USE WARNING LIGHTS OR
WARNING DEVICES
AS MAY BE REQUIRED BY LOCAL OR STATE GOVERNMENT
REGULATIONS. HEADLIGHTS, WARNING LIGHTS AND SMV SIGNS ARE AVAILABLE
THROUGH YOUR NEW HOLLAND DEALER.
39. KEEP THE LOADER CLEAN.
DO NOT ALLOW TRASH, DEBRIS OR OTHER ARTICLES TO
ACCUMULATE IN THE CAB, FLOOR OR FOOTCONTROL PEDAL
AREA THAT MAYHINDER
SAFE MACHINE OPERATION.
40. NEVER OPERATE THE LOADER WITH ANY OF THE SHIELDING REMOVED.
41. NEVER OPERATE THE LOADER WITHOUT WINDOWS AND/OR SCREENS
IN PLACE.
42. NEVER EXTEND ANY PART OF THE BODY OUTSIDE OF THE OPERATOR'S AREA.
43. ALWAYS PROPERLY TIE DOWN THE SKID-STEER LOADER TO A TRUCK OR TRAILER
BEFORE TRANSPORT.
44. MAKE SURE
ALL BYSTANDERS ARE AT A SAFE DISTANCE AWAY FROM THE LOADER
BEFORE STARTING THE ENGINE.
45. DO NOTALLOW ANYONE NEAR THE LOADER WHILE THE ENGINE IS RUNNING AND THE
LOADER IS OPERATIONAL.
46. WHEN USING THE SKID-STEER LOADER TO CRANE OBJECTS, DO NOT ALLOW ANY
PERSON TO RIDE
ON OBJECTS BEING CRANED.
47. DO NOT USE THE SKID-STEER LOADER AS A WORK PLATFORM FOR SUPPORTING
MATERIALS.
48. DO NOT LIFT PERSONNEL OR
ALLOW PERSONNEL TO WORKWHILE STANDING IN THE
BUCKET
OR ON OTHER ATTACHMENTS. THIS IS NOT A MAN-LIFT.
OSHA REQUIREMENTS NOW MAKE IT THE EMPLOYER'S RESPONSIBILITY
TO FULLY
INSTRUCT EACH OPERATOR IN THE PROPER AND SAFE OPERATION OF
ALL OPERATIVE
EQUIPMENT. BOTH EMPLOYER AND EMPLOYEE SHOULD THOROUGHLY FAMILIARIZE
THEMSELVES WITH THE FOLLOWING SECTIONS.
A
CAUTION!
SOME PICTURES IN THIS MANUAL SHOW SAFETY SHIELDS REMOVED OR OPEN
TO SHOW
PARTS BEING SERVICED OR FOR CLARITY.
ALL SHIELDS SHOULD BE CLOSED OR
REPLACED PRIOR TO OPERATING THE MACHINE.
DANGER!
FASTEN SEAT BELT
BEFORE STARTING ENGINE!
THIS LOADER ISA VERYSTABLE UNIT BUTITCAN BE UPSETIF STOPPED SUDDENLYWHEN
THE BUCKET IS RAISED AND LOADED.
THEREFORE, DO NOTSTARTTHE ENGINE BEFORE SECURELY FASTENING THE SEAT BELT,
AND CARRY THE LOAD LOW.
1-6
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
SAFETY DECALS
Thefollowing safety decals have been placed on
your machine
in the areas indicated. They are
intendedforthepersonal safety
of you, andthose
working with you. Please take this manual, walk
around your machine and note the content and
1. DANGER: DO NOT ALLOW
PASSENGERS
TO RIDE ON THE LOADER
AT ANY TIME. DO NOT GET UNDER
BOOM UNLESS SUPPORTED BY THE
BOOM LOCK PINS.
2. CAUTION: DO NOT ALLOW ANYONE TO
OPERATE THE LOADER WITHOUT
PROPER INSTRUCTION.
Part #86521688
1-7
location of these warning signs. Review these
decals with your machine operators.
Keep the decals legible. If they are not, obtain
replacementsfrom your NewHollanddealer. The
decal part numbers are listed with each decal.
Part #86521685
Find manuals at https://best-manuals.com

SECTION 1 - GENERAL INFORMATION
3. DANGER: BEFORE EXITING THE
LOADER, LOWER THE LIFT ARMS AND
ATTACHMENT TO THE GROUND OR
REST LIFTARMS
ON THE BOOM STOPS.
STOP ENGINE AND ENGAGE THE
PARKING BRAKE.
Part #86521683
4. WARNING: DO NOT OVERLOAD! NEVER
LIFT MORE THAN THE MAXIMUM SAE
LOAD RATING OF THE LOADER. NEVER
TRANSPORT A LOADED BUCKET AT
FULL HEIGHT. OPERATE THE LOADER
WITH THE LOAD AS LOWAS POSSIBLE.
L865, Lx865, Lx885 -2200 lbs. (998 kg)
Part #86521718
Lx985
Part #86548195
(Mfg. Rating)
-2800 lbs. (1270 kg)
(Mfg. Rating)
5. WARNING: NEVER OPERATE THE
LOADER WITHOUT THE SEAT BELT
SECURELY FASTENED.
Part #86521686
1-8
AVOID DEATH
BEFORE REMOVING SEATBELT
AND LEAVING SEAT
• LOWER LIFT ARMS TO GROUND
OR REST LIFT ARMS ON STOPS
• STOP ENGINE
• LOCK PARK BRAKE & REMOVE KEY
UP I
Bb:J00~l 2
&CAUTION

SECTION 1 - GENERAL INFORMATION
6. WARNING: KEEP CLEAR OF MOVING
PARTS. KEEP BYSTANDERS CLEAR OF
THE LOADER AT
ALL TIMES UNLESS
THE BOOM IS DOWN
ON THE GROUND
OR THE BOOM IS RESTING
ON THE
BOOM LOCK PINS AND ENGINE IS
OFF.
NEVER EXTEND ANY PART OF THE
BODY OUTSIDE OF THE OPERATOR'S
AREA.
Part #86521673
7. WARNING: KEEP CLEAR! ROTATING
FAN -STOP ENGINE.
Part #9828825
A WARNING
PINCH AREA
Keep away
A WARNING
STOP ENGINE
8. WARNING: DO NOT ALLOW ANYONE
NEAR THE LOADER WHILE THE ENGINE
IS RUNNING AND THE LOADER IS
OPERATIONAL. A
WARNING
Part #86509972
1-9
• UFT ARMS MOVE NEAR ENGINE
HOOD AND FRAME
• NEVER STAND
OR LEAN
ANYWHERE ON LOADER OR
LINKAGE WILL CRUSH YOU
'1EH,HJ"f2

SECTION 1 - GENERAL INFORMATION
9. CAUTION: DO NOT SPRAY ETHER INTO
AIR INTAKE. EXPLOSION AND INJURY
COULD
RESULT.
Part #796286
10. DANGER: USE ONLY THE NEW
HOLLAND CAB JACK KIT
TO TILT THE
CAB. READ INSTRUCTIONS BEFORE
TILTING CAB.
DO NOT REMOVE CAB
HARDWARE UNTIL CAB
JACK IS
INSTALLED. FAILURE
TO DO SO MAY
CAUSE CAB
TO FALL CAUSING
SERIOUS INJURY
OR DEATH.
Part #86521713
11. DANGER: LOCATED ON THE CAB
TILTING JACK. NEW HOLLAND
SKID-STEER LOADER CAB TILTING
TOOL. READ CAB TILTING
INSTRUCTIONS AND USE WITH PROPER
MOUNTING BRACKETS BEFORE
TILTING
CAB.
Part #86508506
1-10
MOO
A CAUTION
DO NOT SPRAY ETHER INTO
AIR INTAKE. EXPLOSION
AND INJURY COULD RESULT.
USE ONLY APPROVED
COLD
START AIDS~
A DANGER
USE ONLY FNH CAB
JACK KIT TO TILT CAB.
READ CAB JACK KIT
USE INSTRUCTIONS
BEFORE TILTING CAB.
w
REMOVE CAB
HARDWARE ONLY
AFTER CAB JACK IS
INSTAll.ED.
FAILURE TO DO SO
MAY CAUSE CAB TO
FALL CAUSING
SERIOUS INJURY OR
DEATH.
196286
A DANGER
FNH SKID-STEER LOADER CAB JILT TOOL
USE WITH PROPER MOUNTING BRACKETS
TO TILT CAB.
READ CAB JACK INSTRUCTIONS
BEFORE USING. w

SECTION 1 - GENERAL INFORMATION
GENERAL SAFETY INFORMATION
HANDLE FLUIDS SAFELY
When you work around fuel or other flammable
material, do not smoke, work near heaters or
other fire hazards.
Do not store flammable material in open
containers.
Store flammable fluids away from fire hazards.
Do not incinerate or puncture pressurized
containers.
Make sure machine is clean oftrash, grease, oil,
and debris.
Do not store oily rags; they can ignite and burn
spontaneously.
Keep a first
aid kit and fire extinguisher handy.
Keep emergency numbers for doctors,
ambulanceservice, hospital,
and fire department
near your telephone.
AVOID HEATING NEAR PRESSURIZED
FLUID LINES
Flammable spray can be generated by heating
near pressurized fluid lines, resulting
in severe
burns to yourself and bystanders.
Do not heat by welding, soldering, or using a
torch near pressurized fluid lines.
Pressurized lines can
be accidentally cut or
damaged when heatgoes beyond the immediate
flame area.
1-11
USE CARE AROUND HIGH-PRESSURE
FLUID LINES
Escaping fluid under pressure can penetrate the
skin causing serious injury.
Avoid the hazard
by relieving pressure before
disconnecting hydraulic or other lines.
Tighten all line connections before applying
pressure.
Check for leaks with a piece of cardboard.
Protect hands
and body from high-pressure
fluids.
If
an accident occurs, see a doctor immediately.
Any fluid injected into the skin must be surgically
removed within a few hours or gangrene may
result. Doctors unfamiliar with this type of injury
should reference a knowledgeable medical
source.

SECTION 1 - GENERAL INFORMATION
USE CARE IN HANDLING AND
SERVICING BATTERIES
Prevent Battery Explosions
Keep sparks, lighted matches, and open flame
awayfrom the top ofthe battery. Battery gas can
explode.
Never check battery charge by placing a metal
object across the posts. Use a voltmeter or
hydrometer.
Do not charge a frozen battery; it may explode.
Warm the battery to 60° F (16° C).
A
WARNING: IF ANY SERVICING OR
ADJUSTMENTS REQUIRE THE BATTERY TO
BE DISCONNECTED, OR WELDING IS
REQUIRED ON THE SKID-STEER LOADER,
DISCONNECT THE
(-) NEGATIVE GROUND
CABLE. FAILURE TO DISCONNECT THE
BATTERY MAY RESULT
IN DAMAGE TO THE
EiC (ELECTRONIC INSTRUMENT CLUSTER)
MONITORING SYSTEM AND OTHER
ELECTRICAL COMPONENTS.
WARNING: IF WELDING
ON AN
ATTACHMENT
IS REQUIRED, FIRST
REMOVE THE ATTACHMENT
FROM THE
LOADER BOOM ATTACHING PLATE.
1-12
A
WARNING: ENGINE STARTING WITH A
BOOSTER BATTERY REQUIRES EXTREME
CARE AS BATTERIES PRODUCE
EXPLOSIVE GASES. THE SLIGHTEST
SPARK CAN CAUSE AN EXPLOSION.
FOLLOW THESE SAFETY TIPS:
1. ALWAYS SHIELD YOUR EYES WHEN
CHARGING
OR WORKING NEAR A
BATTERY. ALWAYS PROVIDE GOOD
VENTILATION.
2. COVER THE BATTERY WITH A PIECE OF
CARPET
OR OTHER HEAVY MATERIAL.
DO NOT REMOVE THE BATTERY VENT
CAPS.
3. CONNECT ONE CABLE TO THE (+)
POSITIVE TERMINAL OF THE WEAK
BATTERY. CONNECT THE OTHER END
OF THE CABLE
TO THE (+) POSITIVE
TERMINAL
OF THE STRONGER
BATTERY.
4. CONNECT THE SECOND CABLE TO THE
(-) NEGATIVE TERMINAL OF THE
STRONGER BATTERY.
5. CONNECT THE REMAINING (-)
NEGATIVE CABLE END TO THE ENGINE
BLOCK ·
OR STARTER GROUND
TERMINAL.
6. REVERSE THIS PROCEDURE WHEN
DISCONNECTING THE BOOSTER.

SECTION 1 - GENERAL INFORMATION
USE SAFE SERVICE PROCEDURES
Wear Protective Clothing
Do not wear loose clothing.
Wear close-fitting clothing.
Wear safety glasses or face shield as required.
Wear other safety equipment appropriate to the
job.
Wear earplugs or earmuffs as required.
SERVICE MACHINES SAFELY
Use caution when working around moving parts.
Ifservicing requires the boom to be
in the raised
position, support the boom
on the boom locks
and remove any attachment from the boom
mounting plate. If servicing requires the
complete loader to be
in the supported position,
support all four wheels off the ground using
adequate jack stands or blocks.
If servicing requires the engine to be operated,
raise the machine and properly support the unit
with adequatejackstandsorblocking with allfour
wheels off the ground.
A
BEFORE SERVICING THE LOADER OR ANY
OF ITS ATTACHED EQUIPMENT, BE SURE
THAT THE ATTACHMENTS ARE LOWERED
TOTHE GROUND OR THE BOOM ARMS ARE
SUPPORTED BY THE BOOM LOCK PINS.
1-13
USE PROPER TOOLS
Use tools appropriate for the job.
lftiltingofthecab
is required, usethepropertools
and follow the procedure for tilting the cab
in
Section 1 ofthis manual.
REVIEW SAFETY EQUIPMENT, SIGNS AND
SHIELDS
Replace missing or damaged safety decals.
Reinstall all shielding removed for servicing.
Replace any damaged or missing shielding.
CONTROLS
Operate unit and check machine functions for
proper operation.
Check seat belt for proper operation, wear, and
damage -Replace as needed.
Check operator restraint system -EiC for proper
operation.
Check boom and bucket spool locks for proper
operation.
Check mechanical boom locks for proper
operation.
Check parking brake for proper operation and
adjustment.

SECTION 1 - GENERAL INFORMATION
MODEL AND SERIAL NUMBER LOCATION
The skid-steer loader model and serial number
tag is located
on the right front interior of the
operator's cab at
1.
The engine model is located on the leftside ofthe
block at
1, and the engine serial number is
located at
2.
For the tightening torques for reassembly, use
the following hardware torque charts unless the
torque is specified
in the instructions.
1-14
Figure 1-1
Figure 1-2

SECTION 1 - GENERAL INFORMATION
MINIMUM HARDWARE TIGHTENING TORQUES
IN FOOT POUNDS (NEWTON-METERS) FOR NORMALASSEMBLY APPLICATIONS
INCH HARDWARE AND LOCKNUTS
SAEGRADE2 SAEGRADE5 SAE GRADES LOCKNUTS
NOMINAL UNPLATED PLATED UNPLATED PLATED UNPLATED PLATED GR.B GR.C NOMINAL
SIZE or W/ZnCr or W/ZnCr or W/ZnCr w/GR5 w/GRS SIZE
PLATED PLATED PLATED BOLT BOLT
SILVER GOLD SILVER GOLD SILVER GOLD
1/4 55* (6.2) 72* (8.1) 86* (9.7) 112*(13) 121* (14) 157* (18) 61* (6.9) 86* (9.8) 1/4
5/16 115* (13) 149* (17) 178* (20) 229* (26) 250* (28) 324* (37) 125* (14) 176* (20) 5/16
3/8 17 (23) 22 (30) 26 (35) 34
(46) 37 (50) 48 (65) 19 (26) 26 (35) 3/8
7/16 27 (37) 35 (47) 42 (57) 54
(73)
59 (80) 77 (104) 30 (41) 42 (57) 7/16
1/2 42 (57) 54 (73) 64 (87) 83
(113) 91 (123) 117(159) 45 (61) 64 (88) 1/2
9/16 60 (81) 77 (104) 92 (125) 120 (163) 130 (176) 169 (229) 65 (88) 92 (125) 9/16
5/8 83
(112) 107 (145) 128(174) 165 (224) 180 (244) 233 (316) 90 (122) 127 (172) 5/8
3/4 146 (198) 189 (256) 226 (306) 293 (397) 319 (432) 413 (560) 160 (217) 226 (306) 3/4
7/8 142 (193) 183 (248) 365 (495) 473 (641) 515 (698) 667 (904) 258 (350) 364 (494) 7/8
1 213 (289) 275 (373) 547 (742) 708 (960) 773 (1048) 1000 (1356) 386 (523) 545 (739) 1
NOTE: Torque values shown with *are inch pounds.
IDENTIFICATION
CAP SCREWS AND CARRIAGE BOLTS
0
SAEGRADE2 SAEGRADE5 SAE GRADES
REGULAR NUTS SAE GRADE 5 SAE GRADE 8
HEX NUTS
HEX NUTS
LOCKNUTS
GRADE IDENTIFICATION
GRADEA NO NOTCHES
GRADE B ONE CIRCUMFERENTIAL NOTCH
GRADE C TWO CIRCUMFERENTIAL NOTCHES •
GRADE IDENTIFICATION
GRADEA NO MARKS
GRADE B THREE MARKS
GRADE C SIX
MARKS
MARKS
NEED NOT BE LOCATED
AT CORNERS
GRADE A NO MARK
GRADE B LETTER B
GRADE C LETTER C
GRADE IDENTIFICATION
1-15

SECTION 1 - GENERAL INFORMATION
MINIMUM HARDWARE TIGHTENING TORQUES
IN FOOT POUNDS (NEWTON-METERS) FOR NORMALASSEMBLY APPLICATIONS
METRIC HARDWARE AND LOCKNUTS
NOMINAL CLASSS.8
CLASS8.8 CLASS 10.9
SIZE UNPLATED PLATED UNPLATED PLATED UNPLATED PLATED
W/ZnCr W/ZnCr W/ZnCr
M4
15*(1.7) 19* (2.2) 23* (2.6) 30* (3.4) 33* (3.7) 42* (4.8)
M6 51* (5.8) 67* (7.6) 79* (8.9) 102* (12) 115* (13) 150* (17)
M8 124* (14) 159* (18) 195* (22) 248* (28) 274* (31) 354* (40)
M10
21 (28) 27 (36) 32 (43)
41 (56) 45 (61) 58 (79)
M12 36 (49) 46 (63) 55 (75) 72 (97) 79 (107) 102 (138)
M16 89 (121) 117 (158) 137 (186) 177 (240) 196 (266) 254 (344)
M20 175 (237) 226 (307) 277 (375) 358 (485) 383 (519) 495 (671)
M24 303 (411) 392 (531) 478 (648) 619 (839) 662 (897) 855 (1160)
NOTE: Torque values shown with *are inch pounds.
IDENTIFICATION
HEX CAP SCREW AND CARRIAGE BOLTS
CLASSES 5.6 AND UP
MANUFACTURER'S IDENTIFICATION
A ■
CD
PROPERTY CLASS
HEX NUTS AND LOCKNUT$
CLASSES 05 AND
UP
MANUFACTURER'S IDENTIFICATION
PROPERTYCLASS CLOCK MARKING
1-16
LOCKNUT
CL.8
W/CL8.8
BOLT
16* (1.8)
56* (6.3)
133* (15)
22 (30)
39 (53)
97 (131)
195 (265)
338 (458)

SECTION 1 - GENERAL INFORMATION
INSTALLATION OF ADJUSTABLE
FITTINGS IN STRAIGHT THREAD
0 RING BOSSES
1. Lubricate the O ring by coating it with a light
oil or petroleum. Install the O ring
in the
groove adjacentto the metal backupwasher
which isassembled atthe extremeend ofthe
groove,
1.
2. Install the fitting into the SAE straight thread
boss until the metal backup washer contacts
the face of the boss, 2.
NOTE: Do not over tighten and distortthe
metal backup washer.
3. Position the fitting by turning out
(counterclockwise) up to a maximum of one
turn. Holding the pad of the fitting with a
wrench, tighten the locknut and washer
against the face of the boss,
3.
Figure 1-3
STANDARD TORQUE DATA FOR HYDRAULIC TUBES AND FITTINGS
TUBE NUTS 0 RING BOSS PLUGS
FOR 37° FLARED FITTINGS ADJUSTABLE FITTING
LOCKNUTS, SWIVEL
JIC -37° SEATS
TORQUE TORQUE
TUBING THREAD FOOT NEWTON FOOT NEWTON
SIZE OD SIZE POUNDS METERS POUNDS METERS
In. mm
Min. Max. Min. Max. Min. Max. Min. Max.
4 1/4 6.4 7/16-20 9
5 5/16 7.9 1/2-20 12
6 3/8 9.5 9/16-18
21
8 1/2 12.7 3/4-18 35
10 5/8 15.9 7/8-14 53
12 3/4
19.1 1-1/16-12 77
14 7/8 22.2 1-3/16-12 90
16 1 25.4 1-5/16-12
110
20 1-1/4 31.8 1-5/8-12 140
24 1-1/2
38.1 1-7/8-12 160
32 2 50.8 2-1/2-12 225
Thesetorques are notrecommended fortubes of
1/2" (12. 7 mm) OD and largerwith wall thickness
of 0.035" (0.889 mm) or less. The torque is
specified for 0.035" (0.889 mm) wall tubes
on
each application individually.
Before installing and torquing 37° flared fittings,
clean the face ofthe flare and threads with a
12
15
24
40
53
82
100
120
150
175
240
12 16 6 10 8 14
16 20 10 15 14 20
29 33 15 20 20 27
47 54 25 30 34
41
72 79 35 40 47 54
104
111
60 70
81
95
122 136 70 80 95 109
149 163 80 90 108 122
190 204 95
115 129 158
217 237 120 140 163 190
305 325 250 300 339 407
clean solvent or Loctite cleaner and apply
hydraulic sealant Loctite no. 569 to the 37° flare
and the threads.
Install fitting and torque to specified torque,
loosen fitting and retorque to specifications.
1-17
