NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 1

23
YOUR NEEDS VARY CONSTANTLY.T7
ADAPTS CONTINUOUSLY.
MORE PRODUCTIVITY AND POWER
T7 tractors boast New Holland's cutting-edge ECOBlue™ SCR technology for Tier 4A compliance.
This means that the 6.7 litre Nef engine benefits from exceptional breathability for a significant
performance advantage. T7 tractors now offer up to 19hp more power and 139Nm of torque over
the existing T7000 range. With Engine Power Management, up to 51hp extra is available for
optimum productivity.
ABSOLUTE DRIVING PLEASURE
T7 tractors are designed to make operation even easier. The new SideWinder™ II armrest ensures
the tractor is less tiring to use over extended periods. The Horizon™ cab offers exceptionally low
noise levels of just 69dB(A) and brilliant all-round visibility.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 2

LOWER OPERATING COSTS
T7 tractors benefit from Nef engines that use ECOBlue™ SCR emission reduction
technology. Matched with the advanced Auto Command™ transmission, fuel use
is cut by up to 10%. 600 hour engine service intervals continue to set the standard.
MAXIMUM VERSATILITY
The nine-model T7 series has a power and transmission choice for every application.
Combined with their exceptional power to weight ratios of up to 25.8kg/hp(CV), these tractors
offer exceptional versatility. From draft to top work, spraying to transport, a T7 tractor will do it all.
Max power with EPM [hp(CV)]
EPM [hp(CV)]
Rated power [hp(CV)]
T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270
T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270
171
188
203
212
218
234
250
260
269
125
140
155
165
167
185
200
215
228
T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270
Horsepower
Engine speed
EPM according to the load on transmission, PTO and hydraulics.
EXACTLY WHAT IT SAYS ON THE BONNET
T7 tractors offer improved performance thanks to the Tier 4A ECOBlue™ SCR advantage, and these productivity
enhancing characteristics are immediately obvious to all users. How? Quite simply, it is on the bonnet. The first two
digits ‘T7’ refer to the tractor’s category and the following three, for example ‘270’, refer to the maximum Engine
Power Management horsepower. What does that mean to you? You can buy your T7 safe in the knowledge that it will
be able to cope with even the most demanding applications. New Holland for ultimate productivity peace of mind.
46
48
48
47
51
49
50
45
41
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 3

THE RANGE45
A LARGER FAMILYFOR DEMANDING
PROFESSIONALS.
New Holland T7 tractors can be specified to match your specific business needs.
Spanning rated powers from 125hp to 228hp, the nine model T7 range can be fitted with a choice of
semi-powershift, full-powershift or constantly variable transmission (CVT). All models can be fitted with a
New Holland loader, all tractors have the option of a fully integrated front linkage and PTO.
11NHT7_0511.qxd:NH_T7_Brochure 25/5/11 6:46 PM Page 4

AN ARMREST TO SUIT YOU
Range Command™ and Power Command™ tractors’ can be specified either with a classic
armrest or New Holland’s advanced SideWinder™ II armrest, complete with
CommandGrip™ handle and IntelliView™ III monitor, as an option. SideWinder II is standard
on Auto Command™ tractors and benefits from the advanced force based CommandGrip
for speed and direction control.
CLASSIC ARMREST
SIDEWINDER™ II ARMREST
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 5

OPERATOR ENVIRONMENT67
FROM DUSK TO DAWN
Cab roof, engine hood and fender
worklights are easily controlled
from a dedicated switch panel.
The operator can set the lights to
match a broad range of applications
for safer, more productive operation.
AT 69DB(A), T7 CABS ARE THE
QUIETEST IN THE SEGMENT
HORIZON™CAB MORE SPACE, BETTER VISIBILITY.
DESIGNED FOR COMFORT AND PRODUCTIVITY
Step up into a standard T7 Horizon™ cab, and regardless
of its specification, you will find it has been designed to fit
you perfectly. Note how the seat and steering wheel adjust
to suit you. All-round visibility is about as good as it gets.
Noise levels are exceptionally low, helping to reduce fatigue.
Enjoy how the seat, cab and axle suspension cushion the
ride. From air-conditioning to optional full climate control,
the Horizon cab will do its best to keep you comfortable.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 6

HEADLAND TURN SEQUENCING
Automated features are only of use when the operator feels comfortable setting
them up and using them. New Holland Headland Turn Sequencing has been refined
and developed over several years to match ease of operation with in-field efficiency.
The system allows the operator to record and store the sequence of operations at
the headland. These are then ‘played back’ automatically when HTS is activated.
Simple and a great way to reduce fatigue over extended working periods.
AUTO COMFORT™SEAT
For operators who spend extended
hours in the tractor, the enhanced
comfort provided by the heated
Auto Comfort™ seat is worth
considering. Fitted with a large air
reservoir to further reduce whole
body vibration, the Auto Comfort
seat delivers an even smoother ride.
EASY CAB ACCESS
Manufactured from a single piece
of glass, the one-piece doors on
New Holland T7 tractors open
wide to provide easy cab access.
The doors are easy to open from
inside the cab and, equally
important, can be closed from the
operator’s seat. Small details that
make a big difference.
8 sec 5 sec 8 sec 5 sec
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 7

SIDEWINDER™ II ARMREST & COMMANDGRIP™ HANDLE89
SIDEWINDER II.
DESIGNED BY FARMERS, FOR FARMERS
As modern tractors offer increasingly sophisticated features there is a risk that they
become more difficult to understand and operate. At New Holland we have made
everything simpler with the SideWinder™ II armrest, designed by farmers, for farmers.
All key controls are accessed from the armrest. Throttle, transmission and hydraulics.
Everything you need to control is quickly and easily accessible. More advanced
features can be quickly accessed. It does not take long to master a T7 tractor.
INTELLIVIEW™III TOUCHSCREEN.
All the information you need at a
glance. Fingertip adjustment of all key
settings and compatible with the New
Holland IntelliSteer™ guidance system.
• Headland turn sequencing, HTS.
Press to record, store and activate
automated headland turn.
• Finger tip control for
up to two remote valves.
• Rear linkage raise / lower.
• Optional IntelliSteer™
autoguidance, automated
steering engagement.
• Forward reverse
shuttle switch.
• Change transmission ratio
up and down.
• Engage Auto Field
or Auto Transport mode.
As awarded by The Chicago Athenaeum:
Museum of Architecture and Design.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 8

•Multifunction joystick. The joystick can be set
to operate the front linkage, loader or remote valves.
•Electronic SideWinder™ II
adjustment. Move the armrest
to the position that suits you.
•Full access to further advanced
controls under the padded armrest.
•Electronic remotes. Easy to reach paddles
provide fingertip hydraulic operation.
Flow and timing can be simply adjusted
through the IntelliView™ III touch screen.
•Rear linkage mouse. Lift heavy mounted
implements with absolute precision.
•Personalized positioning of the hydraulic
joystick and rear linkage mouse available
as a factory-fit option.
"SideWinder II and CommandGrip make
operating a T7 tractor so simple. Of equal
importance, I can show an operator new to the
tractor how everything operates quickly and
easily. SideWinder II is a real advance in tractor
design and a genuine aid in daily productivity."
EASY ACCESS TO ADVANCED FEATURES
Push the symbol. Activate the feature. The Integrated Control Panel, ICP,
makes it simple to access advanced operating features. No need to
scroll through menus to set up Terralock traction management, HTS
headland turn sequencing, Auto PTO or ESM Engine Speed Managment.
• Select paddle or joystick control
for remote valves 3 and 4.
• Throttle up to your desired engine
speed, select Engine Speed
Management, and the speed is fixed.
• Press the Headland Turn Sequencing
button to record and replay the
functions you use most frequently.
• Engage Terralock and it will
automatically manage four-wheel
drive and differential lock selection.
• Auto PTO will disengage and reengage
the PTO during a headland turn.
• Three point hitch levelling and top link
extension at the touch of a button.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 9

PLM10 11
NEW HOLLAND GUIDANCE SYSTEMS
TO MATCH YOUR FARMING NEEDS
FULLY INTEGRATED INTELLISTEER™ GUIDANCE
Guidance system choice will relate to the intended applications and the need to
integrate with existing systems. With T7 series tractors, all IntelliSteer options operate
via factory installed systems that facilitate installation and upgrades. This enables the
selected package to be modified and upgraded simply and more economically.
ALL WIRED UP READY FOR YOUR CHOSEN GUIDANCE SYSTEM
Series T7 tractors can be specified with a fully integrated New Holland designed and developed
IntelliSteer™ Automatic Steering System. Matching DGPS or RTK Technology to fully integrated
control, IntelliSteer helps ensure parallel pass to pass accuracy of up to 1 - 2cm*. IntelliSteer
is ideal for precision work in even the most demanding situations. It is designed to dramatically
improve operator performance and comfort. All this and more at the touch of a button.
* Using RTK correction signal.
INTELLIVIEW - VISIBLE INTELLIGENCE
The IntelliView™ Plus II and IntelliView™ III monitors can be used to set
up the optional New Holland auto guidance systems, and includes a
visual interface that can be employed when operating the IntelliSteer™
system. The IntelliView™ III monitor has a touchscreen display which
allows the programming of a variety of guidance paths, from straight
A-B runs to the most complex adaptive curves. You can also
personalize your settings simply and easily and even transfer
information from your tractor, direct to your Precision Farming software.
INTEGRATED CONTROL SYSTEMS
The New Holland IntelliSteer™ System uses
built in T3 terrain compensated correction
signals (roll, pitch, yaw) to keep the Navigation
Controller II informed of the tractor's
orientation. Also integrated into the hydraulic
system is a control valve which converts the
signals from the Navigation Controller II into
hydraulic movements of the steering system.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 10

LEVELS OF ACCURACY AND REPEATABILITY
New Holland offer four levels of accuracy. This enables you to select the right
IntelliSteer™ system to match your needs and budget. When using RTK correction
with IntelliSteer you can enjoy guaranteed year on year repeatability.
NH 262 RECEIVER
The NH 262 receiver is capable of
working with Autonomous,
OmniSTAR or RTK correction. For
RTK applications a slim profile
radio mounts underneath the
receiver.
RTK BASE STATION
An RTK base station can
be used to broadcasts a
correction signal to
achieve a pass to pass
accuracy of 1-2cm.
GOOD GUIDANCE SAVES MONEY
IntelliSteer helps improve overall
operating efficiency. In poor light
or during long working days,
precision driving is not compromised.
Improved efficiency saves money.
It is as simple as that.
INTELLISTEER.
ON AND OFF SIMPLICITY
The CommandGrip™ handle
incorporates a single button that is
used to activate the IntelliSteer system.
New Holland makes advanced
technology accessible.
3456
0 12
15 20 25 30
5678910
Autonomous OmniSTAR
®
XP OmniSTAR
®
HP RTK GPS
AUTONOMOUS
Total Cost Savings with
auto guidance
HP/XP RTK
IMPROVED PROFIT
30 cm 7 cm 5 cm 2.5 cm
0
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 11

ULTIMATE ENGINE BREATHABILITY
ENGINE12 13
EXCEPTIONAL FUEL ECONOMY:
The existing Tier 3 Nef engine series has
established itself as the benchmark for
fuel economy. The new Tier 4A Nef power
units in T7 tractors go one stage further,
with fuel use cut by up to 10% when
compared to existing T7000 models.
300
250
200
150
100
50
0
T7000
Tier 3
T7.170
T7.185
T7.200
T7.210
T7.220
T7.235
T7.250
T7.260
T7.270
EPM
Rated power
T7
Tier 4A
10% FUEL SAVING
ECOBLUE™ SCR:YOUR POWER GUARANTEE
ECOBlue™ SCR guarantees exceptional
performance and high productivity, independent of
fuel quality, sulphur levels and without the need for
costly diesel additives. With rated powers that span
125hp to 228hp, all T7 models generate extra power
of between 171hp to 269hp with EPM.
Exhaust gas containing NOx
Nitrogen and Water
Dosing Module
AdBlue/DEF tank
AdBlue/DEF additive
Supply module
SCR Catalyst
T7 tractors are powered by the very
latest generation of Nef engines.
Now with proven ECOBlue™ SCR
technology, to meet the stringent
Tier 4A emissions standards. This
uses AdBlue® to transform the
harmful nitrogen oxides contained
in the exhaust gas into harmless
water and nitrogen. This
aftertreament system is separate
from the main engine which means
only clean, fresh air is fed into the
engine. What does this mean?
Clean running power units with
improved performance and
enhanced fuel efficiency.
Fuel consumption (%)
Power output (hp)
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 12

POWERTRAIN TECHNOLOGIES
ENGINE SPEED MANAGEMENT
In applications where a constant PTO speed
is required, the operator can select Engine
Speed Management. This will ensure this
selected speed is accurately maintained
under changing loads. In many applications,
this will enable a fixed forward speed to be
maintained in difficult terrain.
ENGINE POWER MANAGEMENT
Engine Power Management is an renowned
New Holland tractor feature. In short, the
engine develops more power and torque
according to the load on the transmission,
hydraulics and PTO. On a T7.220 tractor,
EPM will deliver up to 51hp extra, but only
when it is needed, to maintain performance.
Horsepower
Engine speed
51hp
EPM according to the load on the
transmission, PTO and hydraulics.
POWERED BY FPT INDUSTRIAL
New Holland are not going it alone when it comes to Tier 4A technology,
they can draw on the experience of their engine development partner:
FPT Industrial.
Pioneers: Fiat invented Common Rail technology in the 1980s and
brought it to the masses in 1997 on the Alfa Romeo 156. They were
the very first to introduce it on agricultural machines. Pioneering. Always.
Cleaner: Fiat S.p.A. have the lowest overall CO2emissions of any
automotive manufacturer in Europe. Cleaner. Everywhere.
Proven: FPT Industrial have already produced over 150,000 SCR
engines during the last five years for the haulage industry. Reliability.
Confirmed.
After all, only those who invented it can reinvent it.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 13

RANGE COMMAND™ AND POWER COMMAND™ TRANSMISSION14 15
PUSH BUTTON SIMPLICITY.
YEARS OF PROVEN TECHNOLOGY
A
B
C
0 1010 2020 30 40 50
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
42
40,7
33,8
28,8
23,9
19,9
16,6
14,3
11,9
10,2
8,4
7
5,8
6,2
5,1
4,4
3,6
3
2,5
12,4
10,3
8,8
7,3
6,1
5,1
(1725rpm)
0 1010 2020 30 40 50
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
42
40,7
33,8
28,8
23,9
19,9
16,6
14,1
11,7
10
8,3
6,9
5,7
4,9
4
3,4
2,9
2,4
2,0
12,9
10,8
9,2
7,6
6,3
5,3
(1725rpm)
Range Command™ Transmission* Power Command™ transmission*
*T7.200 19x6 40kph ECO model shown with 650/65R42 tyres fitted
Range Command is a simple, rugged and well proven transmission.
It provides clutch-free gear changes within each working range.
It is the ideal choice for general farm applications. Power Command
is a full-powershift transmission: you select the gear speed
you want by simply pushing up or downshift buttons.
Only New Holland offers such a simple transmission choice.
kph kph
Reverse ForwardReverse Forward
SEMI-POWERSHIFT UP TO T7.210.
FULL POWERSHIFT
FROM T7.170 TO T7.260
Range Command and Power
Command are based around the
same gear offering. You can choose
between a standard 40kph 18x6
or 28x12 creep speed transmission
or opt for an extra high ratio 19x6
or 29x6 'direct drive' alternative.
This can deliver either 40kph at a
reduced engine speed for economy
or a high 50kph transport speed.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 14

EASY SHUTTLE
The clutchless forward reverse shuttle, operated via
the steering column or the CommandGrip™ handle
fitted to the optional SideWinder™ II armrest, can be
programmed to automatically manage transmission
shifts during a direction change. As a further option,
an electronic park brake can be specified. This is
operated via the shuttle lever, securing the tractor
when neutral is selected.
A SMOOTHER SHIFT IN FIELD AND TRANSPORT
IntelliShift™ gear change management ensures T7
tractors deliver a seamless powershift between each
and every ratio. Programmed to scrutinise transmission
load, speed and transmission oil temperature,
IntelliShift delivers smooth changes all day long.
WORK TOGETHER:
AUTOMATION, COMFORT AND PRODUCTIVITY
Easy to set up and brilliantly effective, Auto Transport and Auto
Field modes can really reduce the effort required to work a T7
tractor over a long working day. With Auto Transport, the tractor
will seamlessly shift ratios like an automatic car.
It will even sense if the tractor is being pushed by a loaded
trailer while descending a hill. If it does, it holds the current
gear to provide engine braking. Auto Field manages both the
engine speed and transmission to optimise performance and
economy. In PTO applications, where a constant engine speed
is the priority, the system will select the transmission ratio to
match the load on the engine. In draft applications, Auto Field
will allow the engine speed to drop to fully exploit the available
torque rise before selecting a lower ratio under load.
ENGINE POWER CURVE
AUTOMATED SHIFT POINT
GEAR CHANGE ENGINE SPEED
OPTIMUM ENGINE SPEED
HIGH TOLERANCE LOW TOLERANCE
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 15

AUTO COMMAND™ TRANSMISSION16 17
INNOVATIVE AUTO COMMAND™TRANSMISSION
OFFERS ADVANCED NEW HOLLAND FEATURES
Designed and built by New Holland, the T7 Auto Command is available from the T7.170 to the T7.270.
This new generation of CVT transmissions benefits from multi direct drive points offering 100% mechanical
efficiency, plus advanced double clutch control. It is the smoothest and most productive CVT available.
A SPEED FOR EVERY NEED
Auto Command allows the operator to set a target
speed of between 20m/hr right through to 50km/hr.
No steps. No range changes. Just seamless speed
to match your every need.
• Force based movement enables the operator to change
speed and direction. On the ICP there is a switch to alter
the response of the speed change.
kph
0 5 10 15 20 25 30 35 40 45 50
Speed diagram
forward
1
23
MAKING THE MOST OF AVAILABLE TORQUE
New Holland has developed its Auto Command™
transmissions so they can exploit the low running
speed, high torque New Holland engines. With 50kph
ECO, the engine can run at a fuel efficient 1550 rpm.
Engine speed at 50 kph (rpm)
• 4 DRIVING MODES TO SUIT YOUR DRIVING STYLE
- Auto Mode. Select the desired target
speed and Auto Command will match
the engine and transmission to maintain it.
- Cruise Mode. Once a desired operating
speed has been achieved, Cruise Mode
allows the operator to set the transmission to
maintain the speed for economy and productivity.
- Manual Mode. Allows the operator to set
the required engine and forward speed.
- PTO mode. As soon as the PTO is engaged,
Auto Command will operate to guarantee
a constant engine speed.
• Target speed adjustment – set a target speed to match
your exact needs. Perfect when moving between fields
or when crop yields have altered.
• Target speed selection – allows you
to change between three target speeds
1500
1400
1300
1600
1550
1650
1700
1700
New T7 Competitor A Competitor B
* only T7.220 - T.270 models
UP TO 10% ENGINE
SPEED REDUCTION
FOR GREATER FUEL
ECONOMY*
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 16

ABOUT AUTO COMMAND TRANSMISSION
"Auto Command makes operating at higher
transport speeds considerably safer. The hill
hold function is excellent, making it less stressful
when pulling onto a road from a steep side road
with a heavily laden trailer safer. Excellent fuel
savings too.”
ACTIVE STOPSTART
A key safety feature of Auto Command is Active StopStart.
When the tractor is brought to a standstill, the transmission
prevents the tractor moving backwards or forwards.
Even with a heavy load. When the transmission takes
up drive there is no risk of roll back on steep inclines.
For safe parking, an electronic brake is easily engaged
via the shuttle lever.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 17

FASTER TURNS. BETTER TRACTION.
GREATER PERFORMANCE
More
Productivity
Axle strength and weight increase with engine power. This ensures a good power
to weight ratio is offered by all models, not just those with highest rated output.
T7.170 to T7.210 models have a gross vehicle weight of up to 11,000kg at 50kph,
this increases to 13,000 kg on the T7.220 and above.
LESS TIME TURNING BOOSTS YOUR OUTPUT
New Holland leads the field in reducing the time it takes to turn on the headland.
Offering a tight 65 degree turn angle, the SuperSteer™ front axle option delivers
rowcrop agility, beating any tractor in the T7's category. The Fast Steer™ system,
compatible with all axle types, means full lock to lock turns are made even more
quickly and with minimal effort. You simply hold down the FastSteer steering rim
and the steering wheel is transformed into a proportional “joystick”.
AXLES & TRACTION18 19
SUPERSTEER +
FAST STEER =
FASTER TURNS
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 18

ADVANCED TRACTION MANAGEMENT
The New Holland Terralock™ system is well established.
The operator simply selects the traction package needed
for a specific application. Terralock will then manage drive
to the front axle and engage and release the differential
locks automatically. During a headland turn or moving from
work to transport, Terralock will ensure the differentials and
four wheel drive are unlocked without operator intervention.
BRAKE OPTIONS
All models are available with front axle brakes
and a choice of hydraulic or pneumatic trailer
braking systems. On SideWinder™ II models,
an engine exhaust brake is optional. This can
be used to help hold the tractor's speed on a
gradual gradient.
vibration at seat base
TERRAGLIDE™FRONT AXLE AND COMFORT RIDE™CAB SUSPENSION.
YOUR COMFORT PARTNERS.
Automatic two stage Comfort Ride™ cab suspension has established itself as a key advance
in operator comfort. Designed to complement the cushioned ride offered by the standard
air suspension seat, Comfort Ride helps reduce fatigue. Terraglide™ front axle suspension
is recommended in operations that include fast top work and extended transport duties.
Terraglide, with integral hub braking, is standard on tractors specified with a 50kph transmission.
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 19

MAKING IT EASIER TO WORK
WITH FRONT MOUNTED IMPLEMENTS
New Holland T7 tractors are designed to
incorporate a fully integrated, factory fitted
front linkage and PTO. All controls are fully
integrated into the armrest and can be
programmed to operate with HTS. The linkage
arms fold up when not in use or can be used
to carry the full standard weight pack.
PTO AND FRONT / REAR LINKAGE20 21
FEATURES TO BOOST YOUR PRODUCTIVITY
NH_T7_Brochure.qxd:NH_T7_Brochure 23/5/11 5:26 PM Page 20
