New Rock Technologies MX series User manual

MX Series Voice Gateway User Manual
New Rock Technologies, Inc.
MX Series Voice Gateway
User Manual
HX4E
MX8A
MX60
MX60E
MX120G
Website: http://www.newrocktech.com
Email: [e-mail]
Document Version: 201706

User Manual MX Series Voice Gateway
Amendment Records
Document Rev. 02 (March 2017)
Added MX60E, and removed MX120. This manual is applicable to New Rock's MX series Voice
Gateway V351.
Document Rev. 01 (June 2016)
This manual is applicable to New Rock’s MX series Voice Gateway V344.
Copyright © 2017 New Rock Technologies, Inc. All Rights Reserved.
All or part of this document may not be excerpted, reproduced and transmitted in any form
or by any means without prior written permission from the company.

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 3
Contents
Amendment Records ............................................................................................................................... 2
Contents....................................................................................................................................................... 3
Figures......................................................................................................................................................... 7
Tables........................................................................................................................................................ 10
1 Overview .............................................................................................................................................. 14
1.1 Product Introduction...............................................................................................................................................................14
1.2 Functions and Features ..........................................................................................................................................................15
1.3 Equipment Structure ...............................................................................................................................................................16
1.3.1 HX4E.................................................................................................................................................................................16
1.3.2 MX8A ...............................................................................................................................................................................18
1.3.3 MX60................................................................................................................................................................................21
1.3.4 MX60E .............................................................................................................................................................................24
1.3.5 MX120G ..........................................................................................................................................................................27
1.4 Web Management Page ........................................................................................................................................................32
1.4.1 Layout..............................................................................................................................................................................32
1.4.2 Buttons Used on Gateway Management Interface .........................................................................................32
2 Parameters Setting ............................................................................................................................. 33
2.1 Login .............................................................................................................................................................................................33
2.1.1 Obtaining Gateway IP Address...............................................................................................................................33
2.1.2 Logging On to Web GUI...........................................................................................................................................33
2.1.3 Gateway Administrator and Operator Rights (Web GUI)..............................................................................34
2.1.4 Accessing Through SSH ............................................................................................................................................35
2.1.5 SSH user Permissions.................................................................................................................................................36
2.2 Basic Configuration..................................................................................................................................................................36
2.2.1 Status...............................................................................................................................................................................36
2.2.2 Network ..........................................................................................................................................................................36
2.2.3 VLAN................................................................................................................................................................................38

User Manual MX Series Voice Gateway
2.2.4 System.............................................................................................................................................................................40
2.2.5 SIP .....................................................................................................................................................................................42
2.2.6 High Availability...........................................................................................................................................................44
2.2.7 TLS&SRTP.......................................................................................................................................................................45
2.2.8 MGCP...............................................................................................................................................................................46
2.2.9 FoIP...................................................................................................................................................................................48
2.2.10 Alarm.............................................................................................................................................................................50
2.3 Line ................................................................................................................................................................................................52
2.3.1 Phone Number.............................................................................................................................................................52
2.3.2 Subscriber Line Features...........................................................................................................................................52
2.3.3 Subscriber Line Batch (Unavailable on the HX4E) ...........................................................................................55
2.3.4 Subscriber Line Characteristics...............................................................................................................................56
2.4 Trunk .............................................................................................................................................................................................59
2.4.1 Phone Number.............................................................................................................................................................59
2.4.2 Trunk Features..............................................................................................................................................................60
2.4.3 Trunk Batch (Unavailable on the HX4E) ..............................................................................................................61
2.4.4 Trunk Characteristics..................................................................................................................................................62
2.5 Routing.........................................................................................................................................................................................64
2.5.1 Digit Map .......................................................................................................................................................................64
2.5.2 Routing Table ...............................................................................................................................................................66
2.5.3 Examples of Routing Rules ......................................................................................................................................70
2.6 Advanced Configuration........................................................................................................................................................71
2.6.1 System.............................................................................................................................................................................71
2.6.2 Auto Provisioning........................................................................................................................................................73
2.6.3 Management System Type ......................................................................................................................................74
2.6.4 Certificate (Available on the HX4E/MX8A).........................................................................................................75
2.6.5 Media Stream ...............................................................................................................................................................76
2.6.6 SIP Configuration ........................................................................................................................................................78
2.6.7 RADIUS (Unavailable on the HX4E).......................................................................................................................81
2.6.8 Greeting..........................................................................................................................................................................82
2.6.9 Call Progress Tone Plan.............................................................................................................................................83
2.6.10 Feature Access Codes..............................................................................................................................................84
2.6.11 Clock Service...............................................................................................................................................................87
2.7 Security.........................................................................................................................................................................................89
2.7.1 Access Security.............................................................................................................................................................89
2.7.2 Access list.......................................................................................................................................................................91
2.7.3 Brute Force Login Prevention .................................................................................................................................93

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 5
2.7.4 ACL-based Traffic Filtering ............................................................................................................................................94
2.7.5 Packet Rate Limiting Based Dynamic Blacklisting ...........................................................................................95
2.7.6 IP Table ...........................................................................................................................................................................98
2.7.7 Voice Security ...............................................................................................................................................................98
2.7.8 Encryption......................................................................................................................................................................99
2.7.9 VPN (Available on the HX4E/MX8A) ................................................................................................................. 100
2.8 Status ......................................................................................................................................................................................... 101
2.8.1 Call Status ................................................................................................................................................................... 101
2.8.2 Call History on FXS................................................................................................................................................... 102
2.8.3 Call History on FXO.................................................................................................................................................. 102
2.8.4 SIP Message Count.................................................................................................................................................. 103
2.9 Logs ............................................................................................................................................................................................ 103
2.9.1 System Status ............................................................................................................................................................ 103
2.9.2 Call Message .............................................................................................................................................................. 104
2.9.3 System Startup .......................................................................................................................................................... 105
2.9.4 Manage Log ............................................................................................................................................................... 105
2.10 Tools ........................................................................................................................................................................................ 107
2.10.1 Configuration Management .............................................................................................................................. 107
2.10.2 Upgrade .................................................................................................................................................................... 108
2.10.3 Restore Factory Settings ..................................................................................................................................... 109
2.10.4 Capture Recordings on the Port....................................................................................................................... 110
2.10.5 IP Capture................................................................................................................................................................. 110
2.10.6 Network Diagnosis (HX4E/MX8A).................................................................................................................... 110
2.11 Product Information........................................................................................................................................................... 111
2.12 Reboot .................................................................................................................................................................................... 111
2.13 Logout..................................................................................................................................................................................... 111
3 Appendix: VLAN Configuration ...................................................................................................... 112
3.1 Automatic Discovery ............................................................................................................................................................ 112
3.1.1 LLDP .............................................................................................................................................................................. 113
3.1.2 DHCP............................................................................................................................................................................. 116
3.2 Manual Configuration.......................................................................................................................................................... 118
3.2.1 Single VLAN................................................................................................................................................................ 118
3.2.2 Multi-Service VLAN ................................................................................................................................................. 119

User Manual MX Series Voice Gateway
4 Making an OpenVPN Client Certification (HX4E/MX8A)............................................................. 125
5 Appendix: High availability configuration.....................................................................................128
6 Appendix: Auto provisioning configuration .................................................................................129

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 7
Figures
Figure 1-0 HX4E Front Panel .......................................................................................................................................................17
Figure 1-1 HX4E Back Panel.........................................................................................................................................................17
Figure 1-2 MX8A Front Panel......................................................................................................................................................19
Figure 1-3 MX8A Back Panel .......................................................................................................................................................19
Figure 1-4 RJ45 to RS232 Serial Cable.....................................................................................................................................20
Figure 1-5 USB to RS232 Converter Cable .............................................................................................................................20
Figure 1-6 MX60 Front Panel ......................................................................................................................................................22
Figure 1-7 Schematic Diagram of MX60 Subscriber Line Connection .........................................................................23
Figure 1-8 MX60 Back Panel-AC ................................................................................................................................................23
Figure 1-9 MX60 Back Panel-DC................................................................................................................................................23
Figure 1-10 MX60E Front Panel..................................................................................................................................................25
Figure 1-11 Schematic Diagram of MX60E Subscriber Line Connection.....................................................................26
Figure 1-12 MX60E Back Panel-AC ...........................................................................................................................................26
Figure 1-13 MX120G Front Panel ..............................................................................................................................................28
Figure 1-14 Schematic Diagram of MX120G Subscriber Line Connection .................................................................29
Figure 1-15 MX120G Back Panel-AC ........................................................................................................................................30
Figure 1-16 MX120G Back Panel-DC........................................................................................................................................30
Figure 1-17 Web GUI......................................................................................................................................................................32
Figure 2-18 Login Interface for MX8A Gateway Configuration ......................................................................................34
Figure 2-19 Status Interface ........................................................................................................................................................36
Figure 2-20 Network Configuration Interface (HX4E/MX8A) ..........................................................................................37
Figure 2-21 Network Configuration Interface (MX60/MX60E/MX120G) ....................................................................37
Figure 2-22 VLAN Configuration Interface.............................................................................................................................39
Figure 2-23 System Configuration Interface..........................................................................................................................41
Figure 2-24 SIP Configuration Interface..................................................................................................................................43
Figure 2-25 High Availability Configuration Interface .......................................................................................................44
Figure 2-26 TLS&SRTP Configuration Interface ...................................................................................................................45
Figure 2-27 MGCP Configuration Interface ...........................................................................................................................46
Figure 2-28 Fax Configuration Interface (HX4E/MX8A).....................................................................................................48
Figure 2-29 MX60/MX60E/MX120G Fax Configuration Interface..................................................................................49
Figure 2-30 Alarm Icon..................................................................................................................................................................51
Figure 2-31 Alarms Interface.......................................................................................................................................................51
Figure 2-32 Configuration Interface for Batch Configuration (Phone Number).............................................................52
Figure 2-33 Subscriber Line Configuration Interface..........................................................................................................53

User Manual MX Series Voice Gateway
Figure 2-34 Feature Batch Configuration Interface.............................................................................................................56
Figure 2-35 Subscriber Line Characteristics Configuration Interface ...........................................................................57
Figure 2-36 Phone Number Configuration Interface..........................................................................................................59
Figure 2-37 Trunk Line Features Configuration Interface.................................................................................................60
Figure 2-38 Trunk Batch Configuration Interface ................................................................................................................62
Figure 2-39 Trunk Characteristics Configuration Interface ..............................................................................................63
Figure 2-40 Configuration Interface for Digit Map .............................................................................................................65
Figure 2-41 Routing Table Configuration Interface ............................................................................................................67
Figure 2-42 Interface of system advanced configuration.................................................................................................72
Figure 2-43 Interface of Auto Provisioning Configuration...............................................................................................73
Figure 2-44 SNMP Configuration Interface............................................................................................................................74
Figure 2-45 TR069 Configuration Interface............................................................................................................................75
Figure 2-46 Certificate Configuration Interface....................................................................................................................76
Figure 2-47 HX4E/MX8A Media Stream Configuration Interface ..................................................................................76
Figure 2-48 MX60/MX60E/MX120G Media Stream Configuration Interface.............................................................77
Figure 2-49 SIP Related Configuration Interface .................................................................................................................78
Figure 2-50 RADIUS Configuration Interface ........................................................................................................................81
Figure 2-51 Greeting Interface ...................................................................................................................................................82
Figure 2-52 Call Progress Tone Configuration Interface ...................................................................................................83
Figure 2-53 Feature Codes Configuration Interface ...........................................................................................................85
Figure 2-54 Clock Service Interface ..........................................................................................................................................87
Figure 2-55 Access Configuration Interface...........................................................................................................................90
Figure 2-56 Access list configuration Interface ....................................................................................................................91
Figure 2-57 Brute Force Login Prevention (Login Retry Lockout) Configuration Interface ..................................93
Figure 2-58 Brute Force Login Prevention (Lockout IP Addresses) Interface ............................................................94
Figure 2-59 Static Defense Configuration Interface ...........................................................................................................94
Figure 2-60 Dynamic Defense Configuration Interface .....................................................................................................96
Figure 2-61 Dynamic Defense (Blocked IP Addresses) Interface....................................................................................97
Figure 2-62 IP Table Configuration Interface ........................................................................................................................98
Figure 2-63 Voice Security Configuration Interface............................................................................................................99
Figure 2-64 Encryption Configuration Interface...................................................................................................................99
Figure 2-65 VPN Configuration Interface ............................................................................................................................ 101
Figure 2-66 Call Status Interface............................................................................................................................................. 102
Figure 2-67 Interface of Call History on FXS....................................................................................................................... 102
Figure 2-68 Interface of Call on FXO ..................................................................................................................................... 102
Figure 2-69 SIP Message Count Interface ........................................................................................................................... 103

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 9
Figure 2-70 System Status Interface...................................................................................................................................... 104
Figure 2-71 Call Message Interface........................................................................................................................................ 105
Figure 2-72 Interface of System Startup .............................................................................................................................. 105
Figure 2-73 Manage Log Interface......................................................................................................................................... 106
Figure 2-74 Log Saving Interface............................................................................................................................................ 107
Figure 2-75 Path Saving Interface .......................................................................................................................................... 107
Figure 2-76 Configuration Management Interface .......................................................................................................... 108
Figure 2-77 Upgrade Interface ................................................................................................................................................ 108
Figure 2-78 Upgrading interface by .img file ..................................................................................................................... 108
Figure 2-79 Upgrade Interface ................................................................................................................................................ 109
Figure 2-80 Restore Factory Settings Interface (HX4E/MX8A)..................................................................................... 109
Figure 2-81 Restore Factory Settings Interface (MX60/MX60E/MX120G) ............................................................... 109
Figure 2-82 Interface for Capturing Port Recordings...................................................................................................... 110
Figure 2-83 Ethereal Capture Interface................................................................................................................................. 110
Figure 2-84 Automatic Diagnosis Interface ........................................................................................................................ 111
Figure 2-85 Ping Diagnosis Interface .................................................................................................................................... 111
Figure 3-86 Scenario Diagram ................................................................................................................................................. 114
Figure 3-87 Procedure of Handling LLDP Message Carrying a VLAN ID ................................................................. 115
Figure 3-88 Procedure of Handling the LLDP Message with no VLAN ID ............................................................... 115
Figure 3-89 LLDP Message........................................................................................................................................................ 116
Figure 3-90 Adding a VLAN ID to the Message to Be Sent .......................................................................................... 116
Figure 3-91 Configuring the Single VLAN ........................................................................................................................... 119
Figure 3-92 A Data Packet Carrying a Corresponding VLAN Tag in the Single VLAN Mode ........................... 119
Figure 3-93 Configuring Voice VLAN to Work in Mode 1............................................................................................. 120
Figure 3-94 Configuring Voice VLAN to Work in Mode 2............................................................................................. 121
Figure 3-95 Configuring Management VLAN .................................................................................................................... 122
Figure 3-96 Network Environment......................................................................................................................................... 122
Figure 3-97 Configuring Multi-Service VLAN..................................................................................................................... 123
Figure 3-98 IP Addresses of the Device in Multi-Service VLAN................................................................................... 123
Figure 3-99 SIP Data Packet Carrying VLAN Tag of the Voice VLAN in the Multi-Service VLAN Mode....... 124
Figure 3-100 RTP Data Packet Carrying VLAN Tag of the Voice VLAN in the Multi-Service VLAN Mode... 124
Figure 3-101 RTP Data Packet Carrying VLAN Tag of the Management VLAN in the Multi-Service VLAN Mode
.................................................................................................................................................................................................... 124

User Manual MX Series Voice Gateway
Tables
Table 1-1 MX Series Gateway Hardware Specifications ....................................................................................................14
Table 1-2 Configuration Combination of HX4E....................................................................................................................16
Table 1-3 Description of HX4E Front Panel............................................................................................................................17
Table 1-4 Description of HX4E Back Panel .............................................................................................................................17
Table 1-5 Indicator Status of HX4E ...........................................................................................................................................18
Table 1-6 Configuration Combination of MX8A ..................................................................................................................18
Table 1-7 Voice Interface Cards Supported by the MX8A................................................................................................19
Table 1-8 Description of MX8A Front Panel ..........................................................................................................................19
Table 1-9 Description of MX8A Back Panel ...........................................................................................................................20
Table 1-10 Indicator Status of MX8A .......................................................................................................................................20
Table 1-11 Configuration Combination of MX60 ................................................................................................................21
Table 1-12 Description of MX60 Front Panel ........................................................................................................................22
Table 1-13 Pin Specifications for MX60 RJ45 Socket Port................................................................................................22
Table 1-14 Description of MX60 Back Panel..........................................................................................................................23
Table 1-15 Meanings of MX60 Indicators ..............................................................................................................................24
Table 1-16 Configuration Combination of MX60E..............................................................................................................24
Table 1-17 Description of MX60E Front Panel......................................................................................................................25
Table 1-18 Pin Specifications for MX60E RJ45 Socket Port..............................................................................................25
Table 1-19 Description of MX60E Back Panel .......................................................................................................................26
Table 1-20 Meanings of MX60E Indicators ............................................................................................................................27
Table 1-21 MX60E System Operation Status.........................................................................................................................27
Table 1-22 MX120G Interface Card...........................................................................................................................................27
Table 1-23 Configuration Combination of MX120G...........................................................................................................28
Table 1-24 Description of MX120G Front Panel...................................................................................................................28
Table 1-25 Pin Specifications for MX120G RJ45 Socket Port ..........................................................................................28
Table 1-26 Corresponding Relation Between MX120G RJ45 Socket and Line Number ........................................29
Table 1-27 MX120G Back Panel .................................................................................................................................................30
Table 1-28 Meanings of MX120G Indicators.........................................................................................................................31
Table 1-29 MX120GSystem Operation State.........................................................................................................................31
Table 1-30 Web GUI Layout Description.................................................................................................................................32
Table 2-1 Default IP Address of Gateway ...............................................................................................................................33
Table 2-2 Default Passwords for logging to Web GUI.......................................................................................................34
Table 2-3 Network Configuration Parameters ......................................................................................................................37
Table 2-4 VLAN Configuration Parameters............................................................................................................................39

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 11
Table 2-5 System Configuration Parameters.........................................................................................................................41
Table 2-6 Codec Methods Supported by Gateways ...........................................................................................................42
Table 2-7 SIP Configuration Parameters.................................................................................................................................43
Table 2-8 Parameters .....................................................................................................................................................................44
Table 2-9 TLS&SRTP Configuration Parameter ....................................................................................................................46
Table 2-10 MGCP Configuration Parameters ........................................................................................................................47
Table 2-11 Fax Configuration Parameters..............................................................................................................................49
Table 2-12 Alarm Type ..................................................................................................................................................................50
Table 2-13 Configuration Parameters of Batch Configuration (Phone Number)...........................................................52
Table 2-14 Subscriber Line Configuration Parameters ......................................................................................................53
Table 2-15 Subscriber Line Characteristics Configuration Parameter ..........................................................................57
Table 2-16 Configuration Parameters of FXO Phone Number .......................................................................................59
Table 2-17 Configuration Parameters of Trunk Features..................................................................................................60
Table 2-18 Trunk Characteristics Configuration Parameter .............................................................................................63
Table 2-19 Description of Digit Map........................................................................................................................................65
Table 2-20 Routing Table Format..............................................................................................................................................68
Table 2-21 Number Transformations.......................................................................................................................................68
Table 2-22 Routing Destination .................................................................................................................................................69
Table 2-23 NAT Configuration Parameters............................................................................................................................72
Table 2-24 Auto Provisioning Configuration Parameters .................................................................................................73
Table 2-25 SNMP Configuration Parameters ........................................................................................................................74
Table 2-26 TR069 Configuration Parameters ........................................................................................................................75
Table 2-27 Media Stream Configuration Parameter...........................................................................................................77
Table 2-28 SIP Related Configuration Parameter ................................................................................................................79
Table 2-29 RADIUS Configuration Parameter .......................................................................................................................82
Table 2-30 Greeting Configuration Parameters ...................................................................................................................83
Table 2-31 Call Progress Tone Configuration Parameters................................................................................................83
Table 2-32 Feature Codes Configuration Parameter..........................................................................................................85
Table 2-33 Clock Service Parameters .......................................................................................................................................88
Table 2-34 Access security setting parameters ....................................................................................................................90
Table 2-35 Login Retry Lockout Parameters..........................................................................................................................93
Table 2-36 Brute Force Login Prevention (Lockout IP Addresses) Information........................................................94
Table 2-37 Static Defense Configuration Parameters ........................................................................................................94
Table 2-38 Dynamic Defense (Rule Configuration) Parameters .....................................................................................96
Table 2-39 Dynamic Defense (Blocked IP Addresses) Information ...............................................................................97
Table 2-40 Subsequent choices for moving the Blocked IP Addresses to static defense.....................................97

User Manual MX Series Voice Gateway
Table 2-41 Encryption Configuration Parameters ...............................................................................................................99
Table 2-42 VPN Configuration Parameters......................................................................................................................... 101
Table 2-43 System Status Parameters................................................................................................................................... 104
Table 2-44 Log Management Configuration Parameters .............................................................................................. 106

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 13

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 14
1 Overview
1.1 Product Introduction
MX Series intelligent VoIP Gateways (MX Gateways) are designed to bridge the traditional telecom
terminal device into IP networks through SIP or MGCP protocols. The main applications include:
For carriers and value-added service providers to provide telephone, fax and voice-band data services
to subscribers using IP access methods such as FTTB, HFC, and ADSL;
To bridge the traditional telecom terminal equipment, such as PBXs, to the VoIP core networks of
carriers;
To connect with an enterprise PBX to provide IP-based voice private network solutions for
institutions, enterprises and schools;
To be used as remote access equipment for IP-PBXs in call center deployment
The MX family has four sub-series: HX4E, MX8A, MX60, MX60E and MX120G, which mainly differ in
port capacities.
Table 1-1 MX Series Gateway Hardware Specifications
Model
Voic
e
ports
Chassis
Installation
CPU
RAM
Flash
Power
HX4E
2 - 4
Plastic Casing
Desktop
MIPS34Kc,
700MHz, SOC
64MB
16MB
12 VDC
MX8A
4 - 8
Metal
Desktop or rack
MIPS34Kc,
700MHz, SOC
128MB
16MB
12 VDC
MX60
16 - 48
19-inch wide
and 1U High
Rack
AT91SAM9G20B
64MB
16MB
100-240
VAC, -48
VDC
(Optional)
MX60E
16 - 48
19-inch wide
and 1U High
Rack
TI A8, 1GHz
128MB
32MB
100-240
VAC, -36 to
-72 VDC
(optional)
Dual power
(optional)
MX120G
48- 96
19-inch wide
and 2U High
Rack
TI A8, 1GHz
256MB
32MB
100-240
VAC, -36 to
-72 VDC
(optional)
Dual power
(optional)

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 15
Hardware for MX series gateways uses high-performance CPUs, ensuring that each product of the series
can achieve full-capacity concurrent calls with high speech quality.
MX gateways software adopts the stable and reliable embedded Linux operating system (OS),
implementing scores of business phone functions, including: call forwarding, call transfer, call hold,
teleconference, caller identification, Do Not Disturb, ring-back tone, hunt group simultaneous ring,
distinctive ring, one phone with two numbers, and fax. In addition, MX gateways are featured with FXO
port second stage dialing with voice prompt, routing table with a maximum of 500 entries, phone digit
manipulation, and PSTN failover upon power-off or network disconnection.
MX gateways support local and remote management operations through Web GUI or SSH, SNMPv2-
based and TR069/TR104/TR106-based centralized management schemes, and auto provisioning.
Maintenance tasks such as modifying configuration, upgrading software, collecting statistical data,
downloading logs, and fault alarms can be performed.
Note: PSTN failover upon power-off or network disconnection is supported by devices with both the FXS
port and the FXO port.
1.2 Functions and Features
Connect analog telephone, PBX, facsimile machine and POS machine to the IP core network, or
PSTN
Work with a service platform to provide various telephone supplementary services
Support protocols: SIP, MGCP
Support STUN. Detecting changes of the reflexive address of the device via STUN, and then
triggering re-registration to the SIP registrar server.
Flexible configuration of subscriber/trunk interfaces
Support G.711, G.729
Support echo cancellation
Up to 500 routing rules can be stored in gateways
Intercom
Support concurrent calls under full load
Support call progress tones for various countries and regions
Support Line second stage dialing or voice prompt
Support PSTN failover on power or network failure
Security strategy: IP filter, encryption
Support PSTN failover through FXO ports
Support G.711 fax pass-through and T.38 fax relay
Support polarity inverse detection and busy tone detection
3-way calling
Compatible with unified communication solutions, such as Call Manager, Lync, Asterisk and Free
SWITCH
Support SNMPv2 and TR069/TR104/TR106

User Manual MX Series Voice Gateway
16 New Rock Technologies, Inc.
Support Web GUI-based management , SSH, automatic software upgrades, and configuration
downloading
Support high availability, implementing a cloud of SIP servers working in primary-standby or load
balancing mode
Support auto provisioning
Support security settings such as accessing whitelists
Message waiting indications (MWI) with high voltage, FSK, or reversed polarity
Support accessing the Web GUI by using HTTPS
Support Ping blocking
Support optional voice interface cards (only supported by the MX8A/MX120G)
Support the VPN client (only available with the HX4E/MX8A)
Support VLAN
Support New Rock Cloud, allowing New Rock devices located behind NAT or firewall to be easily
accessed.
1.3 Equipment Structure
1.3.1 HX4E
The HX4E adopts a compact plastic structural design and can be placed on a desk.
It provides either two or four FXS/FXO ports.
The HX4E supports the following models.
Table 1-2 Configuration Combination of HX4E
Models
Number of FXS Ports
Number of FXO Ports
HX402E
2
0
HX420E
0
2
HX422E
2
2
HX440E
0
4
HX404E
4
0

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 17
Figure 1-0 HX4E Front Panel
Table 1-3 Description of HX4E Front Panel
Item
Description
Power Indicator
WAN
WAN interface indicator
PC
PC interface indicator
FXO/FXS
FXS /FXO port indicator
Figure 1-1 HX4E Back Panel
Table 1-4 Description of HX4E Back Panel
Item
Description
PWR
Power interface, 12 VDC input
PC and
WAN
The PC port is used to connect a computer.
The WAN port is used to connect the uplink network.
Both are 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which, by default, is obtained
through DHCP. If no IP address is obtained, 192.168.2.218 is used by default, and you can change it on
Basic > Network page.
FXO/FXS
FXS port or FXO port

User Manual MX Series Voice Gateway
18 New Rock Technologies, Inc.
Table 1-5 Indicator Status of HX4E
Indicator
Status
Description
PWR(green)
Blinking green
The device is starting.
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address failed to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing failed.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
Blinking green
Calling.
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Blinking green
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Blinking green
A service flow is being transmitted.
Off
A link is not connected.
FXS/FXO
(green)
Steady green
Off-hook or call established
Blinking green
Ringing on incoming call
Off
The port is in idle status
1.3.2 MX8A
The MX8A adopts a compact metal structural design. It can be placed on a desk or installed in a standard
communications cabinet and provides eight analog ports. MX8A supports the following types of
configuration.
Table 1-6 Configuration Combination of MX8A
Models
Number of FXS Ports
Number of FXO Ports
MX8A-4S/4
4
4
MX8A-8S
8
0
MX8A-8FXO
0
8

MX Series Voice Gateway User Manual
New Rock Technologies, Inc. 19
Table 1-7 Voice Interface Cards Supported by the MX8A
Voice Interface Card Types
Number of FXS Ports
Number of FXO Ports
401A-4FXS
4
0
401A-4FXO
0
4
401A-2FXS/2FXO
2
2
Figure 1-2 MX8A Front Panel
Table 1-8 Description of MX8A Front Panel
Item
Description
PWR
Power indicator
STU
Status indicator
WAN
WAN interface indicator
PC
PC interface indicator
VOICE
FXS/FXO port indicator
Figure 1-3 MX8A Back Panel

User Manual MX Series Voice Gateway
20 New Rock Technologies, Inc.
Table 1-9 Description of MX8A Back Panel
Item
Description
CON
The console port is used for local management and testing. PCs can be connected to device by linking
the RS232 port to CON port.
Connecting cables need to be produced or purchased.
If the connection is established between the device and the mobile PC with no RS232 ports, please use
the cable together with a USB to an RS232 converter cable.
Cables are shown below in Figure 1-4 and Figure 1-5.
PC/WAN
The PC port is used to connect a computer.
The WAN port is used to connect the uplink network.
Both are 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which, by default, is obtained
through DHCP. If no IP address is obtained, 192.168.2.218 is used by default, and you can change it on
Basic > Network page.
FXO/FXS
FXS port or FXO port
Figure 1-4 RJ45 to RS232 Serial Cable
Figure 1-5 USB to RS232 Converter Cable
Table 1-10 Indicator Status of MX8A
Indicator
Status
Description
PWR (green)
Blinking green
The device is starting.
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred.
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address fails to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing fails.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
