X-103 6211E/6413E/6425E Quick Reference Guide Ver A.
1. SPK: Speaker Out Connector
 withAudioAmplier
Pin Denition
1 L+
2 L-
3 R+
4 R-
7. USB3_01P: USB 3.2 Connector
Pin Denition Pin Denition
1 +5V 2 USB2_3N
3 USB2_3P 4 GND
5 USB3_RX3N 6 USB3_RX3P
7 GND 8 USB3_TX3N
9 USB3_TX3P 10 +5V
11 USB2_4N 12 USB2_4P
13 GND 14 USB3_RX4N
15 USB3_RX4P 16 GND
17 USB3_TX4N 18 USB3_TX4P
MH1 CGND MH2 CGND
MH3 CGND MH4 CGND
5. HDMI1: HDMI Connector
Pin Denition Pin Denition
1 HDMI1_TX2P 2 GND
3 HDMI1_TX2N 4 HDMI1_TX1P
5 GND 6 HDMI1_TX1N
7 HDMI1_TX0P 8 GND
9 HDMI1_TX0N 10 HDMI1_CLK_P
11 GND 12 HDMI1_CLK_N
13 NC 14 NC
15 HDMI1_SCL 16 HDMI1_SDA
17 GND 18 HDMI1_P5V
19 HDMI1_HPD MH1 CGND
MH2 CGND MH3 CGND
MH4 CGND
6. LAN1, LAN2, LAN3: LAN Connector
Pin Denition Pin Denition
1 LAN1_MDI0P 2 LAN1_MDI0N
3 LAN1_MDI1P 4 LAN1_MDI1N
5 TCT 6 TCTG
7 LAN1_MDI2P 8 LAN1_MDI2N
9 LAN1_MDI3P 10 LAN1_MDI3N
11
LAN1_LED_ACT_POWER 12 LAN1_LED_ACT#
13
LAN1_LED_LINK2500# 14 LAN1_LED_LINK100#
MH1 CGND MH2 CGND
NH1 NC NH2 NC
4. DCIN: DC Power Input
Pin Denition
1 GND
2 GND
3 +VIN
4 +VIN
3. PWR_BTN: System Power Button
Pin Denition
1 GND
2 PWRBTN#
2. USB2_23P: USB 2.0 Connector
Pin Denition
1 +5V
2 USB2_1N
3 USB2_1P
4 GND
5 +5V
6 USB2_2N
7 USB2_2P
8 GND
MH1 CGND
MH2 CGND
MH3 CGND
MH4 CGND
1
5
6
6
6
7
4
2
3

X-103 6211E/6413E/6425E Quick Reference Guide Ver A.
10. BAT: Coin-cell
Battery Connector
Pin Denition
1 GND
2BAT
14. RESET_BTN: Reset Button
Pin Denition
1 GND
2 RESET#
11. MIC_LOUT: MIC-in LINE-out
Connector
Pin Denition
1 LINE_OUT-R
2 LINE_JD
3 AUDGND
4 LINE_OUT-L
5 AUDGND
6 MIC_OUT-R
7 MIC_JD
8 MIC_OUT-L
9 AUDGND
12. USB2_45P: USB 2.0x2 Port
Pin Denition
1 +5V
2 GND
3 USB2_1N
4 GND
5 USB2_1P
6 USB2_2P
7 GND
8 USB2_2N
9 GND
10 +5V
8. MINIPCIE: Mini PCIe Card (PCIe+SATA)
Pin Denition Pin Denition
1 WAKE# 2 3.3V
3 NC 4 GND
5 NC 6 1.5V
7 CLKREQ# 8 UIM_PWR
9 GND 10 UIM_DATA
11 CLKN0 12 UIM_CLK
13 CLKP0 14 UIM_RESET
15 GND 16 UIM_VPP
17 NC 18 GND
19 NC 20 W_DIS#
21 GND 22 RESET#
23
PCIE5_RXN / SATA_RXP 24 3.3V
25
PCIE5_RXP / SATA_RXN 26 GND
27 GND 28 1.5V
29 GND 30 SMB_CLK
31
PCIE5_TXN / SATA_TXN 32 SMB_DATA
33
PCIE5_TXP / SATA_TXP 34 GND
35 GND 36 USB2_6DN
37 GND 38 USB2_6DP
39 3.3V 40 GND
41 3.3V 42 NC
43 GND 44 NC
45 NC 46 NC
47 NC 48 1.5V
49
DAS (Device Activity Signal) 50 GND
51
mSATA Presece Detection 52 3.3V
8
10 11
12
14
9
13
13. FAN: Fan Connector
Pin Denition
1 GND
2 +12V
3 FAN SPEED DETECT
4FAN SPEED
CONTROL
9. CLRCMOS: Clear CMOS
Pin Denition Setting
1 OFF Default
2 OFF
3 ON
4 ON

X-103 6211E/6413E/6425E Quick Reference Guide Ver A.
15. LCD_PWR: LCD Panel Voltage
Select Jumper
Pin Denition Setting
1 +3.3V Default
2Panel Power
3 +5V
16. GPIO: GPIO Connector
Pin Denition Pin Denition
1 +5V 2 GND
3 GPO0 4 GPO1
5 GPO2 6 GPO3
7 GPI0 8 GPI1
9 GPI2 10 GPI3
17. Debug: 80 Debug Port Connector
Pin Denition Pin Denition
1 GND 2 PLTRST#
3 ESPI_CLK 4 ESPI_CS#
5 ESPI_IO3 6 ESPI_IO2
7 ESPI_IO1 8 ESPI_IO0
9 ESPI_RST# 10 3.3V
18
18
18
18
18
18
16
17
15
18. COM1, COM2 (RS232/RS422/RS485)
COM3, COM4, COM5, COM6 (RS232)
Pin RS232 RS422 (If supported) RS485 (If supported)
1 RI
2 CTS
3RTS
4 DSR
5 GND
6 DTR RX-
7 TXD RX+
8 RXD TX+ D+
9 DCD TX- D-

X-103 6211E/6413E/6425E Quick Reference Guide Ver A.
20. M2B: M.2 Key B Connector (3042/3052)
Pin Denition Pin Denition
1 CONFIG3 2 3.3V 41 PCIE_RXN 42 NC
3 GND 4 3.3V 43 PCIE_RXP 44 NC
5 GND 6 POWER_OFF# 45 GND 46 NC
7 USB2_5P 8 WIFI_DIS# 47 PCIE_TXN 48 NC
9 USB2_5N 10 LED# 49 PCIE_TXP 50 RESET(3.3V)
11 NC 51 GND 52 CLKREQ#
Key 53 CLK_DN 54 WAKE#
20 Telit FN980 PCIe/USB
Select Pin 55 CLK_DP 56 NC
21 CONFIG0 22 NC 57 GND 58 NC
23 NC 24 NC 59 NC 60 NC
25 NC 26 WWAN_GPS_ON 61 NC 62 NC
27 GND 28 NC 63 NC 64 NC
29 USB3_RXN 30 UIM_RESET 65 NC 66 NC
31 USB3_RXP 32 UIM_CLK 67 RESET(1.8V) 68 SUS_CLK
33 GND 34 UIM_DATA 69 CONFIG1 70 3.3V
35 USB3_TXN 36 UIM_PWR 71 GND 72 3.3V
37 USB3_TXP 38 NC 73 GND 74 3.3V
39 GND 40 NC 75 CONFIG2
20
19
19. M2E: M.2 Key E Connector (2230)
Pin Denition Pin Denition Pin Denition Pin Denition
1 GND 2 3.3V_1 41 PERP0 42 RESERVED_3
3 USB_D+ 4 3.3V_2 43 PERN0 44 COEX3
5 USB_D- 6 LED1# 45 GND6 46 COEX2
7 GND2 8 PCM_CLK 47 REFCLKP0 48 COEX1
9 SDIO_CLK 10 PCM_SYNC 49 REFCLKN0 50 SUSCLK
11 SDIO_CMD 12 PCM_IN 51 GND7 52 PERST0#
13 SDIO_DATA0 14 PCM_OUT 53 CLKREQ0# 54 W_DISABLE2#
15 SDIO_DATA1 16 LED2# 55 PEWAKE0# 56 W_DISABLE1#
17 SDIO_DATA2 18 GND3 57 GND8 58 I2C_DATA
19 SDIO_DATA3 20 UART_WAKE# 59 PETP1 60 I2C_CLK
21 SDIO_WAKE# 22 UART_RXD 61 PETN1 62 ALERT#
23 SDIO_RESET# 63 GND9 64 RESERVED
Key 65 PERP1 66 UIM_SWP
32 UART_TXD 67 PERN1 68 UIM_POWER_SNK
33 GND4 34 UART_CTS 69 GND10 70 UIM_POWER_SRC
35 PETP0 36 UART_RTS 71 PEFCLKP1 72 3.3V_3
37 PETN0 38 RESERVED_1 73 PEFCLKN1 74 3.3V_4
39 GND5 40 RESERVED_2 75 GND11

X-103 6211E/6413E/6425E Quick Reference Guide Ver A.
21. SW1: LVDS/eDP Panel EDID Select Jumper
For LVDS (Resolution is determined by SW1 setting)
SW1 Position LVDS Panel Setting
Pin4 Pin3 Pin2 Pin1 Resolution Channel Color Depth
ON ON ON ON 800x600 Single 6 bit
ON ON ON OFF 1024x768 Single 6 bit
ON ON OFF ON 1024x768 Single 8 bit
ON ON OFF OFF 1280x768 Single 6 bit
ON OFF ON ON 1280x800 Single 6 bit
ON OFF ON OFF 1280x800 Single 8 bit
ON OFF OFF ON 1280x1024 Dual 8 bit
ON OFF OFF OFF 1366x768 Single 6 bit
OFF ON ON ON 1366x768 Single 8 bit
OFF ON ON OFF 1440x900 Dual 8 bit
OFF ON OFF ON 1400x1050 Dual 8 bit
OFF ON OFF OFF 1600x900 Dual 8 bit
OFF OFF ON ON 1680x1050 Dual 8 bit
OFF OFF ON OFF 1600x1200 Dual 8 bit
OFF OFF OFF ON 1920x1080 Dual 8 bit
OFF OFF OFF OFF 1920x1200 Dual 8 bit Default
For eDP (Resolution is determined by eDP panel)
SW1 Position eDP Panel Setting
Pin4 Pin3 Pin2 Pin1 Max. Resolution
Others Not Supported.
OFF OFF OFF OFF Up to 1920x1080 Default
22. LVDS_EDP: LVDS Connector
Pin Denition Pin Denition
39 GND 40 GND
37 LVDS_DAT7N 38 LVDS_DAT7P
35 LVDS_CLK2N 36 LVDS_CLK2P
33 LVDS_DAT6N 34 LVDS_DAT6P
31 LVDS_DAT5N 32 LVDS_DAT5P
29 LVDS_DAT4N 30 LVDS_DAT4P
27 GND 28 GND
25 LVDS_DAT3N 26 LVDS_DAT3P
23 LVDS_CLK1N 24 LVDS_CLK1P
21 LVDS_DAT2N 22 LVDS_DAT2P
19 LVDS_DAT1N 20 LVDS_DAT1P
17 LVDS_DAT0N 18 LVDS_DAT0P
15 INV_BKLTEN 16 GND
13 INV_BKLTCTRL 14 Hot-Plug Detect
11 N.C 12 N.C
9 +V_PANEL 10 +V_PANEL
7 +V_PANEL 8 GND
5 +V_INV 6 GND
3 +V_INV 4 +V_INV
1 +V_INV 2 +V_INV
