Nexsan BEAST BT60 User manual

This Quick Start Guide is intended to help you quickly get your unit unpacked, mounted, and connected. For
detailed instructions, see the relevant Installation Guide and the Nexsan High-Density Storage User Guide,
which can be downloaded from https://helper.nexsansupport.com/eseries.
BT60 and BT60X
1
NEXSAN BEAST™
Quick Start Guide
Required tools and equipment
To perform the installation, you will need the following tools and equipment:
a suitable equipment rack (1,070mm deep recommended) with sufficient load capacity to hold the unit
a size PH2 Phillips-head screwdriver
For a Nexsan BT60 (main unit), you will also need:
enough CAT5e or CAT6 Ethernet cable to connect the unit to the local area network (LAN)
enough suitable cable to connect the unit to the storage area network (SAN)
Before you begin
Before installing the Nexsan BEAST storage unit, prepare the installation site and rack. The Nexsan BEAST
storage unit is designed to run from a 100–240V power supply and uses 4U of rack space.
Unpack the unit
1Remove the outer packaging sleeve.
2Remove the accessory boxes and disk boxes.
3Open the accessory boxes and make sure that all expected contents are present:
rack mounting hardware package:
two (2) rail assemblies, one left and one right
one (1) cable management arm
four (4) silver screws for securing the rails to the rack posts (PH 10-32 1/2")
four (4) clip nuts and four (4) black bolts (PH 10-32 3/4") for securing the front of the unit to the rack
posts
two (2) power cables
one (1) disposable ESD strap
(BT60 main unit only) one (1) serial cable per RAID Controller
(BT60X expansion unit only) four (4) SAS cables for attaching the expansion unit to the main unit
any additional items that may have been ordered, such as Fibre Channel cables
4Open the disk box and make sure that the proper number of disk drives is included.
5With the help of a second person, and using the lifting straps, carefully lift the unit out of the box and
set it on a flat surface, such as a cart, table, or work bench.
NOTE: The packaging that the unit ships in is reusable and should be retained for future re-shipment.
CAUTION:
Ensure that the ambient temperature at the installation is between 10°C (50°F) and 35°C (95°F).
Always fully stabilize racks with wall anchors or stabilizing legs, or both, before mounting the
Nexsan storage unit or any other components on the rack.
 Place the rack so that there is unrestricted air flow at both the front and rear of the unit.
Ensure that the floor beneath the mounting rack has enough load-bearing capacity to support
the rack and all mounted components.
Ensure that the power drawn by the Nexsan storage unit does not overload the available
electrical supply.
CAUTION:
The Nexsan storage unit is heavy and requires two people to lift it and slide it onto the mounting
rails. Do NOT attempt to mount the unit onto the rails by yourself.
When removing the unit from the packaging, DO NOT lift the unit by any plastic parts or module
handles on the chassis. Lift the unit ONLY using the lifting straps.

2
Attach the rails
NOTE: It is recommended that BEAST RAID storage units be installed low in the rack. A BEAST storage
unit, when fully extended on its rails, can overbalance a rack if it is placed too high up.
NOTE: The rails are labeled “L” (left) and “R” (right) on the bags in which they are shipped and on the rails
themselves. When installing them into the rack, be sure to place them on the correct sides. All references
to “left” and “right” are as viewed while looking at the front of the rack.
1Separate the inner and outer rails by
extending them until the latches engage,
sliding the rail latch tabs to disengage the
latches, then pulling the two rails (inner
and outer) apart.
2Attach the outer rails to the rack by
guiding the alignment posts into the rack
mount holes and hooking the rail hooks
over the outside of the rack posts. Do this
for the front and back of each rail
3Using the four supplied silver bolts, bolt the front and back of each rail to the rack posts.
NOTE: The rails should be installed into the middle 2U of the 4U of rack space where you wish to install
the BEAST. For example, if you want the BEAST to occupy U slots 18 through 21, install the rails into U
slots 19 and 20.
4On the front of the rack, attach the clip nuts above and below each rail.
5Attach the inner rails to the unit by aligning the holes over the guide posts and sliding the rail backward
until the two retention clips click into place.
Remove the PSUs
Remove the PSUs from the unit.
1Ground yourself with the included anti-static wrist strap.
2Press the spring lock tab on each
power supply unit inward to
disengage the latches.
3Carefully remove the PSUs from
the unit. Support the weight of the
PSUs with your free hand while
removing them.
NOTE: Due to the close fit, a firm steady pressure is required to remove the PSU.
CAUTION: Ensure that the rack alignment posts are properly located in the rack post holes and
that the retention hooks are clipped around the outside faces of the rack on both the front and
rear of each rail. Failure to do so can result in equipment damage or injury to personnel.
CAUTION: Handle the PSUs ONLY by the handles and outer coverings. DO NOT touch
any internal components or connectors. Doing so may harm the electronics inside.
12-3
4
Rail retention post
5
23

3
Mount unit on rack
1Remove the lifting straps from the bottom of the unit.
NOTE: Do not use the lifting straps for this procedure.
2With the help of a second person, carefully lift the unit so that the inner
rails on the chassis line up with the outer rails on the rack.
3Slide the unit onto the mounting rails until the rail latches engage.
4Pull the rail latch tab on each side of the
unit forward to disengage the rail
latches.
5Slide the unit the rest of the way into the
rack so that the front panel sits against
the rack face.
Restore the PSUs
1Ground yourself with the included anti-static wrist strap.
2Replace the two Power Supply Units (PSUs) by sliding them into the
PSU slots until the right tab clicks.
NOTE: Make sure that the PSU is right side up. The spring lock tab
should be on the right.
NOTE: DO NOT connect the power cords to the PSUs at this time.
Attach the cable management arm
Attach the cable management arm to the inner and outer rails in back of the unit.
CAUTION:
The Nexsan storage unit is heavy and requires two people to lift it and slide it onto the mounting
rails. Do NOT attempt to mount the unit onto the rails by yourself.
When removing the unit from the packaging, DO NOT lift the unit by any plastic parts or module
handles on the chassis. Lift the unit ONLY by the bottom edges of the chassis.
CAUTION: Handle the PSUs ONLY by the handles and outer coverings. DO NOT touch
any internal components or connectors. Doing so may harm the electronics inside.
CAUTION: Make certain that you mount the cable
management arm with the solid part on the INSIDE and
the hooked guides on the OUTSIDE (as shown below).
Mounting the arm in the wrong orientation can result in
damage to the arm or the unit’s cables.
CAUTION: If the cable management arm is installed and operated without cables fitted, the
linkages in the middle of the assembly must be in the outward position when closed rather than
pivoted inward (as shown below). Failure to comply with this may result in damage to the cable
management arm if it is operated without cables fitted.
1
34
2
HOST
0
HOST
1
HOST
ST
1
HOST
0

4
Load disk drives
1Ground any electrostatic charge from your person by touching a
metal part of the rack or any properly grounded conductive
object (such as the ground point at an anti-static workstation).
2Attach the clip end of the anti-static wrist strap to the rack’s
ESD grounding pin or to any bare metal part of the rack. Secure
the loop end around your wrist.
3Carefully slide the unit forward on the rails until the rail latches
engage.
4Unbolt each side of front panel and lower
it.
5Remove the chassis lid by pulling it
forward, then lifting up.
6Remove the disks from the disk boxes,
gripping them by the guides on the sides
of each disk.
NOTE: Do not remove disks from the disk
boxes by pulling on the ejection handles.
7Using the drive guides to help you orient
the disks, carefully load each disk drive into a drive slot.
Make sure that each disk is fully seated and that the drive
ejection handles are flat against each drive.
NOTE: Don’t let disks drop freely onto the connectors on the
PCB. Doing so may damage disks or connectors.
8Replace the chassis lid.
9Release the front panel retainer arms by pressing down on the hinges.
10 Raise the front panel and bolt it back into place.
11 Disengage the rail latches by sliding the latch tabs on each side of
the unit forward.
12 Carefully slide the unit all the way into the rack.
13 Using the four supplied black bolts, bolt the front of the unit to the
rack.
CAUTION:
Do not lean on or place any heavy object on the unit while it is extended. Doing so may damage
the drawer slide mechanism or overbalance the rack.
Computer components and disk drives are sensitive to electrostatic discharge (ESD). Be sure to
ground any electrostatic charge from your person before touching components with your
hands or with any tools. While installing the unit, use the anti-static wrist-strap shipped with
the unit.
CAUTION: Always load disk drives in rows of 15 across the width of the drive drawer, starting at
the front of the drive bay. Leaving gaps between disk drives decreases cooling efficiency and may
result in some disk drives overheating.
CAUTION: Be sure that you load all drives so that their connectors line up with the connectors on
the motherboard and with their labels facing left. The drive holders are keyed so that inserting
them in their correct orientation is easy. Do NOT force a drive into its slot if you encounter
significant resistance.
23
4
7
13
PWR ENVDSK STAT

5
Attach Cables
Connect BT60X expansion unit to BT60 main unit
1Insert one SAS cable into each expansion port (EXP 0 and EXP 1) on the first RAID Controller of the
main unit.
2Insert the other ends of the SAS cables into the EXP IN 0 and 1 expansion ports on the left Expansion
Controller in the expansion unit.
3Repeat Step 1 and Step 2 for the second RAID Controller and Expansion Controller.
Connect BT60 to LAN and SAN
Host Connector Types
4Connect the unit to your local area network (LAN) by attaching 100Mb/s Ethernet cable to the
Management (MGMT) port. This enables you to access the unit’s graphical user interface (GUI).
5Connect the unit to your storage area network (SAN) by attaching 1Gb/s Ethernet cables to the iSCSI
ports, or by attaching Fibre Channel or 10Gb/s Ethernet cables to the Host ports on each controller.
NOTE: If a Fibre Channel or 10GbE card is installed, only the left two
iSCSI ports are active.
6Run all cables through the cable management arm and secure them with
the included straps.
NOTE: Be sure to leave enough slack in all cables so that no cables are
pulled taut when the unit is fully extended on the rails.
CAUTION: If you are installing two expansion units onto a single main storage unit, or if you need
to “hot-add” the expansion unit to a running main storage unit, you MUST follow the instructions
under Attach Expansion Unit to Main Storage Units in the Nexsan BEAST Installation Guide,
which is on the Product Manuals and Software Tools CD included with the unit.
EXP 0 EXP 1
STATMGMT SERIAL
HOST
0
HOST
1
L1L0
EXP 0 EXP 1
STATMGMT SERIAL
HOST
0
HOST
1
L1L0
SW0 SW0
EXP 0 EXP 1
L1 STATL0
EXP 0 EXP 1
L1L0
EXP 0 EXP 1
L1 STATL0
EXP 0 EXP 1
L1L0
EXP 0 EXP 1
STATMGMT SERIAL
HOST
0
HOST
1
L1L0
SW0
)LEUH&KDQQHORU*E( ports
Expansion Ports Mana
g
ement Port Serial Port iSCSI Ports
SW0 switch
Fibre Channel 10gb Ethernet, Optical 10gb Ethernet, Copper
EXP0 EXP1
STATMGMT SERIAL
HOST
0
HOST
1
L1L0
EXP0 EXP1
STATMGMT SERIAL
HOST
0
HOST
1
L1L0

Part number: P0450111 Rev: DRelease Date: October 2017
Related Documentation: Nexsan Beast Installation and FRU Removal and
Replacement Guides, Nexsan High Density Storage User Manual
Copyright © 2016 Nexsan Corporation. All Rights Reserved. Nexsan®, Beast®, and the Nexsan logo are trademarks or registered trademarks of Nexsan
Corporation. All other trademarks and registered trademarks are the property of their respective owners.
Technical Support
By Phone:
U.S. & Canada: Toll free, [phone]
Global: U.S. Toll, [phone]
By Email: [email protected]
NEXSAN 900 E Hamilton Ave, Suite 230, Campbell, CA 95008 | p. 1.866.463.9726 |www.nexsan.com
Power On the Unit
BT60 with BT60X expansion unit
1Attach the power cords to the PSUs on both the main unit and the expansion unit.
NOTE: DO NOT connect the other ends of the power cords to A/C power at this time.
2Run the power cables through the cable management arm and secure them with straps or zip ties.
NOTE: Be sure to leave enough slack in all cables so that the cable management arm can fully extend.
3Connect the power cords for the EXPANSION unit to A/C power.
4Wait approximately 10 seconds, then connect the power cords for the MAIN unit to A/C power.
NOTE: You may need to use the SW0 switch to initiate the power up sequence. Press and hold the SW0
switch until you hear the systems cooling fans start up and then release. Do not hold the SW0 switch in
for longer than that as that may cause the product's controllers to start in Emergency Mode.
NOTE: If the audible alarm sounds when the unit is first powered on, this may be because the controller
batteries are discharged. Press either SW0 switch on the rear of the unit to silence the alarm.
5When the main unit is fully powered up (this may take up to 5 minutes), check the EXP IN L0 and L1
LEDs next to the expansion ports on the Expansion Modules. Both LEDs should be green.
NOTE: If either of the EXP IN LEDs are flashing amber, you must power down both units, correct the
cabling (see Attach Cables), and then repeat Step 1 through Step 5.
BT60 alone
1Attach the two power cords to the PSUs.
NOTE: DO NOT connect the other ends of the power cords to A/C power at this time.
2Run the power cables through the cable management arm and secure them with straps or zip ties.
NOTE: Be sure to leave enough slack in all cables so that the cable management arm can fully extend.
3Connect each power cord to A/C power.
NOTE: You may need to use the SW0 switch to initiate the power up sequence. Press and hold the SW0
switch until you hear the systems cooling fans start up and then release. Do not hold the SW0 switch in
for longer than that as that may cause the product's controllers to start in Emergency Mode.
NOTE: If the audible alarm sounds when the unit is first powered on, this may be because the controller
batteries are discharged. Press either SW0 switch on the rear of the unit to silence the alarm.
Register the Unit
The Product ID is located on the bottom left of the rear panel. Go to http://register.nexsan.com to register
your product.
Configure the Unit
1When the unit has finished starting up, access it via a web browser from a computer that is on the same
LAN as the unit’s MGMT port is connected to by entering the IP address into the browser’s address field.
NOTE: The default IP addresses for the RAID Controllers are 10.11.12.13 and 10.11.12.14. It is very
important, however, that you change these IP addresses by following the instructions under Initial
Network Address Setup in Chapter 1 of the Nexsan High Density Storage User Guide.
2Click the Click Here To Log In button.
3Accept the EULA when it is displayed by clicking the I Agree button.
4Follow the instructions in Chapter 1, Basic Setup of the Nexsan High Density Storage User Manual
(which is on the Product Manuals and Software Tools CD included with the unit) to get started with your
new Nexsan BEAST RAID storage system.
CAUTION:
When applying power to the unit, use ONLY the IEC power cords originally supplied with the
unit. Do NOT use other power cords, even if they appear identical to the supplied cords.
The Nexsan BEAST storage units do not have power switches. Do NOT apply power to the unit
until it is fully installed, with all disk drives in place.
