Next 779943 User manual

Assembly instructions
IMPORTANT- RETAIN FOR FUTURE REFERENCE CALL: 0333 777 8999
Produced in Poland for Next Retail Ltd.
779943-2014-V1
With: Assembly instructions
Missing or damaged parts
Need Help?
SLIDE MORROR DOORS
779943
Actual product size
H203 x W102 cm
P40073L1

PH2
1
BEFORE YOU START
1 hours
Tools required
not supplied not supplied
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777 8999
and they will be happy to arrange for a replacement to be sent
to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had the
product for 28 days or less you may be offered a replacement,
refund or for a fully trained home service technician to visit your
home to assess the fault and repair the product where possible.
If you have had the product for more than 28 days we will send
an independant home service technician to review and repair
the product where possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To View our full furniture range please visit www.next.co.uk
Produced in Poland for Next Retail Ltd.
2 person assembly
Assembly instructions
Warnings
We suggest you retain these instructions for future reference.
Keep fittings out of children’s reach and keep children well
away from the construction area.
This product should only be used on firm, level ground.
Please periodically check all fittings and re-tighten as
necessary.
Please do not sit or stand on your furniture.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause deterioration of the colour.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean floor to protect it from
damage.
Do’s
We suggest you spend a short time reading through this leaflet
before you start.
When you are ready to start, make sure that you have the
right tools and plenty of space.
Unwrap all packaging materials and place the components
on a clean surface to protect it from damage.
We recommend that the packaging is used to protect the
surfaces during assembly.
Carefully check that you have all the parts before beginning
assembly.
Due to the size of the product we recommend that it is
assembled in the room intended for use.
Ensure the product is fully assembled as illustrated and all
fixings are fully tightened before use.
Wipe occasionally with a soft cloth slightly dampened with
water. Then buff with a dry clean soft cloth.
Wood will mellow and change colour over time, we recommend
that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
If the glass is chipped or broken, stop using the product and
consult the supplier. When cleaning glass panel use a damp
cloth with washing up liquid or soft soap if necessary. Do not
use washing powders or any other substances containing
abrasives since these substances scratch glass panel.
The glass used in this product is toughened and complies
with BS EN 12150-1:2000, clauses 8.3 & 8.4
Don’ts
Do not drag or pull your furniture.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the finish.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause wood to warp or finishes to de-laminate.
Do not place hot items (e.g. hot drinks) directly on to the wood
surface. Please make sure you use a placement or coaster.
Do not place very hot or very cold items on the glass surface,
unless adequately thick table mats or coasters are used to
provent such items from coming into contact with the glass.
Do not use glass as a chopping surface. Do not strike the glass
with hard or pointed items.
SLIDE MORROR DOORS
779943
779943-2014-V1
Number of people required to assemble
Two persons are required to assemble this item.
Time to assemble

GETTING TO KNOW YOUR PRODUCT
2
Components supplied. Please use this guide if you require replacement parts.
Ref Dimensions Visual Qty Ctn
12U
12M
12L
13U
13M
13L
14
14
101,7x67,6 cm
101,7x67,8 cm
101,7x67,6 cm
101,7x67,6 cm
101,7x67,8 cm
101,7x67,6 cm
98x6 cm
98x6 cm
1
1
1
1
1
1
2
2
Produced in Poland for Next Retail Ltd.
3
3
3
2
2
2
2
3
Assembly instructions
14
14
14
14
Z
Z
Z1
Z2
12L
13L
12M
13M
12U
13U
SLIDE MORROR DOORS
779943
779943-2014-V1

Fixtures and fittings
supplied (actual size)
3
Qty
Ref Dimensions
96
mm 10 20 30 40 50 60 70 80 90 100 110 120 130
Produced in Poland for Next Retail Ltd.
Assembly instructions
S2
3,0x13mm
Qty
Ref Dimensions Visual
J11
Z
Z1
Z2
SC
E5
E9
E6
E7
E8
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1
1
2
2
2
2
1
1
3
2
Fixtures and fittings supplied (not to scale)
44mm
29mm
P13 4
3,5x13mm
E21 28
6,3x11mm
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
Fittings are supplied with carcass.
SLIDE MORROR DOORS
779943
779943-2014-V1

4
Produced in Poland for Next Retail Ltd.
1
2
Assembly instructions
E6 x 2 E21 x 14
E5 x 1 E9 x 1
S2
33
E5
E21
22
1
2
11
E9
E21
E9
22
1
2
11
23 mm
23 mm
E21
E21
E6
E6
S2 x 32
3,0x13mm
14
14
12L
12L
12M
12M
12U
12U
6,3x11mm
SLIDE MORROR DOORS
779943
779943-2014-V1

5
Produced in Poland for Next Retail Ltd.
Assembly instructions
3
Z1 x 1 S2 x 16
Z x 1 SC x 1
3,0x13mm
44mm
S2
S2
SC
SC
Z
Z1
12L
12U
12M
SLIDE MORROR DOORS
779943
779943-2014-V1

6
Produced in Poland for Next Retail Ltd.
Assembly instructions
4
5E21 E7
22
11
E21 E7
20 mm
20 mm
E21
E21
E8
E8
4
S2
S2 x 32
3,0x13mm
14
14
13L
13L
13M
13M
13U
13U
E21 x 14
E7 x 2 E8 x 2
6,3x11mm
SLIDE MORROR DOORS
779943
779943-2014-V1

Assembly instructions
7
Produced in Poland for Next Retail Ltd.
6
Z2 x 1 S2 x 16
Z x 1 SC x 2
3,0x13mm
44mm
29mm
S2
S2
SC
SC
Z2
Z2
Z
ZSC
SC
13L
13U
13M
SLIDE MORROR DOORS
779943
779943-2014-V1

2
1
3
4
12
13
Assembly instructions
8
Produced in Poland for Next Retail Ltd.
7
1
11
3
4
22
2
5
2
6
6
SZ
E9
E9
33
E7
b
a
44
2
9
8
1
13
13
12
12
12
SLIDE MORROR DOORS
779943
779943-2014-V1

Assembly instructions
9
Produced in Poland for Next Retail Ltd.
8
J11 x 2 P13 x 4
3,5x13mm
Wall fixings are not supplied with this product as different wall materials require different
types of fixing devices( such as Rawl plugs used on brick work).You must use fixing
devices suitable for the type of wall you intend to mount this product to.
Please ensure that the head of any screw used has a diameter greater than the diameter
of the mounting hole on the product and that the fixing is safe and secure before use.
*
SLIDE MORROR DOORS
779943
779943-2014-V1
STEP 2
P13
J11
NOT SUPPLIED
J11
STEP 1
G7
G7
C7
N1A
*

Produced in Poland for Next Retail Ltd.
Actual product size
H203 x W102 cm
SLIDE MORROR DOORS
779943
779943-2014-V1
2030mm
1020 mm 1020 mm
