Next Claro 347876 User manual

Claro Tall Shelves
347876
Assembly instructions
Actual product size:
H178 x W80 x D40cm
Need Help?
With: Assembly instructions
Missing or damaged parts
CALL: 0333 777 8999
IMPORTANT ─ RETAIN FOR FUTURE REFERENCE
Produced in China for Next Retail Ltd.
673886-2014-V1 2

We suggest you retain these instructions for future reference
Keep fittings out of children’s reach and keep children well
away from construction area
This product should only be used on firm level ground
Avoid exposing the furniture to excessive heat or direct sunlight
as this can cause deterioration of the UV bosses glue.
Unwrap all packaging materials and place the components on
top of the carton box or on a clean floor to protect it from
damage.
WARNING: In order to prevent overturning this product
must be used with the wall attachment device provided.
Do’s
We suggest you spend a short time reading through this leaflet
before you start
When you are ready to start, make sure that you have the right
tools and plenty of space
We recommend that the packaging is used to protect the
surfaces during assembly
Carefully check that you have all the parts before beginning
assembly
Ensure the product is fully assembled as illustrated and all
fixings fully tightened before use. Check fixings regularly to
ensure they remain tight
Please take care when handling or moving the furniture as
careless handling may cause damage or injury
It is recommended that before moving heavy objects to a new
location they are completely dis-assembled to avoid personal
injury or damage to the furniture. Please be careful to retain all
fittings when doing this.
Always wipe dry after cleaning
To clean your item, please use a soft cloth slightly dampened
with water and wipe clean. Then buff with a dry clean cloth.
Glass can scratch in normal use there fore protect surfaces
from scratches and marks by using mats and coasters.
Don’ts
Do not use the glass as a chopping surface. Do not strike the
glass with hard or pointed items
If the glass is chipped or broken stop using the product and
consult the manufacturer or supplier.
Numberof people required to assemble
Two people are required to assemble this item.
Time to assemble
Tools required
Missing parts
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777
8999 and they will be happy to arrange for a replacement
to be sent to you free of charge.
Home service technicians
If you have a fault with your product please contact our
customer service team on 0333 777 8999. If you have had
the product for 28 days or less you may be offered a
replacement, refund or for a fully trained home service
technician to visit your home to assess the fault and repair
the product where possible. If you have had the product for
more than 28 days we will send an independent home
service technician to review and repair the product where
possible and recommend further action.
You can write to us at
Home Customer Services
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To view our full furniture range pleasevisit
www.next.co.uk
Claro Tall Shelves
347876
Assembly instructions
BEFORE YOU START
Produced in China for Next Retail Ltd.
673886-2014-V1 3
30 mins

Claro Tall Shelves
347876
Assembly instructions
GETTING TO KNOW YOUR PRODUCT
Produced in China for Next Retail Ltd.
673886-2014-V1 4
Ref Dimensions Visual
Qty
Ctn
1
80 x 40 x 2cm
1
2
2
176 x 40 x 6cm
1
1
3
176 x 40 x 6cm
1
1
1
2
Ref
Dimensions Visual Qt
y
Ctn
4
66.2 x 39.5 x 0.8cm
4
3
5
67 x 5 x 1.5cm
1
1
6
186 x 2 x 1cm
2
1
35
6
4

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 5
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty *Extra
AM4 x 10mm 16 2
BM6 X 10mm 11 2
CM8 X 20mm 8 1
DDia.10 x 10mm 1 1
mm 10 20 30 40 50 60 70 80 90 100
Fixtures and fittings supplied (not to scale)
Ref Dimensions Visual Qty
E5mm 2
F22 X 21 X 16mm 16
G72 x 25 x 14mm 2

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 6
1
2
2
5
E
B x 2
M6 X 10MM
Locate the bottom bar (5) onto the leg (2) as
shown.
B
5
2
Fix the bottom bar (5) to the leg (2) using allen
bolts (B) and the allen key (E).

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 7
3
4
3
Fix the bottom bar (5) to the leg (3) using
allen bolts (B) and the allen key (E).
Locate the bottom bar (5) into the leg (3) as
shown.
3
5
B x 2
M6 X 10MM
5E
B

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 8
Cx 8
5
6
E
C
M8 X 20MM
Fix the top shelf(1) to the leg (2) (3) using
the allen key (E) and the bolts (C).
EB
Fix the brace bar (6) to the legs (2)(3)
using the allen key (E) and the bolts (B).
B x 2
M6 X 10MM
3
6
2
3
2
1

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 9
7
8
B
E
Fix the brace bars (6) using the allen bolt
(B) the nut (D) and the allen key (E).
6
D
Fix the brace bar (6) to the legs (2)(3)
using the allen key (E) and the bolts (B).
3
6
2
B x 2
M6x 10
D x 1
Dia.10 x 10mm
B x 2
M6 X 10MM
EB

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 10
9
10
E
B x 2
M6 X 10MM
Fix the wall brackets (G) to the legs (2)(3)
as shown and tighten with an allen bolt
(B) and the allen key (E)
G
B
G x 2
2
3

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 11
11
12
B x 2
M6 X 10MM
Remove the wall brackets (G) as shown
and place somewhere safe.
Move the shelving unit into the place of
intended use next to a wall. Adjust the feet
to ensure the unit is stable. The wall bracket
(G) may also require some adjustment to fit
correctly depending on any obstructions
behind the shelf such as skirting boards,
picture rails etc.
With a pencil accurately mark the position of
the screw holes onto the wall. Now carefully
move the shelf away from the wall to create
space for drilling.
wall
G x 2
G x 2
G
EG
B

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 12
13
14
B x 2
M6 X 10MM
Fix the wall brackets (G) to the legs (2) (3)
as shown and secure with the allen bolts
(B) and the allen key (E)
E
B
G x 2
G
For safety we would advise this unit is fitted to the wall. Ensure the fittings used to
attached the wall bracket (G) are suitable for the wall material type. If in doubt seek
professional advice. Before drilling, ensure the size of hole will be correct to fit the
rawl plug (not included).
Warning: Ensure the area to be drilled is free from hidden electrical wires, water and
gas pipes.
G x 2
G
3
2

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 13
15
16
Adjust the plastic screws of the shelf clip
(F) with a screwdriver as shown. With 2
people carefully slide the shelves into the
clips.
M4 X 10MM
Fix the shelf clips (F) to the legs (2)(3) as
shown and tighten with the screws (A)
and the screwdriver.
AF
A x 16
F x 16
F x 16
4
F
3
2

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 14
17
Adjust the plastic screw of the shelf clips
(F) with a screwdriver as shown.
F x 16
4
F

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 15
1We recommend the use of the wall bracket provided for safety reasons. Wall fixings
are not included please source suitable fixings for your wall type. If in doubt, please
consult a qualified tradesperson.
WARNING: Always ensure the wall to be drilled is free from hidden electrical wires,
water and gas pipes.

Claro Tall Shelves
347876
Assembly instructions
Produced in China for Next Retail Ltd.
673886-2014-V1 16
Actual product size:
H178 x W80 x D40cm
178
310
370
370
370
310
WARNING:
Glass shelf Max
load is 17KGS
17kg Max
Per shelf
