Next HENRY 423498 User manual

IMPORTANT - RETAIN FOR FUTURE REFERENCE
Actual product size
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Need Help?
CALL: 0333 777 8999
With: Assembly instructions
Missing or damages parts
Assembly instructions
HENRY LADDER SHELVING
423498
H180 x W108.1 x D40.1cm

PH2
BEFORE YOU START
15min
1Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
Number of people required to assemble
Time to assemble
Tools required
Do’s
Two people are required to assemble this item
We suggest you spend a short time reading through this leaflet before you start
When you are ready to start, make sure that you have the right tools and plenty of space
Unwrap all packaging materials and place the components on a clean surface to protect it from damage,
we recommend that the packaging is used to protect the surfaces during assembly
Carefully check that you have all the parts before beginning assembly
Due to the size of the product we recommend that it is assembled in the room intended for use
Ensure the product is fully assembled as illustrated and all fixings fully tightened before use
Wipe occasionally with a soft cloth slightly dampened with water. Then buff with a dry clean soft cloth
Wood will mellow and change colour over time, we recommend that ornaments and items placed on the surface are
moved regularly for the first few months to prevent uneven mellowing
Don’ts
Do not drag or pull your furniture
Do not rub or scrub the surface when cleaning
Do not use silicone based furniture polish. Silicone in furniture polishes can break down the finish
Never allow any kind of liquid to remain on your furniture. Absorption can cause wood to warp or finishes to de-laminate
Do not place hot items (e.g. hot drinks) directly on to the wood surface. Please make sure you use a placemat or coaster

GETTING TO KNOW YOUR PRODUCT
2Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
1
8
9
10
11
11
11
11
6
7
2
3
4
5

34 x 6cm
Ref Dimensions Visual Qty
11
Ctn
14
Ref Dimensions Visual Qty
1
Ctn
Components supplied. Please use this guide if you require replacement parts
.
2
3
4
5
6
108.1 x 34cm
108.1 x 34cm
108.1 x 34cm
108.1 x 34cm
108.1 x 34cm
180 x 6cm
11
1 1
7180 x 6cm 1 1
8180 x 6cm 1 1
9180 x 6cm 1 1
10 40 x 6cm 1 1
1 1
1 1
1
1
1
1
3Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498

4Ø4 x 20mm 1b
N/AØ8 x 38mm 2c
Fixtures and fittings
supplied (actual size)
Ref Dimensions Qty Spare
Qty
N/AØ10 x 50mm 2d
N/AØ15x 17.2mm 2f
4
Fixtures and fittings supplied (not to scale)
Ref Dimensions Qty Visual
Spare
Qty
N/A N/Ao 2
N/A N/Ax 1
N/A N/Ak 55
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
Short Side

5
1
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
TURN THE CAM IN A CLOCKWISE DIRECTION
PUSH THE TWO PANELS TOGETHER ALLOWING THE
DOWEL TO ALIGN WITH THE HOLE
WHEN TIGHTENING THE CAM
TURN THE CAM IN A CLOCKWISE DIRECTION UNTIL THE
ARROW POINTS IN THE POSITIONS SHOWN IN THE
DIAGRAMS BELOW
START MAXIMUM
LOCK
9
8
10

2
3
6
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
2
3
4
5
9
8
1
8
9

4
5
7
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
1
2
3
4
5
7
11
11
11
11
11
11
11
11
6

6
8
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
PH2 x x 1
PH2 b x 4
4 x 20mm
8
9
b
b
b
b
Short Side
Short Side

9Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
Assembly instructions
HENRY LADDER SHELVING
423498
7
9
8
o
o
PH2 o x 2
WALL
SCREW
We recommend the use of the wall attachment bracket/strap provided for safety reasons.
Secure the other end of the strap to the wall with an appropriate screw and wall plug for your wall
type (not provided).
To hide the strap behind the unit, drill the hole lower than the top of unit.
Warning: Always ensure intended wall area to be drilled is free from hidden electrical wires, water,
and gas pipes.
If in doubt please consult a qualified trades person.
k x 55
k
k
k
k
k
k
k
k
k
k
k
k
k
k
k
k

Actual product size
H180 x W108.1 x D40.1cm
Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
HENRY LADDER SHELVING
423498
1081mm
401mm
340mm
1800mm

Produced in Indonesia for Next Retail Ltd.
423498-2016-V1
HENRY LADDER SHELVING
423498
