NEXTLED NT-6648 User manual

Model NT-6648 (Patent Pending)
10” Triple Light Mode
Under Car
LED Work Light
The rechargeable NextLED Under Car Work Light is
highly versatile and is designed to illuminate nearly
every project you have under your car. This work light
features three distinct modes of operating. The first
is a high power, super bright, 500 lumens wide angle
light which illuminates the entire disc. The second is a
highly flexible 18” detail light with a zoom function that
can be used to eliminate shadows by pinpointing light
on the exact spot you are working on. The third is a
UVA light which which emits from the center disc and
can be used to provide leak detection. The disc light
measures 10” and comes standard with 4 steel wheels
that allow you to quickly and easily move the light
around underneath the car.
CAUTION:
Read all instructions and warnings before operating!
SAVE THESE INSTRUCTIONS!
WARNING: To avoid serious injury or death from electrical shock or fire:
1. This fixture MUST ALWAYS BE USED IN ACCORDANCE WITH ALL
ELECTRICAL AND SAFETY CODES AND ORDINANCES, including
the most recent National Electric Code (NEC) and with the
Occupational Safety and Health Act (OSHA) Volume 1 on General
Industry Standards and interpretations.
2. ALWAYS make certain that the power source conforms to the rating
on the fixture.
3 DO NOT inspect or service the fixture while charging.
4. CAUTION: This fixture is for indoor use. Keep dry. Do not open,
drop, short-circuit, incinerate, expose to temperatures higher
than 140ºF, or charge/use if damaged.
5. People with pacemakers should consult their physician(s) before
use. Electromagnetic fileds in close proximity to heart pacemaker
could cause pacemaker interferance or pacemaker failure
6. This fixture is not explosive-proof, DO NOT use in potentially
dangerous locations, such as in flammable or explosive
atmospheres.
7. NEVER operate the light with the clear protective glass
broken or removed.
8. NEVER LOOK DIRECTLY INTO LIGHT SOURCE. LED’s are extremely
bright and can damage eyes with prolonged exposure.
9. KEEP AWAY from heating vents, radiators, or other sources of heat.
10. KEEP OUT OF REACH OF CHILDREN.
LITHIUM BATTERY SAFETY WARNINGS
LITHIUM BATTERIES STORE A LARGE AMOUNT OF ENERGY AND
WILL VENT FIRE OR EXPLODE IF MISTREATED:
1. Keep work light dry.
2. DO NOT DO ANY OF THE FOLLOWING TO BATTERY PACK:
a. Drop
b. Open
c. Short-circuit
d. Puncture
e. Incinerate
f. Expose to temperatures greater than 140ºF.
3. Charge work light only according to these instructions
PRODUCT INSTRUCTION
1. Push down on the toggle power switch to
turn on the LED light. The switch shows LED.
2. Push down on the toggle power switch to
turn on the UVA light. The switch shows UV.
3. Push the toggle power switch to the middle
position to turn off the light.
4. To operate the flexi-light, take the flexi-light
and position it so that it is shining directly on
the area that you need illuminated. Push the button on the head
of the flexi-light once to turn on and a second time to turn off.
CORDED OPERATION
While the charger is plugged in, the under-car light will continue to
operate normally, while the battery is charging.
FLEXI-LIGHT USAGE
To operate the flexi-light, take the flexi-light and position it so that
it is shining directly on the area that you need illuminated. The
flexi-light has a zoom feature in the head of the LED. If you pull up
on the head of the light, it will zoom the light. If you pull back on the
head, it will spread the light back out. To store the flexi-light, simply
wrap the cord around the base of the under-car light, and snap the
head in place.
MAINTENANCE
Only qualified service personel must perform repairs. Opening or
visible attempts to open or repair work light will void any warranty
and/or cause damage to the product or personal injury.
CAUTION! Do not use solvents such as gasoline, turpentine,
etc. to clean the unit. Aerosols and other chemical will fog the
clear polycarbonate lens.

TO RECHARGE THE BATTERIES
Attach the provided USB cord to the port at the side of the light
and attach the other end to an appropriate 5V charger. Full charge
should take approximately 3 hours. During operation, when the
unit’s battery is low and needs to be charged, a red LED light will
illuminate. When the unit is charging a red LED will illuminate.
When the battery is fully charged, the LED will turn green.
ONE YEAR LIMITED WARRANTY
If this NextLED®product fails due to defect in materials or
workmanship, NextLED®will at its option, repair it or replace it
with the same or comparable model, free of charge.
For repair or replacement under warranty, return to the retail
establishment where the product was purchased.
This warranty gives you specific legal rights and you may have
other rights that vary from state to state.
This warranty is void if damage or defect has resulted from accident,
abuse, misuse or faulty repair. In no event will NextLED®be liable for
any consequential, special, incidental, or indirect damages of any
kind arising out of the use or misuse of this product.
Maximum liability shall not in any case exceed the purchase price
of the product including shipping. Some states do not allow the
exclusion or limitation of incidental or consequential damages so the
above exclusions or limitations may not apply to you.
Your product, accessories and packaging should be discarded
in an environmentally responsible way.
Illustrations, figures and photos may vary slightly due to our
program of continuous product improvements.
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
© 2021 Distributed by SunZi Products Inc.
Schaumburg, IL
Visit www.mynextled.com
Customer Service: [phone]
v.1
MADE IN CHINA
SPECIFICATIONS
LED’s:...........................Two Illumination settings: White & UVA
Max. brightness...........Disc Light is 500 lumens
Flexible Light is 200 lumens
Disc Light comes standard with a UV
switch for leak detection (UVA)
Runtime:.......................6hrs. (Disc Light) / 10 hrs. Flexible Light
by fully charged battery
Battery size:.................Two rechargeable lithium-Ion
batteries included; 3.7v 5200 mAh
Functions 2 ways:........Cordless with batteries and also
works while plugged into an outlet
Micro USB charger:.....5V / 2A rechargeable
Charging cable ............Included
Charging time:..............3 hrs (charger: 5V / 2A)
Net weight:...................2.0 lbs.
IP rating:......................IP43
Under car light dia. .....10”
Flexible light length......18”
