NexusLink GPL-1200WAC User manual

261072-042
Version A1.1, February 3, 2021
GPL-1200WAC
G.hn+11ac Wi-Fi Powerline Adapter
User Manual

1
Preface
This manual provides information related to the installation and operation of this device.
The individual reading this manual is presumed to have a basic understanding of
telecommunications terminology and concepts.
If you find the product to be inoperable or malfunctioning, please contact technical
support for immediate service by email at [e-mail]
For product update, new product release, manual revision, or software upgrades, please
visit our website at https://www.nexuslinkusa.com
Important Safety Instructions
In order to keep the safety of users and your properties, please follow these safety
instructions:
1. This power line access point is designed for indoor use only; DO NOT place this power
line access point outdoor.
2. DO NOT put this power line access point at or near hot or humid places, like a kitchen
or bathroom. Also, do not leave this power line access point in the car under direct
sunlight.
3. DO NOT pull any connected cable with force; disconnect it from the power line access
point first.
4. If you want to place this power line access point at high places, please make sure the
power line access point is firmly secured. Falling from high places would damage the
power line access point and its accessories, and warranty will be void.
5. There’s no user-serviceable part inside the access point. If you found that the power
line access point is not working properly, please contact your dealer of purchase and ask
for help. DO NOT disassemble the access point, warranty will be void.
6. If the power line access point falls into water when it’s powered, DO NOT use your hand
to pick it up. Switch the electrical power off before you do anything, or contact an
experienced electrical technician for help.

2
Copyright
Copyright©2021 NexusLink. All rights reserved. The information contained herein is
proprietary to NexusLink. No part of this document may be translated, transcribed,
reproduced, in any form, or by any means without prior written consent of NexusLink
Corporation.
This program is free software: you can redistribute it and/or modify it under the terms of
the GNU General Public License as published by the Free Software Foundation, either
version 3 of the License, or (at your option) any later version.
This program is distributed in the hope that it will be useful, but WITHOUT ANY
WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A
PARTICULAR PURPOSE. See the GNU General Public License for more details.
You should have received a copy of the GNU General Public License along with this
program. If not, see http://www.gnu.org/licenses/
NOTE: This document is subject to change without notice.
Protect Our Environment
This symbol indicates that when the equipment has reached the end
Of its useful life, it must be taken to a recycling centre and processed
Separate from domestic waste.
The cardboard box, the plastic contained in the packaging, and the parts that make up
this device can be recycled in accordance with regionally established regulations. Never
dispose of this electronic equipment along with your household waste; you may be subject
to penalties or sanctions under the law. Instead, please be responsible and ask for
disposal instructions from your local government.

3
CATALOG
CHAPTER 1 INTRODUCTION ............................................................................................................................. 5
1.1 SYSTEM REQUIREMENTS .................................................................................................................................... 5
CHAPTER 2 HOW TO INSTALL GPL-1200AC .................................................................................................. 6
CHAPTER 3 LED INDICATIONS ....................................................................................................................... 12
CHAPTER 4 BUTTON FUNCTIONS .................................................................................................................. 13
CHAPTER 5 WIRELESS SYSTEM AND NETWORK SETUP ....................................................................... 14
5.1 CONNECT TO POWER LINE ACCESS POINT BY WEB BROWSER ............................................................................ 14
5.2 CONNECTING TO WEB MANAGEMENT INTERFACE ........................................................................................... 15
5.3 VIEW SYSTEM INFORMATION ........................................................................................................................... 16
5.4 NETWORK SETTINGS ........................................................................................................................................ 18
5.5 STATIONS LIST .................................................................................................................................................. 18
5.6 NETWORK TIMING ............................................................................................................................................ 19
5.7 ACCESS POLICY ................................................................................................................................................ 20
5.8 ADMINISTRATION ............................................................................................................................................. 21
5.9 MONITOR.......................................................................................................................................................... 22
5.10 LOGOUT.......................................................................................................................................................... 22
CHAPTER 6 WIRELESS CONFIGURATIONS ................................................................................................. 23
6.1 2.4G WIRELESS SETTINGS ............................................................................................................................... 23
6.1.1 Multiple BSS ............................................................................................................................................. 24
6.2 2.4G SECURITY SETTINGS ............................................................................................................................... 25
6.3 2.4G WPS SETTINGS ........................................................................................................................................ 26
6.4 2.4G AIR TIME MANAGEMENT ........................................................................................................................ 27
6.4.1 2.4Ghz Air Time Management ................................................................................................................. 27
6.4.2 Configuration .......................................................................................................................................... 28
6.4.3 Per BSS Weights ...................................................................................................................................... 28
6.4.4 Per Station Weights ................................................................................................................................. 28
6.5 5G WIRELESS SETTINGS .................................................................................................................................. 29
6.5.1 Multiple BSS ............................................................................................................................................. 30
6.6 5G SECURITY SETTINGS .................................................................................................................................. 31
6.7 5G WPS SETTINGS .......................................................................................................................................... 32
6.8 5G AIR TIME MANAGEMENT ........................................................................................................................... 33
6.8.1 5Ghz Air Time Management .................................................................................................................... 33
6.8.2 Configuration .......................................................................................................................................... 34
6.8.3 Per BSS Weights ...................................................................................................................................... 34
6.8.4 Per Station Weights ................................................................................................................................. 34
CHAPTER 7 G.HN/POWERLINE SETUP ......................................................................................................... 35
7.1 CONFIGURE STATIC IP MODE ....................................................................................................................... 35
7.2 LOGGING IN ...................................................................................................................................................... 36
7.3 G.HN INTERFACE .............................................................................................................................................. 37
7.3.1 Basic Configuration ................................................................................................................................. 38
7.3.2 NDIM Configuration ................................................................................................................................ 38
7.3.3 Encryption Configuration via WEB UI .................................................................................................... 38
7.4 IP INTERFACE ................................................................................................................................................... 39
7.4.1 IP config ................................................................................................................................................... 40
7.5 ETHERNET INTERFACE ...................................................................................................................................... 41
7.6 DEVICE INTERFACE .......................................................................................................................................... 42
7.6.1 Hardware information .............................................................................................................................. 42
7.6.2 Software information ................................................................................................................................ 42
7.6.3 Security ..................................................................................................................................................... 43
7.6.4 SW update ................................................................................................................................................. 43
7.6.5 HTTP SW update ...................................................................................................................................... 43
7.7 MULTICAST INTERFACE .................................................................................................................................... 44
7.7.1 MCAST Configuration .............................................................................................................................. 44
7.8 QOS MENU........................................................................................................................................................ 45
7.8.1 QoS Configuration ................................................................................................................................... 45
7.9 VLAN INTERFACE ............................................................................................................................................ 48
7.9.1 VLAN Configuration................................................................................................................................. 48

4
7.10 G.HN SPECTRUM INTERFACE........................................................................................................................... 49
7.10.1 Notches ................................................................................................................................................... 49
7.11 LOG FILE INTERFACE ...................................................................................................................................... 50
7.11.1 Log File................................................................................................................................................... 50
7.12 ADVANCED INTERFACE ................................................................................................................................... 51
CHAPTER 8 CLI COMMANDS FOR TR069 SETTINGS VIA TELNET ....................................................... 52

5
Chapter 1 Introduction
NexusLink’s GPL-1200WAC is designed to meet the growing demand for perfect
connectivity and coverage across multiple devices connected concurrently throughout the
home. The G.hn Powerline Wi-Fi extender allows users to take Wi-Fi with them anywhere
throughout the home or backyard and enjoy a seamless wireless experience.
1.1 System Requirements
Computer or network devices with wired or wireless network interface card
Any connected devices must feature a network port
Web browser (Microsoft Internet Explorer 4.0 or above, Google Chrome web
browser, Opera web browser, or Safari web browser)
An available AC power socket (100 – 240 V, 50/60Hz)

6
Chapter 2 How to Install GPL-1200WAC
(A) Understanding the AC1200 G.hn Powerline Adapter
How to Create a Basic (2 unit) G.hn Powerline Network – Recommended Setup
A G.hn Powerline Network can consist of a minimum of 2 and up to 16 devices total.
**The GPL-1200 can be replaced by another G.hn Powerline Adapter.
NOTE: The following steps show how to create or add onto a G.hn Powerline Network
using a GPL-1200WAC.
(A minimum of two G.hn Powerline Adapters are required to create a proper connection.)
If this is the first time you are setting up a G.hn Powerline Network please continue to
Section B.
If you already have an established G.hn Powerline Network and are adding an
additional adapter, please skip to Section C.
Purpose
Recommended
Primary Adapter
Second Adapter
• Connecting a single dedicated
Internet Device
GPL-1200**
GPL-1200**
• Bringing wireless to a remote
location
GPL-1200**
GPL-1200WAC
• Connecting a PoE Enabled Device
GPL-1200**
GPL-1200PoE
LED Descriptions
are Listed Below
Reset Button
Press for more than10
seconds for Factory Reset.
WPS Connection Button
Gigabit
Ethernet
Port
Power Port
WiFi
Power
On/Off
Button
On/Off
Power
Button
Adapter
Pairing
Button

7
(B) Creating a New G.hn Network
1. Plug a GPL-1200* unit into the power outlet closest to the Network Device
(Modem, Router). Do not plug the adapter into a power strip or surge protector,
as network performance could degrade significantly.
*NOTE: It is suggested that you use the GPL-1200 as the primary connection to the
Network Device, however the GPL-1200 can be replaced by another G.hn
Powerline Adapter.
2. Connect the GPL-1200 to a Network Device with an Ethernet (RJ-45) cable.
(Wait 10 seconds for the Network Indicator to light up GREEN, which
indicates a good connection. A flashing GREEN light indicates that the device
has a good connection and is also sending data).
Network Device
(Modem, Router)
Ethernet Cable
GPL-1200
GPL-1200

8
(C) Adding to an Existing G.hn Network
3. Plug the GPL-1200WAC into the power outlet closest to the location you want to
add wireless and/or near an Internet-Enabled Device you would like to directly
connect to the adapter. The PLC Indicator should light up.
4. Optionally, to add an Internet-Enabled Device, directly connect the GPL-
1200WAC to the Internet-Enabled Device with an Ethernet cable. (The Network
Indicator on the GPL-1200 and the LAN Indicator of the GPL-
1200WAC should both be GREEN representing a strong connection).
(D)
Security Setup
NOTE: G.hn Adapters will automatically “pair” in “non-secure” mode. It is highly
recommended to follow Step 5 to create a secure connection.
5. Press the “Config” Button of a GPL-1200 in the existing network for 2 seconds. You will
see the Security Indicator start flashing GREEN. Within two minutes, press the “PLC
Sync” Button on the GPL-1200WAC for 2 seconds until you see the Security Indicator
start flashing GREEN.(When the adapters are successfully paired and secured
with a strong connection the GPL-1200’s Connection Indicator and Security
Indicator will be solid GREEN and the GPL-1200WAC’s PLC Indicator and
Security Indicator will be solid GREEN.)
6. Repeat Steps 3 to 5 to add additional adapters/devices.

9
(E) Connecting Your WiFi Devices to the New GPL-
1200WAC
Access Point
7. For some devices (E.g. laptops, cameras, set-top-boxes, etc.) wireless
connectivity can be done via WPS (Wireless Protected Setup). WPS allows you to
simply connect devices to the new Access Point without entering a
username/password manually. To do this, please follow the instructions in
Section F below.
8. You have created a new Internet Access Point and it is now active and ready to
use! To connect your WiFi devices to your new GPL-1200WAC WiFi Access Point,
select the GPL-1200WAC Access Point using your WiFi device’s standard network
list. The Network Name (SSID) and Password (WiFi Key) can be found on the
bottom of the GPL-1200WAC.
9. Go to Section G.
(F) Setup of Wireless Devices via WPS
(WiFi Protected Setup)
10. Press and hold the “WPS” Button for more than 2 seconds on the GPL-1200WAC
to activate its WPS. The GPL-1200WAC’s WiFi Indicators should flash
to indicate a WPS connection is in progress.
11. Within two minutes, press the “WPS” Button (often the WPS/Reset Button) on
your remote Internet-Enabled Devices to activate WPS.
12. The devices will establish a secure connection.

10
(G) You Have Successfully Installed Your G.hn Powerline
Adapter with WiFi!
(H) Troubleshooting
The following information should help you diagnose basic setup or installation problems.
1) SECURITY Indicator is OFF: The SECURITY Indicator is off when the Powerline Adapter
is paired in “non-secure” mode to the G.hn Network. It is
optional to pair the device in “secure mode.” To pair the
device in “secure mode," please refer to Section D, Step
5.
2) LAN Indicator is OFF: The LAN Indicator is off when the
Powerline Adapter does not have a device directly
connected to its Ethernet Port. If there is a device
connected and if the LAN Indicator is off, please check
that the Ethernet port of the Powerline Adapter is
connected firmly to the Ethernet port of the device. You
can also check the condition of the Ethernet cable by
using another Ethernet cable to test if the indicator turns
on.
3) WiFi Indicators are OFF: The WiFi Indicators are off
when the WiFi is not enabled. You can turn on both indicators, (i.e. enable WiFi) by
pressing the “WiFi” Button on the front of the device. You can also login to the
GPL-1200WAC Web Interface and enable WiFi (5GHz only). Please refer to section 6.5
of the User Manual for additional details.
SECURITY
LAN
WiFi
PLC
PLC
Security
LAN
5 GHz 2.4 GHz

11
4) PLC Indicator is OFF: The PLC Indicator is off when the Powerline Adapter is not
paired to the G.hn Network. If this indicator is off, then plug both Powerline Adapters
that you are attempting to pair into power outlets that are located within the same
room. All of the indicators of the device should blink (approx. 10 seconds), and
the PLC Indicator should light up. If the PLC Indicator does not light up, it may indicate
the existing G.hn network is secure and you have to pair the GPL-1200WAC to it in
“secure mode.” To do so, press the “Config" Button on the GPL-1200 for 2 seconds
(Holding for more than 4 seconds will clear the security key and require a re-pairing).
Within 2 minutes, press the "PLC Sync" Button on the GPL-1200WAC for 2 seconds. The
PLC Indicator will then light up GREEN. Afterwards, you can plug the units back into
their original location.
* If you have tried all of the above and are still experiencing problems, you can reset all
devices to factory default by pushing the “Reset” Button on the GPL-1200WAC for more
than 10 seconds AND the “Config” Button on the GPL-1200 for 10 seconds.
FOR MORE HELP: For instructions on advanced features, FAQ, etc., please visit the GPL-
1200WAC online Product Webpage on our website.
GPL-1200WAC
GPL-1200

12
Chapter 3 LED Indications
LED
COLOR
MODE
DESCRIPTION
Green
On
The current connection (line rate) is more than 40
Mbps
Blink
System rebooting
Orange
On
The current connection (line rate) is more than 20
Mbps and less than 40 Mbps
Red
On
(1). The current connection (line rate) is between 1
and 20 Mbps per second)
(2). The PLC is in unsecure mode* and connected
to other PLCs
Off
No PLC connection exists
Green
Off
2.4GHz WLAN is disabled
On
2.4GHz WLAN is on or activity occurring (tx/rx data
and message)
Blink
(1). Fast Blinking:
1.WPS SSID/Key sync copy failed
(2). Slow Blinking:
1. Normal WPS sync activity
2. WPS SSID/Key sync activity
3. System in Factory Reset process
Blue
Off
5GHz WLAN is disabled
On
5GHz WLAN is on or activity occurring (tx/rx data
and message)
Blink
(1). Fast Blinking:
1.WPS SSID/Key sync copy failed
(2). Slow Blinking:
1. Normal WPS sync activity
2. WPS SSID/Key sync activity
3. System in Factory Reset process
Green
Off
LAN Interface down
On
LAN Interface up 10/100/1000
Orange
Blink
(1). Fast Blinking:
1. WPS SSID/Key sync copy failed
(2). Slow Blinking:
1. WPS SSID/Key sync activity
2. System in Factory Reset process
Green
Off
Node is not secure, it has neither received nor
generated network key parameters (domain name
and encryption key)
On
Node is secure (it has either received or generated
network keys)
Blink
Node is in configuration mode (able to exchange
network keys)

13
Chapter 4 Button Functions
BUTTON
WORDING ON
ENCLOSURE
BUTTON
FUNCTION
SECONDS
TO PUSH
BUTTON
DESCRIPTION
1
On/Off
Power the device
On and Off
N/A
Press the power
button once to turn
the GPL-1200WAC On.
Press the power
button once to turn
the GPL-1200WAC Off.
2
PLC Sync
PLC pairing
+2sec
Press more than 2
seconds ( LED
starts slow blinking),
and configuration
period is open
3
WPS
WPS
2-5 sec
1. Press for 2-5
seconds, and both
& LEDs
blink slowly.
2. Then release the
button, the AP
WPS is in process.
WiFi SSID/PW
copy
+5 sec
Press for +5 seconds,
&, ,
and the LEDs
blink slowly, the WLAN
is in sync with main
gateway for SSID and
Key on 2.4GHz
4
RESET
Factory reset
+10 sec
Press more than 10
seconds: a factory
reset of the system
(both G.hn & WiFi) is
performed
5
WiFi ON/OFF
Switch off/on
2.4GHz/5GHz
WiFi interfaces
+2 sec
Disable/enable both
2.4G/5GHz WLAN
interfaces by pushing
the button for +2s
2&3
N/A
Switch off/on all
LED’s
+2 sec
Turn on/off all LED’s
by pushing both PLC
Sync and WPS buttons
simultaneously for +2s

14
Chapter 5 wireless System and Network Setup
5.1 Connect to power line access point by web
browser
GPL-1200WAC supports two kinds of management IP.
(1) DHCP client, which gets a dynamic IP address from the Modem/Broadband
Router/Home Gateway that it is connected to by default.
(2) Static IP, 192.168.0.5 by default, which can be configurable in the web UI.
Before you can connect to the power line access point and start configuration procedures,
your computer must be able to get an IP address automatically (dynamic IP address).
GPL-1200WAC gets a dynamic IP address from Modem/Broadband Router/Home Gateway
that it is connected to by default. However, the current IP info of GPL-1200WAC would be
displayed at the Modem/Broadcom Router/Home Gateway.
Also, the static IP of GPL-1200WAC can be accessed by the default static IP address of
192.168.0.5, subnet mask 255.255.255.0. Change your PC’s static IP address to
192.168.0.100, subnet mask 255.255.255.0 for accessing web UI management.

15
5.2 Connecting to Web Management Interface
All functions and settings for the Wi-Fi AP of GPL-1200WAC must be configured via the
web management interface. Please start your web browser, and input ‘192.168.0.5’in the
address bar, then press the ‘Enter’ key. The following will be displayed:
Please input user name and password in their respective fields, default user name is
‘root’, and default password is ‘12345’, then press the Login button, to view the web
management interface of this access point.
NOTE: If you can’t see the web management interface, and you’re
being prompted to input user name and password again, it means
you didn’t input username and password correctly.

16
5.3 View System Information
The system information is on the left-side of the web page as shown below.

17
Here are descriptions of every item:
Heading
Description
2.4GHz Network
Displays 2.4GHz AP status, Channel, MAC, BSSID and
SSID string.
5GHz Network
Displays 5GHz AP status, Channel, MAC, BSSID and
SSID string.
Common
WiFi and G.hn Image version information.
WiFi Image version:
GPL-1200WAC-WLAN-684125CTU-C01_R01
G.hn Image version:
GPL-1200WAC-PLC-64R39873CTU-C01_R01

18
5.4 Network Settings
This page allows you to set the IP address for the web UI. Click the Apply button to
reboot the system and implement your changes.
5.5 Stations List
This is page shows the information of wireless Stations that are connected to GPL-
1200WAC.
Here are descriptions of every item:
Heading
Description
MAC address
This option will list the Wireless stations connected to
the GPL-1200WAC at the 2.4G or 5GHz Interface.
Rate (MCS)
MCS# on the wireless interface with the station.
Bandwidth
Bandwidth, 20/40MHz for 2.4GHz, 20/40/80MHz for
5GHz

19
5.6 Network Timing
This page allows you to set the local time zone for TR069 management.
Heading
Description
Enable NTP
You can decide to set up NTP client by clicking checkbox.
Primary NTP Server
Input the Primary NTP Server, for example:
us.pool.ntp.org, etc.
Secondary NTP Server
Input the Secondary NTP Server, for example:
wwv.nist.gov
Local Time Zone
You can select your Time Zone from the drop-down
menu.
