NexusLink GPL-2000S4 User manual

261072-040
261072-048
GPL-2000S4
G.hn Powerline Adapter
User Manual
Version A1.0, December 15, 2020

1
Preface
This manual provides information related to the installation and operation of this
device. The individual reading this manual is presumed to have a basic
understanding of telecommunications terminology and concepts.
If you find the product to be inoperable or malfunctioning, please contact technical
support for immediate service by email at [e-mail]
For product update, new product release, manual revision, or software upgrades,
please visit our website at https://nexuslinkusa.com
Important Safety Instructions
With reference to unpacking, installation, use, and maintenance of your electronic
device, the following basic guidelines are recommended:
•Do not use or install this product near water, to avoid fire or shock hazard. For
example, near a bathtub, kitchen sink or laundry tub, or near a swimming pool.
Also, do not expose the equipment to rain or damp areas (e.g. a wet
basement).
•To safeguard the equipment against overheating, make sure that all openings in
the unit that offer exposure to air are not blocked.
•Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightening. Also, do not use
the telephone to report a gas leak in the vicinity of the leak.
WARNING
•Disconnect the PLC from the power source before servicing
•For indoor user only
•Do NOT open the casing
•Do NOT use near water
Power Specifications:
I/P： 100-240VAC, 50/60Hz, 0.2A
Copyright
Copyright©2020 NexusLink. All rights reserved. The information contained herein
is proprietary to NexusLink. No part of this document may be translated,
transcribed, reproduced, in any form, or by any means without prior written
consent of NexusLink.
NOTE: This document is subject to change without notice.

2
Protect Our Environment
This symbol indicates that when the equipment has reached the end of its
useful life, it must be taken to a recycling centre and processed separate
from domestic waste.
The cardboard box, the plastic contained in the packaging, and the parts that make
up this PLC can be recycled in accordance with regionally established regulations.
Never dispose of this electronic equipment along with your household waste; you
may be subject to penalties or sanctions under the law. Instead, please be
responsible and ask for disposal instructions from your local government.

3
Table of Contents
CHAPTER 1 PRODUCT INFORMATION ............................................................................................. 4
1.1 FRONT PANEL AND LED INDICATORS................................................................................................... 4
1.2 SIDE PANEL .......................................................................................................................................... 5
1.3 BOTTOM PANEL ................................................................................................................................... 5
1.4 QUICK INSTALL GUIDE ......................................................................................................................... 6
1.5 HOW TO UNDERSTAND THE COVERAGE LED COLORS ................................................................... 10
CHAPTER 2 G.HN/POWERLINE SETUP ........................................................................................... 11
2.1 IP CONFIGURATION ............................................................................................................................ 11
2.2 LOGGING IN ....................................................................................................................................... 13
CHAPTER 3 G.HN INTERFACE ........................................................................................................... 14
3.1 BASIC CONFIGURATION...................................................................................................................... 14
3.2 NDIM CONFIGURATION ..................................................................................................................... 15
3.3 ENCRYPTION CONFIGURATION VIA WEB UI ...................................................................................... 15
CHAPTER 4 IP INTERFACE ................................................................................................................. 16
4.1 IP CONFIG .......................................................................................................................................... 16
CHAPTER 5 ETHERNET INTERFACE............................................................................................... 18
CHAPTER 6 DEVICE INTERFACE ..................................................................................................... 19
6.1 HARDWARE INFORMATION ................................................................................................................. 19
6.2 SOFTWARE INFORMATION................................................................................................................... 19
6.3 SECURITY ........................................................................................................................................... 19
6.4 SW UPDATE ........................................................................................................................................ 19
6.5 HTTP SW UPDATE ............................................................................................................................. 20
CHAPTER 7 MULTICAST INTERFACE ............................................................................................. 21
7.1 MCAST CONFIGURATION .................................................................................................................. 21
CHAPTER 8 QOS MENU ....................................................................................................................... 23
8.1 QOS CONFIGURATION ........................................................................................................................ 23
CHAPTER 9 VLAN INTERFACE ......................................................................................................... 25
9.1 VLAN CONFIGURATION .................................................................................................................... 25
CHAPTER 10 G.HN SPECTRUM INTERFACE ................................................................................. 27
10.1 NOTCHES ......................................................................................................................................... 27
CHAPTER 11 LOG FILE INTERFACE ................................................................................................ 28
11.1 LOG FILE .......................................................................................................................................... 28
CHAPTER 12 ADVANCED INTERFACE............................................................................................. 29
CHAPTER 13 SPECIFICATIONS ......................................................................................................... 30
The setup images used in this manual are for reference only. The contents of these
images may vary according to firmware version. The official image contents are based
on the newest firmware version.

4
Chapter 1 Product Information
1.1 Front Panel and LED indicators
LED
Color
Mode
Description
Power LED
Green
On
The Adapter is powered on.
Off
Off
The Adapter is powered off.
G.hn Link LED
Green
On
The current connection (line rate) is more than 40Mbps.
Orange
On
The current connection (line rate) is between 5Mbps and
40Mbps.
Red
On
The current connection (line rate) is 5Mbps or less.
Off
Off
No G.hn detected.
Security LED
Green
On
The Adapter is secure (it has received or generated
network keys).
Blink
The Adapter is in the process of being secure.
Off
Off
The Adapter is not secure.

5
1.2 Side Panel
Item Name
Description
Security
Push the button for more than 2 seconds to pair the devices
and get a random domain name and password.
Reset
Press more than 10 seconds (until all three LED’s are
OFF) and release: a factory reset is performed.
1.3 Bottom Panel
LED
Color
Mode
Description
Ethernet
LED
Green
On
An Ethernet LAN connection is established
@1000Mbps.
Blink
Data over the Ethernet LAN connection is being
transmitted @1000Mbps.
Yellow
On
An Ethernet LAN connection is established
@10/100Mbps.
Blink
Data over the Ethernet LAN connection is being
transmitted @10/100Mbps.
Off
Off
An Ethernet LAN connection is not established.
Ethernet Ports

6
1.4 Quick Install Guide
Understanding Your Powerline Adapter
LED
Color
Mode
Description
Power LED
Green
On
The Adapter is powered on.
Off
Off
The Adapter is powered off or faulty.
Connection
LED
Green
On
The current connection (line rate) is more than
40Mbps.
Orange
On
The current connection (line rate) is between 5Mbps
and 40Mbps.
Red
On
The current connection (line rate) is less than
5Mbps.
Off
Off
An Adapter connection does not exist.
Security
LED
Green
On
The Adapter is secure (it has received or generated
network keys).
Blink
The Adapter is in the process of being secure.
Off
Off
The Adapter is not secure.
Ethernet
LED
Green
On
An Ethernet LAN connection is established
@1000Mbps.
Blink
Data over the Ethernet LAN connection is being
transmitted @1000Mbps.
Yellow
On
An Ethernet LAN connection is established
@10/100Mbps.
Blink
Data over the Ethernet LAN connection is being
transmitted @10/100Mbps.
Off
Off
An Ethernet LAN connection is not established.
Ethernet
Port
LED Icons
Descriptions
are provided
below
Security Button
Enables Device
Synchronization
in Secure Mode
Reset Button
Press for more
than 10 seconds
for Factory Reset
A

7
Initial Powerline Adapter Setup
NOTE: A minimum of two G.hn Powerline Adapters are required.
If you are setting up a G.hn Powerline network for the first time, then
follow the steps below.
If you are adding to an existing G.hn Powerline network, then skip to
Steps 3-5.
1. Plug one Powerline Adapter into a power outlet near your Network
Device (Modem, Router, or Access Point).
For maximum performance, please plug the Powerline Adapter
directly into the wall outlet. Do not plug into a power strip or surge
protector, as network performance could degrade significantly.
2. Connect the Powerline Adapter to your Network Device (Modem,
Router, or Access Point) with an Ethernet (RJ-45) cable. Wait 10
seconds for the Ethernet LED to light up GREEN, which indicates a
connection is established. A flashing GREEN light indicates that the
device is sending data.
Ethernet Cable
Network Device
(Modem, Router, or
Access Point)
B

8
Device Connection
3. Plug the additional Powerline Adapter into a power outlet
near the Internet-enabled device (ex. TV, PC, STB, DVR, etc.).
4. Connect this Powerline Adapter to the Internet-enabled device
(ex. TV, PC, STB, DVR, etc.). with an Ethernet (RJ-45) cable. The
Connection LED and Ethernet LED on both of the Powerline
Adapters should be GREEN, which represents a strong connection.
Pairing the Powerline Adapters
5. Press the Security Button on one Adapter until you see the
Security LED start blinking GREEN. Then press the Security
Button on the second Adapter until you see the Security LED
start blinking GREEN. The Security LED and the
Connection LED should be solid GREEN on both Adapters
when they are successfully paired.
Note: If you are adding to an existing G.hn Powerline network,
then press the Security Button on any Adapter in the existing G.hn
Powerline network until you see the Security LED start blinking
GREEN. Then press the Security Button on the Powerline Adapter
you are adding until you see the Security LED start blinking
GREEN.. The Security LED and the Connection LED will light up
GREEN on all adapters within the G.hn Powerline network.
6. Repeat Steps 3 to 5 to add additional Powerline Adapters.
Please note that up to 16 devices can be connected within
a G.hn Powerline Network.
You Have Succesfully Set Up Your G.hn Powerline Network!
C
E
D
Network Device
(Modem, Router, or
Access Point)
Set-Top-Box

9
Troubleshooting
The following information should help you diagnose basic setup
or installation problems.
Connection LED is OFF: The Connection LED shows that the
Powerline Adapter is connected to the G.hn Network. If the
indicator is off, then plug both Powerline Adapters that you are
attempting to pair into power outlets that are located within the
same room. The Connection LED should light up GREEN. If not,
then press the Reset Button on each adapter for more than 10
seconds. Afterwards, you can plug the units back into their
original location.
Ethernet LED is OFF: If the Ethernet LED fails to light up, check that
the LAN port of the Powerline Adapter is connected firmly to the
LAN port of the other device. To check the condition of the
Ethernet cable, use another cable to test the same connection.
Security LED is OFF: If the Security LED is off, then it means the
Powerline Adapter is not securely paired. Press the Security Button
on the Powerline Adapter for 2 seconds until you see the Security
LED start flashing GREEN.Repeat this on the other Powerline
Adapter. The Security LED and the Connection LED will light up
GREEN on both adapters. This means the adapters are now
securely paired and have a strong connection.
To join an existing G.hn Powerline network, press the Security
Button on any Powerline Adapter in the existing G.hn Powerline
network for 2 seconds until you see the Security LED start flashing
GREEN. Then press the Security Button on the additional Powerline
Adapter. The Security LED and the Connection LED will light up
GREEN on both adapters.
*If you have tried the above and are still experiencing problems, you
can reset all devices to factory default by pushing the Reset Button for
more than 10 seconds (until all the LEDs of the device blink).
F

10
1.5 How to understand the COVERAGE LED colors
The COVERAGE LED displays quality of the network and provides important
information that will provide solutions to common questions, such as why a High
Definition (HD) movie is not showing or shows with pixels. The COVERAGE LED
indicator will vary its color depending on the estimated speed of the Powerline
connection. The speed is measured in Megabits Per Second (Mbps).
Color
Information
RED
The current connection has low quality, basic Internet activities
ex. 5Mbps are possible but the Powerline is unable to transmit either
a Standard Movie or High Definition (HD) Movie.
ORANGE
The current connection has good quality and Internet activities ex.
greater than 5Mbps and less than 40Mbps to transmit Standard
Movie and HD Movie.
GREEN
The current connection has excellent quality and Internet
activities ex. greater than 40Mbps to transmit multiple Standard
Movies and HD Movies.

11
Chapter 2 G.hn/Powerline Setup
2.1 IP Configuration
DHCP MODE
GPL-2000S4 supports two kinds of management IP simultaneously.
To obtain an IP address from the DCHP server, follow the steps provided below.
NOTE: The following procedure assumes you are running Windows. However,
the general steps involved are similar for most operating systems (OS).
Check your OS support documentation for further details.
STEP 1: From the Network Connections window, open Local Area Connection (You
may also access this screen by double-clicking the Local Area Connection
icon on your taskbar). Click the Properties button.
STEP 2:Select Internet Protocol (TCP/IP) and click the Properties button.
STEP 3: Select Obtain an IP address automatically as shown below.
STEP 4: Click OK to submit these settings.
If you experience difficulty with DHCP mode, you can try static IP mode instead.

12
STATIC IP MODE
In static IP mode, you assign IP settings to your PC manually.
Follow these steps to configure your PC IP address to use subnet 192.168.0.x.
NOTE: The following procedure assumes you are running Windows. However,
the general steps involved are similar for most operating systems (OS).
Check your OS support documentation for further details.
STEP 1:From the Network Connections window, open Local Area Connection (You
may also access this screen by double-clicking the Local Area Connection
icon on your taskbar). Click the Properties button.
STEP 2:Select Internet Protocol (TCP/IP) and click the Properties button.
STEP 3: Change the IP address to the 192.168.0.x (5<x<255) subnet with subnet
mask of 255.255.255.0. The screen should now display as shown below.
STEP 4: Click OK to submit these settings.

13
2.2 Logging In
Perform the following steps to login to the web user interface.
STEP 1: Start the Internet browser and enter the default IP address for the device
in the Web address field. For example, if the default IP address is
192.168.0.5, type http://192.168.0.5
STEP 2: A dialog box will appear, such as the one below. Input the default
Authentication Password.
Authentication Password: admin
Click OK to continue.
Note:
The Factory Reset password is: betera

14
Chapter 3 G.hn Interface
3.1 Basic Configuration
•MAC Address Displays the MAC address of the device.
•Device ID Device ID of this node.
•Domain Name string of all nodes in the network.
•Force node Type force the modem to have a particular role (END POINT or
DOMAIN MASTER)
•Node Type
Shows the current status of the device.
•G.hn profile of all nodes in the network: selecting which G.hn profile must
be applied to the network (PLC 50MHz, PLC 50MHz with MIMO, PLC 100MHz,
COAX 100MHz and PHONE 100MHz).

15
3.2 NDIM Configuration
•NDIM mode set to Automatic for enabling automatic DOD selection
functionality and set to Manual for manual configuration of DOD.
•Domain ID (DOD) manually set the DOD number from 1 to 15 to use a different
preamble seed than the default 0.
3.3 Encryption Configuration via WEB UI
•Pairing Password used for authentication. Write a custom password to
manually create a secure domain.
Available Connections
•In this tab table, all the available G.hn connections are presented. Remote
node DID and MAC address, transmission and reception physical speeds.

16
Chapter 4 IP Interface
4.1 IP config
In the IP configuration tab of one G.hn node, the IPv4 and IPv6 settings can be read
and changed.
IPv4 subsection:
•DHCPv4 enabled: in the case of choosing ”NO" IP configuration in the following
parameters, the IPv4 Address, Subnet Mask, Default Gateway and DNS should
be configured; fill these fields in. In the case of choosing “YES” they will be
filled automatically when configuration is received from the DHCPv4 server.
•IPv4 address/netmask: IPv4 address / netmask of this device.
•Default Gateway: IPv4 gateway to connect the device to other LAN segments.
•DNS: Domain Name Server IP (IPV4).
•Additional address #1/2: additional fixed IPv4 addresses that will always be
configured at boot time.

17
IPv6 subsection:
•DCHPv6 enabled: in the case of choosing ”NO" IP configuration in the following
parameters, the IPv6 Address, prefix, Default Gateway and DNS should be
configured; fill these fields in. In the case of choosing “YES” they will be filled
automatically when configuration is received from the DHCPv6 server.
•IPv6 Address / prefix: IPv6 address / prefix of the device to read the node's
DHCPv6 address in case the DHCPv6 is enabled.
•Default Gateway: IPv6 gateway to connect the node to other LAN segments.
•DNS: Domain Name Server IP (IPV6).
•Additional address #1/2/3/4: additional fixed IPv6 addresses that will always
be configured at boot time.
•IPv6 Link-Local Address: to read the node's Link Local address.
•IPv6 SLAAC address: IPv6 address, automatically obtained by means of the
SLAAC mechanism.
NTPv4/v6 subsection:
•NTPv4/v6 client enabled: Enable/disable NTP client.
•Resynchronization time: Configure re-synchronization interval time in
minutes.
•NTP IPv4/v6 address: Hostname or IP (IPv4 or IPv6) of NTP server.

18
Chapter 5 Ethernet Interface
The Ethernet table shows the status & Info of the Ethernet interface; including
Interface, Speed, Duplex, Interface Type, Mode, Internal PHY & Link.
Powersaving
Ethernet powersaving can be disabled, enabled by Ethernet link or enabled by
Ethernet activity; idle timer can be configured as well.

19
Chapter 6 Device Interface
6.1 Hardware information
In this tab, basic information such as MAC Address and Serial Number of the selected
node is shown.
6.2 Software information
Shows the FW version and system uptime.
6.3 Security
The nodes in the network: to change the configuration password string from the
default ("admin") to another; decided by the user.
6.4 SW update
Current loaded firmware version is shown. Any flash section can be upgraded; the first
flash section should be selected and after clicking on the "OK" button the
corresponding file should be chosen. Usually, a reboot should be performed
afterwards to make sure the changes are effective.
The protocol is by FTP client or TFTP client. L2 is proprietary and is reserved for future
use.
