Nice TITAN12L 912L Installation and operating manual

Residential | Commercial | Industrial | Anti-Ram | Parking
800-321-9947 •253-867-3700 • www.hysecurity.com
912L LA
TITAN12L/12L1 912L actuator
Vehicular swing gate actuator
MX4685 REV. A ©2019
Installation Reference Manual
IMPORTANT!
These instructions apply only to the 912L actuator.
Control box installation/operation is described in a separate control box manual.

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
2| www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
LIST OF INSTRUCTIONS
INSTRUCTION 1A: INSTALL PIVOT ARM TO GATE (PULL-TO-OPEN) ............. 5
INSTRUCTION 1B: INSTALL PIVOT ARM TO GATE (PUSH-TO-OPEN) ............ 6
INSTRUCTION 2: MOUNT ACTUATOR TO PIVOT ARM ............................. ...... 7
INSTRUCTION 3: AFFIX GATE BRACKET TO ACTUATOR ARM ....................... 8
INSTRUCTION 4: POSITION GATE BACKET ON GATE ....................................10
INSTRUCTION 5: AFFIX GATE BRACKET TO GATE ......................................... 11
INSTRUCTION 6: OPEN MECHANICAL RELEASE .............................................12
INSTRUCTION 7: MANUALLY SET GATE OPEN/CLOSE LIMITS ..................... 13
INSTRUCTION 8: RUN ACTUATOR CABLE(S) TO CONTROL BOX .................14
INSTRUCTION 9A, 9B, 9C, 9D: WIRE ACTUATOR TO CONTROL BOARD ....15
INSTRUCTION 10A, 10B: SETTING ACTUATOR FINE LIMITS ..........................19
INSTRUCTION 11: ACTUATOR CABLE/TERMINAL WIRING ........................... 21
CONTENTS
LIST OF INSTRUCTIONS ......................................................................2
SECTION 1: TITAN 912L ACTUATOR OVERVIEW ............................3
SECTION 2: INSTALLATION SAFETY ................................................4
SECTION 3: TOOLS NEEDED FOR INSTALLATION ........................4
SECTION 4: ACTUATOR - MECHANICAL INSTALLATION .............5
3.1 MANUALLY SET GATE OPEN/CLOSE LIMITS ......................13
3.2 RUN ACTUATOR CABLE(S) TO CONTROL BOX .................14
3.3 936 CONTROL BOARD WIRING: PULL-TO-OPEN ..............15
3.4 936 CONTROL BOARD WIRING: PUSH-TO-OPEN .............16
3.5 1050 CONTROL BOARD WIRING: PULL-TO-OPEN ............17
3.6 1050 CONTROL BOARD WIRING: PUSH-TO-OPEN ...........18
3.7 SETTING ACTUATOR FINE LIMITS .......................................19
3.8 ACTUATOR CABLE REPLACEMENT WIRING ...................... 21
SECTION 4: PART DRAWINGS ........................................................ 22
SECTON 5: WARRANTY .................................................................... 23

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 3
• TITAN 912L-1 = Actuator with 12’ harness
• TITAN 912L-2 = Actuator with 42’ harness
(dual gate only)
PIVOT ARM (P/N 1116)
ACTUATOR BOLT KIT
(P/N 1125)
GATE BRACKET,
BLACK
(P/N 10025215)
TITAN912L ACTUATOR PARTS IDENTIFICATION
PART# DESCRIPTION QTY
912L-1 ACTUATOR WITH 12 FOOT HARNESS 1
912L-2 (DUAL GATE ONLY) ACTUATOR WITH 42 FOOT HARNESS 1
1116 PIVOT ARM 1
10025215 or PD0959A0000 GATE BRACKET (BLACK or ANODIZED) 1
1125 ACTUATOR BOLT KIT 1
TITAN912L ACTUATOR SPECIFICATIONS
DRIVE Electromechanical Stainless Steel Screw
GATE LENGTH and WEIGHT MAX. • Up to 600 lb. for 20 foot leaf (272 kg for 6 m)
• Up to 1000 lb for an 8 ft leaf (453 kg for 2.4 m)
OPEN/CLOSE TIME (TO 90°) 14 - 16 seconds (adjustable)
TEMPERATURE RATING -4º to 122º F (-20º to 50º C)
OPERATING VOLTAGE 12VDC
ACTUATOR DIMENSIONS 43(L) x 4(W) x 6.75 inches (D)
[109.2(L) x 10(W) x 17.5 cm (D)]
USER CONTROLS 936 or 1050 control board
LISTED TO UL325 936 & 1050 Control Boards: Usage Class I, II, III, IV
ACTUATOR WEIGHT 19.75 lb (8.96 kg)
Congratulations on selecting a Nice gate operator TITAN 912L actuator. With proper selection, system de-
sign, installation and maintenance this operator should provide years of reliable operation. This manual covers
ONLY the installation of the actuator.
IMPORTANT!
For control box installation, wiring, operation, maintenance instructions and all safety information, refer to
the appropriate control box installation manual used for the system:
• CBOX936
• CBOX1050
SECTION 1: TITAN 912L ACTUATOR OVERVIEW
GATE BRACKET,
GALVANIZED
(P/N PD0959A0000)

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
4| www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
• DISCONNECT POWER AT THE CONTROL PANEL BEFORE MAKING ANY ELECTRIC SERVICE POWER
CONNECTIONS.
• BE AWARE OF ALL MOVING PARTS AND AVOID CLOSE PROXIMITY TO ANY PINCH POINTS.
Below is a list of tools necessary for installation of the Titan actuator:
• Welder (for pivot arm) unless optional bolt-on pivot arm (P/N 446) is used.
• Basic hand tools (screwdrivers, wrenches, pliers, etc..)
• Torx 25 tool (for removing actuator cover screws)
• Level (for ensuring pivot arm and actuator are level).
• Framing square (for determining pivot arm location)
• Torch/Chop Saw (for cutting pivot arm)
• Grinder (for sanding Pivot Arm)
• Welder and associated tools (for axing pivot arm to post)
IMPORTANT!
• The gate operator installation is NOT a “do-it-yourself” project. Use a qualied gate operator installation
company to install this system to ensure a safe and reliable installation.
• It is the responsibility of the property owner to ensure the installer is qualied to carry out the installation
in a safe and professional manner.
• Consult local government agencies for up-to-date rules and regulations to satisfy licensing, codes or
regulations that regulate automated gate system design and installation.
• The gate for which the gate operator is intended to be used should itself be installed correctly so that it
is level and plumb and the gate opens easily and evenly.
• Note that Nice swing gate systems are not intended for installation on an incline.
SECTION 2: INSTALLATION SAFETY
SECTION 3: TOOLS NEEDED FOR INSTALLATION
WARNING!
READ ALL SAFETY INFORMATION WHEN INSTALLING A SWING GATE SYSTEM! SEE EITHER
OF THE FOLLOWING MANUALS FOR SAFETY INFORMATION:
• CBOX936 Control Box Installation Manual (with 936 control board)
• CBOX1050 Control Box Installation Manual (with 1050 control board)

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 5
LEFT SIDE VERTICAL VIEW
IMAGE 1A-1: "PULL TO OPEN" PIVOT ARM INSTALLATION
INSTALL PIVOT ARM TO GATE: PULL-TO-OPEN
1A
1. Securely mount the pivot arm to the hinge post (IMAGE 1A-1).
2. If necessary, cut pivot arm for correct placement of the actuator mounting
hole. Measurements are taken from the center of pivot of the gate hinge.
3. It is strongly recommended to weld the pivot arm to the hinge post.
TOP VIEW
6” 6”
13” 13”
SECTION 4: ACTUATOR - MECHANICAL INSTALLATION
NOTE: Welding is much
preferred but Nice offers an
optional bolt-on pivot arm
(P/N 446) for when welding is
not possible.
PIVOT ARM PIVOT ARM
PIVOT ARM
1/2”
HINGE POST
CENTER OF HINGE
CENTER LINE OF
ATTACHMENT POINT
FOR GATE BRACKET
CENTER OF HINGE
GATE CLOSED
DIRECTION OF OPENING
CAUTION!
NEVER WELD PARTS TO THE GATE OR POSTS WHEN THE CONTROL BOARD IS
POWERED TO AVOID IRREPAIRABLE DAMAGE TO THE CIRCUIT BOARD!
HINGE POST HINGE POST

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
6| www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
IMAGE 1B-1: "PUSH TO OPEN" PIVOT ARM INSTALLATION
1B
1. Securely mount the pivot arm to the hinge post (IMAGE 1B-1).
2. If necessary, cut pivot arm for correct placement of the actuator
mounting hole. Measurements are taken from the center of pivot of
the gate hinge.
3. It is strongly recommended to weld the pivot arm to the metal post.
INSTALL PIVOT ARM TO GATE: PUSH-TO-OPEN
CAUTION!
NEVER WELD PARTS TO THE GATE OR POSTS WHEN THE CONTROL BOARD IS
POWERED TO AVOID IRREPAIRABLE DAMAGE TO THE CIRCUIT BOARD!
TOP VIEW
6” 6”
11” 11”
PIVOT ARM
PIVOT ARM
PIVOT ARM
1/2”
HINGE POST
CENTER OF HINGE
HINGE POST HINGE POST
CENTER LINE OF
ATTACHMENT POINT
FOR GATE BRACKET
CENTER OF HINGE
GATE CLOSED
DIRECTION OF OPENING
LEFT SIDE VERTICAL VIEW
NOTE: Welding is much preferred
but Nice offers an optional bolt-
on pivot arm (P/N 446) for when
welding is not possible.

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 7
2MOUNT ACTUATOR TO PIVOT ARM
IMAGE 2-1: INSTALLING ACTUATOR TO PIVOT ARM
IMAGE 2-2: ACUATOR LEVEL
IMAGE 2-3: LEVEL ACTUATOR
(GATE CLOSED)
1. Mount actuator to pivot arm as
shown in IMAGE 2-1 using 1/2” bolt
and lock nut. Tighten lock nut until
secure. Ensure there is no binding.
2. Use bubble level to ensure actua-
tor is level and plumb in both open
and closed positions (IMAGE 2-2 &
2-3).
1/2”x 3.5” BOLT
ACTUATOR
1/2”LOCK NUT
PIVOT ARM
PIVOT ARM
CABLE
LOOP
LEVEL
LEVEL
LEVEL
LEVEL
IMPORTANT!
• Use a bubble level to ensure pivot arm and actuator
are plumb and level in open and close positions.
• Ensure that actuator mounting hardware is tight
enough to prevent movement, vibration, wobble,
or shifting when the actuator is in operation..
• Note cable loop to allow strain relief for cable during
actuator movement.
ACTUATOR

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
8| www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
AFFIX GATE BRACKET TO ACTUATOR ARM
3
1/2”x 2” BOLT
BLACK GATE
BRACKET
ACTUATOR
ARM
1/2” WASHER, ZINC
(GALVANIZED
BRACKET ONLY)
1/2” LOCK
NUT
IMAGE 3-1: GATE BRACKET TO ACTUATOR USING BOLT, WASHERS, & NUT
WASHER (STAINLESS
STEEL)
WASHER (ZINC)
IMAGE 3-2: GATE BRACKET TO ACTUATOR USING HITCH PIN AND R-CLIP
HITCH PIN
R-CLIP (INSERT INTO HITCH
PIN HOLE)
HOLE FOR R-CLIP
The bracket may be connected to the actuator arm using the 1/2” x 3” bolt, washer, and lock nut (IMAGE
3-1).
A hitch pin and R-clip are included in case fast decoupling of the actuator from gate is required. Note that
the mechanical release on the actuator motor may be opened to allow manual operation of the gate in
the event of a power failure without need for decoupling from the gate.
NOTE: There are two styles of bracket, black or silver (galvanized) and either one may be included in
the actuator kit. Both brackets are installed the same, except for different washer count. See next page
for images of both brackets after installation to the actuator arm using bolt, washers, and nut, as well as
hitch pin and R-clip.

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 9
BLACK GATE
BRACKET
ACTUATOR
ARM
BOLT
WASHER (STAINLESS STEEL)
WASHER (STAINLESS STEEL)
WASHER (ZINC)
WASHER (ZINC)
WASHER (ZINC)
LOCK NUT
GALVANIZED BRACKET
(Requires three washers)
BLACK BRACKET
(Requires two washers)
BOLT
ACTUATOR
ARM
GALVANIZED GATE
BRACKET
GALVANIZED GATE
BRACKET
ACTUATOR
ARM
GATE BRACKET
IMAGE 3-5: SILVER (GALVANIZED) GATE BRACKET WITH HITCH PIN AND R-CLIP
HITCH PIN
R-CLIP
GALVANIZED BRACKET
(with hitch pin)
NOTE: Hitch pin and R-Clip may also be used on older black bracket as well.
3: AFFIX GATE BRACKET TO ACTUATOR ARM (CONT.)
IMAGE 3-3: BLACK GATE BRACKET WITH BOLT, 2X WASHER, NUT
IMAGE 3-4: SILVER (GALVANIZED) GATE BRACKET WITH BOLT, 3X WASHER, NUT

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
10 | www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
1. Place gate in:
a) OPEN position for PULL-TO-OPEN conguration (IMAGE 4-1).
b) CLOSED position for PUSH-TO-OPEN congurations ( IMAGE 4-2).
2. With actuator arm fully retracted, rotate entire actuator on the pivot arm around until the gate
bracket attached to the actuator is positioned on a supporting structure of gate.
3. Mark position of gate bracket on gate or clamp into position.
4POSITION GATE BRACKET ON GATE
GATE OPEN (PULL-TO-OPEN)
IMAGE 4-1: PULL-TO-OPEN GATE BRACKET LOCATION
IMAGE 4-2: PUSH-TO-OPEN GATE BRACKET LOCATION
ACTUATOR
PIVOT
ARM
GATE BRACKET LOCATION
ARMATURE
FULLY RETRACTED
GATE CLOSED (PUSH-TO-OPEN)
GATE BRACKET LOCATION
TRAFFIC DIRECTION
TRAFFIC DIRECTION
ARMATURE
FULLY RETRACTED
HINGE
POST
WALL
HINGE
POST
PIVOT ARM ACTUATOR

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 11
1. Weld the gate bracket to the gate supporting structure (IMAGE 5-1) or use supplied 3/8” bolts
and nuts from kit (IMAGE 5-2).
2. If welding is not possible, drill two holes to match bracket mounting holes and afx with two
3/8”x2.5” screws and 3/8” nuts included in the bolt kit (IMAGE 5-2).
IMAGE 5-1: GATE BRACKET WELDED TO GATE
IMAGE 5-2: GATE BRACKET AND HARDWARE (BLACK BRACKET SHOWN)
5AFFIX GATE BRACKET TO GATE
GATE BRACKET
3/8”x2.5”
HEX BOLT (x2)
WELD
3/8” NUT (x2)
1/2”
GATE BRACKET
CENTERLINE
ACTUATOR
ARM
1/2” FROM TOP
SURFACE OF PIVOT
ARM TO CENTERLINE. SEE
INSTRUCTION 1A & 1B.
IMPORTANT! Ensure bracket centerline is 1/2” above the top of the pivot arm.
GATE BRACKET
IMPORTANT! Use a bubble level to assure after mounting that actuator is level and plumb.
CAUTION!
NEVER WELD PARTS TO THE GATE OR POSTS WHEN THE CONTROL BOARD IS
POWERED TO AVOID IRREPAIRABLE DAMAGE TO THE CIRCUIT BOARD!
NOTE:
Attach gate bracklet only to
structural supports. If unsure of
exact bracket location, tack weld
or clamp until gate can be tested.

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
12 | www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
6OPEN MECHANICAL RELEASE
1. Lift up the rubber key cap (IMAGE 6-1A).
2. Insert key and turn 90° clockwise (IMAGE 6-1B).
3. Lift up the mechanical release (IMAGE 6-1C).
4. After mechanical release is opened, the actuator arm should now be freely extended and retracted
manually.
NOTE: If manual extension is not possible, the actuator must be partially extended using the motor once
the actuator is powered by the control board.
To extend actuator using the motor, close the mechanical release and momentarily press the OPEN Button
(Push-To-Open) or CLOSE Button (Pull-To-Open) to extend the actuator beyond it’s fully retracted state,
then press the STOP Button. Open the mechanical release again and manual extention should be possible.
ABC
IMAGE 6-1: OPEN ACTUATOR MECHANICAL RELEASE
IMPORTANT! The actuator key MUST be left with the customer. The key is necessary if the gate must be
manually opened in the event of loss of power.

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 13
7MANUALLY SET GATE OPEN/CLOSE LIMITS
To mechanically “teach” the actuator the rough open and close limits, ensure the machanical release is still
open on the actuator, then move the gate manually as follows:
1. Close gate(s) all the way (IMAGE 7-1A) to desired close limit position.
2. Open gate(s) all the way (IMAGE 7-1B) to desired open limit position.
3. Place gates in mid position (IMAGE 7-1C).
4. CLOSE mechanical release of actuator, but do not lock it yet.
IMPORTANT! If done carefully, manually setting the gate limits may not require further adjustment. Do
not push the gate past the desired limits open or close, or they must be re-adjusted per ne adjustment
INSTRUCTION 10A or 10B in this manual.
A
B
C
IMAGE 7-1: MANUAL SETTING OF CLOSE/OPEN LIMITS
4.1 MANUALLY SET GATE OPEN/CLOSE LIMITS

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
14 | www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
8RUN ACTUATOR CABLE(S) TO CONTROL BOX
Run the cable of the actuator closest to the control box through a hole (with rubber grommet) drilled in the
bottom on the control box. If necessary, entry may be made elsewhere on the control box.
If a dual gate installation:
1. Dig a trench across the driveway deep enough to accomodate the longer harness cable from the actuator
farthest from the control box.
2. Run the cable through a conduit and lay this in the trench.
3. Cover the trench and use asphault patch if needed.
4. Run the 2nd cable into a hole (with rubber grommet) in the bottom of the control box.
NOTE: Ensure the cable(s) reaches into the control box sufciently to reach the MOTOR inputs on the
control board.
4.2 RUN ACTUATOR CABLE(S) TO CONTROL BOX

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 15
IMAGE 9A-1: 936 BOARD - PULL-TO-OPEN - SINGLE GATE
IMAGE 9A-2: 936 BOARD - PULL-TO-OPEN - DUAL GATE
9A 936 CONTROL BOARD WIRING: PULL-TO-OPEN
IMPORTANT! For dual gate systems, do NOT yet connect the second actuator to the control board. It will
be connected at a later step in these instructions.
IMPORTANT! For dual
gate systems, wire the
2nd harness into the
connector, but do not
connect it to the control
board yet. It will be
connected at a later step.
2nd ACTUATOR WITH
LONGER HARNESS
TO MOTOR 2
Connect harness wires to MOTOR 1 for your chosen conguration per Instruction 9A, 9B, 9C, or 9D.
5.1 936 CONTROL BOARD WIRING: PULL-TO-OPEN
SECTION 5: 912L ACTUATOR WIRING

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
16 | www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
IMAGE 9B-2: 936 BOARD - PUSH-TO-OPEN - DUAL GATE
IMAGE 9B-1: 936 BOARD - PUSH-TO-OPEN - SINGLE GATE
9B 936 CONTROL BOARD WIRING: PUSH-TO-OPEN
WHITE
BLUE
GREEN
YELLOW
ORANGE
BLACK
RED
MOTOR 1
WHITE
BLUE
GREEN
YELLOW
ORANGE
BLACK
RED
BLUE
GREEN
YELLOW
BLACK
RED
WHITE
ORANGE
MOTOR 1 MOTOR 2
NOTE:
If a gate moves in opposite direction from what is expected, reverse the motor power lead wiring (red &
black wires) for that motor.
In dual gate systems, the longer actuator cable is usually conneted to MOTOR 2, but if the actuator with
longer cable has a shorter run time it may be connected to MOTOR 1 instead of MOTOR 2 if the Gate
Sync option is used.
IMPORTANT! For dual
gate systems, wire the
2nd harness into the
connector, but do not
connect it to the control
board yet. It will be
connected at a later step.
2nd ACTUATOR WITH
LONGER HARNESS
TO MOTOR 2
5.2 936 CONTROL BOARD WIRING: PUSH-TO-OPEN

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 17
NOTE:
If a gate moves in opposite direction from what is expected, reverse the motor power lead wiring (red &
black wires) for that motor.
In dual gate systems, the longer actuator cable is usually connected to MOTOR 2.
IMAGE 9C-2: 1050 BOARD - PULL-TO-OPEN - DUAL GATE
IMAGE 9C-1: 1050 BOARD - PULL-TO-OPEN - SINGLE GATE
9C 1050 CONTROL BOARD WIRING: PULL-TO-OPEN
MOTOR 1
MOTOR 1 MOTOR 2
2nd ACTUATOR WITH
LONGER HARNESS
TO MOTOR 2
IMPORTANT! For dual gate
systems, wire the 2nd harness
into the connector, but do not
connect it to the control board
yet. It will be connected at a
later step.
5.3 1050 CONTROL BOARD WIRING: PULL-TO-OPEN

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
18 | www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
IMAGE 9D-2: 1050 BOARD - PUSH-TO-OPEN - SINGLE GATE
IMAGE 9D-1: 1050 BOARD - PUSH-TO-OPEN - SINGLE GATE
9D 1050 CONTROL BOARD WIRING: PUSH-TO-OPEN
MOTOR 1
MOTOR 1 MOTOR 2
2nd ACTUATOR WITH
LONGER HARNESS TO
MOTOR 2
IMPORTANT! For dual gate
systems, wire the 2nd harness
into the connector, but do not
connect it to the control board
yet. It will be connected at a
later step.
NOTE:
If a gate moves in opposite direction from what is expected, reverse the motor power lead wiring (red &
black wires) for that motor.
In dual gate systems, the longer actuator cable is usually connected to MOTOR 2.
5.4 1050 CONTROL BOARD WIRING: PUSH-TO-OPEN

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
MX4685 REV. A ©2019 Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 www.hysecurity.com | 19
1. Open the actuator mechanical release, remove two torx 25 screws, and lift off cover.
2. Remove plastic cap covering the two adjustment wheels (IMAGE 10-1).
3. Press the CLOSE button on the control board. The gate should close until it hits the CLOSE limit
switch (LED = RED).
4. If the CLOSE limit is not acceptable (gate closed too far or not enough), re-open the gate partially
and then turn the turn the EXTEND Adjustment Wheel a few revolutions in “extend more” or
“extend less” direction as needed, then press CLOSE button on the Control Board again to check.
5. Check gate and repeat Steps 4-5 as necessary until CLOSE limit is acceptable.
6. Press the OPEN button on control board. The gate should open until it hits the OPEN limit switch
(LED = GREEN).
7. If the OPEN limit is not acceptable (gate open too far or not open all the way), re-close the gate
partially and then turn the RETRACT Adjustment Wheel a few revolutions in “retract more” or
“retract less” direction and press OPEN button on the Control Board again to check.
8. Check gate and repeat Steps 7-8 as necessary until OPEN limit is acceptable.
9. When nished, replace plastic cap on switches, afx actuator cover with two screws, engage
mechanical release, and lock.
10A SETTING ACTUATOR FINE LIMITS: PULL-TO-OPEN
IMPORTANT!
The actuator key MUST be left with the customer. The key is necessary if the gate must be manually
opened in the event of loss of power.
IMPORTANT NOTE FOR DUAL GATE SYSTEMS!
If a dual gate system, only the primary actuator should be connected to the control board at this point. After
determining limits for the rst actuator per INSTRUCTION 10A or 10B (below), unplug it from the Motor
1 input and plug in the secondary actuator to the MOTOR 1 input, then repeat steps in INSTRUCTION
10A or 10B for the second actuator. When nished, plug rst actuator back onto MOTOR 1 input, and the
secondary actuator into the MOTOR 2 input.
After installation of the control box (per separate installation instructions), the rst operation to perform after
the board has scanned for monitored safety devices is to ensure the open and close limits are acceptable.
Refer to INSTRUCTION 10A or 10B to determine open and close limits. To “teach” limits to the control board,
see seperate control box installation manual.
SECTION 6: SETTING ACTUATOR FINE LIMITS

TITAN 912L Actuator
INSTALLATION REFERENCE MANUAL
20 | www.hysecurity.com Nice/HySecurity, 6705 S 209th St, Ste 101, Kent, WA 98032 - TF: 800-321-9947 MX4685 Rev. A ©2019
1. Open the actuator mechanical release, remove two Torx 25 screws, and lift off cover.
2. Remove plastic cap covering the two adjustment wheels (IMAGE 10-1).
3. Press the CLOSE button on the control board. The gate should close until it hits the CLOSE limit switch
(LED = RED).
4. If the CLOSE limit is not acceptable (gate closed too far or not enough), open the gate partially and
turn the RETRACT Adjustment Wheel a few revolutions in “retract more” or “retract less” direction as
needed, then press CLOSE button on the Control Board again to check.
5. Check gate and repeat Steps 4-5 as necessary until CLOSE limit is acceptable.
6. Press the OPEN button on control board. The gate should open until it hits the OPEN limit switch
(LED = GREEN).
7. If the OPEN limit is not acceptable (gate open too far or not open all the way), close the gate partially
and then turn the EXTEND Adjustment Wheel a few revolutions in “extend more” or “extend less”
direction and press OPEN button on the Control Board again to check.
8. Check gate and repeat Steps 7-8 as necessary until OPEN limit is acceptable.
9. When nished, replace plastic cap on switches, afx actuator cover with two screws, engage mechanical
release, and lock.
10B SETTING ACTUATOR FINE LIMITS: PUSH-TO-OPEN
EXTEND
WHEEL
RETRACT
WHEEL
RETRACT LESS
RETRACT LESS
RETRACT MORE
RETRACT MORE
RETRACT CAM MOVEMENT
EXTEND CAM MOVEMENT
EXTEND MORE
EXTEND MORE EXTEND LESS
EXTEND LESS
Remove rubber cap
to expose wheels
IMAGE 10-1: TITANL1 ACTUATOR LIMIT SWITCH LOCATIONS & FUNCTIONS
IMPORTANT!
The actuator key MUST be left with the customer. The key is necessary if the gate must be manually
opened in the event of loss of power.
