Nice Soon User manual

THE COMPACT GUIDELESS SOLUTION
FOR SECTIONAL DOORS
NICE SOON

SOON
298 mm
63
115
10,8
375
67
24,3
126,5
24VBLUEBUSOPERASOLEMYO
For sectional doors* up to 20 m2.
24 Vdc electromechanical gear motor
with absolute encoder.
*For balanced sectional doors equipped with anti-crash
(safety device useful in case of spring breaking).
Versatile
Ideal in residential contexts also for large doors,
multi-user contexts with intensive use and industrial
with small doors for example 3 x 3 m loading points.
All in one
built-in control unit. No guide or ratchet.
Easy to install: Soon can be fitted directly onto the shaft
of a sectional door; compact, particularly in width, in order
to make assembly easy in any position.
CODE DESCRIPTION PACK/PALLET
SO2000 IRREVERSIBLE, 24 Vdc, WITH ABSOLUTE ENCODER FOR DOORS
UP TO 5 mIN HEIGHT
20
User-friendly thanks to the BlueBUS system
that enables users to connect the photocell couples
and control unit using just two wires.
Practical: the control unit and PS124 buffer battery (optional)
can be connected by means of a simple connector and can be
housed directly inside the motor.
Energy saving: when the system is not being used it will
switch over to standby.
Reliable and precise: memorization of limit switch positions
on opening and closing; gradual starting and slowdown during
closing; the abosolute encoder technology guarantees precision
without the need of a limit switch, reliability and long term
safeguard of the set values.
Safe: obstacle detection system; motor absorption is monitored
during movement, self-diagnosis by means of a flashing light
and courtesy light.
Last generation of 8.2 KOhm optical and sensitive edges can also
be connected.
Simple maintenance
Removable terminals and receivers.
Easy to certify
Passes impact tests without further accessories.
TECHNICAL SPECIFICATIONS
CODE
ELECTRICAL DATA
POWER SUPPLY Vac 50/60 Hz
ABSORPTION A
POWER W
PERFORMANCE DATA
SPEED (rpm)
TORQUE Nm
WORK CYCLE CYCLES/HOUR
DIMENSIONAL AND GENERAL DATA
PROTECTION LEVEL IP
WORKING TEMP. °C MIN/MAX
DIMENSIONS mm
WEIGHT kg
DIMENSIONS
PROTECTIVE FLAP
COMPLETE WITH COURTESY
LIGHT 21 W.
USERS CAN CONNECT
AND PROGRAMME THE
CONTROL UNIT, MODIFY ITS
FUNCTIONS
AND CHANGE THE LAMP
WITHOUT HAVING TO
DISASSEMBLE THE CASING
NEW RELEASE SYSTEM
WITH 4 m LONG CORD
SO2000
230
1.6
350
30
50
15
40
20 ÷ +50
115x300x375 h
10.5

1
58
9
10 23
7
6
4
ACCESSORIES
COMPATIBILITY TABLE WITH CONTROL SYSTEMS AND ACCESSORIES
INSTALLATION DIAGRAM
SOLEMYO KIT
THE SOLAR POWER TO
AUTOMATE GATES, GARAGE
DOORS OR BARRIER GATES.
IT4WIFI
INTERFACCIA WIFI
INTELLIGENTE PER GESTIRE
VIA SMARTPHONE CANCELLI
E PORTE DA GARAGE*
*Non compatibile con Kit Solemyo e PS324
SOA2
SPARE CONTROL UNIT
FOR SO2000.
PS124
24 V BATTERY
WITH INTEGRATED
BATTERY CHARGER.
PC/PACK 1
CRA9
ADAPTER FOR DIAMETER
31.75 1.1/4”, 35
AND 40 mm SHAFTS.
PC/PACK 1
TS
SIGNBOARD.
PC/PACK 1
1. MOTOR
2. TRANSMITTER
3. PHOTOCELLS MOUNTED ON POSTS
4. PHOTOCELLS
5. FLASHING LIGHT
6. DIGITAL OR KEY SWITCHES
7. SENSITIVE EDGES SENSOR
8. SYP SOLAR PANEL
9. PSY24 BATTERY BOX
10. OVIEW MULTIFUNCTION DISPLAY
RECEIVER TRANSMITTER PHOTOCELLS FLASHING LIGHT
CODE
Built-in* FLOXI2R* OXI ERA INTI ERA ONE ERA FLOR NICEWAY EPS EPM EPL EPSB EPMB EPLB F210 FT210 F210B FT210B EL EL24 ELB WLT
SO2000 ●●●●● ●●● ●● ●●
*Radio receiver incompatible with Opera system
Solemyo SOLAR POWER ACCESSORIES
Sectional door
