Niche Flip Flop FF2822 Series User manual

Missing Parts? Assembly Questions?
Call us at 1-866-816-3822 or email [email protected] for immediate assistance.
www.mynichefurniture.com
BEFORE YOU ASSEMBLE:
• Place all parts on a clean, smooth surface to avoid scratching the parts
• Check to be sure you have all parts & hardware
• Remove all wrapping materials & packing straps
• Keep all hardware, small parts & packaging out of reach of children
• Do not tighten all screws/bolts until product is completely assembled
PARTS & HARDWARE:
A: Cam Pin (4)
Missing Parts? Assembly Questions?
Call us at 1-866-816-9822 or email [email protected] for immediate assistance.
B: Cam Lock (4)
ASSEMBLY INSTRUCTIONS: FF2822XX - Flip Flop 28” High Folding Bookcase
F: Bookcase Shell G: Bookcase Top
Tools Needed:
Philips Screwdriver
C: Dowel Rod (2) D: Inserts (4) E: Glue
H: Allen Key

www.mynichefurniture.com
Missing Parts? Assembly Questions?
Call us at 1-866-816-9822 or email [email protected] for immediate assistance.
STEP 1:
ASSEMBLY INSTRUCTIONS: FF2822XX - Flip Flop 28” High Folding Bookcase
STEP 2:
STEP 3:
Figure 1: To open Cam Lock, point
arrow toward Cam Pin Hole. To lock
Cam, turn clockwise.
Insert some Glue (E), and then two
Dowel Rods (C) into the Bookcase
Top (G) in the holes marked (x) on
the image to the right.
Place 4 Inserts (D) into the holes
marked (y) in the holes indicated
on the image. Screw 4 Cam Pins
(A) into the inserts.
B
Attach Bookcase Top (G) to the
Bookcase Shell (F) by inserting Cam
Pins (A) into Cam Pin Holes and
locking them tight using the Allen
Key (H) or Philips Screwdriver.
Fold out the legs and flip down the shelves on the Bookcase Shell (F). Place 4 Cam Locks (B) in the
Bookcase Shell (F) with the arrow on the lock facing up (See figure 1)
B B
G
F
F
y
yy
Gy
xx
