Niche NLCST1418 User manual

PROBLEMS OR QUESTIONS?
Call us at 866-816-9822 or email [email protected]
mynichefurniture.com
ASSEMBLY INSTRUCTIONS:
NLCST1418 — Niche Lux C-Shaped Side Table
BEFORE YOU ASSEMBLE:
• Place all parts on a clean, smooth surface to avoid scratching the parts
• Check to be sure you have all parts and hardware
• Remove all wrapping materials, including any staples & packing straps
• Keep all hardware, small parts and packaging out of reach of children
• Do not tighten all screws/bolts until product is completely assembled
PARTS & HARDWARE:
3: 1x Leg
4: 1x Support
A: 4x Cam
Pins
B: 3x Bolts
D: 4x Pegs
E: 1x Hex Tool F: 4x Caps
G: 4x Casters
C: 4x Cam
Locks
1: 1x Top
2: 1x Base

PROBLEMS OR QUESTIONS?
Call us at 866-816-9822 or email [email protected]
mynichefurniture.com
STEP 1:
STEP 3: STEP 4:
STEP 2:
ASSEMBLY INSTRUCTIONS:
NLCST1418 — Niche Lux C-Shaped Side Table
Insert 3 Cam Pins (A) into the predrilled holes
on the face of Top (1).
Insert 4 Casters (G) into the predrilled holes
on the face of Base (2).
Insert 1 Cam Pin (A) into the predrilled holes on the face
of Leg (3). Next, insert 4 Pegs (D) into the predrilled holes
on the edges of Leg (3). And then, insert 2 Cam Locks (C)
into the predrilled holes on the edges of Leg (3).
Insert 2 Cam Pins (C) into predrilled holes on Support (4).
Note: Make sure Cam Pin arrow is pointing towards hole.
Next, line up hole on Support (4) with the Cam Pin (C)
on Leg (3). Press Support (4) down into place. And then
tighten the connecting Cam Pin (C).
Note: Make sure Cam Pins on Parts Leg (3) and Support
(4) are on the same end of your assembly.
A1
3
A
C
C
D D
2
G
Note: Make sure the Arrows
on the Cam Pins (A) are
facing towards the holes on
the edge of Leg (3).
4
4
3
C

PROBLEMS OR QUESTIONS?
Call us at 866-816-9822 or email [email protected]
mynichefurniture.com
STEP 5: STEP 6:
STEP 7:
Attach Top (1) onto the assembled Leg (3) and Support
(4) by lining up the Cam Pins (A) with the predrilled
holes. Then, tighten the 3 Cam Locks (C).
Align Base (2) with the Pegs (D) on the bottom of Leg (3),
and press down into place. Next, Attach Base (2) by
inserting 3 Bolts (B) into the predrilled holes and tightening.
Insert Caps (F) onto all exposed Cam Locks (C).
ASSEMBLY INSTRUCTIONS:
1
A
C3
4
2
3
B
F
NLCST1418 — Niche Lux C-Shaped Side Table
