Nikon COOLSHOT PRO II STABILIZED User manual

En
Fr
Instruction manual/Manuel d’utilisation
LaserRangefinder/Télémètre laser

3
En
Fr
CONTENTS
English
Introduction
Read this First......................................................................4
SAFETY AND OPERATION PRECAUTIONS..................5
Getting to know the Laser Rangefinder
Key features..........................................................................8
Nomenclature/Composition..........................................9
Internal display ................................................................ 10
Functions
STABILIZED function ...................................................... 11
First Target Priority algorithm..................................... 11
Dual LOCKED ON
(First Target Priority detection notice function)... 11
Actual Distance Indicator............................................. 11
Inserting/Replacing battery
Type of battery................................................................. 12
Inserting/Replacing battery........................................ 12
Battery level indicator ................................................... 12
Navigating the menus
Changing the measurement display mode........... 14
Changing the internal display luminance (F1)..... 15
Changing the distance display unit (F2)................. 16
Switching the electronic sound (F3) ON or OFF ... 17
Operation diagram of the setting menus .............. 18
Measurement
Adjusting the focus of the internal display............ 19
Measuring.......................................................................... 19
Single measurement...................................................... 20
Continuous measurement........................................... 20
Technical notes
Specifications ................................................................... 21
Troubleshooting/Repair ............................................... 23
English

4
En
Fr
Introduction
Read this First
Thank you for purchasing the Nikon Laser Rangefinder.
Before using the product, read this manual thoroughly to ensure proper use.
After reading this manual, keep it in a readily accessible place for future reference.
llAbout the manual
• No part of the manual may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language in any form, by any means, without Nikon’s prior written permission.
• Illustrations and display content shown in this manual may differ from the actual product.
• Nikon will not be held liable for any errors this manual may contain.
• The appearance, specifications, and capabilities of this product are subject to change without notice.
llAbout controls for radio interference
• This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules and to EU EMC directive. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
Notice for customers in Canada
CAN ICES-3(B)/NMB-3(B)

5
En
Fr
SAFETY AND OPERATION PRECAUTIONS
Strictly observe the guidelines
contained in this manual in
order to use this product safely
and prevent possible injury or
property damage to you and
others. Understand the contents
thoroughly for correct use of the
product.
WARNING
This indicates that improper use by
ignoring the contents described
herein can result in potential death
or serious injury.
CAUTION
This indicates that improper use by
ignoring the contents described
herein can result in potential injury
or material loss.
SAFETY PRECAUTIONS (Laser)
This product uses an invisible laser
beam. Be sure to observe the
following:
WARNING
• Do not press the PWR button while
looking into the laser emission
aperture. You may damage your
eyes.
• Do not aim at eyes.
• Do not point the laser at people.
• Do not look at lasers with other
optical instruments such as lenses
or binoculars. You may damage
your eyes.
• When not measuring, keep your
fingers away from the PWR button
to avoid accidentally emitting the
laser.
• When not in use for an extended
period, remove the battery.
• Do not disassemble, remodel, or
repair the product. The laser
emission may be harmful to your
health. If the product is
disassembled, remodeled, or
repaired, it is no longer
guaranteed by the manufacturer.
• Store the product in a place out of
reach of children.
SAFETY PRECAUTIONS
(Monocular)
WARNING
• Never look directly at the sun,
intense light, or lasers while using
this product. It may seriously
damage the eyes or cause
blindness.
• Users of medical devices such as
cardiac pacemakers should not use
this product and its accessories.
Magnets built into the product
and accessories can cause medical
device malfunctions. Also, keep
credit cards and electronic media
away from this product and its
accessories. Recorded data may
get corrupted.
CAUTION
• Keep the plastic bag used to wrap
this product or other small parts
out of reach of children. The bag
may block their mouths and noses
and cause them to suffocate.
• Be careful of children inadvertently
swallowing small parts or
accessories. If children swallow
such parts, see a doctor
immediately.

6
En
Fr
• Turn off this product when not in
use.
• When carrying this product, store
it in the case.
• If this product fails to operate
correctly for any reason,
discontinue use immediately and
consult with a Nikon authorized
service representative.
• Do not leave this product in an
unstable place. It may fall and
cause injury or malfunction.
• Do not use this product while
walking. You may walk into
something or fall and cause injury
or malfunction.
• Do not swing this product by the
strap. You may hit others and
cause injury.
• The rubber parts of this product
(such as the eyecup) may
deteriorate if used or stored for a
long period of time. The
deteriorated rubber may attach on
clothes and cause stains. Check
their condition before use, and
consult with a Nikon authorized
service representative if a defect is
found.
• Using the rubber eyecup for
extended periods of time may
cause skin inflammation. If you
develop any symptoms, stop use
and see a doctor immediately.
PRECAUTIONS
(Lithium battery)
Incorrect use may cause the lithium
battery to rupture or leak, which will
corrode the device or stain your
hands and clothing.
Be sure to observe the following:
• Install the battery with the + and
– poles positioned correctly.
• Remove the battery when this is
depleted or will not be used for
extended periods.
• Keep the battery away from fire or
water. Never disassemble the
battery.
• Do not charge the lithium battery.
• Do not short the terminal of the
battery chamber.
• Do not carry the battery together
with keys or coins in a pocket or
bag. You may short the battery and
cause overheating.
• If liquid leaked from the lithium
battery comes into contact with
clothing or skin, rinse with plenty
of water. If it enters the eyes or
mouth, rinse with water and
consult a doctor immediately.
• When disposing of the lithium
battery, follow your local area
regulations.
HANDLING AND OPERATION
PRECAUTIONS
• Do not subject this product to
physical shock.
• If you accidentally apply strong
physical shock or drop the product
and suspect a malfunction, consult
with your local dealer or a Nikon
authorized service representative
immediately.
• Do not use the product
underwater.
• Wipe off any rain, water, sand, or
mud on the product as soon as
possible with a soft, clean cloth.
• When this product is exposed to
extreme temperature changes
(suddenly brought from a cold
place to a warm place or vice-
versa), the lens surfaces may get
cloudy. Do not use the product
until the cloudiness has
disappeared.
• Do not leave the product in a car
on a hot or sunny day, or near heat
generating equipment.

7
En
Fr
• Do not leave the
eyepiece in direct
sunlight. The
condenser effect of
the lens may
damage the internal
display surface.
CARE AND MAINTENANCE
PRECAUTIONS
LENS
Be careful that you do not directly
touch the lens surface with your
hands when cleaning it. Remove
dust or lint with a blower*. For
fingerprints or other stains that
cannot be removed with a blower,
wipe the lens with a dry soft cloth or
cleaning cloth for eyeglasses, using a
spiral motion that starts at the center
of the lens and working towards the
edges. Wiping too firmly or wiping
with a hard material may damage
the lens. If this fails, gently wipe the
lens using a cloth lightly dampened
with commercial lens cleaner.
MAIN BODY
After gently removing dust with a
blower, clean the body surface with a
soft, clean cloth. After use at a
seaside, wipe off salt that may be on
the body surface with a damp, soft,
clean cloth, and then wipe with a dry
cloth. Do not use benzene, thinner,
or other cleaners containing organic
solvents.
STORAGE
Water condensation or mold may
occur on lens surfaces because of
high humidity. Therefore, store the
product in a cool, dry place. After use
on a rainy day or at night, thoroughly
dry it at room temperature, then
store in a cool, dry place.
* A rubber cleaning tool that blows
air from a nozzle.
En Symbol for separate collection applicable
in European countries
This symbol indicates that this battery is
to be collected separately.
The following apply only to users in
European countries.
• This battery is designated for
separate collection at an appropriate
collection point. Do not dispose of as
household waste.
• For more information, contact the
retailer or the local authorities in
charge of waste management.
En Symbol for separate collection applicable
in European countries
This symbol indicates that this product is
to be collected separately.
The following apply only to users in
European countries.
• This product is designated for
separate collection at an appropriate
collection point. Do not dispose of as
household waste.
• For more information, contact the
retailer or the local authorities in
charge of waste management.

8
En
Fr
Key features
• STABILIZED function is employed for reducing the
vibrations caused by hand movement
• Red internal display is easy-to-read
• Employs the First Target Priority algorithm that
makes a flagstick easy to measure
• Notifies with a LOCKED ON sign (First Target
Priority detection sign) and electronic sound when
measuring overlapping subjects and the distance
to the closest subject is displayed
• High-quality 6× finder with multilayer coating
• Larger ocular for easy viewing
• Select from four measurement display modes
• Golf mode (default setting) displays the slope
adjusted distance (horizontal distance ± height)
which is useful for golf
• Built-in Actual Distance Indicator
• Press and hold down the PWR button to activate
the continuous measurement function (up to
approx. 8 seconds)
• Automatic power shut-off (approx. 8 sec.
unoperated from standby screen)
• Waterproof and fogproof (not designed for
underwater usage)
• Invisible/Eyesafe EN/IEC Class 1M Laser
llAbout measurement results
This device is a basic rangefinder. Its measurement results cannot be used as official evidence.
This product uses an invisible laser beam for
measuring. It measures the time the laser beam
takes to travel from the rangefinder to the target
and back. Laser reflectivity and measurement
results may vary according to climatic and
environmental conditions, as well as the color,
surface finish, size, shape and other
characteristics of the target.
Measurement may be inaccurate or fail in the
following cases:
• In snow, rain or fog
• Small or slender target
• Black or dark target
• Target has stepped surface
• Moving or vibrating target
• When measuring the surface of water
• Target measured through glass
• When the target is glass or a mirror
• When laser incidence to the target’s reflective
surface is oblique
Getting to know the Laser Rangefinder

9
En
Fr
Nomenclature/Composition
0
a
7
6
5
4
3
2
9
8
1
bc
Composition
• Body ×1
• Lithium battery (CR2) ×1
• Case ×1
1MODE button
2PWR button (POWER ON/Measurement
button)
36× monocular eyepiece
4Eyecup/Diopter adjustment ring
5Diopter index
6Strap eyelet
7Battery-chamber cover
8Battery-chamber cover “Open”indication
9Monocular objective lens/Laser emission
aperture
0Actual Distance Indicator
aInvisible Laser detector aperture
bProduct number label
cIndication

10
En
Fr
Internal display
1Height (actual distance at golf mode setting)
: “Failure to measure” or“Unable to measure”
2Target mark
: Aim at the target you want to measure.
Position the target at the center of the mark.
3Unit of measure (m: meter/YD: yard)
4Distance
: “Failure to measure”or “Unable to measure”
5Battery level indicator
6Measurement display mode indications
7Laser irradiation mark
: Appears while the laser is being irradiated for a
measurement. Do not look towards the objective lens
side while this mark is shown.
8LOCKED ON sign (First Target Priority detection sign)
: When measuring overlapping subjects, and the
distance to the closest subject is displayed, this sign is
lit.
8
7
6
5
4
3
2
1
• The internal display of this product is enlarged by the eyepiece. Although you may see dust that has
entered, it does not effect the accuracy of measurement.

11
En
Fr
STABILIZED function
llON and OFF
The STABILIZED function is activated concurrently when the Laser Rangefinder is ON.
When the Laser Rangefinder is OFF, the STABILIZED function automatically turns off.
First Target Priority algorithm
When measuring overlapping subjects, First Target Priority algorithm displays the distance to the closest
subject.
Dual LOCKED ON (First Target Priority detection notice function)
When measuring overlapping subjects, such as a flagstick with trees in the background, and the distance
to a closest subject is displayed, LOCKED ON sign (First Target Priority detection sign)* is lit in the
viewfinder with an electronic sound (if the electronic sound setting is on).
*Single measurement: When measuring overlapping subjects and the distance to a closest subject is
displayed, the LOCKED ON sign appears with an electronic sound.
Continuous measurement: When displayed figures shift to a closer subject, the LOCKED ON sign appears
with an electronic sound.
LOCKED ON sign (First Target Priority
detection sign) is lit.
Actual Distance Indicator
When the measurement display mode is actual distance mode, the Actual Distance Indicator blinks while
the Laser Rangefinder is ON.
You can find out at a glance that the inclinometer function is not being used.
Functions
