Nikon WT-3 User manual

Wireless Transmitter
WT-
WT-3
WT-
WT-3
WT-3
User's Manual
Ck
Ch
En
Kr

En
User’s Manual
Wireless Transmitter
W T-3
WT-3

Trademark Information
Macintosh and Mac OS are trademarks of Apple Computer, Inc. Microsoft and
Windows are registered trademarks of Microsoft Corporation. All other trade names
mentioned in this manual or the other documentation provided with this Nikon
product are trademarks or registered trademarks of their respective holders.
Apple Public Source License
This product includes Apple mDNS source code that is subject to the terms of the
Apple Public Source License located at URL http://developer.apple.com/darwin/.
Portions copyright © 1999-2004 Apple Computer, Inc. All Rights Reserved.
This file contains Original Code and/or Modifications of Original Code as defined in
and that are subject to the Apple Public Source License Version 2.0 (the ‘License’).
You may not use this file except in compliance with the License. Please obtain a
copy of the License at http://www.opensource.apple.com/apsl/ and read it be-
fore using this file.
The Original Code and all software distributed under the License are distributed on
an ‘AS IS’ basis, WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
AND APPLE HEREBY DISCLAIMS ALL SUCH WARRANTIES, INCLUDING WITHOUT
LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, QUIET ENJOYMENT OR NON-INFRINGEMENT. Please see the License for
the specific language governing rights and limitations under the License.

i
For Your Safety
To prevent damage to your Nikon product or injury to yourself or to others, read
the following safety precautions in their entirety before using this equipment. Keep
these safety instructions where all those who use the product will read them.
The consequences that could result from failure to observe the precautions listed in
this section are indicated by the following symbol:
This icon marks warnings, information that should be read before using this
Nikon product to prevent possible injury.
WARNINGS
Do not disassemble
Failure to observe this precaution could result in fire, electric shock, or other injury.
Should the product break open as the result of a fall or other accident, disconnect
the camera power source and take the product to a Nikon-authorized service rep-
resentative for inspection.
Cut power immediately in the event of malfunction
Should you notice smoke or an unusual smell coming from the equipment, imme-
diately unplug the AC adapter and remove the battery, taking care to avoid burns.
Continued operation could result in injury. After removing the battery, take the
equipment to a Nikon-authorized service representative for inspection.
Do not use in the presence of flammable gas
Failure to observe this precaution could result in explosion or fire.
Keep dry
Do not immerse in or expose to water or rain. Failure to observe this precaution
could result in fire or electric shock.
Do not handle with wet hands
Failure to observe this precaution could result in electric shock.
Keep out of reach of children
Failure to observe this precaution could result in injury.

ii
Observe proper precautions when handling batteries
Batteries may leak or explode if improperly handled. Observe the following precau-
tions when handling batteries for use in this product:
• Be sure the product is off before replacing the battery. If you are using an AC
adapter, be sure it is unplugged.
• Use only batteries approved for use in this equipment.
• Do not attempt to insert the battery upside down or backwards.
• Do not short or disassemble the battery.
• Do not expose the battery to flame or to excessive heat.
• Do not immerse in or expose to water.
• Replace the terminal cover when transporting the battery. Do not transport or
store with metal objects such as necklaces or hairpins.
• Batteries are prone to leakage when fully discharged. To avoid damage to the
product, be sure to remove the battery when no charge remains.
•
When the battery is not in use, attach the terminal cover and store in a cool place.
• Immediately after use, or when the product is used on battery power for an ex-
tended period, the battery may become hot. Before removing the battery, turn
the camera off and allow the battery to cool.
• Discontinue use immediately should you notice any changes in the battery, such
as discoloration or deformation.
Do not expose to high temperatures
Do not leave the device in a closed vehicle under the sun or in other areas subject
to extremely high temperatures. Failure to observe this precaution could result in
fire or in damage to the casing or internal parts.
Observe caution when using the WA-E1
When using the WA-E1 extended range antenna (available separately), be careful
not to put the tip of the antenna in your eye accidentally. Failure to observe this
precaution could result in blindness or other visual impairment.
CD-ROMs
The CD-ROMs on which the software and manuals are distributed should not be
played back on audio CD equipment. Playing CD-ROMs on an audio CD player
could cause hearing loss or damage the equipment.
Follow the instructions of hospital and airline personnel
This device emits radio frequency radiation that could interfere with medical or
navigational equipment. Do not use this device in a hospital or on board an air-
plane without first obtaining the permission of hospital or airline staff.

iii
This product, which contains encryption software developed in the United States,
is controlled by the United States Export Administration Regulations and may not
be exported or re-exported to any country to which the United States embargoes
goods. As of April 2006 the following countries were subject to embargo: Cuba,
Iran, North Korea, Libya, Sudan, and Syria.
Notice for Customers in the U.S.A.
U.S.A. Federal Communications Commission (FCC) Declaration of Conformity
This device complies with Part 15 of the FCC rules. Operation of the device is sub-
ject to the following two conditions: (1) this device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including interfer-
ence that may cause undesired operation.
Products that contain a radio transmitter are
labeled with FCC ID and may also carry the
FCC logo. WT-3A
Notices
• No part of the manuals included with
this product may be reproduced, trans-
mitted, transcribed, stored in a retrieval
system, or translated into any language
in any form, by any means, without
Nikon’s prior written permission.
• Nikon reserves the right to change
the specifications of the hardware and
software described in these manuals at
any time and without prior notice.
• Nikon will not be held liable for any
damages resulting from the use of this
product.
• While every effort has been made to
ensure that the information in these
manuals is accurate and complete, we
would appreciate it were you to bring
any errors or omissions to the attention
of the Nikon representative in your area
(address provided separately).

iv
FCC Radio Frequency Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to pro-
vide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
CAUTIONS
Modifications
The FCC requires the user to be notified that any changes or modifications made
to this device that are not expressly approved by Nikon Corporation may void the
user’s authority to operate the equipment.
Interface Cables
Use the interface cables sold or provided by Nikon for your equipment. Using other
interface cables may exceed the limits of Class B Part 15 of the FCC rules.

v
FCC Radiation Exposure Statement
The available scientific evidence does not show that any health problems are associ-
ated with using low power wireless devices. There is no proof, however, that these
low power wireless devices are absolutely safe. Low power wireless devices emit
low levels of radio frequency energy (RF) in the microwave range while being used.
Whereas high levels of RF can produce health effects (by heating tissue), exposure to
low level RF that does not produce heating effects causes no known adverse health
effects. Many studies of low level RF exposures have not found any biological effects.
Some studies have suggested that some biological effects might occur, but such
findings have not been confirmed by additional research. This Wireless Transmitter
(WT-3A) has been tested and found to comply with the Federal Communications
Commission (FCC) guidelines on radio frequency energy (RF) exposures. The maxi-
mum SAR levels tested for the Wireless Transmitter (WT-3A) have been shown to be
0.2 W/kg at head.
This equipment complies with both FCC and IC radiation exposure limits set forth
for an uncontrolled environment. When the Wireless Transmitter is connected
with the WA-E1 extended range antenna, it is considered as a mobile radiator and
should be installed and operated with a minimum distance of 20 cm between the
radiator and your body. This device should not be co-located or operated with any
other antenna or transmitter.
Notice for Customers in the State of California, U.S.A.
WARNING: Handling the cord on this product will expose you to lead, a chemical known
to the State of California to cause birth defects or other reproductive harm. Wash hands
after handling.
Nikon Inc.,
1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A.
Tel.: [phone]

vi
CAUTION: This class B digital apparatus
meets all requirements of the Canadian
Interference Causing Equipment Regula-
tions.
ATTENTION: Cet appareil numérique de la
classe B respecte toutes les exigences du
Règlement sur le matériel brouilleur du
Canada.
Notices for Customers in Canada
RSS-GEN Exposure of Humans to RF Fields
This equipment complies with both FCC and IC radiation exposure limits set forth
for an uncontrolled environment. When the Wireless Transmitter is connected
with the WA-E1 extended range antenna, it is considered as a mobile radiator and
should be installed and operated with a minimum distance of 20 cm between the
radiator and your body. The installer of this radio equipment must ensure that the
antenna is located or pointed such that it does not emit RF field in excess of Health
Canada limits for the general population; consult Safety Code 6, obtainable from
Health Canada’s website at http://www.hc-sc.gc.ca/rpb.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
This device has been designed to operate with the antenna listed below, and
having a maximum gain of 3.0 dB. Antennas not included in this list or having a
gain greater than 3.0 dB are strictly prohibited for use with this device. The required
antenna impedance is 50 ohms.
• The WA-E1 extended range antenna (available separately)
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that permitted for successful communication.

vii
Notice for Customers in Europe
Hereby, Nikon, declares that this digital camera is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
Notice for Customers in France
Outdoor use of wireless transceivers is prohibited in France.
Symbol for Separate Collection in European Countries
This symbol indicates that this product is to be collected separately.
The following apply only to users in European countries:
• This product is designated for separate collection at an appropriate col-
lection point. Do not dispose of as household waste.
• For more information, contact the retailer or the local authorities in charge of
waste management.

viii
Table of Contents
For Your Safety.........................................................i
Notices...................................................................iii
Introduction...........................................1
Supported Modes.............................................2
TheWT-3 Setup Utility CD ................................2
System Requirements.......................................3
Parts of the WT-3..............................................5
Setup.....................................................8
Updating the Camera Firmware........................9
Installing the WT-3 Setup Utility ....................10
Copying Network Profiles to the Camera ........15
Connecting the WT-3......................................26
Inserting the Battery......................................28
Uploading Images: Transfer Mode.......... 30
Connecting to the Host or ftp Server...............30
Uploading Images ..........................................33
Interrupting Transmission ................................... 34
Transfer Status..................................................... 34
Network Status.................................................... 35
Controlling the Camera: PC Mode........... 37
Connecting to the Computer ..........................37
Controlling the Camera Using
Nikon Capture 4..............................................39
Network Status.................................................... 40
Printing Pictures: Print Mode ................ 42
Selecting a Printer..........................................42
Printing Pictures.............................................44
Printing Pictures Using the PD-10Wireless
Printer Adapter...............................................45
Menu Guide.......................................... 47
Wireless LAN System ......................................47
Mode..............................................................47
Choose Profile.................................................47
FTP Registration (for Connection to
ftp Servers Only) ................................................. 48
Editing ftp Profiles............................................... 48
Settings (Transfer Mode Only) ........................59
Auto Send............................................................ 59
Delete After Send ................................................ 59
Send File As......................................................... 60
Send Folder ......................................................... 60
Deselect All.......................................................... 60
Print (Print Mode Only) ..................................60
Appendices .......................................... 61
Creating ftp Profiles Using the Camera
Menus ............................................................61
Troubleshooting .............................................64
Glossary..........................................................66
Specifications .................................................70
Index ..............................................................73

1
Thank you for purchasing a WT-3 or WT-3A wireless transmitter for compatible
Nikon digital cameras. The WT-3 is for use in the country of sale, the countries of the
European Union (EU) and European Free Trade Association (EFTA), Thailand, Japan,
and Hong Kong. The WT-3A is for use in the country of sale, Canada, and the United
States of America. The principal difference between the WT-3 and WT-3A is in the
number of channels supported ( 20, 49); unless otherwise stated, all references to
the WT-3 also apply to the WT-3A.
This manual describes how to connect the WT-3, how to control the camera from a
computer, and how to transmit images to a computer or printer. Before using the
WT-3, be sure to read the notices and warnings on pages i–vii.
The following symbols and conventions are used throughout this manual:
This icon marks cautions, infor-
mation that should be read be-
fore use to prevent damage to
the product.
This icon marks notes, informa-
tion that should be read before
using the device.
This icon marks tips, additional
information that may be helpful
when using the product.
This icon indicates that more in-
formation is available elsewhere
in this manual.
Background Knowledge
This manual assumes basic knowledge of ftp servers and local area networks (LAN).
For more information on installing, configuring, and using devices in a network,
contact the manufacturer or network administrator.
Life-Long Learning
As part of Nikon’s “Life-Long Learning”commitment to ongoing product support and
education, continually-updated information is available on-line at the following sites:
• For users in the U.S.A.: http://www.nikonusa.com/
• For users in Europe and Africa: http://www.europe-nikon.com/support
• For users in Asia, Oceania, and the Middle East: http://www.nikon-asia.com/
Visit these sites to keep up-to-date with the latest product information, tips, an-
swers to frequently-asked questions (FAQs), and general advice on digital imaging
and photography. Additional information may be available from the Nikon repre-
sentative in your area. See the URL below for contact information:
http://nikonimaging.com/
Introduction

2
Supported Modes
The WT-3 connects the camera to wireless and Ethernet networks. The camera can
then be controlled remotely from a computer or photographs transmitted from the
camera to an ftp server or printer. The WT-3 supports the following modes:
Mode Host Description Network type
Transfer
mode
Computer or
ftp server
Upload new or existing photographs to
host. Wireless and
Ethernet
30
PC mode Computer Control camera from computer. 37
Print
mode
Computer Print JPEG photographs on printer con-
nected to network computer. 42
PD-10 wireless
printer adapter
Print JPEG photographs on PictBridge
printer connected to optional PD-10
wireless printer adapter.
Wireless
only 45
The WT-3 Setup Utility CD
The supplied WT-3 Setup Utility CD contains the following:
• WT-3 Setup Utility ( 10, 15): Use this software to copy host profiles to the camera.
• D200 A and B firmware version 2.00 ( 9): Update to this version of the camera firm-
ware before using the WT-3.
• D200 firmware update manual ( 9): Read this manual for instructions on updating
the camera firmware.
Wireless Networks: Infrastructure Versus Ad-hoc
Wireless networks may be either infrastructure or ad-hoc.
• Infrastructure: Connection is via a wire-
less LAN access point.
• Ad-hoc: A peer-to-peer wireless network
consisting solely of the WT-3 and the
host.
WT-3
Host
Wireless LAN
access point
WT-3
Host

3
System Requirements
Before using the WT-3 or WT-3 Setup Utility CD, confirm that your system meets the
following requirements:
Camera
• Model: Nikon D200 digital single-lens reflex camera
• Firmware: A and B version 2.00 (provided on supplied WT-3 Setup
Utility CD)
Power source One EN-EL3e rechargeable Li-ion battery (supplied with D200) or
EH-6 AC adapter (available separately)
OS1
• To connect to a computer: Windows XP Service Pack 1 or later (Service
Pack 2 recommended) or Mac OS X version 10.3 or later required
(Power PC G4/G5 CPUs only). Connection to computers on other
networks via router not supported.
• To upload pictures to an ftp server: Operation has been confirmed with
Windows XP Professional and Mac OS X version 10.3 or later. Under
these operating systems, ftp servers can be configured using stan-
dard ftp services such as IIS (Internet Information Services). Internet
ftp connections and ftp servers running third-party software are not
supported.
Network
• Wireless: Wireless LAN access point or computer with built-in or ex-
ternal wireless LAN adapter (IEEE 802.11b or 802.11g compliant).2
• Ethernet: Ethernet cable and computer with built-in or external Eth-
ernet port (100 base-TX or 10 base-T)

4
Miscellaneous
• WT-3 Setup Utility: required to copy computer profiles to camera
(camera can be configured for use with ftp servers using either
WT-3 Setup Utility or camera menus). WT-3 Setup Utility can not
be used to configure camera for use with optional PD-10 wireless
printer adapter.
• CD-ROM drive: required when installing WT-3 Setup Utility
• USB:
UC-E4 USB cable (included with camera) and computer with built-
in USB port required when copying network profiles to camera.3
1. For the latest information on supported operating systems, see the Nikon web-
site for your area ( 1).
2. For information on wireless network settings for Windows XP Professional and
Mac OS X, see the online help for the WT-3 Setup Utility.
3. Connect the camera directly to the computer. The camera may not function as
expected when connected via a hub, extension cable, or keyboard.
The PD-10 Wireless Printer Adapter
A PictBridge-compatible printer with a flat (type A) USB connector is required for
connection to the PD-10. A computer is not required.
Multiple Transmitters
Simultaneous use of multiple WT-3 wireless transmitters with a single host may pro-
duce unexpected results. Do not attempt to use more than one WT-3 per host.

5
Parts of the WT-3
Connector cover
Knob ( 26)
Mounting screw ( 26)
Built-in antenna
Connector for extended
range antenna
Battery chamber
cover holder ( 26)
Power connector
AF-ON button
(6)
Main command
dial ( 6)
Status LEDs ( 35, 40, 44):
POWER (green),
LINK (orange),
BUSY (green)
Battery chamber
cover latch ( 28)
USB cable ( 26)
Power connector
cover ( 26)
DC-IN connector ( 29)
Ethernet connector
(30, 37, 42)
Tripod socket
Sub-command
dial ( 6)
Shutter-release
button ( 6)
Control lock
( 6, 27)
Signal connector
Extended range antenna
connector cap

6
The WA-E1 Extended Range Antenna (Available Separately)
The optional WA-E1 extended range antenna with tri-
pod mount can be used to extend the range of wire-
less transmitters.
When using the WA-E1, remove the antenna connec-
tor cap (햲) and connect the antenna as shown at right
(햳).
Restrictions on Wireless Devices
Wireless regulations vary from country to country. Wireless devices are available for
purchase only in countries in which they have been certified for use.
The WT-3 Controls
The WT-3 is equipped with a shutter-release button, AF-ON button, and command
dials for ease of use when taking photographs in tall (portrait) orientation. The shut-
ter-release button and command dials perform the same functions as the match-
ing controls on the camera body; for more information, see the camera manual. If
desired, the controls on the WT-3 can be disabled by rotating the control lock to
the Lposition. Please note that the control lock can not be used to turn the camera
on or off.
Sh
utter-re
l
ease
b
utto
n
Contro
l
l
oc
k
S
u
b
-
comman
d
d
ia
l
Ma
in
c
omman
d
d
ia
l
The command dials on the WT-3 are affected by the option selected for Custom
Setting f5 (Command dials). See the camera manual for details.
The function performed by the WT-3 AF-ON button is
determined by the option selected for Custom Setting
a10 (AF-ON for MB-D200).

7
Option Description
AF-ON+
Focus Area
(default)
AF-ON button on WT-3 performs same function as camera AF-ON
button. Focus area can be selected by pressing AF-ON button on
WT-3 and rotating sub-command dial.
AF-ON AF-ON button on WT-3 performs same function as camera AF-ON
button.
AE/AF-L+
Focus Area
AF-ON button on WT-3 performs same function as camera AE-L/AF-L
button. Focus area can be selected by pressing AF-ON button on
WT-3 and rotating sub-command dial.
AE/AF-L AF-ON button on WT-3 performs same function as camera AE-L/AF-L
button.
Focus Area Focus area can be selected by pressing AF-ON button on WT-3 and
rotating sub-command dial.
Same as
FUNC button
AF-ON button on WT-3 performs function currently assigned to
camera FUNC. button using Custom Setting f4 (FUNC. Button).

8
Setup
Follow the steps below to prepare the WT-3 for use:
Update the camera firmware : The WT-3 is supported from camera firmware A version
2.00 and B version 2.00. Users of earlier versions will need to update the camera
firmware as described in the firmware update manual on the supplied WT-3 Setup
Utility CD.
Connect the WT-3 ( 26)
Insert the battery ( 28)
Copy network profiles to the camera ( 15)
Install the WT-3 Setup Utility ( 10)
Copy network profiles to the camera: Users of Windows XP Service Pack 1 or later
or Mac OS X version 10.3 or later can copy computer or printer profiles to
the camera using the supplied WT-3 Setup Utility. Skip this step when using
the camera rather than a computer to adjust settings for connection to an
ftp server in transfer mode ( 61).
After setting up the WT-3 as described on the following pages, proceed to“Upload-
ing Images: Transfer Mode” ( 30), “Controlling the Camera: PC Mode” ( 37), or
“Printing Pictures: Print Mode”( 42).

9
Updating the Camera Firmware
The WT-3 is supported from camera firmware A version 2.00 and B version 2.00.
Display the camera firmware version as described in the camera manual. If earlier
versions are installed, update the camera firmware as described in the firmware
update manual on the supplied WT-3 Setup Utility CD.
To display the firmware update manual, start the Install
Center as described in Steps 1–3 of “Install the WT-3
Setup Utility” on page 10 (Windows) or 13 (Macintosh)
and click D200 Firmware to display the “D200 Firm-
ware”folder. Double-clicking INDEX.pdf displays a list
of languages; click a language to display the update
manual (Adobe Reader or Adobe Acrobat Reader 4.0
or later required).
D200 Firmware
Additional Updates
Once the camera firmware has been updated for use with the WT-3 as described
above, all subsequent updates should be performed with the WT-3 connected
( 26) and Off selected for Wireless transmitter > Wireless LAN system ( 47).
