Nivus OCM PRO CF User manual

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 1
Instruction Manual for
OCM Pro CF Measurement Device
(Original Instruction manual – German)
valid as of Software Revision No. 5.08
Firmware Radar: v1.00
NIVUS GmbH
Im Taele 2
75031 Eppingen, Germany
Phone [phone] / 91 91 - 0
Fax [phone] / 91 91 - 999
E-mail: [email protected]
Internet: www.nivus.com

Branch offices
page 2
®
IVUS AG
Hauptstrasse 49
CH - 8750 Glarus
Tel.: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.nivus.de
NIVUS Austria
Mühlbergstraße 33B
A-3382 Loosdorf
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.nivus.de
NIVUS France
14, rue de la Paix
F - 67770 Sessenheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.nivus.com
NIVUS U.K. Ltd
Wedgewood Rugby Road
Weston under Wetherley
Royal Leamington Spa
CV33 9BW, Warwickshire
Tel.: [phone]
E-mail: [email protected]
Internet: www.nivus.com
NIVUS U.K.
1 Arisaig Close
Eaglescliffe
Stockton on Tees
Cleveland, TS16 9EY
Phone: [phone]
E-mail: [email protected]
Internet: www.nivus.com
NIVUS Sp. z o.o.
ul. Hutnicza 3 / B-18
PL - 81-212 Gdynia
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.nivus.pl
NIVUS Middle East (FZE)
Building Q 1-1 ap. 055
P.O. Box: 9217
Sharjah Airport International
Free Zone
Tel.: [phone]
Fax: [phone]
E-Mail: [e-mail]
Internet: www.nivus.com
NIVUS Korea Co. Ltd.
#411 EZEN Techno Zone,
1L EB Yangchon Industrial Complex,
Gimpo-Si
Gyeonggi-Do 415-843,
Tel. [phone]
Fax. [phone]
E-Mail: [email protected]
Internet: www.nivus.com

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 3
Translation
If the device is sold to a country in the European currency area, this in-
struction handbook must be translated into the language of the country in
which the device is to be used.
Should the translated text be unclear, the original instruction handbook
(German) must be consulted or the manufacturer contacted for clarifica-
tion.
Copyright
No part of this publication may be reproduced, transmitted, sold or dis-
closed without prior permission. Damages will be claimed for violations.
All rights reserved.
Names
The use of general descriptive names, trade names, trademarks and the
like in this handbook does not entitle the reader to assume they may be
used freely by everyone. They are often protected registered trademarks
even if not marked as such.

Instruction manual
OCM Pro CF
page 4 OCM Pro CF - Rev. 09as of 07.06.2016
®
1General.................................................................................7
2Safety Instructions and Hazard Warnings.........................9
2.1 Used Hazard Warnings.................................................................9
2.2 Safeguards and Precautions.......................................................10
2.3 Liability Disclaimer.......................................................................10
2.4 User’s Responsibilities................................................................11
2.5 Device Identification....................................................................12
2.6 Installation of Spare Parts and Parts subject to wear and tear...13
2.7 Device Versions ..........................................................................13
3Overview and Intended Use..............................................14
3.1 Overview .....................................................................................14
3.2 Intended Use...............................................................................16
4Specifications ....................................................................17
5Storing, Delivery and Transport.......................................18
5.1 Receipt ........................................................................................18
5.2 Delivery .......................................................................................18
5.3 Storing.........................................................................................18
5.4 Transport.....................................................................................18
5.5 Return..........................................................................................18
6Functional Description......................................................19
6.1 General........................................................................................19
6.2 Level measurement using water ultrasound ...............................23
6.3 Level Measurement using Pressure............................................24
6.4 Level Measurement using external Level Sensor.......................24
6.5 Flow Velocity Detection...............................................................25
6.6 Flow velocity via Surface Radar OFR.........................................27
7Installation and Connection..............................................28
7.1 Installation Instructions................................................................28
7.1.1 Fastening Wall Mount Enclosure ................................................28
7.1.2 Wall Mount Enclosure Dimensions .............................................29
7.2 Electrical Installation....................................................................30
7.2.1 Connection of Transmitter in Wall Mount Enclosure...................30
7.2.2 Sensor connection - Wall mount enclosure ................................34
7.2.3 Wall Mount Enclosure Overvoltage Protection ...........................38
7.3 Connection of the panel mount enclosure...................................41
7.3.1 Fastening the panel mount enclosure.........................................41
7.3.2 Panel Mount Enclosure Dimensions...........................................41
7.3.3 Panel Mount Enclosure Transmitter Connection ........................41
7.3.4 Panel mount enclosure sensor connection.................................43
7.3.5 Panel Mount Enclosure Overvoltage Protection .........................47
7.4 Power Supply Wall and Panel Mount Enclosure.........................49
7.5 Regulator Mode...........................................................................50
7.5.1 General........................................................................................50
7.5.2 Construction of Measurement Section........................................52
7.5.3 Regulator Mode Wiring Diagram.................................................53
7.5.4 Control Algorithm.........................................................................53
7.6 Communication ...........................................................................54
7.6.1 General........................................................................................54
7.6.2 Communication Options..............................................................56
7.6.3 Communication Setup via Access Portal....................................57
7.6.4 Data Transmission ......................................................................59

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 5
8Initial Start-Up....................................................................65
8.1 General........................................................................................65
8.2 Operator Panel............................................................................66
8.3 Display.........................................................................................67
8.4 Operation Basics.........................................................................69
9Parameter Setting..............................................................70
9.1 Setting Basics..............................................................................70
9.2 Operation Mode (RUN) ...............................................................73
9.3 Display Menu (EXTRA)...............................................................77
9.4 Parameter Menu (PAR)...............................................................79
9.5 Parameter Menu (PAR)...............................................................79
9.5.1 Parameter Menu "Measurement Place"......................................79
9.5.2 Parameter Menu “Level “ ............................................................86
9.5.3 Parameter Menu „velocity “.........................................................98
9.5.4 Parameter Menu "Analog Inputs “.............................................105
9.5.5 Parameter Menu "Digital Inputs "..............................................107
9.5.6 Parameter Menu "Analog Outputs"...........................................109
9.5.7 Parameter Menu "Digital Outputs “ ...........................................111
9.5.8 Parameter Menu "Control unit " ................................................114
9.5.9 Parameter Menu "Settings “......................................................122
9.5.10 Parameter Menu "Storage Mode “ ............................................124
9.5.11 Data Structure on Memory Card ...............................................128
9.5.12 Parameter Menu "Communication “..........................................130
9.6 Signal Input/Output Menu (I/O).................................................136
9.6.1 I/O Menu „Analog inputs ” .........................................................136
9.6.2 I/O Menu "Digital Inputs ”..........................................................137
9.6.3 I/O Menu „Analog Outputs” .......................................................137
9.6.4 I/O Menu „Digital Outputs” ........................................................138
9.6.5 I/O Menu „Sensors”...................................................................138
9.6.6 I/O Menu "Interfaces"................................................................141
9.6.7 I/O Menu "Controller" ................................................................141
9.6.8 I/O-Menu "Memory Card"..........................................................142
9.6.9 I/O-Menu Communication .........................................................145
9.7 Calibration and Calculation Menu (CAL)...................................145
9.7.1 Cal-Menu "Level“.......................................................................145
9.7.2 Cal-Menu "Flow Velocity “.........................................................146
9.7.3 Cal-Menu "Analog Outputs “ .....................................................149
9.7.4 Cal-Menu "Relay Outputs “ .......................................................150
9.7.5 Cal-Menu "Simulation “ .............................................................151
10 Parameter Tree.................................................................152
11 Troubleshooting ..............................................................162
12 Verification of the Measurement Systems.....................166
12.1 General......................................................................................166
12.2 Verification of Combi Sensor with Pressure Measurement Cell166
12.3 Verification of external Level Measurement..............................167
12.4 Verification and Simulation of Input and Output Signals...........168
12.5 Verification of Flow Velocity Measurement...............................168
13 Maintenance and Cleaning .............................................170
13.1 Transmitter................................................................................170
13.2 Sensors .....................................................................................170
14 Accessories .....................................................................171
15 Table "Manning - Strickler Coefficients “......................172

Instruction manual
OCM Pro CF
page 6 OCM Pro CF - Rev. 09as of 07.06.2016
®
16 Emergency.......................................................................173
17 Dismantling/Disposal......................................................173
18 Table of Pictures..............................................................173
19 Index.................................................................................177
20 Certificates and Approvals .............................................179

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 7
1 General
Important
READ CAREFULLY BEFORE USE
KEEP IN A SAFE PLACE FOR LATER REFERENCE
This Instruction manual for the flow measurement unit OCM Pro CF is intended
for the initial start-up of the unit depicted on the title page. This manual is orient-
ed exclusively to qualified expert personnel.
Read this instruction manual carefully and completely prior to installation and
connection since it contains relevant information on this product. Observe the
notes and particularly follow the warning notes and safety instructions.
Keep this manual in a safe place and make sure it is available for the users of
this product at any time.
If you should have problems to understand information contained within this in-
struction manual either contact the manufacturer or one of the distributors for
further support. The manufacturer cannot be held responsible for damage to
persons or material due to incorrectly understood information in this instruction.
In case of selling the instrument this instruction manual shall be provided to the
purchaser since it is a part of the standard delivery.
Detailed information on how to operate the complete system can be found in the
accompanying instruction manual oft NIVUS, Sensors etc.
Personnel requirements
Installation, commissioning and maintenance shall be executed only by person-
nel meeting the demands as follows:
- Expert personnel with relevant training an appropriate qualification
- Personnel authorised by the plant operator
Qualified personnel
within the context of this documentation or the safety notes on the product
itself are persons who are sufficiently familiar with installation, mounting, start-
ing up and operation of the product and who have the relevant qualifications
for their work; for example.
- Training, instruction or authorisation to activate/deactivate, isolate, ground,
and mark electric circuits and devices/systems according to the safety en-
gineering standards.
- Education and instruction according to the standards of safety engineering
regarding the maintenance and use of adequate safety equipment.
- First aid training

Instruction manual
OCM Pro CF
page 8 OCM Pro CF - Rev. 09as of 07.06.2016
®
Applicable documentation
For the installation and operation of the complete system extra instruction man-
uals or technical descriptions may be required apart from this manual.
- Technical Instructions for correlation sensors and Electronic box
- Technical and Installation Instruction for Radar sensors OFR
These manuals are provided with the auxiliary units or sensors.

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 9
2 Safety Instructions and Hazard Warnings
2.1 Used Hazard Warnings
The general warning symbol indicates the risk of personal injuries or death. In
the text section the general warning symbol is used in conjunction with the
signal words described below.
DANGER
Hazard warnings
Indicates an immediate high risk which may result in death or severe personal
injury if not avoided.
WARNING
Danger of electrical shock
Indicates a possible danger by electrical power with moderate risk which may
result in death or severe personal injury if not avoided.
WARNING
Warning notice
Indicates a possible danger with moderate risk which may result in death or
severe personal injury if not avoided.
CAUTION
Notes for caution
Indicates a possible danger with moderate risk that may result in minor or
moderate injury or may result in property damage, if not avoided.
Important Note
Indicates a situation that could cause damage on this instrument if it is not
avoided.
Contains information that should be highlighted.
Note
Indicates a situation that will not result personal injury.

Instruction manual
OCM Pro CF
page 10 OCM Pro CF - Rev. 09as of 07.06.2016
®
2.2 Safeguards and Precautions
WARNING
Germ contamination
Please note that due to the operation in the waste water field the measure-
ment system and cables may be loaded with dangerous disease germs. Re-
spective precautionary measures must be taken to avoid damage to one’s
health.
Wear protective clothing.
WARNING
Observe regulations for health and safety at work
Before starting installation work, observing the work safety regulations need to
be checked.
Failure to do so may cause personal injury..
WARNING
Do not disable safety devices!
It is strictly prohibited to disable the safety devices or to change the way they
work.
Failure to observe may cause personal injury as well as to system damage.
WARNING
Disconnect from power supply
Disconnect the instrument from power supply before you begin to execute
maintenance, cleaning and/or repair works. Repair works shall be executed
solely by expert personnel.
Disregarding may lead to electrical shocks.
Important Note
The entire measurement system shall be installed and put into operation only
by qualified personnel.
2.3 Liability Disclaimer
The manufacturer reserves the right to change the contents of this document in-
cluding this liability disclaimer without prior notice and cannot be held responsi-
ble in any way for possible consequences resulting from such changes.
For connection, initial start-up and operation of the OCM Pro CF the following in-
formation and higher legal regulations (e.g. in Germany VDE), such as Ex-
regulations as well as safety requirements and regulations in order to avoid ac-
cidents, must be kept.
All operations on the device which go beyond installation or connection
measures in principle shall be carried out by NIVUS staff or personnel author-
ised by NIVUS due to reasons of safety and guarantee. The manufacturer is not
liable for failures resulting from improper or inappropriate use.

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 11
2.4 User’s Responsibilities
Important Note
In the EEA (European Economic Area) national implementation of the frame-
work directive 89/391/EEC and corresponding individual directives, in particu-
lar the directive 89/655/EEC concerning the minimum safety and health re-
quirements for the use of work equipment by workers at work, as amended,
are to be observed and adhered to.
The customer shall obtain any local operating permits required and observe the
provisions contained therein.
In addition to this, he must observe local laws and regulations on
- personnel safety (accident prevention regulations)
- safety of work materials and tools (safety equipment and maintenance)
- disposal of products (laws on wastes)
- disposal of materials (laws on wastes)
- cleaning (cleansing agents and disposal)
- environmental protection
Connections:
As an operator make sure prior to activating the OCM Pro CF that during instal-
lation and initial start-up, if executed by the operator himself, the local regula-
tions (such as regulations for electrical connection, operation in channels) are
observed.

Instruction manual
OCM Pro CF
page 12 OCM Pro CF - Rev. 09as of 07.06.2016
®
2.5 Device Identification
The instructions in this manual are valid only for the type of device indicated on
the title page. The nameplate is fixed on the bottom of the device and contains
the following:
- Name and address of manufacturer
- CE label
- Type and serial number
- Year of manufacture
- Ex-label (on Ex-version devices only) as mentioned in chapter Specifica-
tions.
It is important for queries and replacement part orders to specify type, year of
manufacture and serial number (Article no. if necessary). This ensures correct
and quick processing.
OCM Pro CF iin front panel enclosure with S4/M4 backplane:
OCM Pro CF in wall mount enclosure with S3/M3 backplane:
OCM Pro CF in wall mount enclosure with S4/M4 backplane:
Ex nameplate:
Fig. 2-1 OCM Pro CF nameplates

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 13
2.6 Installation of Spare Parts and Parts subject to wear and tear
We herewith particularly emphasize that replacement parts or accessories,
which are not supplied by us, are not certified by us, too. Hence, the installation
and/or the use of such products may possibly be detrimental to the device’s abil-
ity to work or even lead to instrument failure.
Damages or measurement errors caused by the use of non-original parts and
non-original accessories are left at user’s risk. You can find spare parts or ac-
cessories in chapter 14.
2.7 Device Versions
The OCM Pro CF measurement transmitter is available in different versions. The
type key below gives a brief overview on the various possibilities.
The transmitters vary in terms of the number of inputs and outputs, enclosure
construction, data transmission options, power supply and Ex protection. The
current type of device is indicated by the article number, which can be found on
a weatherproof label on the bottom of the enclosure.
From the type key below the type of device can be specified precisely.
OCP- Type
S4
M4
R4
F0
W0
00
IN
MA
MI
MG
A4
D4
0
E
OCP-
Intrinsically safe sensor supply in Ex zone 1
Internet communication via GPRS (GSMantenna required) (for W0
l)
Power Supply
100-240 V AC / 47-63 Hz
9-36 V DC
ATEX Approvals
none
Internet communication via internal ISDNmodem(for W0 enclosure)
Standard version with 2 relays, 2 mA output (galv. isolated), 1 mA input
(galv. isolated with 2-w ire sensor supply) or for external level measurement
Multifunctional version with 5 relays, 4 mA outputs (galv. isolated), 4 digital inputs, 5 analog
inputs (1 of themgalv. isolated with 2-w ire sensor supply), integrated 3-point step controller
with flush function, connecting options for up to 3 sensors
Panel mounting IP54 / IP20, no data transmission available
Construction
Wall-mounting IP65
Data Transmission
without Internet communication (for F0 enclosure)
Internet communication via Intranet (for W0 enclosure)
Internet communication via internal analog modem(for W0 enclosure)
Multifunctional version with 5 relays, 4 mA outputs (galv. isolated), 4 digital inputs, 5 analog
inputs (1 of themgalv. isolated with 2-w ire sensor supply), integrated 3-point step controller
with flush function, connecting options for one Radar sensors, type OFR
Fig. 2-2 Type key for OCM Pro CF measurement transmitters

Instruction manual
OCM Pro CF
page 14 OCM Pro CF - Rev. 09as of 07.06.2016
®
3 Overview and Intended Use
3.1 Overview
A Wall mount enclosure
B Panel mount enclosure
1 Slot with plugged Memory Card
2 USB interface (for service purposes only)
3 Keypad
4 Graphic display
5 Cable glands (only wall mount enclosure)
6 Terminal clamp housing with cover (only wall mount enclosure)
Fig. 3-1 Overview enclosure

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 15
1 Flow velocity wedge sensor, type POA-V2H1/V2U1
2
Flow velocity wedge sensor, type POA-V200/V2D0
3
Flow velocity wedge sensor, type CS2
4
Flow velocity pipe sensor, type CS2, with sensor screw joint and retaining element
5
Flow velocity pipe sensor, type POA, with sensor screw joint and retaining element
6 Air-ultrasonic level sensor, type OCL-L1
7 Flow velocity wedge sensor, type CSM-V100
8
Flow velocity wedge sensor, type CSM-V1D0
9
Air-ultrasonic level sensor, type DSM
10
Electronic Box, type EBM
11 Flow velocity radar sensor, type OFR
Fig. 3-2 Overview sensors and electronic box

Instruction manual
OCM Pro CF
page 16 OCM Pro CF - Rev. 09as of 07.06.2016
®
3.2 Intended Use
Important Note
The device is exclusively intended to be used for purposes as described
below.
Modifying or using the devices for other purposes without the written consent
of the manufacturer will not be considered as use in accordance with the re-
quirements.
Damages resulting from this are left at user’s risk.
The device is designed for a lifetime of approx. 10 years. After that period an
inspection in addition with a general overhaul must be carried out.
The measurement device type OCM Pro CF including the respective sensor
technology supplied by NIVUS is intended to be used for continuous flow meas-
urement of slight to heavy polluted media in part filled and full channels, pipes or
similar. Here the allowed maximum values, as specified in chapter 0, must be
strictly kept. All cases which vary from these conditions and are not approved by
NIVUS GmbH in written form are left at owner’s risk.
Important Note
Install the device outside of Ex zones!
The Ex approval of the sensors is part of the „Technical Description for Corre-
lation Sensors“.
Ex-Identification
Transmitter:
II (2)G [Ex ib Gb] IIB
CAUTION
Damages invalidate the Ex protection
Damage might invalidate the Ex protection.
The OCM Pro CF then is not allowed to be used in Ex area any longer.
Protect the OCM Pro CF from shocks, drops or other damage.
Note
The approval is only valid in connection with the respective indication on the
device nameplate.
The Ex-version of OCM Pro CF is matched to the NIVUS sensors regarding
the assessment of intrinsically safe electrical systems according to
EN 60079-25.
In case of using sensors from third party manufacturers the operator must
carry out a system review according to EN 60079-25!
The required specifications of the OCM Pro CF Ex version can be taken from
the EC-type examination certificate TÜV 00 ATEX 1572.

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 17
4 Specifications
Supply power
100 – 240 V AC, +10% /-15%, 47 to 63Hz
or 9- 36 V DC
Max. consumption
AC: 31 VA / DC: 34 W
Typ. consumption
1x POA-V1U1 + 1x NMC0 + 1 relay energised,
230 V AC: (rounded) 14 W
1x POA-V1U1 + 1 relay energised, 230 V AC = (rounded) 14 W
Wall mount enclosure
-
Material: Polycarbonate
- Weight: approx. 3400g
- Protection: IP 65
Panel mount enclosure
-
Material: Polycarbonate
- Weight: approx. 2800 g
- Protection: IP 54 (front side), IP 20 (reverse side)
Ex-Approval (optional)
II (2)G [Ex ib Gb] II B
Operating temperature
-20°C to +50°C [Ex: -20°C to +40°C]
Storage temperature
-30°C to +70°C
Max. humidity
80%, non-condensing
Display
Back-lit graphic display, 128 x 128 pixel
Operation
18 keys, dialog mode in German, English, French, Czech, Italian,
Spanish, Polish, Danish, Swedish
Inputs
-
1 x 4-20 mA for external level measurement (2-wire sensor)
- 1 x RxTx-Bus for NIVUS air-ultrasonic sensor type OCL/DSM
- 1 x (type S4) or 4 x (type M4) 0/4-20 mA 12 bit resolution for external
level measurement, external control set points and external units data
storage, accuracy +/- 0.4 % of final value (20 mA)
- 4 digital inputs (type M4 only)
- 1 (type S4) or 2/3 (type M4) velocity sensors (POA, CS2 or electronic
box EBM + CSM) connectable
Outputs
-
2 x (type S4) or 4 x (type M4) 0/4-20 mA, load 500 Ohm,
12 bit resolution, accuracy better than 0.1 %
- 2 x (type S4) or 5x (type M4) switchable relays, loadable up to 230 V
AC / 2 A (cos. φ0.9), minimum switching load 10 mA
Data memory
-
1 MB internal data memory for programming and saving of readings
- optional plug-in Compact Flash Card up to 128 MB
Storage cycle
1 to 60 minutes
Data transmission
(for panel mount enclosure
only)
-
Modbus TCP using integrated web server coupling via networks
- (LAN /WAN, Internet)
- Internet via Ethernet
- internal ISDN-, GPRS- or analog modem (optional)
Sensors (optional)
For the specifications on the according sensors please see the appropriate instruction manuals or tech-
nical descriptions.

Instruction manual
OCM Pro CF
page 18 OCM Pro CF - Rev. 09as of 07.06.2016
®
5 Storing, Delivery and Transport
5.1 Receipt
Check your delivery according to the delivery note for completeness and intact-
ness immediately after receipt. Report any damage in transit to the carrier im-
mediately. Send a written report to NIVUS GmbH Eppingen as well.
Report any delivery incompleteness in writing to your representative or directly
to NIVUS Eppingen within two weeks
Mistakes cannot be rectified later!
5.2 Delivery
The standard delivery of the OCM Pro CF measurement system contains:
- the instruction manual with the certificate of conformity. Here, all necessary
steps to correctly install and to operate the transmitter are listed.
- one OCM Pro CF transmitter, type S4, M4 or R4
- one pc. of evaluation software type NivuSoft 2.0 for Windows®Vista, 7 or 8
Check any additional accessories by using the delivery note.
5.3 Storing
Maintain the storage conditions:
max. Temperature: + 70°C
min. Temperature: - 30°C
max. humidity: 80 %, non-condensing
During the storage always protect the device from corrosive or organic solvent
vapours, radioactive radiation and strong electromagnetic radiation.
5.4 Transport
Protect the measurement system from shock and impact loads and vibrations.
The transportation must be carried out in the original packaging.
5.5 Return
The units must be returned at customer cost to NIVUS Eppingen in the original
packaging free of charge.
Returns with insufficient postage will not be accepted!

Instruction manual
OCM Pro CF
®
OCM Pro CF - Rev. 09as of 07.06.2016 page 19
6 Functional Description
6.1 General
The OCM Pro CF is a stationary measurement system for flow measurement
and storage of the detected measurement data. Type M4 additionally allows to
use a 3-step controller to drive a slide valve or similar flow control actuator. Fur-
thermore up to 4 external measurement values can be stored. Wall mount en-
closure units can be accessed remotely using the TCPIP protocol via Internet.
The device is designed to be used for measurements primarily in slight to heavy
polluted media with various compositions. It can be operated in part filled and full
channels and pipes with various shapes and dimensions.
Important Note
The method of flow velocity investigation is based on the ultrasound reflection
principle. Hence, it is indispensable for the system to work that there are
particles in the water, which are able to reflect the ultrasonic signal sent by the
sensor (dirt particles, gas bubbles or similar). Alternative the surface velocity
can be measured by using an OFR radar sensor. This sensor must not get in
contact with the medium.
The OCM Pro CF type S4 either uses a POA or a CS2 sensor which simultane-
ously determines flow velocity and flow level. Alternatively, a CSM sensor in
con-junction with the electronic box EBM may be connected, which however
merely is a flow velocity sensor.
Type M4 allows to connect up to 3 POA or CS2 sensors or type EBM electronic
boxes with type CSM sensors at the same time to accurately detect the flow ve-
locity at one common measurement point.
In order to connect a type OFR surface radar the first sensor input can be used.
Use a transmitter type R4 for this kind of connection.

Instruction manual
OCM Pro CF
page 20 OCM Pro CF - Rev. 09as of 07.06.2016
®
Fig. 6-1 Possible combinations OCP type S4 / R4
Note
A maximum of one OFR surface radar can be connected.
h
v
sensor type POA/CS2
sensor type OCL
OCP/S4
AI external level
Sensor 4
Sensor 1
h
v
sensor type CSM
sensor type DSM
Sensor 2
Sensor 3
Electronic Box
type EBM
OCP/S4
AI external level
Sensor 4
Sensor 1
Sensor 2
Sensor 3
h
Sensor type OFR
OCP/S4 + R4
AI external level
Sensor 4
Sensor 1
Sensor 2
Sensor 3
