NKT Photonics SuperK FIANIUM FIU-6 User manual

Item 800-613-01
SUPERK FIANIUM
PRODUCT GUIDE
White Light Laser

PRODUCT GUIDE
This guide includes the following NKT Photonics Lasers:
SuperK FIANIUM FIU-6
Supercontinuum White Light Laser with or without optional Variable Repetition
Rate and approximately 2.2 watts total power
SuperK FIANIUM FIU-15
Supercontinuum White Light Laser with or without optional Variable Repetition
Rate and approximately 5.5 watts total power
SuperK FIANIUM FIR-20
Supercontinuum White Light Laser with or without optional Variable Repetition
Rate and approximately 6.5 watts total power
SuperK FIANIUM Product Guide Revision 1.4 01-2021 W-10456

3
GUIDE OVERVIEW
This product guide is intended to provide functional, operational and installation
information for the SuperK FIANIUM laser systems. The guide is divided into
three sections:
• SuperK FIANIUM Description – introduces the laser’s theory and
functionality, its features and interfaces, and describes the safety labels and
their placement.
• Installing the Laser – includes the details on how to install the laser chassis
variants and connect it to the management platform and your application
systems.
• Operating the Laser – provides information and procedures on how to
configure communications with the laser and manage its operation.
For information on how to safely deploy and operate the laser refer to the
following documents:
• SuperK FIANIUM Safety, Handling and Regulatory Information
Target Audience This guide is for technical personnel involved in the selection, planning and
deployment of lasers in laboratory and industrial settings. The guide assumes a
reasonable knowledge level of lasers, photonic principles and electrical interface
connectivity.
Chapters Inside This guide includes the following chapters:
• Chapter I “Laser Description” — Describes the SuperK FIANIUM laser series
including its general operational principles, management and interfaces.
• Chapter 2 “Mechanical Installation” — Includes information and procedures
on how to correctly install the laser chassis. Procedures within this chapter
focus on providing adequate temperature regulation.
• Chapter 3 “Connecting the Laser” — This chapter provides the information on
how to physically connect the safety interlock, power, the optical collimator,
and the synchronization interfaces.
• Chapter 4 “Connecting External Control” — This chapter provides the details
on how to implement external signals to modulate the output, enhance
power stability and gate the output pulses.
• Chapter 5 “Front Panel Controls” — Describes the laser’s front panel menu
and controls that directly operate the laser.
• Chapter 6 “Using CONTROL to Turn ON the Laser” — Provides information
and procedures on how to connect to the laser’s management software and
use it to turn the laser emissions ON and OFF.

4
• Chapter 7 “CONTROL Interface” — Includes descriptions and procedures of
all other CONTROL menu and panel items.
• Appendices — The guide includes multiple appendices including laser
specifications, support contact details, pinout information, accessory
descriptions and miscellaneous procedures supporting the laser operation
and installation.
Added information
and Safety Notices
Lasers are highly dangerous devices that can cause serious injury and property
damage. This guide use the following symbols to either highlight important safety
information or provide further information in relation to a specific topic.
Note: Highlights additional information related to the associated topic and/or pro-
vides links or the name of the NKT guides describing the additional information.
Caution: Alerts you to a potential hazard that could cause loss of data, or damage
the system or equipment.
Warning: The laser safety warning alerts you to potential serious injury that may
be caused when using the laser.
Revision The section records the document revision details.
Release date Version and changes
2020-September 1.0 first release
2020-October 1.1 Updated External feedback description
2020-October 1.2 Updated Interlock descriptions and added additional
synchronization and gate cabling specifications throughout.
2020-December 1.3 The following changes were made:
•Updated power button usage descriptions.
•Added appendix C External Bus Pinout.
2021-January 1.4 The following changes were made:
•Updated support contact details in appendix B.
•Rearranged parapgraph order of appendix D.

5
