SPN10
Semi-Electric Stacker
Note:Owner and Operator MUST read and understand this operating
instructions before use this stacker.

1
Welcome to use our half-electric stacker SPN series. Your stacker is made of high
quality steel and SPED mast and was designed to give a durable, reliable and easy
to use product. For your safety and correct operation, please carefully read this
instruction book and warnings on the stacker before using it.
NOTE: All of the information reported herein is based on data available at the
moment of printing. We reserves the right to modify our own products at any
moment without notice and incurring in any sanction. So, it is suggested to
always verify possible updates.
1. STRUCTURAL DATA FORM
Model
SPN10
Capacity
Kg
1000
Lift Height
mm
1600/2500/3000/3500
Fork Size
mm
900x150x60 or 1100x160x60
Overall Height
mm
2077/1827/2077/2327
Lift Speed with/without
Load
mm/sec
80/130
Lower Speed with/without
Load
mm/sec
0~420/0~190
Min. Fork Height
mm
85
Battery
DC12V, 120AH
Motor of Hydraulic Pump
DC12V, 1.5KW
2. SAFETY GUIDANCE
2.1 Operator should read all warning signs and instructions here and on the
stacker before using it.
2.2 Do not operate a stacker unless you are familiar with it and have been trained
or authorized to do so.
2.3 Do not operate a stacker unless you have checked its condition. Give special
attention to the chain, the wheels, the handle, the guide frame, the pilot wheel,
the mast, battery, etc.
2.4 Do not use on a slopping ground or on a barbaric or explosive danger
environment.
2.5 Do not take up any people on the forks.
2.6 When forks lifting, forbid anyone to stand under the forks or pass through the
forks.
2.7 The operator had better take on gloves for labor protecting.
2.8 Do not move the stacker when the goods are lifted to the height more than
300mm.
2.9 When the goods have been transported or lifted, all people should be away
from the forks for 600mm.
2.10The weight of goods should be distributed on the two forks, do not use only one
fork. The center of gravity of goods should be in the center of two forks.
2.11 Do not load over maximum capacity.
2.12 Before using or charging it, check cell liquid, if not enough, full it with distilled

2
water.
2.13 Charging should be in dry and ventilated location, and far away from the fire.
2.14 Keeping the forks in the lowest position if not using.
2.15 At other special condition or place, the operator should be carefully to operate
the stacker.
3. MAINTENANCE
3.1 Hydraulic oil
Please check the oil level every six months. The oil can be hydraulic oil: ISO
VG32, its viscosity should be 32cSt at 40oC, total volume is about 4.0lt.
3.2 Daily check and maintenance
It is necessary to check the stacker daily. Special attention should be paid to the
wheels, the axles, as thread, rags, etc., it may block the wheels, the fork and the
mast, the chain, the battery should be checked, too. The forks should be unloaded
and lowered in the lowest position when the job is over.
3.3 Lubrication
Use motor oil or grease to lubricate all movable parts.
4. HOW TO CHARGE STORAGE BATTERY
4.1 Charge storage battery when its voltage is less than 10 Volt.
4.2 Please check the battery liquid before charging, if it is not enough, add some
distilled water.
4.3 The charging environment should be ventilated and far away from the fire.
4.4 If the stacker not use for long time, charge it for not less than two hours every
week.
4.5 The voltage on the indicator should not be over 15 Volt when charging.
4.6 Do not use the stacker when charging.
5. CONTROL PANEL
Fig. 1
5.1 Urgent switch

3
When you press down this switch, it will switch off the power, and then you turn it
clockwise, it will switch on the power.
5.2 Voltage meter
It indicates the voltage of battery. When its voltage is less than 10 Volt, you should
not use this stacker, you must charge it.
5.3 Control stick
This stick controls the forks to lower or lift.
5.4 Charger socket
6. TROUBLES SHOOTING
No
Trouble
Clause
Fixing Methods
1
The forks can not be up
the max. height.
-The hydraulic oil is not enough.
-Pour in the oil.
2
The forks can not be
lifted up.(Motor is rotary)
-Without hydraulic oil.
-The oil has impurities.
-Fill in the oil.
-Change the oil.
3
The motor cannot run.
-The urgent switch is pressed
down, cut off the power.
-The voltage is too lower.
-The connectors of electrical
wire is loose.
-The contactor of DC motor is
bad.
-Turn it clockwise, switch on
the power
-Charge it.
-Turn it firm.
-Replace with new one.
4
The forks cannot be
descended.
-The piston rod or mast is
deformed resulting from partial
loading slanting to one side or
over-loading.
-The fork was kept in the high
position for long time with
piston rod bared to arise in
rusting and jamming of the rod.
-The release valve of pump is
not opened.
- Replace with new one.
-Keeping the fork in the lowest
position if not using, and pay
more attention to lubricate
the rod.
-Check it, if damaged, replace
with new one.
5
Leaks
-Sealing parts worn or damaged.
-Some part cracked or worn into
small.
-Replace with the new one.
-Replace with the new one.
6
The fork descends
without the release
valve worked.
-The impurities in the oil cause
the release valve to be unable
to close tight.
-Sealing parts worn or damaged.
-The release valve is damaged.
-Replace with new oil.
-Replace with the new one.
-Replace with the new one.
7
Battery cannot be
charged
-Battery is bad.
-The charging plug is loose.
-Replace with the new one.
-Turn it firm.
NOTE: DO NOT ATTEMP TO REPAIR THE STACKER UNLESS YOU
ARE TRAINED AND AUTHORIZED TO DO SO.
7. Parts List

4
7.1 SPN1025/SPN1525 、SPN1030/SPN1530andSPN1035/SPN1535 part list
SPN1025/SPN1525 、SPN1030/SPN1530andSPN1035/SPN1535 part list

5
No.
Code
Description
Qty.
No.
Code
Description
Qty.
101
D13570012
Inner Mast (2.5)
1
155
503020012
Washer
1
D13570018
Inner Mast (3.0)
1
156
502040020
Nut
1
102
504040022
Locking Ring
2
157
D01640004
Foot Plate
1
103
349010201
Bearing
2
158
504030004
Locking Ring
1
104
422260011
Roller For Chain
2
159
301726012
Shaft
1
105
504030013
Locking Ring
2
160
D01640003
Brake
1
106
5010808010C0
Screw
1
161
302010116
Spring
1
107
504040025
Locking Ring
8
162
422680028
Bolt
1
108
349010119
Bearing
8
163A
349030011
Sprocket Wheel
1
109
422670037
Roller (φ88x36)
4
163
422680046
Sprocket Wheel
1
109A
422670035
Roller (φ106x36)
4
164
422670019
Seat of Turning
Wheel
1
110
504030018
Locking Ring
8
165
30301WH054
Big Wheel
2
111
5010410020C0
Bolt
2
166
349010113
Bearing
4
112
5010408040C0
Bolt
6
167
506060017
Oil holder
2
113
422670020
Crutch of Idler
Pulley
2
168
422680037
Washer
2
114
301726012
Shaft
2
169
502040012
Locking Nut
2
115
422680012
Idler Pulley
2
170
422660031A
Axle for wheel
2
116
504030004
Locking Ring
2
171
30301WH017
Loading Roller
4
117
D13570010
Mast (2.5)
1
172
349010113
Bearing
8
D13570016
Mast (3.0)
1
173
503010036
Washer
8
118
301727017
Hoop
1
174
301810037
Shaft
4
119
502030005
Nut
4
175
333050001
Linking Plate
4
120
50101010040
Bolt
1
176
505020088
Elastic Pin
8
121
502990006
Nut
2
177
D13570011
Fork Carriage
1
122
422670027
Protecting
Meshwork
1
178
504030021
Locking Ring
2
122A
422670028
Protecting
Meshwork
1
179
D06520013
Long Axle
1
123
506030109
Press Washer
8
180Y
422670015
Fork
2
124
503010058
Elastic Washer
8
181
502030011
Nut
4
125
5010506016C0
Bolt
8
182
422680024
Bolt
2
126
350230001
Handle
2
183
505020031
Pin
4
127
422680014
Cover
1
184
505040010
Cotter pin
8
128
30909400006
Charging Plug
1
185
349030136
Chain (1025)
2
129
30906200006
Urgent Switch
1
349030131
Chain (1030)
2
130
30916400394
Pump Station
1
186
504070041
O-Ring
1
131
30905100004
Voltage Meter
1
187
351420015
Body of Adjusting
Valve
1
132
502030005
Nut
4
188
G110203006
Safety Valve
1
133
5010506016C0
Bolt
6
192
503030008
Seal Washer
1
134
30901700002
Battery
1
193
422020186
Elbow Bend
1
135
5010610016C0
Bolt
2
194
30916400328
Vitta
1
136
422570030
Cap
2
195
422020187
Elbow Bend
1
137A
349010121
Bearing (6206)
2
196
G36020001
Earthen Pipe (2.5)
1
137
349010119
Bearing (6205)
1
G36020002
Earthen Pipe (3.0)
1

6
138A
622020032
Bearing (30206)
2
197
G07020003
Sleeve
1
138
349010145
Bearing (30205)
1
198
504080020
Dust Ring
1
139
422670019
Seat of Wheel
1
199
422680035
Cover
1
140
350230002
Draw-Bar for
Turning
1
200
351420021
Piston Rod (2.5)
1
351420023
Piston Rod (3.0)
1
141
302990030
Gas spring
1
201
351420016
Piston
1
142
504030003
Locking Ring
2
202
504070071
O-Ring
2
143
422670014
Washer
2
203
504070107
O-Ring
1
144
301726010
Shaft
1
204
504010041
Seal
1
145
504030004
Locking Ring
2
205
422680039
Supporting Loop
1
146
301726014
Shaft
1
207
502040024
Nut
1
147
504030003
Locking Ring
2
208
D06520012
Traverse
1
148
301726009
Shaft
1
209
422680026
Box
1
149
D01630001
Seat of Draw-Bar
1
210
301799039
Washer
8
150
211
422040575
Washer
8
151
G36040002
Washer
1
212
502030005
Nut
1
151A
G36040004
Washer
1
213
30911100010
Fuse
1
152
503010054
Washer
2
214
30910100034
Charger
1
153
349030033
Chain
1
154
503010068
Washer
1

7
7.2 SPN1025G/SPN1525G、SPN1030G /SPN1530 andSPN1035G/SPN1535
part list

8
SPN1025G/SPN1525G 、SPN1030G /SPN1530G andSPN1035/SPN1535part
list
No.
Code
Description
Qty.
No.
Code
Description
Qty.
101
D13570012
Inner Mast (2.5)
1
153
349030033
Chain
1
D13570018
Inner Mast (3.0)
1
154
503010068
Washer
1
102
504040022
Locking Ring
2
155
503020012
Washer
1
103
349010201
Bearing
2
156
502040020
Nut
1
104
422260011
Roller For Chain
2
157
D01640004
Foot Plate
1
105
504030013
Locking Ring
2
158
504030004
Locking Ring
1
106
5010808010C0
Screw
1
159
301726012
Shaft
1
107
504040025
Locking Ring
8
160
D01640003
Brake
1
108
349010119
Bearing
8
161
302010116
Spring
1
109
422670037
Roller (φ88x36)
4
162
422680028
Bolt
1
109A
422670035
Roller (φ106x36)
4
163A
349030011
Sprocket Wheel
1
110
504030018
Locking Ring
8
163
422680046
Sprocket Wheel
1
111
5010410020C0
Bolt
2
164
422670019
Seat of Turning
Wheel
1
112
5010408040C0
Bolt
6
165
30301WH054
Big Wheel
2
113
422670020
Crutch of Idler Pulley
2
166
349010113
Bearing
4
114
301726012
Shaft
2
167
506060017
Oil holder (
2
115
422680012
Idler Pulley
2
168
422680037
Washer
2
116
504030004
Locking Ring
2
169
502040012
Locking Nut
2
117A
D13570007
Mast (2.5)
1
170
422660031A
Axle for wheel
2
D13570013
Mast (3.0)
1
171
30301WH017
Loading Roller
4
118
301727017
Hoop
1
172
349010113
Bearing
8
119
502030005
Nut
4
173
503010036
Washer
8
120
50101010040
Bolt
1
174
301810037
Shaft
4
121
502990006
Nut
2
175
333050001
Linking Plate
4
122
422670027
Protecting Meshwork
1
176
505020088
Elastic Pin
8
122A
422670028
Protecting Meshwork
1
180
422670015
Mobile Forks
group
1
123
506030109
Press Washer
8
181
502030011
Nut
4
124
503010058
Elastic Washer
8
182
422680024
Bolt
2
125
5010506016C0
Bolt
8
183
505020031
Pin
4
126
350230001
Handle
2
184
505040010
Cotter pin
8
127
422680014
Cover
1
185
349030136
Chain (1025)
2
128
30909400006
Charging Plug
1
349030131
Chain (1030)
2
129
30906200006
Urgent Switch
1
186
504070041
O-Ring
1
130
30916400394
Pump Station
1
187
351420015
Body of Adjusting
Valve
1
131
30905100004
Voltage Meter
1
188
G110203006
Safety Valve
1
132
502030005
Bolt
4
192
503030008
Seal Washer
1
133
5010506016C0
Bolt
6
193
422020186
Elbow Bend
1
134
30901700002
Battery
1
194
30916400328
Vitta
1
135
5010610016C0
Bolt
2
195
422020187
Elbow Bend
1
136
422570030
Cap
2
196
G36020001
Earthen Pipe (2.5)
1
137A
349010121
Bearing (6206)
2
G36020002
Earthen Pipe (3.0)
1

9
137
349010119
Bearing (6205)
1
197
G07020003
Sleeve
1
138A
622020032
Bearing (30206)
2
198
504080020
Dust Ring
1
138
349010145
Bearing (30205)
1
199
422680035
Cover
1
139
422670019
Seat of Wheel
1
200
351420021
Piston Rod (2.5)
1
140
350230002
Draw-Bar for Turning
1
351420023
Piston Rod (3.0)
1
141
302990030
Gas spring
1
201
351420016
Piston
1
142
504030003
Locking Ring
2
202
504070071
O-Ring
2
143
422670014
Washer
2
203
504070107
O-Ring
1
144
301726010
Shaft
1
204
504010041
Seal
1
145
504030004
Locking Ring
2
205
422680039
Supporting Loop
1
146
301726014
Shaft
1
207
502040024
Nut
1
147
504030003
Locking Ring
2
208
D06520012
Traverse
1
148
301726009
Shaft
1
209
422680026
Box
1
149
D01630001
Seat of Draw-Bar
1
210
301799039
Washer
8
150
1
211
422040575
Washer
8
151
G36040002
Washer
1
212
502030005
Nut
1
151A
G36040004
Washer
1
213
30911100010
Fuse
1
152
503010054
Washer
2
214
30910100034
Charger
1

10
7.3 SPN1016 part list

11
SPN1016 part list
No.
Code
Description
Qty.
No.
Code
Description
Qty.
101A
422670008
Holding plate
1
160
D01640003
Brake
1
102
504040022
Locking Ring
2
161
302010116
Spring
1
103
349010201
Bearing
2
162
422680028
Bolt
1
104
422260011
Roller For Chain
2
163A
349030011
Sprocket Wheel
1
105
504030013
Locking Ring
2
163
422680046
Sprocket Wheel
1
106
5010808010C0
Screw
1
164
422670019
Seat of Turning
Wheel
1
107
504040025
Locking Ring
4
165
30301WH054
Big Wheel
2
108
349010119
Bearing
4
166
349010113
Bearing
4
109
422670037
Roller (φ88x36)
4
167
506060017
Oil holder
2
110
504030018
Locking Ring
4
168
422680037
Washer
2
117S
D13570004
Mast (1.6)
1
169
502040012
Locking Nut
2
118
301727017
Hoop
1
170
422660031A
Axle for wheel
2
119
502030005
Nut
2
171
30301WH017
Loading Roller
4
120
50101010040
Bolt
1
172
349010113
Bearing
8
121
502990006
Nut
2
173
503010036
Washer
8
122S
422670027
Protecting
Meshwork
1
174
301810037
Shaft
4
123
506030109
Press Washer
6
175
333050001
Linking Plate
4
124
503010058
Elastic Washer
6
176
505020088
Elastic Pin
8
125
5010506016C0
Bolt
6
177S
D13550004
Fork Carriage
1
126
350230001
Handle
2
178
504030021
Locking Ring
2
127
422680014
Cover
1
179
D06520013
Long Axle
1
128
30909400006
Charging Plug
1
180Y
422670015
Fork
2
129
30906200006
Urgent Switch
1
181
502030011
Nut
4
130
30916400394
Pump Station
1
182
422680024
Bolt
2
131
30905100004
Voltage Meter
1
183
505020031
Pin
4
132
502030005
Bolt
4
184
505040010
Cotter pin
8
133
5010506016C0
Bolt
6
185
349030133
Chain
2
134
30901700002
Battery
1
186
504070041
O-Ring
1
135
5010610016C0
Bolt
2
187
351420015
Body of Adjusting
Valve
1
136
422570030
Cap
2
188
G110203006
Safety Valve
1
137A
349010121
Bearing (6206)
2
192
503030008
Seal Washer
1
137
349010119
Bearing (6205)
1
193
422020186
Elbow Bend
1
138A
622020032
Bearing (30206)
2
194
30916400328
Vitta
1
138
349010145
Bearing (30205)
1
195
422020187
Elbow Bend
1
139
422670019
Seat of Wheel
1
196
G36020005
Earthen Pipe (1.6)
1
140
350230002
Draw-Bar for
Turning
1
197
G07020003
Sleeve
1
141
302990030
Gas spring
1
198
504080020
Dust Ring
1
142
504030003
Locking Ring
2
199
422680035
Cover
1
143
422670014
Washer
2
200
351420022
Piston Rod (1.6)
1

12
144
301726010
Shaft
1
201
351420016
Piston
1
145
504030004
Locking Ring
2
202
504070071
O-Ring
2
146
301726014
Shaft
1
203
504070107
O-Ring
1
147
504030003
Locking Ring
2
204
504010041
Seal
1
148
301726009
Shaft
1
205
422680039
Supporting Loop
1
149
D01630001
Seat of
Draw-Bar
1
207
502040024
Nut
1
150
209
422680026
Box
1
151
G36040002
Washer
1
210
301799039
Washer
8
151A
G36040004
Washer
1
211
422040575
Washer
8
152
503010054
Washer
2
212
502030005
Nut
1
153
349030033
Chain
1
213
30911100010
Fuse
1
154
503010068
Washer
1
214
30910100034
Charger
1
155
503020012
Washer
1
156
502040020
Nut
1
157
D01640004
Foot Plate
1
158
504030004
Locking Ring
1
159
301726012
Shaft
1

13
7.4 SPN1016G part list

14
SPN1016G part list
No.
Code
Description
Qty.
No.
Code
Description
Qty.
101A
422670008
Holding plate
1
157
D01640004
Foot Plate
1
102
504040022
Locking Ring
2
158
504030004
Locking Ring
1
103
349010201
Bearing
2
159
301726012
Shaft
1
104
422260011
Roller For Chain
2
160
D01640003
Brake
1
105
504030013
Locking Ring
2
161
302010116
Spring
1
106
5010808010C0
Screw
1
162
422680028
Bolt
1
107
504040025
Locking Ring
4
163A
349030011
Sprocket Wheel
1
108
349010119
Bearing
4
163
422680046
Sprocket Wheel
1
109
422670037
Roller (φ88x36)
4
164
422670019
Seat of Turning
Wheel
1
110
504030018
Locking Ring
4
165
30301WH054
Big Wheel
2
117SG
D13570001
Mast (1.6)
1
166
349010113
Bearing
4
118
301727017
Hoop
1
167
506060017
Oil holder (
2
119
502030005
Nut
2
168
422680037
Washer
2
120
50101010040
Bolt
1
169
502040012
Locking Nut
2
121
502990006
Nut
2
170
422660031A
Axle for wheel
2
122S
422670027
Protecting
Meshwork
1
171
30301WH017
Loading Roller
4
123
506030109
Press Washer
6
172
349010113
Bearing
8
124
503010058
Elastic Washer
6
173
503010036
Washer
8
125
5010506016C0
Bolt
6
174
301810037
Shaft
4
126
350230001
Handle
2
175
333050001
Linking Plate
4
127
422680014
Cover
1
176
505020088
Elastic Pin
8
128
30909400006
Charging Plug
1
180SG
422670015S
Mobile Forks
group
1
129
30906200006
Urgent Switch
1
181
502030011
Nut
4
130
30916400394
Pump Station
1
182
422680024
Bolt
2
131
30905100004
Voltage Meter
1
183
505020031
Pin
4
132
502030005
Bolt
4
184
505040010
Cotter pin
8
133
5010506016C0
Bolt
6
185
349030133
Chain
2
134
30901700002
Battery
1
186
504070041
O-Ring
1
135
5010610016C0
Bolt
2
187
351420015
Body of Adjusting
Valve
1
136
422570030
Cap
2
188
G110203006
Safety Valve
1
137A
349010121
Bearing (6206)
2
192
503030008
Seal Washer
1
137
349010119
Bearing (6205)
1
193
422020186
Elbow Bend
1
138A
622020032
Bearing (30206)
2
194
30916400328
Vitta
1
138
349010145
Bearing (30205)
1
195
422020187
Elbow Bend
1
139
422670019
Seat of Wheel
1
196
G36020005
Earthen Pipe (1.6)
1
140
350230002
Draw-Bar for
Turning
1
197
G07020003
Sleeve
1
141
302990030
Gas spring
1
198
504080020
Dust Ring
1
142
504030003
Locking Ring
2
199
422680035
Cover
1
143
422670014
Washer
2
200
351420022
Piston Rod (1.6)
1

15
144
301726010
Shaft
1
201
351420016
Piston
1
145
504030004
Locking Ring
2
202
504070071
O-Ring
2
146
301726014
Shaft
1
203
504070107
O-Ring
1
147
504030003
Locking Ring
2
204
504010041
Seal
1
148
301726009
Shaft
1
205
422680039
Supporting Loop
1
149
D01630001
Seat of Draw-Bar
1
207
502040024
Nut
1
150
1
209
422680026
Box
1
151
G36040002
Washer
1
210
301799039
Washer
8
151A
G36040004
Washer
1
211
422040575
Washer
8
152
503010054
Washer
2
212
502030005
Nut
1
153
349030033
Chain
1
213
30911100010
Fuse
1
154
503010068
Washer
1
214
30910100034
Charger
1
155
503020012
Washer
1
156
502040020
Nut
1
version number：090720
