Nokia 201 User manual

Nokia 201 User Guide
Issue 1.0

Contents
Safety 4
Get started 5
Keys and parts 5
Insert a SIM card and battery 6
Charge the battery 7
Switch the phone on or off 8
Insert a memory card 8
GSM antenna 9
Connect a headset 10
Attach the wrist strap 10
Basic use 10
Access codes 10
Lock the keys 11
Indicators 11
Copy contacts or pictures from your
old phone 12
Use your phone without a SIM card 12
Calls 12
Make a call 12
View your missed calls 13
Call the last dialled number 13
Divert calls to your voice mailbox or
another phone number 13
Contacts 14
Save a name and phone number 14
Use speed dial 14
Send your contact information 14
Write text 15
Write using the keyboard 15
Predictive text input 16
Messaging 16
Send a message 16
Save an attachment 17
Listen to voice messages 17
Send an audio message 18
Mail and chat 18
About Mail 18
Send a mail 18
Read and reply to mail 18
About Chat 18
Chat with your friends 19
Connectivity 19
Bluetooth 19
USB data cable 21
Clock 22
Change the time and date 22
Alarm clock 22
Pictures and videos 22
Take a picture 22
Record a video 23
Send a picture or video 23
Organise files 23
Music and audio 24
Media player 24
FM radio 25
Browse the web 26
About the web browser 26
Browse the web 27
Add a bookmark 27
Fit a web page to your phone display 28
Save on data costs 28
Clear your browsing history 28
About Communities 29
Device management 29
Update device software using your
device 29
2Contents

Update phone software using your
PC 31
Restore original settings 31
Back up your pictures and other
content to a memory card 31
Protect the environment 31
Save energy 31
Recycle 32
Product and safety information 32
Contents 3

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for
use with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near
your ear when the loudspeaker is in use.
4Safety

Get started
Keys and parts
1Charger connector
2Earpiece
3Screen
4Selection keys
5Internet key
6Call key
7Keypad
8Microphone
9Headset connector/Nokia AV connector (3.5 mm)
10 Micro-USB connector
11 Wrist strap hole
12 Messaging key
13 End/Power key
14 Navi™ key (scroll key)
Get started 5

15 Camera lens
16 Loudspeaker
17 Memory card slot
Insert a SIM card and battery
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card,
a micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may
damage the card or the device, and may corrupt data stored on the card.
This phone is intended for use with a BL-5J battery. Always use original Nokia
batteries.
1 Place your finger in the recess at the bottom of the phone, and carefully lift and
remove the back cover.
2 If the battery is inserted, lift it out.
6 Get started

3 Slide the SIM card holder to unlock it (1), and use your fingernail to lift it. Make
sure the contact area would face down when the SIM card holder is lowered (2),
insert the SIM card into the holder, and lower the holder (3). Slide the card holder
to lock it (4).
4 Line up the contacts of the battery and the battery compartment, and insert the
battery. To replace the back cover, direct the top locking catches toward their
slots, and press down until the cover locks into place.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time. If the phone indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the charger from the phone,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.
Get started 7

If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Switch the phone on or off
Press and hold the power key .
You may be prompted to get the configuration settings from your network service
provider. For more information on this network service, contact your network service
provider.
Insert a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.
Your phone supports memory cards with a capacity of up to 32 GB.
1 Open the cover of the memory card slot.
2 Make sure the contact area of the memory card is facing up, and insert the card.
Push the card in, until it locks into place.
3 Close the cover of the memory card slot.
8 Get started

Important: Do not remove the memory card when an application is using it.
Doing so may damage the memory card and the device and corrupt data stored on
the card.
You can remove or replace the memory card without switching the phone off.
Remove the memory card
Push the card in, until it is released, and pull the card out.
GSM antenna
The antenna area is highlighted.
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.
Get started 9

Connect a headset
Do not connect products that create an output signal, as this may damage the device.
Do not connect any voltage source to the Nokia AV connector. If you connect an
external device or headset, other than those approved by Nokia for use with this
device, to the Nokia AV connector, pay special attention to volume levels.
Attach the wrist strap
Remove the back cover, thread the strap through the hole, and loop the strap around
the wrist strap peg.
Wrist straps may be available separately.
Basic use
Access codes
The security code helps to protect your phone against unauthorised use. You can
create and change the code, and set the phone to request the code. Keep the code
secret and in a safe place separate from your phone. If you forget the code and your
phone is locked, your phone will require service. Additional charges may apply, and
10 Basic use

all the personal data in your phone may be deleted. For more information, contact a
Nokia Care point or your phone dealer.
The PIN code supplied with the SIM card protects the card against unauthorised use.
The PIN2 code supplied with some SIM cards is required to access certain services. If
you enter the PIN or PIN2 code incorrectly three times in succession, you are asked
for the PUK or PUK2 code. If you do not have them, contact your service provider.
The module PIN is required to access the information in the security module of your
SIM card. The signing PIN may be required for the digital signature. The barring
password is required when using the call barring service.
To set how your phone uses the access codes and security settings, select Menu >
Settings > Security.
Lock the keys
To avoid accidentally making a call when your phone is in your pocket or bag, lock the
keys.
Select Menu, and then press *.
Unlock the keys
Select Unlock, and press *.
Set the keys to lock automatically
1 Select Menu > Settings and Device > Automatic keyguard > On.
2 Define the length of time after which the keys are locked automatically.
Indicators
You have unread messages.
You have unsent, cancelled, or failed messages.
The keypad is locked.
The phone does not ring for incoming calls or text messages.
An alarm is set.
or The phone is registered to the GPRS or EGPRS network.
or A GPRS or EGPRS connection is open.
or The GPRS or EGPRS connection is suspended (on hold).
Bluetooth is activated.
If you have two phone lines, the second line is in use.
All incoming calls are diverted to another number.
The currently active profile is timed.
A headset is connected to the phone.
Basic use 11

The phone is connected to another device, using a USB data cable.
Copy contacts or pictures from your old phone
Want to copy your content from your previous compatible Nokia phone and start
using your new phone quickly? You can copy, for example, contacts, calendar entries,
and pictures to your new phone, free of charge.
1 Activate Bluetooth in both phones.
Select Menu > Settings > Connectivity > Bluetooth and On.
2SelectMenu > Settings > Sync and backup.
3SelectPhone switch > Copy to this.
4 Select the content to copy and Done.
5 Select your previous phone from the list.
6 If the other phone requires a passcode, enter the passcode. The passcode, which
you can define yourself, must be entered in both phones. The passcode in some
phones is fixed. For details, see the user guide of the other phone.
The passcode is valid only for the current connection.
7 If prompted, allow connection and copying requests.
Use your phone without a SIM card
Do your children want to play with your phone, but you don't want them to accidentally
make a call? Some features of your phone, such as games and the calendar, may be
used without inserting a SIM card. Features that are dimmed in the menus cannot be
used.
Calls
Make a call
1 On the home screen, enter the phone number.
To delete a number, select Clear.
12 Calls

2 To make the call, press the call key.
3 To end the call, press the end key.
View your missed calls
Want to see who made the call you missed?
On the home screen, select View. The caller's name is displayed, if stored in the
contacts list.
Missed and received calls are logged only if supported by the network, and the device
is switched on and within the network service area.
Call back the contact or number
Go to the contact or number, and press the call key.
View the missed calls later
Select Menu > Contacts > Log and Missed calls.
Call the last dialled number
Trying to call someone, but they are not answering? It is easy to call them again.
1 On the home screen, press the call key.
2 Go to the number, and press the call key.
Divert calls to your voice mailbox or another phone number
When you cannot answer, you can divert your calls to your voice mailbox or to another
number (network service).
1 Select Menu > Settings > Call > Call divert.
2 Select when to divert the incoming calls:
All voice calls — Divert all incoming voice calls.
If busy — Divert voice calls when busy.
If not answered — Divert voice calls only when not answered.
If out of reach — Divert voice calls when the device is switched off or out of
network coverage for a certain period.
If not available — Divert voice calls when not answered, or the device is busy, or
switched off, or out of network coverage.
3 Select Activate > To voice mailbox or To other number.
4IfIf not answered or If not available is selected, set the length of time after which
a call is forwarded.
Calls 13

Contacts
Save a name and phone number
Select Menu > Contacts.
Select Add new, and enter the number and name.
Add or edit the details of a contact
1SelectNames and a contact.
2SelectOptions > Add detail.
Tip: To add a ringtone or picture for a contact, select the contact and Options > Add
detail > Multimedia.
Use speed dial
You can quickly call your friends and family when you assign your most-used phone
numbers to the number keys of your phone.
Select Menu > Contacts > More > Speed dials.
Assign a phone number to a number key
1 Go to a number key, and select Assign. 1 is reserved for the voice mailbox.
2 Enter a number or search for a contact.
Remove or change a phone number assigned to a number key
Go to a number key, and select Options > Delete or Change.
Make a call
On the home screen, press and hold a number key.
Deactivate speed dialling
Select Menu > Settings and Call > Speed dialling > Off.
Send your contact information
Want to send your phone number or mail address to a person you just met? Add your
own contact information to your contacts list, and send a business card to the person.
Select Menu > Contacts and Names.
1 Select the contacts list entry that contains your information.
2SelectOptions > More > Business card and the sending type.
14 Contacts

Save a received business card
Select Show > Save.
Write text
Write using the keyboard
Your phone has a full keyboard.
Set the writing language
Select Options > Writing language and the desired language. To change the writing
language, you can also press the function key, and then press the ctrl key.
Switch between number and letter mode
Press the function key repeatedly, until the symbol for the desired input method is
displayed.
Lock number mode
Press the function key twice. To return to normal mode, press the function key.
Switch between the character cases
Press the shift key.
Insert a number or character printed at the top right corner of a key
Press and hold the corresponding key.
Delete a character
Select Clear. You can also press the backspace key .
Insert a special character or symbol
Press the sym key, and select the desired symbol. To view more symbols, press the
sym key again.
Insert a new line
Press the enter key.
Insert a space
Press the space key.
Copy or cut text
Press and hold the shift key, and scroll to highlight a word, phrase, or section of text.
Press and hold the ctrl key, and then press C(copy) or X(cut).
Write text 15

Paste text
Go to the desired location, press and hold the ctrl key, and then press V.
Predictive text input
Predictive text input is based on a built-in dictionary. Not all languages are supported.
Activate or deactivate predictive text input
Select Options > More > Prediction settings > On or Off.
Switch between predictive and traditional text input
Press and hold the ctrl key, and then press the space key.
You can also select and hold Options.
Write text with predictive text input
1 Start writing a word, using the character keys. Your phone suggests possible
words.
2 To confirm a word, press the space key.
If the word is not correct, scroll through the list of suggested words, and select
the desired word.
3 Start writing the next word.
Messaging
Send a message
Keep in touch with your family and friends with text and multimedia messages. You
can attach your pictures, videos, and business cards to your message.
Select Menu > Messaging.
1SelectCreate message.
2 Write your message.
3 To add an attachment , select Options > Insert object.
4SelectSend to.
5 To enter a phone number or mail address manually, select Number or mail. Enter
a phone number, or select Mail, and enter a mail address. To select a recipient or
a contact group, select Contacts or Contact groups.
6SelectSend.
Tip: To insert a special character or smiley, select Options > Insert symbol.
16 Messaging

Sending a message with an attachment may be more expensive than sending a normal
text message. For more information, contact your service provider.
You can send text messages that are longer than the character limit for a single
message. Longer messages are sent as two or more messages. Your service provider
may charge accordingly.
Characters with accents, other marks, or some language options, take more space,
limiting the number of characters that can be sent in a single message.
If the item you insert in a multimedia message is too large for the network, the device
may automatically reduce the size.
Only compatible devices can receive and display multimedia messages. Messages
may look different in different devices.
Save an attachment
You can save attachments from multimedia and mail messages to your phone.
Save an attachment from a multimedia message
1 Select Menu > Messaging.
2 Open the message.
3 Select Options > Show contents.
4 Select the desired file and Options > Save.
Save an attachment from a mail
1 Select Menu > Mail.
2 Open the mail.
3 Select the attachment.
4 Select View, and download the attachment.
Pictures and videos are saved in Gallery.
Listen to voice messages
When you can't answer, you can divert calls to your voice mailbox and listen to your
messages later.
You may need a voice mailbox subscription. For more information on this network
service, contact your service provider.
1 Select Menu > Messaging > More > Voice messages and Voice mailbox
number.
2 Enter your voice mailbox number, and select OK.
Messaging 17

3 To call your voice mailbox, on the home screen, press and hold 1. If prompted,
select the desired SIM card.
Send an audio message
Don't have time to write a text message? Record and send an audio message instead.
Select Menu > Messaging.
1SelectMore > Other messages > Audio message.
2 To record your message, select .
3 To stop recording, select .
4SelectSend to and a contact.
Mail and chat
About Mail
Select Menu > Mail.
You can use your phone to read and send mail from your mail accounts from different
mail service providers.
Send a mail
Select Menu > Mail and a mail account.
1SelectOptions > Compose new.
2 Enter the recipient’s mail address and the subject, and write your message.
3 To attach a file, for example, a picture, select Options > Attach > Attach file.
4 To take a picture to attach to the mail, select Options > Attach > Attach new
picture.
5SelectSend.
Read and reply to mail
Select Menu > Mail and a mail account.
1 Select a mail.
2 To reply to or forward a mail, select Options.
About Chat
Select Menu > Messaging > Chat.
You can exchange instant messages with your friends. Chat is a network service.
18 Mail and chat

You can leave the Chat application running in the background while you use other
features of your phone, and still be notified of new instant messages.
Using services or downloading content may cause transfer of large amounts of data,
which may result in data traffic costs.
Chat with your friends
Select Menu > Messaging > Chat.
You can sign in to and chat in several services at the same time. You must separately
sign in to each service.
You can have ongoing conversations with several contacts at the same time.
1 If several chat services are available, select the desired service.
2 Sign in to the service.
3 In your contacts list, select the contact you want to chat with.
4 Write your message in the text box at the bottom of the display.
5 Select Send.
Connectivity
Bluetooth
About Bluetooth connectivity
Select Menu > Settings > Connectivity > Bluetooth.
Use Bluetooth to connect wirelessly to compatible devices, such as other mobile
devices, computers, headsets, and car kits.
You can also send items from your device, copy files from your compatible PC, and
print using a compatible printer.
Bluetooth uses radio waves to connect, and devices must be within 10 metres (33
feet) of each other. Obstructions, such as walls or other electronic devices, can cause
interference.
Connectivity 19

Connect to a wireless headset
Want to keep working at your computer during a call? Use a wireless headset. You
can also answer a call, even if your phone is not directly at hand.
1SelectMenu > Settings > Connectivity > Bluetooth and Bluetooth > On.
2 Switch the headset on.
3 To pair your phone and the headset, select Conn. to audio access..
4 Select the headset. If the headset is not in the list, select New search.
5 You may need to enter a passcode. For details, see the user guide of the headset.
Send a picture or other content to another device using Bluetooth
Use Bluetooth to send pictures, videos, business cards, and other content created
by you to your computer or a friend's compatible phone or device.
1 Select the item to send.
2SelectOptions > Send > Via Bluetooth.
3 Select the device to connect to. If the desired device is not displayed, to search
for it, select New search. Bluetooth devices within range are displayed.
4 If the other device requires a passcode, enter the passcode. The passcode, which
you can define yourself, must be entered in both devices. The passcode in some
devices is fixed. For details, see the user guide of the device.
The passcode is valid only for the current connection.
The available options may vary.
Connect automatically to a paired device
Do you regularly connect your phone to another Bluetooth device, such as a car kit,
headset, or your PC? You can set your phone to connect automatically.
20 Connectivity
