Nokia 6202 Classic User manual

6202 Classic 6208 Classic RM-458
Service Manual Level 1&2
ISSUE1
Confidential
1
SERVICE MANUAL
Level 1&2
Transceiver characteristics
Band:
RM-458: EGSM 900/1800/1900
Display:
2.4” 16.7 M colour display
Camera:
3.2 MP AF camera with 2 LED and 8 x zoom
Operating System:
Series 40
Connections:
Bluetooth 2.0, micro USB connector, 2 mm
charging connector, 3.5 mm AV connector
Transceiver with BL-4S battery pack
Talk time Standby Note
Up to 3.5 hours Up to 320
hours
Depends on
network
parameters
and phone
settings
Copyright @ 2008 NOKIA. All rights reserved

6202 Classic 6208 Classic RM-458
Service Manual Level 1&2
ISSUE1
Confidential
2
1. Change history ................................................................................................................................3
2. Copyright ........................................................................................................................................4
3. Warnings and cautions ....................................................................................................................5
3.1 Warnings ..................................................................................................................................5
3.2 Cautions ...................................................................................................................................5
4. ESD protection.................................................................................................................................6
5. Care and maintenance.....................................................................................................................7
6. Battery information.........................................................................................................................8
7. Exploded view.................................................................................................................................9
8. Service devices ..............................................................................................................................10
9. SW-update ....................................................................................................................................11
10. Disassembly instruction ..........................................................................................................12
11. Assembly hints........................................................................................................................21
12. Solder components .................................................................................................................22
Copyright @ 2008 NOKIA. All rights reserved

6202 Classic 6208 Classic RM-458
Service Manual Level 1&2
ISSUE1
Confidential
3
1. CHANGE HISTORY
Status Version No. Date Comments
Draft 0.1 03.12.2008 First draft
Approved 1.0 31.12.2008 First approved version
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note that NOKIA provides also
other guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly
and comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors
may exist. If you find any errors or if you have further suggestions, please notify NOKIA using
the address below:
CMO Operation & Logistics
Training and Vendor Development
Multimedia Creation & Support
mailto:[e-mail]
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.
Copyright @ 2008 NOKIA. All rights reserved

6202 Classic 6208 Classic RM-458
Service Manual Level 1&2
ISSUE1
Confidential
4
2. COPYRIGHT
Copyright © 2008 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in
any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of
Nokia Corporation. Other product and company names mentioned herein may be trademarks
or tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.
Copyright @ 2008 NOKIA. All rights reserved

6202 Classic 6208 Classic RM-458
Service Manual Level 1&2
ISSUE1
Confidential
5
3. WARNINGS AND CAUTIONS
Please refer to the phone’s user guide for instructions relating to operation, care and
maintenance including important safety information. Note also the following:
3.1 Warnings
1. CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED WITH ELECTRONIC ENGINE
MANAGEMENT SYSTEMS AND ANTI–SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT
CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT
THE VEHICLE DEALER/MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE
ELECTRONIC SYSTEMS TO RF ENERGY.
2. THE HANDPORTABLE TELEPHONE MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN
POTENTIALLY EXPLOSIVE ATMOSPHERES, EG PETROL STATIONS (SERVICE STATIONS),
BLASTING AREAS ETC.
3. OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES,
MAY INTERFERE WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL
DEVICES. CONSULT A PHYSICIAN OR THE MANUFACTURER OF THE MEDICAL DEVICE IF YOU
HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY ALSO BE SUBJECT TO
INTERFERENCE.
3.2 Cautions
1. Servicing and alignment must be undertaken by qualified personnel only.
2. Ensure all work is carried out at an anti–static workstation and that an anti–static wrist
strap is worn.
3. Use only approved components as specified in the parts list.
4. Ensure all components, modules screws and insulators are correctly re–fitted after
servicing and alignment.
5. Ensure all cables and wires are repositioned correctly
Copyright @ 2008 NOKIA. All rights reserved
