Nokia 6650d-1bH User manual

1
6650 User Guide
9206316
Draft
FCC Draft
Model: 6650d-1bH
21 February 2008

2
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-
324 product is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC. A copy of the Declaration of
Conformity can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Care, and Navi are trademarks or registered
trademarks of Nokia Corporation. Nokia tune is a sound mark of Nokia Corporation. Other
product and company names mentioned herein may be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
This product includes software licensed from Symbian Software Ltd ©
1998-2007. Symbian and Symbian OS are trademarks of Symbian Ltd.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2007. Tegic Communications, Inc. All rights reserved.
Java™ and all Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information,
including that related to promotional, internal, and commercial uses, may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES
SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY
APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
0434
FCC Draft
Model: 6650d-1bH
21 February 2008

3
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR
WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may
vary by region. Please check with your Nokia dealer for details, and availability of language
options.
This device complies with Directive 2002/95/EC on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
NO WARRANTY
The third-party applications provided with your device may have been created and may be
owned by persons or entities not affiliated with or related to Nokia. Nokia does not own the
copyrights or intellectual property rights to the third-party applications. As such, Nokia does
not take any responsibility for end-user support, functionality of the applications, or the
information in the applications or these materials. Nokia does not provide any warranty for
the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE APPLICATIONS ARE PROVIDED
AS IS WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA NOR
ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE, MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-
PARTY PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
Export controls
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
FCC NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC can require you to stop using your telephone if
such interference cannot be eliminated. If you require assistance, contact your local service
facility. This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by Nokia could void the user's authority
to operate this equipment.
9206316 draft
FCC Draft
Model: 6650d-1bH
21 February 2008

4
Contents
Safety................................................ 6
Support ............................................. 8
Help ...................................................................... 8
Service settings ................................................. 8
Troubleshooting your phone.......................... 9
Gameplay ......................................................... 10
1. Get started.................................. 10
Insert a SIM card and battery.................... 10
MicroSD card slot .......................................... 12
Charge the battery ........................................ 13
Switch the phone on and off ..................... 14
Welcome application.................................... 14
Access codes ................................................... 14
2. Your phone ................................. 16
Keys and parts ................................................ 16
Standby mode................................................. 17
Indicators ......................................................... 18
Menu ................................................................. 19
Volume control............................................... 19
Keypad lock (keyguard)................................ 20
Normal operating position.......................... 20
Connect a compatible headset .................. 21
Connect a USB data cable .......................... 21
3. Call functions ............................. 21
Make a voice call........................................... 21
Answer or reject a call ................................. 23
Video calls........................................................ 24
Call settings..................................................... 25
Video sharing .................................................. 27
Log ..................................................................... 29
4. Write text ................................... 29
Traditional and predictive text input ....... 29
Copy and delete text .................................... 30
5. Messaging................................... 31
Write and send messages............................ 31
Inbox.................................................................. 32
E-mail................................................................ 32
Outbox .............................................................. 34
View messages on the SIM card ................ 34
Cell broadcast ................................................. 34
Service commands ......................................... 34
Messaging settings........................................ 34
Instant messaging.......................................... 35
6. Push to Talk ............................... 35
Switch PTT on and off................................... 36
Add Contacts ................................................... 36
Make and receive a PTT call........................ 37
Change from PTT to mobile call................. 39
Call Me Alerts.................................................. 39
Voice Messages............................................... 39
PTT Settings ..................................................... 39
7. Address Book.............................. 40
Save and manage contact information ... 40
Add a ringing tone......................................... 41
8. Media.......................................... 41
Music player .................................................... 41
RealPlayer......................................................... 44
Flash Player...................................................... 45
Recorder............................................................ 45
9. Gallery ........................................ 45
Download files ................................................ 46
View videos and images ............................... 46
Edit images ...................................................... 46
Print images..................................................... 47
Transfer videos from PC ............................... 47
10.Camera ...................................... 47
Capture an image and record a video...... 48
Camera settings.............................................. 48
11.Positioning................................ 49
GPS data ........................................................... 49
Landmarks ........................................................ 49
Positioning settings....................................... 49
12.Internet ..................................... 49
Browse the web .............................................. 49
FCC Draft
Model: 6650d-1bH
21 February 2008

5
13.Personalisation.......................... 53
Themes.............................................................. 53
Profiles.............................................................. 53
14.Time management .................... 54
Clock.................................................................. 54
Calendar ........................................................... 55
15.Office applications ................... 55
Notes................................................................. 55
Calculator......................................................... 55
Converter.......................................................... 55
16.Settings ..................................... 56
Keypad lights .................................................. 56
Voice commands............................................ 56
Phone settings................................................ 57
Speech............................................................... 59
Settings wizard............................................... 59
17.Data management .................... 59
Install or remove applications ................... 59
File manager.................................................... 61
Licences............................................................. 61
Device manager .............................................. 63
18.Connectivity.............................. 64
PC Suite............................................................. 64
Bluetooth connectivity ................................. 64
USB connection .............................................. 66
Remote synchronisation............................... 67
Connection manager..................................... 67
19.Applications.............................. 68
Phone Inspector.............................................. 68
20.Battery information ................. 68
Charging and discharging............................ 68
Talk and standby times................................. 69
Nokia battery authentication guidelines. 70
Care and maintenance................... 70
Additional safety information...... 72
Index............................................... 76
FCC Draft
Model: 6650d-1bH
21 February 2008

SAFETY
6
SAFETY
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could
affect performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
■About your device
The wireless device described in this guide is approved for use on the UMTS 850
and 1900, EGSM 850 and 900, and GSM 1800 and 1900 networks. Contact your
service provider for more information about networks.
When using the features in this device, obey all laws and respect local customs,
privacy and legitimate rights of others, including copyrights.
Copyright protections may prevent some images, music (including ringing tones),
and other content from being copied, modified, transferred, or forwarded.
Your device supports internet connections and other methods of connectivity.
Like computers, your device may be exposed to viruses, malicious messages and
applications, and other harmful content. Exercise caution and open messages,
FCC Draft
Model: 6650d-1bH
21 February 2008

SAFETY
7
accept connectivity requests, download content, and accept installations only
from trustworthy sources. To increase the security of your device, consider
installing antivirus software with a regular update service and using a firewall
application.
Your device may have preinstalled bookmarks and links for third-party internet
sites. You may also access other third-party sites through your device. Third-
party sites are not affiliated with Nokia, and Nokia does not endorse or assume
liability for them. If you choose to access such sites, you should take precautions
for security or content.
Important: Your device can only support one antivirus application.
Having more than one application with antivirus functionality could
affect performance and operation or cause the device to stop
functioning.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features require special network features. These features are not available on
all networks; other networks may require that you make specific arrangements
with your service provider before you can use the network services. Your service
provider can give you instructions and explain what charges will apply. Some
networks may have limitations that affect how you can use network services. For
instance, some networks may not support all language-dependent characters
and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device
menu. Your device may also have a special configuration such as changes in
menu names, menu order, and icons. Contact your service provider for more
information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as web browsing, e-mail,
push to talk, instant messaging, and multimedia messaging, require network
support for these technologies.
FCC Draft
Model: 6650d-1bH
21 February 2008

Support
8
■Enhancements, batteries, and chargers
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from the AC-4 or AC-5 chargers.
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When
you disconnect the power cord of any enhancement, grasp and pull the plug, not
the cord.
Practical rules about accessories and enhancements
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement, grasp
and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted and
are operating properly.
• Installation of any complex car enhancements must be made by qualified
personnel only.
Support
■Help
Your phone has context-sensitive help. To access help when an
application is open, select Options > Help. To switch between help and
the application that is open in the background, select and hold , and
select from the list of open applications.
To open help from the main menu, select > Tools > Help > Help.
Select an application to view a list of help topics, and select the related
help text. To open a keyword list, select Options > Search.
■Service settings
Before you can use multimedia messaging, instant messaging, push to
talk, e-mail, synchronisation, streaming, and the browser, you must
have the proper configuration settings on your phone. Your phone may
automatically configure browser, multimedia messaging, access point,
and streaming settings based on the SIM card used. Otherwise, you can
FCC Draft
Model: 6650d-1bH
21 February 2008

Support
9
use Sett. wizard application to configure the settings, or you may
receive the settings directly as a configuration message, which you save
to your phone. For more information on availability, contact your service
provider or nearest authorized Nokia dealer.
When you receive a configuration message, and the settings are not
automatically saved and activated, 1 new message is displayed. To save
the settings, select Show > Options > Save. You may need to enter a
PIN code provided by the service provider.
■Troubleshooting your phone
If you have problems with your phone, try the following before taking it
to a service point:
Reset the phone
Switch the phone off, remove the battery, reinsert it, and switch the
phone on.
Restore original factory settings
Select > Settings > General > Factory settings. Your documents and
files are not deleted.
Visit the Nokia support website
Visit www.nokia.com/support or your local Nokia website for product
support and FAQs. On this website, you can also find:
• The latest version of this guide, additional information, downloads
and services related to your Nokia product.
• List of local Nokia contact centers, if you need to contact customer
service.
• Your nearest Nokia service centers for maintenance services. Before
sending your phone for repair, always back up or make a record of
data in your phone.
Update your phone software
Nokia may produce software updates that may offer new features, enhanced
functions, or improved performance. You may be able to request these updates
through the Nokia Software Updater PC application. To update the device
FCC Draft
Model: 6650d-1bH
21 February 2008

Get started
10
software, you need the Nokia Software Updater application and a compatible PC
with Microsoft Windows 2000 or XP operating system, broadband internet
access, and a compatible data cable to connect your device to the PC.
To get more information and to download the Nokia Software Updater
application, visit www.nokia.com/softwareupdate or your local Nokia web site.
If software updates over the air are supported by your network, you may also be
able to request updates through the device. See "Update software," p. 63.
Downloading software updates may involve the transmission of large amounts of
data through your service provider's network. Contact your service provider for
information about data transmission charges.
Make sure that the device battery has enough power, or connect the charger
before starting the update.
■Gameplay
Your phone is compatible with the N-Gage™ gaming experience. With
N-Gage, you can download and play high-quality multiplayer games.
For more information, visit www.n-gage.com.
For the full N-Gage experience, you need internet access on your phone
through the cellular network. Contact your service provider for more
information on data services.
1. Get started
■Insert a SIM card and battery
Always switch the device off and disconnect the charger before removing the
battery.
This phone uses BP-4L batteries.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider or other vendor.
FCC Draft
Model: 6650d-1bH
21 February 2008

Get started
11
1. To open the back cover, press teh black button on the lower part of
the back cover (1), slide the cover forward (2), and lift (3). To remove
the battery, lift it as shown (4).
2. To release the SIM card holder, slide it backwards (4), and lift it (5).
Insert the (U)SIM card in the SIM card holder (6). Make sure that the
gold colored contact area on the card is facing downwards, and the
beveled corner faces upwards.
Close the SIM card holder (7), and slide it forward to lock it (8).
FCC Draft
Model: 6650d-1bH
21 February 2008

Get started
12
3. Replace the battery (9). Replace the back cover (10, 11).
■MicroSD card slot
Use only compatible microSD cards approved by Nokia for
use with this device. Nokia uses approved industry
standards for memory cards, but some brands may not be
fully compatible with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
Keep microSD cards out of the reach of small children.
You can extend the available memory with a microSD memory card. You
can insert or remove a microSD card without switching the phone off.
Important: Do not remove the memory card in the middle of an
operation when the card is being accessed. Removing the card in the
middle of an operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
Insert a microSD card
Note that the memory card may be supplied with the phone, and may
already be inserted.
FCC Draft
Model: 6650d-1bH
21 February 2008

Get started
13
Open the side door (1). Place the microSD card in the slot with the
gold colored area facing down (2). Push the card gently to lock it into
place. Close tight the side door (3).
Remove a microSD card
Open the side door. Push the card gently to release it. Remove memory
card and press 'OK' is displayed. Pull the card out, and select OK. Close
tight the side door.
■Charge the battery
1. Connect the charger to the
wall socket.
2. Open the side door (1), and
connect the charger plug to
the charger connector in the
phone (2).
3. After charging, close tight the side door.
If the battery is completely discharged, it may take a few minutes before
the charging indicator appears on the display or before any calls can be
made.
The charging time depends on the charger and the battery used.
Charging a BP-4L battery with the AC-5 charger takes approximately
80 minutes.
FCC Draft
Model: 6650d-1bH
21 February 2008

Get started
14
■Switch the phone on and off
Press and hold the power/call end key.
If the phone asks for a PIN code, enter the PIN
code, and select OK.
If the phone asks for the lock code, enter the lock
code, and select OK. The factory setting for the
lock code is 12345.
Set time and date
To set the correct time zone, time, and date,
select the country you are presently in, then enter the local time and
date.
■Welcome application
The Welcome application starts when you switch on your phone for the
first time.
With the Welcome application, you can access the following
applications:
Tutorial — Learn about the features of your phone and how to use them.
Sett. wizard — Configure connection settings. See "Settings wizard,"
p. 59.
Transfer — Copy or synchronize data from other compatible devices.
To open Welcome later, select > Help > Welcome.
■Access codes
Select > Settings > General > Security > Phone and SIM card to set
how your phone uses the access codes.
Lock code
The lock code (5 digits) helps to lock your phone. The preset code is
12345. Change the code, and set the phone to request the code.
When the device is locked, calls may be possible to the official emergency
number programmed into your device.
FCC Draft
Model: 6650d-1bH
21 February 2008

Get started
15
PIN codes
The personal identification number (PIN) code or the universal personal
identification number (UPIN) code (4 to 8 digits) help to protect your
SIM card. The (U)PIN code is usually supplied with the SIM card. Set the
phone to request the code each time the phone is switched on.
The PIN2 code may be supplied with the SIM card and is required for
some functions.
The module PIN is required to access the information in the security
module. The signing PIN is required for the digital signature. The module
PIN and the signing PIN are supplied with the SIM card if the SIM card
has a security module in it.
PUK codes
The personal unblocking key (PUK) code or the universal personal
unblocking key (UPUK) code (8 digits) are required to change a blocked
PIN code and UPIN code, respectively. The PUK2 code is required to
change a blocked PIN2 code.
If needed, contact your local service provider for the codes.
Call restriction password
The restriction password (4 digits) is required when using Call
restriction. You can obtain the password from your service provider. If
the password is blocked, contact your service provider.
FCC Draft
Model: 6650d-1bH
21 February 2008

Your phone
16
2. Your phone
■Keys and parts
Power key (1)
Loudspeaker (2)
Earpiece (3)
Volume keys (4)
Left and right selection keys (5)
Menu key (6),
hereafter described as "select "
Clear key (7)
Call key (8)
End key (9)
Navi™ scroll key (10),
hereafter referred to as scroll key
Number keys (11)
Microphone (12)
Nokia AV Connector (2.5 mm)
(13)
Loudspeaker (14)
Charger connector (15)
microSD card slot (16)
USB connector (17)
FCC Draft
Model: 6650d-1bH
21 February 2008

Your phone
17
Media keys:
Rewind, zoom out (19)
Play/Pause/Stop and
autofocus/capture key (20)
Fast forward, zoom in (21)
Camera lens (22)
Camera flash (23)
■Standby mode
When you have switched on the phone, and it is registered to a network,
the phone is in the standby mode and ready for use.
To open the list of last dialed numbers, press the call key.
To use the voice commands or voice dialing, press and hold the right
selection key.
To change the profile, press the power key, and select a profile.
To start a connection to the web, press and hold 0.
Active standby
When active standby is enabled, you can use the display for fast access
to frequently used applications. To select whether the active standby is
shown, select > Settings > General > Personalisation >
Standby mode > Active standby > On or Off.
In active standby the default applications are shown across the top of
the active standby area, and calendar, to-do, and player events are listed
below. To select an application or event, scroll to it, and select it.
Offline profile
To activate the Offline profile, press the power key, and select Offline.
When the Offline profile is active, the connection to the wireless
network is turned off. All wireless radio frequency signals to or from
your phone are prevented, and you can use your phone without a (U)SIM
card. Use the offline profile in radio sensitive environments—on board
FCC Draft
Model: 6650d-1bH
21 February 2008

Your phone
18
aircraft or in hospitals. You can listen to music using the music player
when the offline profile is active.
To leave the Offline profile, press the power key, and select another
profile.
Important: In the offline profile you cannot make or receive any calls,
or use other features that require cellular network coverage. Calls may
still be possible to the official emergency number programmed into
your device. To make calls, you must first activate the phone function by
changing profiles. If the device has been locked, enter the lock code.
■Indicators
or — The phone is connected to a UMTS or GSM network.
— HSDPA (network service) in the UMTS network is activated.
— The phone is in the offline mode and not connected to a cellular
network.
— A memory card is inserted in the phone.
— You received one or several messages to the Inbox folder in
Messaging.
— You received new e-mail in your remote mailbox.
— There are messages waiting to be sent in Outbox.
— You have missed calls.
— Ringing type is set to Silent and Message alert tone and E-mail
alert tone are set to Off.
— The phone keypad is locked.
— The loudspeaker is activated.
— An alarm is active.
— All calls to the phone are diverted to another number.
or — A headset or a loopset is connected to the phone.
or or — A GPRS packet data connection is active, the connection
is on hold, or a connection is available.
FCC Draft
Model: 6650d-1bH
21 February 2008

Your phone
19
or or — A packet data connection is active in a part of the
network that supports EGPRS, or the connection is on hold, a connection
is available. Your phone may not use EGPRS in the data transfer.
or or — A UMTS packet data connection is active, the
connection is on hold, or a connection is available.
or — Bluetooth is switched on, or data is being transmitted using
Bluetooth.
— A USB connection is active.
Other indicators may also be shown.
■Menu
In the menu you can access the functions in your phone. To access the
main menu, press .
To open an application or a folder, scroll to it, and press the scroll key.
To change the menu view, select > Options > Change Menu view and
a view type.
If you change the order of the functions in the menu, the order may
differ from the default order described in this user guide.
To close an application or a folder, select Back and Exit as many times as
needed to return to the standby mode, or select Options > Exit.
To display and switch between open applications, press and hold .
Scroll to an application, and select it.
To mark or unmark an item in applications, press #. To mark or unmark
several consecutive items, press and hold #, and scroll up or down.
Leaving applications running in the background increases the demand on battery
power and reduces the battery life.
■Volume control
To adjust the earpiece or loudspeaker volume during a call or when
listening to an audio file, press the volume keys. To activate or
deactivate the loudspeaker during a call, select Loudspeaker or
Handset.
Warning: Do not hold the device near your ear when the loudspeaker is
in use, because the volume may be extremely loud.
FCC Draft
Model: 6650d-1bH
21 February 2008

Your phone
20
■Keypad lock (keyguard)
To lock the keypad in the phone mode, press the left selection key and *
within 1.5 seconds. To set the phone to automatically lock the keypad
after a certain time, select > Settings > General > Security > Phone
and SIM card > Keypad autolock period > User defined and the desired
time.
To unlock the keypad in the phone mode, select Unlock, and press *
within 1.5 seconds.
To lock the keypad in the music mode, press the power key quickly, and
select Lock keypad. To unlock the keypad in the music mode, select
Unlock > OK.
When the keypad is locked, calls may be possible to the official emergency
number programmed into your device.
■Normal operating position
Your device has internal
antennas.
Cellular antenna (1)
Bluetooth antenna
(2)
Use the phone only in
its normal operating
position (3).
Note: As with any radio transmitting device, avoid touching an antenna
unnecessarily when the antenna is in use. For example, avoid touching
the cellular antenna during a phone call. Contact with a transmitting or
receiving antenna affects the quality of the radio communication, may
cause the device to operate at a higher power level than otherwise
needed, and may reduce the battery life.
FCC Draft
Model: 6650d-1bH
21 February 2008
