Nokia 6700 classic User manual

Nokia 6700 slide User Guide
.
Issue 3.0

Contents
Safety 5
About your device 5
Network services 7
Thank you for helping us help the
environment 8
Find help 8
Support 8
Software updates over the air 9
Update software using your PC 10
In-device help 10
Get started 11
Insert SIM card and battery 11
Insert a memory card 12
Charge the battery 12
Switch the device on and off 13
Antenna locations 14
Configuration settings 14
Settings wizard 14
Your device 15
Keys and parts 15
Home screen 16
Offline profile 17
Display indicators 17
Power saver 19
Menu 19
Volume control 19
Keypad lock (keyguard) 20
Access codes 20
Remote lock 21
Installations 21
Connect a compatible headset 21
Connect a USB data cable 22
Wrist strap 22
Call functions 23
Voice calls 23
Video calls 25
Call settings 27
Personalisation 30
Themes 30
Profiles 31
Camera 32
Capture an image 32
Panorama mode 33
Record video clips 33
Gallery 34
About Gallery 34
Contacts 35
Manage names and numbers 35
2Contents
© 2010 Nokia. All rights reserved.

Save and edit names and
numbers 35
Ringing tones, images, and call text
for contacts 35
Copy contacts 36
Stay connected with your online
friends 36
Write text 37
Traditional text input 37
Predictive text input 38
Change the writing language 38
Copy and delete text 39
Messaging 39
Write and send messages 40
E-mail 41
Internet 46
Web browser 46
Share online 48
Nokia Video Centre 50
Search 51
Time management 52
Calendar 52
Alarm clock 53
Clock settings 54
Music 54
Music player 54
FM Radio 55
Settings 56
Application settings 56
Device and SIM card security 56
Common accessory settings 56
Restore original settings 57
Data management 57
Install or remove applications 57
File manager 59
Device manager 60
Connectivity 62
Transfer content from another
device 62
PC connections 63
Bluetooth 63
Data cable 67
Sync 68
Green tips 69
Save energy 69
Recycle 70
Save paper 70
Learn more 70
Product and safety
information 70
Contents 3
© 2010 Nokia. All rights reserved.

Index 77
4Contents
© 2010 Nokia. All rights reserved.

Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on
when wireless phone use is
prohibited or when it may
cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
keep your hands free to
operate the vehicle while
driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions.
Switch the device off in
aircraft, near medical
equipment, fuel, chemicals,
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved
accessories and batteries. Do
not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-
resistant. Keep it dry.
About your device
The wireless device described in this
HSUPA networks. Contact your service
Safety 5
© 2010 Nokia. All rights reserved.
MHz
guide is approved for use on the (E)GSM
850, 900, 1800 and 1900 networks,
and UMTS 900, 1900 and 2100
MHz
HSDPA
and

provider for more information about
networks.
Your device supports several
connectivity methods and like
computers may be exposed to viruses
and other harmful content. Exercise
caution with messages, connectivity
requests, browsing, and downloads.
Only install and use services and
software from trustworthy sources that
offer adequate security and protection,
such as applications that are Symbian
Signed or have passed the Java
Verified™ testing. Consider installing
antivirus and other security software on
your device and any connected
computer.
Your device may have preinstalled
bookmarks and links for third-party
internet sites and may allow you to
access third-party sites. These are not
affiliated with Nokia, and Nokia does
not endorse or assume liability for
them. If you access such sites, take
precautions for security or content.
Warning:
To use any features in this device, other
than the alarm clock, the device must be
switched on. Do not switch the device
on when wireless device use may cause
interference or danger.
When using this device, obey all laws
and respect local customs, privacy and
legitimate rights of others, including
copyrights. Copyright protection may
prevent some images, music, and other
content from being copied, modified, or
transferred.
Make back-up copies or keep a written
record of all important information
stored in your device.
When connecting to any other device,
read its user guide for detailed safety
instructions. Do not connect
incompatible products.
The images in this guide may differ from
your device display.
Refer to the user guide for other
important information about your
device.
6Safety
© 2010 Nokia. All rights reserved.

Network services
To use the device you must have service
from a wireless service provider. Some
features are not available on all
networks; other features may require
that you make specific arrangements
with your service provider to use them.
Network services involve transmission
of data. Check withyour service provider
for details about fees in your home
network and when roaming on other
networks. Your service provider can
explain what charges will apply. Some
networks may have limitations that
affect how you can use some features of
this device requiring network support
such as support for specific technologies
like WAP 2.0 protocols (HTTP and SSL)
that run on TCP/IP protocols and
language-dependent characters.
Your service provider may have
requested that certain features be
disabled or not activated in your device.
If so, these features will not appear on
your device menu. Your device may also
have customized items such as menu
names, menu order, and icons.
Safety 7
© 2010 Nokia. All rights reserved.

Thank you for helping us help
the environment
Thank you for helping us help the
environment. As you may know, not
everyone who needs a new phone
needs a new charger. It’s probably one
of the reasons why you chose a Nokia
6700 slide. Your new Nokia phone has
no charger and far less packaging. A
smaller box means less material, less
waste, and more efficient
transportation, helping reduce your
carbon footprint. Not making new
chargers saves energy and raw
materials. All of which means less CO2
emissions and a healthier planet.
So thanks again, from us and the
environment. Remember, you can also
charge your phone using an AC-8 or
AC-10 charger or the enclosed CA-101D
cable. Alternatively, if you already have
an old Nokia charger with a thicker plug,
simply purchase a CA-44 adapter.
Find help
Support
When you want to learn more about
how to use your product or you are
unsure how your device should
function, see the support pages at
www.nokia.com/support or your local
Nokia website, www.nokia.mobi/
support (with a mobile device), the Help
application in the device, or the user
guide.
If this does not resolve your issue, do
one of the following:
•Restart the device: switch off the
device, and remove the battery.
After about a minute, replace the
battery, and switch on the device.
•Restore the original factory settings
as explained in the user guide. Your
documents and files will be deleted
in the reset, so back up your data
first.
•Update your device software
regularly for optimum performance
and possible new features, as
explained in the user guide.
8 Thank you for helping us help the environment
© 2010 Nokia. All rights reserved.

If your issue remains unsolved, contact
Nokia for repair options. See
www.nokia.com/repair. Before sending
your device for repair, always back up
the data in your device.
Software updates over the air
Select > Settings > Data mgr. >
SW update.
With Software update (network
service), you can check if there are
updates available for your device
software or applications, and download
them to your device.
Downloading software updates may
involve the transmission of large
amounts of data (network service).
Make sure that the device battery has
enough power, or connect the charger
before starting the update.
Warning:
If you install a software update, you
cannot use the device, even to make
emergency calls, until the installation is
completed and the device is restarted.
Be sure to back up data before accepting
installation of an update.
After updating your device software or
applications using Software update, the
instructions related to the updated
applications in the user guide or the
helps may no longer be up to date.
Select Options and from the following:
Start update — Download the
available updates. To unmark specific
updates that you do not want to
download, select the updates from the
list.
Update via PC — Update your device
using a PC. This option replaces the Start
update option when updates are only
available using the Nokia Software
Updater PC application.
View details — View information on
an update.
View update history — View the
status of previous updates.
Settings — Change the settings, such
as the default access point used for
downloading updates.
Disclaimer — View the Nokia licence
agreement.
Find help 9
© 2010 Nokia. All rights reserved.

Update software using your PC
Nokia Software Updater is a PC
application that enables you to update
your device software. To update your
device software, you need a compatible
PC, broadband internet access, and a
compatible USB data cable to connect
your device to the PC.
To get more information and to
download the Nokia Software Updater
application, go to www.nokia.com/
softwareupdate.
In-device help
Your device contains instructions to
help to use the applications in your
device.
To open help texts from the main menu,
select > Help > Help and the
application for which you want to read
instructions.
When an application is open, to access
the help text for the current view, select
Options > Help.
When you are reading the instructions,
to change the size of the help text, select
Options > Decrease font size or
Increase font size.
You can find links to related topics at the
end of the help text.
If you select an underlined word, a short
explanation is displayed.
Help texts use the following indicators:
shows a link to a related help
topic.
shows a link to the application
being discussed.
When you are reading the instructions,
to switch between help texts and the
application that is open in the
background, press and hold the menu
key, and select from the list of open
applications.
10 Find help
© 2010 Nokia. All rights reserved.

Get started
Insert SIM card and battery
1 To remove the back cover of the
device, open the micro USB
connector cover, press the release
button, and lift the back cover off.
2 Slide the SIM card holder back to
unlock it (1), lift the SIM card holder
(2), and slide the SIM card into the
SIM card holder (3).
Ensure that the contact area on the
card is facing down on the device,
and the bevelled corner is facing
down in the SIM card holder.
3 Lower the SIM card holder (4), and
slide it forward to lock it (5).
4 Insert the battery.
5 To replace the back cover, direct the
bottom locking catches toward
their slots (1), and press until the
cover locks into place (2).
Get started 11
© 2010 Nokia. All rights reserved.

Always switch the device off and
disconnect the charger before removing
the battery.
Insert a memory card
The memory card may be supplied with
the device, and may already be inserted.
1 Remove the back cover of the
device.
2 Place the card in the slot with the
contact area facing down (1), and
push the card gently to lock it into
place (2).
3 Replace the back cover.
Charge the battery
Your battery has been partially charged
at the factory. If the device indicates a
low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the battery is fully charged,
disconnect the charger from the
device, then from the wall outlet.
12 Get started
© 2010 Nokia. All rights reserved.

You do not need to charge the battery
for a specific length of time, and you can
use the device while it is charging. If the
battery is completely discharged, it may
take several minutes before the
charging indicator appears on the
display or before any calls can be made.
Tip: If you have old compatible Nokia
chargers, you can use them with your
device by attaching the CA-44 charger
adapter to the old charger. The adapter
is available as a separate accessory.
USB charging
You can use USB charging when a wall
outlet is not available. When charging
your device with the USB data cable, the
charging time is longer. USB charging
efficiency varies significantly. In some
cases, it may take a very long time for
charging to start and the device to start
functioning.
With USB charging, you can also transfer
data with the USB data cable while
charging the device.
1 Connect a compatible USB device to
your device using a compatible USB
data cable.
Depending on the type of the device
that is used for charging, it may take
a while for charging to start.
2 If the device is switched on, select
from the available USB mode
options on the display of the device.
Switch the device on and off
Press and hold the power key to switch
the device on and off. Press the power
key briefly to end a call or close an
application.
If the device asks for a PIN code, enter
the PIN code, and select OK.
Get started 13
© 2010 Nokia. All rights reserved.

If the device asks for the lock code, enter
the lock code, and select OK. The factory
setting for the lock code is 12345.
To set the correct time zone, time, and
date, select the country you are
presently in, then enter the local time
and date.
Antenna locations
Your device may have internal and
external antennas. Avoid touching the
antenna area unnecessarily while the
antenna is transmitting or receiving.
Contact with antennas affects the
communication quality and may cause
a higher power level during operation
and may reduce the battery life.
Configuration settings
Before you can use multimedia
messaging, e-mail, synchronisation,
streaming, and the browser, you must
have the proper configuration settings
in your device. Your device may
automatically configure browser,
multimedia messaging, access point,
and streaming settings based on the SIM
card used. If not, you can use the
Settings wizard application to configure
the settings. You may receive the
settings as a configuration message
that you can save to your device. For
more information on availability,
contact your service provider or nearest
authorised Nokia dealer.
When you receive a configuration
message, and the settings are not
automatically saved and activated, 1
new message is displayed. To save the
settings, select Show > Options >
Save. You may need to enter a PIN code
provided by the service provider.
Settings wizard
Select > Settings > Sett. wizard.
Use Settings wizard to define e-mail and
connection settings. The availability of
the items in Settings wizard depends on
the features of the device, SIM card,
service provider, and the data in the
Settings wizard database.
14 Get started
© 2010 Nokia. All rights reserved.

To start Settings wizard, select Start.
To get the best results when using the
settings wizard, keep your SIM card
inserted in the device. If the SIM card is
not inserted, follow the instructions on
the display.
Select from the following:
Operator — Define the operator-
specific settings, such as MMS, internet,
WAP, and streaming settings.
E-mail setup — Configure a POP, IMAP,
or Mail for Exchange account.
The settings available for editing may
vary.
Your device
Keys and parts
1Light sensor
2Left selection key
3Home key
4Call key
5Number keys
6End/Power key
7Clear key C
8Right selection key
9Navi™ key (scroll key)
10 Secondary camera lens
11 Earpiece
Your device 15
© 2010 Nokia. All rights reserved.

12 Wrist strap eyelet
13 Nokia AV connector (2.5 mm)
14 Micro USB connector
15 Charger connector
16 Main camera lens
17 Camera flash
18 Microphone
19 Loudspeaker
20 Capture key
The surface of this device is nickel-free.
Home screen
When you have switched on the device,
and it is registered to a network, the
device is in the home screen and ready
for use.
To open a list of most recently dialled
numbers, press the call key.
To use voice commands or voice
dialling, press and hold the right
selection key.
To change the profile, press the power
key briefly, and select a profile.
To open a connection to the web, press
and hold 0.
To activate or deactivate Bluetooth
connectivity, press and hold *.
To modify the home screen, select
> Settings > Settings and
General > Personalisation >
16 Your device
© 2010 Nokia. All rights reserved.

Standby mode and from the available
options.
Offline profile
To quickly activate the Offline profile,
press the power key briefly, and select
Offline.
To switch to another profile, press the
power key briefly, and select a profile.
When the Offline profile is active, all
connections that use radio frequencies
are closed. However, you can use your
device without the SIM card and listen
to the radio or music. Remember to
switch off your device when wireless
phone use is prohibited.
Important: In the Offline profile you
cannot make or receive any calls, or use
other features that require cellular
network coverage. Calls may still be
possible to the official emergency
number programmed into your device.
To make calls, you must first activate the
phone function by changing profiles. If
the device has been locked, enter the
lock code.
Display indicators
The device is being used in a UMTS
network or a GSM network
(network service). The bar next to
the icon indicates the signal
strength of the network at your
current location. The higher the
bar, the stronger the signal.
High-speed downlink packet
access (HSDPA) / high-speed
uplink packet access (HSUPA)
(network service) in the UMTS
network is activated.
The device is using the Offline
profile and is not connected to a
cellular network.
The battery charge level. The
higher the bar, the stronger the
charge in the battery.
You have unread messages in the
Inbox folder in Messaging.
You have received new e-mail in
the remote mailbox.
Your device 17
© 2010 Nokia. All rights reserved.

There are messages waiting to be
sent in the Outbox folder in
Messaging.
You have missed calls.
The keys of the device are locked.
An alarm is active.
You have activated the Silent
profile, and the device does not
ring for an incoming call or
message.
Bluetooth connectivity is
activated.
A Bluetooth connection is
established. When the indicator is
blinking, your device is trying to
connect with another device.
A GPRS packet data connection is
available (network service).
indicates that the connection is
active. indicates that the
connection is on hold.
An EGPRS packet data connection
is available (network service).
indicates that the connection is
active. indicates that the
connection is on hold.
A UMTS packet data connection is
available (network service).
indicates that the connection is
active. indicates that the
connection is on hold.
HSDPA/HSUPA is supported and
available (network service). The
icon may vary between regions.
indicates that the connection is
active. indicates that the
connection is on hold.
Your device is connected to a
computer with a USB data cable.
The second phone line is being
used (network service).
All calls are forwarded to another
number. If you have two phone
lines, a number indicates the
active line.
18 Your device
© 2010 Nokia. All rights reserved.

A headset or a loopset is
connected to the device.
A hands-free car kit is connected
to the device.
A text phone is connected to the
device.
Your device is synchronising.
Other indicators may also be displayed.
Power saver
Select > Settings > Settings.
To define the screen saver settings,
select General > Personalisation >
Display and from the following:
Power saver time-out — Set the
length of time that the device is inactive
before the power saver is activated.
Light time-out — Set the length of
time that the device is inactive before
the screen is dimmed.
Menu
Press .
In the menu, you can access the
functions in your device.
To open an application or a folder, select
the item.
If you change the order of the functions
in the menu, the order may differ from
the default order described in this user
guide.
To change the menu view, select
Options > Change Menu view.
To close an application or a folder, select
Options > Exit.
To display and switch between open
applications, press and hold the home
key, and select an application.
Leaving applications running in the
background increases the demand on
battery power and reduces the battery
life.
Volume control
To adjust the volume when listening to
an audio file, scroll up or down.
To adjust the volume during a call, scroll
left or right.
Your device 19
© 2010 Nokia. All rights reserved.

To activate or deactivate the
loudspeaker during a call, select
Loudsp. or Handset.
Warning:
Continuous exposure to high volume
may damage your hearing. Listen to
music at a moderate level, and do not
hold the device near your ear when the
loudspeaker is in use.
Keypad lock (keyguard)
To unlock the keypad, open the slide, or
select Unlock, then quickly select OK.
Select > Settings > Settings and
General.
To set the device to lock the keypad
when you close the slide, select Slide
handling > Keyguard activation.
To set the device to automatically lock
the keypad after a certain length of
time, select Security > Phone and SIM
card > Keypad autolock period >
User defined, and select the desired
time.
When the device or keypad is locked,
calls may be possible to the official
emergency number programmed into
your device.
Access codes
Select > Settings > Settings.
To define how your device uses the
access codes and security settings,
select General > Security > Phone
and SIM card and from the following:
•The PIN (UPIN) code, supplied with
the SIM (USIM) card, helps to protect
the card against unauthorised use.
•The PIN2 (UPIN2) code, supplied
with some SIM (USIM) cards, is
required to access certain services.
•PUK (UPUK) and PUK2 (UPUK2) codes
may be supplied with the SIM (USIM)
card. If you enter the PIN code
incorrectly three times in
succession, you are asked for the
PUK code. If the codes are not
supplied, contact your service
provider.
•The security code helps to protect
your phone against unauthorised
use. You can create and change the
code, and set the phone to request
the code. Keep the code secret and
in a safe place separate from your
20 Your device
© 2010 Nokia. All rights reserved.
