Nokia 6800 User manual

User’s Guide for Nokia 6800

List of menu functions
1. Messages
1. Text messages
1. Create message
2. Inbox
3. Sent items
4. Archive
5. Templates
6. My folders
7. Distribution lists
8. Delete messages
2. Multimedia msgs.
1. Create message
2. Inbox
3. Outbox
4. Sent items
5. Saved items
6. Delete messages
3. E-mail
1. Open
1. Create e-mail
2. Retrieve
3. Send now
4. Send and retrieve
5. Inbox
6. Outbox
7. Deleted items
8. Sent items
9. Drafts
10.Archive
11.Settings
2. Web access
3. Service settings
4. Details
4. Chat
5. Voice messages
1. Listen to voice messages
2. Voice mailbox number
6. Info messages
7. Message settings
1. Text messages
2. Multimedia msgs.
3. Other settings
8. Service commands
2. Call register
1. Missed calls
2. Received calls
3. Dialled numbers
4. Delete recent call lists
5. Call duration
6. Call costs
7. GPRS data counter
8. GPRS connection timer
3. Profiles
1. General
2. Silent
3. Meeting
4. Outdoor
5. Pager
4. Settings
1. Time and date
settings
2. Call settings
1. Call divert
2. Anykey answer
3. Automatic redial
ii Copyright © 2004 Nokia. All rights reserved.

4. Speed dialling
5. Call waiting
6. Summary after call
7. Send my caller identity
8. Line for outgoing calls1
3. Phone settings
1. Language
2. Memory status
3. Security keyguard
4. Cell info display
5. Welcome note
6. Network selection
7. Confirm SIM service actions
8. Help text activation
9. Start-up tone
4. Display settings
1. Wallpaper
2. Colour schemes
3. Operator logo
4. Screen saver timeout
5. Display brightness
5. Tone settings
1. Incoming call alert
2. Ringing tone
3. Ringing volume
4. Vibrating alert
5. Message alert tone
6. Keypad tones
7. Warning tones
8. Alert for
6. Enhancement settings2
7. Security settings
8. Restore factory settings
5. Organiser
1. Alarm clock
2. Calendar
3. To-do list
6. Notes
7. Radio
8. Gallery
1. View folders
2. Add folder
3. Delete folder
4. Rename folder
5. Gallery downloads
9. Games
1. Select game
2. Game downloads
3. Memory
4. Settings
10.Applications
1. Select application
2. App. downloads
3. Memory
11. Ex tras
1. Calculator
2. Wallet
3. Synchronisation
4. Countdown timer
5. Stopwatch
1. For availability, contact your network operator or service provider.
2. This menu is only shown if the phone is or has been connected to a headset, handsfree
unit or loopset available for the phone.
Copyright © 2004 Nokia. All rights reserved. iii

12.Connectivity
1. Infrared
2. GPRS
13.Services
1. Home
2. Bookmarks
3. Service inbox
4. Settings
5. Go to address
6. Clear the cache
14.SIM services1
1. Only shown if supported by your SIM card. The name and contents vary depending on
the SIM card.
iv Copyright © 2004 Nokia. All rights reserved.

DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product NHL-6
is in conformity with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found at
http://www.nokia.com/phones/declaration_of_conformity/.
Copyright © 2003 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People and Pop-Port are trademarks or registered trademarks
of Nokia Corporation. Other product and company names mentioned herein may be
trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software
Copyright (C) 1997-2003. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA
Security.
Java is a trademark of Sun Microsystems, Inc.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without
prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law,
no warranties of any kind, either express or implied, including, but not limited to, the
implied warranties of merchantability and fitness for a particular purpose, are made in
relation to the accuracy, reliability or contents of this document. Nokia reserves the
right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by market. Please check with the Nokia
dealer nearest to you. Please dispose of batteries properly.
Issue 1
Copyright © 2004 Nokia. All rights reserved. v

Contents
FOR YOUR SAFETY....................... ix
Network Services .......................... x
About enhancements.................... x
Access codes................................. xi
Overview of the phone
functions ................................... xiii
Messaging concept ........................ xiii
Multimedia messaging service
(MMS) ................................................ xiii
Polyphonic sound (MIDI) .............. xiii
General Packet Radio Service
(GPRS) ................................................. xiv
Loudspeaker....................................... xiv
MIDP JavaTM applications............ xiv
Stereo radio....................................... xiv
Over the Air (OTA) settings
service.................................................. xv
Shared memory ................................. xv
1. Your phone .............................. 1
Keys (flip closed)................................. 1
Connectors............................................ 2
Keys (flip open).................................... 2
Standby mode...................................... 3
Screen saver .............................................. 3
Wallpaper................................................... 3
Essential indicators in standby
mode............................................................ 4
Headset.................................................. 5
2. Getting started......................... 6
Installing the SIM card and
the battery............................................ 6
Charging the battery ......................... 7
Switching the phone on and off.... 7
Opening the flip.................................. 8
Switching the keyboard lights on
or off............................................................ 9
Keypad lock (Keyguard) .................... 9
3. Call functions........................ 11
Making a call..................................... 11
Speed dialling a phone number........ 11
Making a conference call ................... 12
Answering or rejecting an
incoming call ..................................... 12
Call waiting ............................................ 13
Options during a call....................... 13
Loudspeaker............................................ 13
4. Writing text........................... 15
Writing text using the messaging
keyboard.............................................. 15
Typing accented characters ............... 16
Writing text when the flip is
closed................................................... 16
Setting predictive text input on
or off......................................................... 16
Using predictive text input ................ 16
Using traditional text input ............... 17
Tips for writing text ............................. 18
vi Copyright © 2004 Nokia. All rights reserved.

5. Contacts ................................. 19
Selecting settings for contacts.... 19
Saving names and phone
numbers (Add contact)................... 19
Saving multiple numbers and text
items per name...................................... 20
Searching for a name in
contacts.............................................. 20
Editing a name, number or
text item............................................. 21
Erasing names and numbers......... 21
Copying contacts ............................. 21
Sending and receiving a business
card...................................................... 22
Speed dialling ................................... 22
Info numbers..................................... 22
Service numbers............................... 23
My numbers ...................................... 23
Caller groups..................................... 23
6. Using the menu ..................... 24
Accessing a menu function........... 24
7. Menu functions ..................... 25
Messages (Menu 1) ......................... 25
Text messages (SMS service)............. 25
Templates................................................ 27
Archive folder and my folders........... 28
Distribution lists.................................... 28
Multimedia messages.......................... 29
Deleting messages................................ 32
E-mail messages ................................... 32
Chat .......................................................... 36
Voice messages...................................... 37
Info messages ........................................ 38
Message settings .................................. 38
Font size setting.................................... 40
Service commands................................ 40
Call register (Menu 2) ..................... 40
Recent calls lists.................................... 41
Call counters and call timers............. 41
Profiles (Menu 3).............................. 42
Settings (Menu 4)............................. 43
Time and date settings........................ 43
Call settings............................................ 43
Phone settings ....................................... 45
Display settings ..................................... 46
Tone settings.......................................... 48
Enhancement settings......................... 48
Security settings.................................... 49
Restore factory settings...................... 50
Organiser (Menu 5).......................... 50
Alarm clock............................................. 50
Calendar................................................... 51
To-do list ................................................. 52
Notes (Menu 6)................................. 53
Radio (Menu 7) ................................. 54
Tuning a radio channel........................ 55
Using the radio ...................................... 55
Gallery (Menu 8)............................... 56
Games (Menu 9) ............................... 57
Launching a game ................................ 57
Game downloads................................... 58
Memory status for games................... 58
Game settings ........................................ 58
Applications (Menu 10) .................. 58
Launching an application ................... 59
Downloading an application.............. 60
Memory status for applications........ 60
Extras (Menu 11).............................. 61
Calculator................................................ 61
Wallet....................................................... 62
Synchronisation..................................... 64
Countdown timer.................................. 66
Stopwatch............................................... 66
Copyright © 2004 Nokia. All rights reserved. vii

Connectivity (Menu 12)................. 67
Infrared .................................................... 67
GPRS......................................................... 68
WAP services (Menu 13)................ 69
Basic steps for accessing and using
WAP services.......................................... 69
Setting up the phone for a WAP
service ...................................................... 69
Connecting to a WAP service............ 72
Browsing the pages of a WAP
service ...................................................... 73
Ending a WAP connection.................. 74
Appearance settings of the WAP
browser .................................................... 74
Bookmarks............................................... 74
Service inbox.......................................... 75
The cache memory................................ 76
Browser security settings ................... 76
Cookies..................................................... 78
SIM services (Menu 14) ................. 79
8. PC Connectivity ..................... 80
PC Suite .............................................. 80
GPRS, HSCSD and CSD ........................ 81
Using data communications
applications....................................... 81
9. Battery information .............. 82
Charging and Discharging............. 82
10. Mobile Enhancements......... 83
Battery ................................................ 83
Indoor.................................................. 83
Travel Charger (ACP-12) ..................... 83
Indoor and Vehicle .......................... 84
Boom Headset (HDB-4)....................... 84
Vehicle ................................................ 84
Mobile Charger (LCH-9)...................... 84
11. Care and Maintenance ....... 85
12. Important Safety
Information................................ 86
Index........................................... 90
viii Copyright © 2004 Nokia. All rights reserved.

FOR YOUR SAFETY
Read these simple guidelines. Breaking
the rules may be dangerous or illegal.
Further detailed information is given in
this manual.
Do not switch the phone on
when wireless phone use is
prohibited or when it may cause
interference or danger.
ROAD SAFETY COMES FIRST
Don't use a hand-held phone
while driving.
INTERFERENCE
All wireless phones may get
interference, which could affect
performance.
SWITCH OFF IN HOSPITALS
Follow any regulations or rules.
Switch the phone off near
medical equipment.
SWITCH OFF IN AIRCRAFT
Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELLING
Don't use the phone at a
refuelling point. Don't use near
fuel or chemicals.
SWITCH OFF NEAR BLASTING
Don't use the phone where
blasting is in progress. Observe
restrictions, and follow any
regulations or rules.
USE SENSIBLY
Use only in the normal position.
Don't touch the antenna
unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may
install or repair phone
equipment.
ENHANCEMENTS AND BATTERIES
Use only approved
enhancements and batteries. Do
not connect incompatible
products.
CONNECTING TO OTHER DEVICES
When connecting to any other
device, read its user's guide for
detailed safety instructions. Do
not connect incompatible
products.
BACKUP COPIES
Remember to make backup
copies of all important data.
WATER-RESISTANCE
Your phone is not water-
resistant. Keep it dry.
CALLING
Ensure the phone is switched on
and in service. Enter the phone
number, including the area code,
then press . To end a call,
press . To answer a call, press
.
EMERGENCY CALLS
Ensure the phone is switched on
and in service. Press as many
times as needed (e.g. to exit a
call, to exit a menu, etc.) to clear
the display. Enter the emergency
number, then press . Give
your location. Do not end the call
until told to do so.
Copyright © 2004 Nokia. All rights reserved. ix

Network Services
The wireless phone described in this guide is approved for use on the EGSM 900 and
GSM 1800 networks.
Dualband is a network dependent feature. Check with your local service provider if you
can subscribe to and use this feature.
A number of features included in this guide are called Network Services. These are
special services that you arrange through your wireless service provider. Before you can
take advantage of any of these Network Services, you must subscribe to them through
your service provider and obtain instructions for their use from your service provider.
Note: Some networks may not support all language-dependent characters
and/or services.
About enhancements
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from ACP-7, ACP-8, ACP-12, LCH-9 and
LCH-12.
Warning: Use only batteries, chargers and enhancements approved by the
phone manufacturer for use with this particular phone model. The use of any
other types may invalidate any approval or warranty applying to the phone,
and may be dangerous.
For availability of approved enhancements, please check with your dealer.
When you disconnect the power cord of any enhancements, grasp and pull the plug, not
the cord.
x Copyright © 2004 Nokia. All rights reserved.

Access codes
•Security code (5 to 10 digits):
The security code protects your
phone against unauthorised use,
and is supplied with the phone.
The preset code is 12345. When
you have changed the code, keep
the new code secret and in a safe
place separate from your phone.
To change the code, and to set
the phone to request it, see
”Security settings” on page 49.
If you key in an incorrect security
code five times in succession, the
phone may display Code error.
Wait for five minutes and key in
the code again.
•PIN code and PIN2 code (4 to 8
digits): The PIN (Personal
Identification Number) code
protects your SIM card against
unauthorised use. The PIN code is
usually supplied with the SIM
card.
Set the phone to request the PIN
code each time the phone is
switched on, see ”Security
settings” on page 49.
The PIN2 code may be supplied
with the SIM card and is required
to access some functions, such as
charging unit counters.
If you key in an incorrect PIN
code three times in succession,
the phone may display PIN code
blocked and ask you to key in the
PUK code. Contact your service
provider to obtain the PUK code.
•PUK and PUK2 codes (8 digits):
The PUK (Personal Unblocking
Key) code is required to change a
blocked PIN code. The PUK2 code
is required to change a blocked
PIN2 code.
If the codes are not supplied with
the SIM card, contact your local
service provider.
•Barring password (4 digits): The
barring password is required
when using the Call barring
service, see ”Security settings” on
page 49. You can obtain the
password from your service
provider.
•Module PIN and signing PIN:
The module PIN is required to
access the information in the
security module. See ”Security
module” on page 76. The signing
PIN is needed for the digital
signature. See ”Digital signature”
on page 78.
Copyright © 2004 Nokia. All rights reserved. xi

The module PIN and the signing
PIN are supplied with the SIM
card if the SIM card has a
security module in it.
If you key in an incorrect PIN
code several times, the phone
may display PIN code blocked
and ask you to key in the PUK
code. Contact your service
provider to get the PUK code.
•Wallet code (4-10 digits): The
wallet code is required to access
the wallet services. If you key in a
wrong wallet code several times,
the wallet application is blocked
for five minutes. For further
information, see ”Wallet” on
page 62.
xii Copyright © 2004 Nokia. All rights reserved.

Overview of the phone functions
Your Nokia 6800 phone is approved
for use on EGSM 900 and GSM 1800
networks. It provides many functions
which are practical for daily use,
such as the messaging keyboard for
easy and convenient writing,
calendar, clock, alarm clock,
countdown timer, calculator, games
and many more.
■Messaging concept
Your phone combines the functions
of a normal mobile phone and a
messaging device. When the flip is
closed you can use all functions of
your phone like in any other mobile
phone. By opening the flip of the
phone you can use the additional
messaging keyboard, which is
specially designed for writing text
easily and comfortably, see ”Writing
and sending messages” on page 26.
■Multimedia messaging
service (MMS)
The phone is able to send
multimedia messages that contain
text and a picture and receive
multimedia messages containing
text, a polyphonic ringing tone and a
picture. You can save the pictures
and ringing tones for personalising
your phone, see ”Multimedia
messages” on page 29
■Polyphonic sound
(MIDI)
Polyphonic sound consists of several
sound components that are played
at the same time. Your phone can
play four instruments at the same
time from over 40 sound
components presaved in your phone
as ringing tones and message alert
tones. The phone supports Scalable
Polyphonic MIDI (SP-MIDI) format.
You can receive polyphonic ringing
tones via the multimedia service, see
”Reading and replying to a
multimedia message” on page 30 or
you can download them via the
gallery menu, see ”Gallery (Menu 8)”
on page 56, or via PC Suite, see ”PC
Suite” on page 80.
Copyright © 2004 Nokia. All rights reserved. xiii

■General Packet Radio
Service (GPRS)
GPRS technology allows mobile
phones to be used for sending and
receiving data over an Internet
Protocol (IP) - based network. GPRS
as such is a data bearer that enables
wireless access to data networks
such as the Internet. The
applications that use GPRS are WAP
services, MMS and text (SMS)
messaging, downloading JavaTM
applications and the PC dial-up (for
example, Internet and e-mail). Note
that your phone supports three
simultaneous GPRS connections.
Before you can use GPRS
technology
• Contact your network operator or
service provider for availability
and subscription to the GPRS
service.
• Save the GPRS settings for each
of the applications used over
GPRS.
See ”Setting up the phone for a
WAP service” on page 69,
”Message settings” on page 38
and ”GPRS” on page 68.
Pricing for GPRS and applications
For more detailed information on
pricing, contact your network
operator or service provider.
■Loudspeaker
This feature allows you to use your
phone as a loudspeaker during a call,
such as a conference call, and carry
out other tasks simultaneously,
while you talk. You can, for example,
write messages, check your calendar
notes or play games. See
”Loudspeaker” on page 13.
■MIDP JavaTM
applications
Your phone supports Java and
includes some Java applications and
games that have been especially
designed for mobile phones. You can
also download new applications and
games to your phone, see
”Applications (Menu 10)” on page
58.
■Stereo radio
Your phone has an integrated stereo
radio. You can listen to the radio
using a headset or via the
loudspeaker, see ”Radio (Menu 7)”
on page 54.
xiv Copyright © 2004 Nokia. All rights reserved.

■Over the Air (OTA)
settings service
In order to use WAP, MMS, GPRS and
other wireless services, you need to
have proper settings on your phone.
You may receive the settings directly
as an OTA message and then save
them on your phone. For more
information on the availability of the
settings, contact your network
operator, service provider or the
nearest authorised Nokia dealer.
■Shared memory
The following features in this phone
may share memory: contacts, text
and multimedia messages, images
and ringing tones in gallery,
calendar, to-do notes, Java games,
applications, notes application and
e-mail. Using any such features may
reduce the memory available for any
features sharing memory. This is
especially true with heavy use of any
of the features (although some of
the features may have a certain
amount memory specially allotted to
them in addition to the amount of
memory shared with other features).
For example, saving many images,
Java applications etc. may take all of
the shared memory and your phone
may display a message that the
memory is full. In this case, delete
some of the information or entries
stored in the shared memory
features before continuing.
Copyright © 2004 Nokia. All rights reserved. xv

xvi Copyright © 2004 Nokia. All rights reserved.

Your phone
Copyright © 2004 Nokia. All rights reserved. 1
1. Your phone
■Keys (flip closed)
1. Power key
Switches the phone on and off.
For example, when the keypad is
locked, briefly pressing the power
key turns the phone’s display
lights on for approximately 15
seconds.
2. Volume key
Adjusts the volume of the
earpiece, the headset and the
loudspeaker.
3. Selection keys and
The function of the keys depends
on the guiding text shown on the
display above the keys, for
example Menu and Contacts in
standby mode.
4. 4-way joystick
Enables scrolling through names,
phone numbers, menus or
settings. The 4-way joystick is
also used to move the cursor up
and down, and right and left
when writing text, using the
calendar, and in some game
applications.
5. dials a phone number, and
answers a call. In standby mode it
shows the most recently called
number.
6. ends an active call. Exits
from any function.
7. - enter numbers and
characters.
and are used for
various purposes in different
functions.
8. Ear piece

Your phone
2 Copyright © 2004 Nokia. All rights reserved.
■Connectors
1. Charger connector
2. Pop-PortTM connector for
headsets, data cable and other
enhancements.
3. Infrared (IR) port
4. Loudspeaker
5. Microphone
■Keys (flip open)
When you open the flip, the display
graphics are rotated 90 degrees and
the left and right selection keys
change positions, but the guiding
texts above the left and right
selection keys do not change. For
using the keys to write and edit text,
see ”Writing text using the
messaging keyboard” on page 15.
1. Keyboard light key switches
the keyboard light on or off to
provide additional lighting while
using the keyboard. See also
”Switching the keyboard lights
on or off” on page 9.
2. Profile key opens a list of
profiles when pressed briefly.
Pressing and holding down the
key switches the phone off.
3. Backspace deletes
characters.
4. Enter key forces a line feed
when editing text.
5. Shift keys and enter
upper case letters and symbols.
You can either press the shift key
first and then the desired key or
press both keys at the same time.
6. Space bar keys and
enter a space.
7. Power key/ Left selection key
switches the power on, when the
phone’s messaging keyboard is
open and the phone is switched
off. The function of the left
selection key depends on the
guiding text shown on the
display above the key.

Your phone
Copyright © 2004 Nokia. All rights reserved. 3
8. Character key opens a set of
characters and symbols during
editing.
■Standby mode
When the phone is ready for use (the
flip can be either closed or open),
and you have not keyed in any
characters, the phone is in standby
mode.
1. Shows the name of the network
in which the phone is currently
being used, or the operator logo
when no wallpaper is displayed.
2. Shows the signal strength of the
cellular network at your current
location. The higher the bar, the
stronger the signal.
3. Shows the battery charge level.
The higher the bar, the more
power in the battery
4. The left selection key in standby
mode is Menu.
5. The right selection key in standby
mode is Contacts.
See also ”Essential indicators in
standby mode” on page 4.
Screen saver
With the flip closed, the phone
automatically activates a digital
clock screen saver to save power in
standby mode. It will be activated
after a certain length of time when
none of the phone functions have
been used, see ”Screen saver” on
page 47. Press any key or open the
flip to deactivate the screen saver.
Note that if you have not set the
time, 00:00 is displayed. To set the
time, see ”Clock” on page 43.
Wallpaper
You can set your phone to display a
background picture as wallpaper
when the phone is in standby mode,
see ”Wallpaper” on page 46.

Your phone
4 Copyright © 2004 Nokia. All rights reserved.
Essential indicators in
standby mode
You have received one or
several text or picture
messages. See ”Reading and
replying to a message” on
page 26.
You have received one or
several multimedia
messages. See ”Writing and
sending a multimedia
message” on page 29.
You have received one or
several voice messages. See
”Voice messages” on page
37.
The phone’s keypad is
locked. See ”Keypad lock
(Keyguard)” on page 9and
”Security keyguard” on page
45.
The phone does not ring for
an incoming call or a text
message because Incoming
call alert is set to Off and
Message alert tone is set to
Off. See ”Tone settings” on
page 48.
The alarm clock is set to On.
See ”Alarm clock” on page
50.
The countdown timer is
running. See ”Countdown
timer” on page 66.
The stopwatch is running in
the background. See
”Stopwatch” on page 66.
When a GPRS connection is
established, this indicator is
shown on the top left of the
display. See ”GPRS
connection” on page 68 and
”Browsing the pages of a
WAP service” on page 73.
The GPRS connection is
suspended (on hold), for
example, if there is an
incoming or outgoing call
during a GPRS dial-up
connection.
The infrared connection
indicator. See ”Infrared” on
page 67.
All your calls are diverted to
another number. If you have
two phone lines, the divert
indicator for the first line is
and for the second line
is . See ”Call divert” on
page 43.
or If you have two phone lines,
the indicator displays the
selected phone line. See
”Line for outgoing calls” on
page 45.
The loudspeaker has been
activated. See
”Loudspeaker” on page 13.
