Nokia N71 User manual

FCC DRAFT
Nokia N71 User Guide
9237522
FCC Draft
R1114_en.book Page 1 Tuesday, January 24, 2006 2:04 PM

FCC DRAFT
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole
responsibility that the product RM-112 is in
conformity with the provisions of the following
Council Directive: 1999/5/EC. A copy of the
Declaration of Conformity can be found at http://
www.nokia.com/phones/declaration_of_conformity/
The crossed-out wheeled bin means that within the European Union the
product must be taken to separate collection at the product end-of-life.
This applies to your device but also to any enhancements marked with
this symbol. Do not dispose of these products as unsorted municipal
waste.
Copyright © 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this
document in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Pop-Port, and Visual Radio are trademarks or
registered trademarks of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
This product includes software licensed from Symbian Software Ltd (c) 1998-
200(6). Symbian and Symbian OS are trademarks of Symbian Ltd.
Java™ and all Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc.
Stac ®, LZS ®, ©1996, Stac, Inc., ©1994-1996 Microsoft Corporation. Includes one
or more U.S. Patents: No. 4701745, 5016009, 5126739, 5146221, and 5414425.
Other patents pending.
Hi/fn ®, LZS ®,©1988-98, Hi/fn. Includes one or more U.S. Patents: No. 4701745,
5016009, 5126739, 5146221, and 5414425. Other patents pending.
Part of the software in this product is © Copyright ANT Ltd. 1998. All rights reserved.
US Patent No 5818437 and other pending patents. T9 text input software Copyright
(C) 1997-2006. Tegic Communications, Inc. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for
personal and noncommercial use in connection with information which has been
encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged
in a personal and noncommercial activity and (ii) for use in connection with
MPEG-4 video provided by a licensed video provider. No license is granted or shall
be implied for any other use. Additional information including that relating to
promotional, internal and commercial uses may be obtained from MPEG LA, LLC.
See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the right to make
changes and improvements to any of the products described in this document
without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income
or any special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided ‘as is’. Except as required by applicable
law, no warranties of any kind, either express or implied, including, but not limited
to, the implied warranties of merchantability and fitness for a particular purpose,
are made in relation to the accuracy, reliability or contents of this document. Nokia
reserves the right to revise this document or withdraw it at any time without prior
notice.
The availability of particular products may vary by region. Please check with the
Nokia dealer nearest to you.
This device may contain commodities, technology or software subject to export
laws and regulations from the US and other countries. Diversion contrary to law is
prohibited.
FCC / INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a
telephone in close proximity to receiving equipment). The FCC or Industry Canada
can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device
complies with part 15 of the FCC rules. Operation is subject to the condition that
this device does not cause harmful interference.
ISSUE 1 EN, 9237522
R1114_en.book Page 2 Tuesday, January 24, 2006 2:04 PM

FCC DRAFT
Contents
3
Contents
For your safety...........................................6
Your Nokia N71.........................................9
Settings .................................................................................... 9
Transfer content..................................................................... 9
Essential indicators.............................................................10
Keypad lock (keyguard)......................................................11
Volume and loudspeaker control ....................................11
Clock........................................................................................11
Memory card tool................................................................12
File manager .........................................................................13
Useful shortcuts...................................................................14
Multimedia key ....................................................................15
Help .........................................................................................15
Tutorial ...................................................................................15
Camera..................................................... 16
Camera display.....................................................................16
Take pictures.........................................................................16
Edit images............................................................................20
Tips on taking good photographs ...................................20
Video recorder display........................................................21
Record videos........................................................................21
Gallery.......................................................25
View images and video clips............................................26
Edit video clips.....................................................................26
Slide show .............................................................................28
Presentations........................................................................28
Albums ...................................................................................29
Image print ...........................................................................29
Media applications ..................................31
RealPlayer..............................................................................31
Movie director......................................................................33
Messaging.................................................35
Write text..............................................................................36
Write and send messages .................................................37
Inbox—receive messages...................................................39
Mailbox ..................................................................................41
View messages on a SIM card.........................................43
Messaging settings.............................................................43
Make calls ................................................48
Voice calls .............................................................................48
Answer or reject a call.......................................................50
R1114_en.book Page 3 Tuesday, January 24, 2006 2:04 PM

FCC DRAFT
Contents
4
Log........................................................................................... 51
Contacts (phonebook).............................54
Save names and numbers.................................................54
Copy contacts ...................................................................... 55
Add ringing tones for contacts....................................... 56
Create contact groups....................................................... 56
Services.....................................................57
Services access point ......................................................... 57
Bookmarks view................................................................... 57
Connection security ........................................................... 58
Browse.................................................................................... 58
Download and purchase items........................................ 59
End a connection ................................................................ 59
Services settings.................................................................. 60
Calendar....................................................61
Create calendar entries ..................................................... 61
Meeting requests ................................................................ 61
Calendar views..................................................................... 62
Manage your calendar entries ........................................ 62
Calendar settings ................................................................ 62
My own.....................................................63
Music player ......................................................................... 63
Visual Radio (network service)........................................ 64
Instant messaging (network service).............................66
Games..................................................................................... 69
Connectivity .............................................70
Bluetooth connectivity...................................................... 70
Infrared connection............................................................ 73
Data cable ............................................................................. 74
PC connections .................................................................... 74
Connection manager.......................................................... 74
Synchronization................................................................... 75
Device manager ................................................................... 75
Office........................................................77
Calculator.............................................................................. 77
Converter............................................................................... 77
Notes ...................................................................................... 77
Recorder................................................................................. 78
Personalize your device...........................79
Profiles—set tones............................................................... 79
Change the look of your device ...................................... 80
Active standby mode.......................................................... 81
Tools..........................................................82
Settings Wizard .................................................................. 82
Settings.................................................................................. 83
Voice commands ................................................................. 92
R1114_en.book Page 4 Tuesday, January 24, 2006 2:04 PM

FCC DRAFT
Contents
5
Application manager ..........................................................93
Activation keys.....................................................................95
Troubleshooting ...................................... 96
Q&A.........................................................................................96
Battery information................................ 99
Charging and discharging.................................................99
Nokia battery authentication guidelines......................99
Care and maintenance ......................... 101
Additional safety information............. 102
R1114_en.book Page 5 Tuesday, January 24, 2006 2:04 PM

6
FCC DRAFT
For your safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY Do not switch the
device on when wireless phone use is
prohibited or when it may cause interference
or danger.
ROAD SAFETY COMES FIRST Obey all local
laws. Always keep your hands free to operate
the vehicle while driving. Your first
consideration while driving should be road
safety.
INTERFERENCE All wireless devices may be
susceptible to interference, which could affect
performance.
SWITCH OFF IN HOSPITALS Follow any
restrictions. Switch the device off near
medical equipment.
SWITCH OFF IN AIRCRAFT Follow any
restrictions. Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELLING Do not use
the device at a refuelling point. Do not use near
fuel or chemicals.
SWITCH OFF NEAR BLASTING Follow any
restrictions. Do not use the device where
blasting is in progress.
USE SENSIBLY Use only in the normal
position as explained in the product
documentation. Do not touch the antenna
unnecessarily.
QUALIFIED SERVICE Only qualified personnel
may install or repair this product.
ENHANCEMENTS AND BATTERIES Use only
approved enhancements and batteries. Do not
connect incompatible products.
WATER-RESISTANCE Your device is not
water-resistant. Keep it dry.
BACK-UP COPIES Remember to make
back-up copies or keep a written record of all
important information stored in your device.
R1114_en.book Page 6 Tuesday, January 24, 2006 2:04 PM

7
FCC DRAFT
CONNECTING TO OTHER DEVICES When
connecting to any other device, read its user
guide for detailed safety instructions. Do not
connect incompatible products.
EMERGENCY CALLS Ensure the phone
function of the device is switched on and in
service. The keypad is active only in the fold
open mode. Press as many times as
needed to clear the display and return to the
start screen. Enter the emergency number,
then press . Give your location. Do not end
the call until given permission to do so.
About your device
The wireless device described in this guide is approved for
use on the EGSM 900,1800, and 1900 networks. Contact
your service provider for more information about networks.
When using the features in this device, obey all laws and
respect privacy and legitimate rights of others.
When taking and using images or video clips, obey all laws
and respect local customs as well as privacy and legitimate
rights of others.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on.
Do not switch the device on when wireless device use
may cause interference or danger.
Network services
To use the phone you must have service from a wireless
service provider. Many of the features in this device
depend on features in the wireless network to function.
These network services may not be available on all
networks or you may have to make specific arrangements
with your service provider before you can utilize network
services. Your service provider may need to give you
additional instructions for their use and explain what
charges will apply. Some networks may have limitations
that affect how you can use network services. For
instance, some networks may not support all
language-dependent characters and services. Network
features are designated in this guide by (network service).
Your service provider may have requested that certain
features be disabled or not activated in your device. If so,
they will not appear on your device menu. Your device may
also have been specially configured. This configuration
may include changes in menu names, menu order and
icons. Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL)
that run on TCP/IP protocols. Some features of this device,
such as MMS, browsing, e-mail and content downloading
R1114_en.book Page 7 Tuesday, January 24, 2006 2:04 PM

8
FCC DRAFT
using the browser or over MMS, require network support
for these technologies.
For availability and information on using SIM card
services, contact your SIM card vendor. This may be the
service provider, network operator, or other vendor.
Enhancements, batteries, and
chargers
Always switch the device off and disconnect the charger
before removing the battery.
Check the model number of any charger before use with
this device. This device is intended for use when supplied
with power from a DC-4, AC-3 and AC-4 charger, and
from an AC-1, ACP-7, ACP-8, ACP-9, ACP-12, LCH-8,
LCH-9, or LCH-12 charger when used with the charger
adapter CA-44 delivered with your device.
The battery intended for use with this device is BL-5C.
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this
particular model. The use of any other types may
invalidate any approval or warranty, and may be
dangerous.
For availability of approved enhancements, please check
with your dealer. When you disconnect the power cord of
any enhancement, grasp and pull the plug, not the cord.
R1114_en.book Page 8 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
9
FCC DRAFT
Your Nokia N71
Model number: Nokia N71
Hereinafter referred to as Nokia N71.
Settings
Your Nokia N71 normally has MMS, GPRS, streaming, and
mobile Internet settings automatically configured, based
upon your service provider or network operator
information. You may have settings from your service
providers already installed in your device, or you may
receive the settings from the service providers as a special
text message.
Transfer content
You can copy content such as contacts and calendar
entries from a compatible Nokia device to your Nokia N71
using Bluetooth connectivity or infrared. The type of
content that can be copied depends on the device model.
Copyright protections may prevent some images, music
(including ringing tones), and other content from being
copied, modified, transferred or forwarded.
You can insert your SIM card in the other device. When
Nokia N71 is switched on without a SIM card, the offline
profile is automatically activated.
To avoid duplicate entries, you can transfer the same type
of information (for example, contacts) from the other
device to your Nokia N71 only once.
Transfer content
1Press , and select Tools > Transfer > Copy data on
your Nokia N71.
2In the information view, select Continue.
3Select whether you want to use Bluetooth connectivity
or infrared to transfer the data. Both devices must
support the selected connection type.
4If you select Bluetooth connectivity to search for
devices, select Continue. The visibility of the other
device must be on. Select your other device from the
list. You are asked to enter a code on your Nokia N71.
Enter a code (1–16 digits), and select OK. Enter the
same code on the other device, and select OK. The
devices are now paired. See ‘Pair devices’, p. 72.
For some device models, the Transfer application is
sent to the other device as a message. To install
Transfer on the other device, open the message, and
follow the instructions on the display.
R1114_en.book Page 9 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
10
FCC DRAFT
If you select infrared, connect the two devices. See
‘Infrared connection’, p. 73.
5From your Nokia N71, select the content you want to
copy from the other device.
Content is copied from the memory and compatible
memory card (if inserted) of the other device to the
corresponding location in your Nokia N71 and compatible
memory card (if inserted). Copying time depends on the
amount of data to be transferred. You can cancel copying
and continue later.
Essential indicators
The device is being used in a GSM network.
You have one or more unread messages in the Inbox
folder in Messaging.
You have received new e-mail in the remote mailbox.
There are messages waiting to be sent in the Outbox
folder.
You have missed calls.
Shown if Ringing type is set to Silent and Message
alert tone, IM alert tone, and E-mail alert tone are set
to Off.
The device keypad is locked.
A clock alarm is active.
The second phone line is being used (network service).
All calls to the device are diverted to another
number. If you have two phone lines (network service), the
indicator for the first line is and for the second
.
A headset is connected to the device.
The connection to a headset with Bluetooth
connectivity has been lost.
A loopset is connected to the device.
A TTY is connected to the device.
A data call is active.
A GPRS or EDGE packet data connection is available.
A GPRS or EDGE packet data connection is active.
A GPRS or EDGE packet data connection is on hold.
Bluetooth connectivity is on.
Data is being transmitted using Bluetooth
connectivity.
A USB connection is active.
An infrared connection is active. If the indicator is
blinking, the device is trying to connect to the other device
or the connection has been lost.
R1114_en.book Page 10 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
11
FCC DRAFT
Keypad lock (keyguard)
Use the keypad lock to prevent the keys from being
accidentally pressed.
To lock, in standby mode, press , then . When the
keys are locked, is shown on the display.
To unlock in fold open mode, press , then .
To lock the keypad, in fold open mode press the power key,
and select Lock keypad.
To lock the keypad, in fold closed mode press the power key
twice to select Lock keypad, and press the cover key.
When the keypad lock is on, calls may be possible to the
official emergency number programmed into your device.
To turn on the display light when the keypad lock is on,
press the power key.
Volume and loudspeaker control
To increase or decrease the
volume level when you have
an active call or are listening
to a sound, press or .
The built-in loudspeaker allows you to speak and listen
from a short distance without having to hold the device to
your ear.
Warning: Do not hold the device near your ear
when the loudspeaker is in use, because the volume
may be extremely loud.
To use the loudspeaker during a call, select Options >
Activate loudsp..
To turn off the loudspeaker, select Options > Activate
handset.
Clock
Tip! To view the time and date in fold closed mode,
press and hold the cover key.
Press , and select Clock. To set a new alarm, select
Options > Set alarm. When an alarm is active, is
shown.
To turn off the alarm, select Stop, or to stop the alarm for
5 minutes, select Snooze.
If the alarm time is reached while the device is switched
off, the device switches itself on and starts sounding the
alarm tone. If you select Stop, the device asks whether you
want to activate the device for calls. Select No to switch
off the device or Yes to make and receive calls. Do not
select Yes when wireless phone use may cause
interference or danger.
R1114_en.book Page 11 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
12
FCC DRAFT
To cancel an alarm, select Clock > Options > Remove
alarm.
Clock settings
To change the clock settings, select Clock > Options >
Settings.
To change the time or date, select Time or Date.
To change the clock shown in the standby mode, select
Clock type > Analog or Digital.
To allow the mobile phone network to update the time,
date, and time zone information to your device (network
service), select Auto time update > On.
To change the alarm tone, select Clock alarm tone.
World clock
To open the world clock view, open Clock, and press .
In the world clock view, you can view the time in different
cities.
To add cities to the list, select Options > Add city. You
can add a maximum of 15 cities to the list.
To set your current city, scroll to a city, and select
Options > My current city. The city is displayed in the
clock main view, and the time in your device is changed
according to the city selected. Check that the time is
correct and matches your time zone.
Memory card tool
Press , and select Tools > Memory. You can use a
compatible memory card as extra storage space and for
backing up the information in the device memory.
To back up information from the device memory to a
memory card, select Options > Backup phone mem.
To restore information from the memory card to the device
memory, select Options > Restore from card.
Format a memory card
When a memory card is reformatted, all data on the card
is permanently lost.
Some memory cards are supplied preformatted and others
require formatting. Consult your retailer to find out if you
must format the memory card before you can use it.
To format a memory card, select Options > Format mem.
card. Select Yes to confirm.
R1114_en.book Page 12 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
13
FCC DRAFT
Eject the memory card
1Before you eject the card, press
the power key, and select
Remove mem. card. All
applications are closed.
2When Remove memory card
and press 'OK' is displayed,
open the door of the memory
card slot.
3Press and release the memory card to eject it from the
slot.
4Remove the memory card, close the door, and select
OK.
Important: Do not remove the memory card in the
middle of an operation when the card is being accessed.
Removing the card in the middle of an operation may
damage the memory card as well as the device, and data
stored on the card may be corrupted.
File manager
Many features of the device, such as contacts, messages,
images, videos, ringing tones, calendar notes, documents,
and downloaded applications, use memory to store data.
The free memory available depends on how much data is
already saved in the device memory.
You can use a compatible memory card as extra storage
space. Memory cards are rewritable, so you can delete old
information and save new data on a memory card.
To browse files and folders in the device memory or on a
memory card (if inserted), press , and select Tools > File
mgr.. The device memory view ( ) opens. Press to
open the memory card view ( ) (if available).
To move or copy files to a folder, press and at the
same time to mark a file, and select Options > Move to
folder or Copy to folder.
To find a file, select Options > Find and the memory from
which to search, and enter a search text that matches the
file name.
View memory consumption
To view what types of data you have in the device and how
much memory the different data types consume, select
Options > Memory details. The amount of available free
memory is shown in Free memory.
Memory low—free memory
The device notifies you if the device or the memory card
memory is low.
R1114_en.book Page 13 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
14
FCC DRAFT
To free device memory, transfer data to a compatible
memory card, if you have one. Mark files to be moved, and
select Move to folder > Memory card and a folder.
You can also transfer media files to a compatible PC, for
example, using the transfer option in Gallery. See
‘Gallery’, p. 25.
Tip! You can use Nokia Phone Browser available in
Nokia PC Suite to view the different memories in your
device and transfer data.
To remove data to free memory, use File mgr., or go to the
respective application. For example, you can remove the
following:
• Messages from Inbox, Drafts, and Sent folders in
Messaging
• Retrieved e-mail messages from the device memory
• Saved Web pages
• Saved images, videos, or sound files
• Contact information
•Calendarnotes
• Downloaded applications. See also ‘Application
manager’, p. 93.
• Any other data that you no longer need
Useful shortcuts
Use shortcuts to quickly get the most from your device.
Refer to the relevant sections in this user guide for further
details of the functions.
Standby mode
• To switch between applications that are open, press
and hold , and select an application. If memory is
low, the device may close some applications. The device
saves any unsaved data before closing an application.
Leaving applications running in the background
increases the demand on battery power and reduces
the battery life.
• To start the camera, press .
• To call your voice mailbox (network service), press and
hold .
• To open multimedia applications, press or press and
hold . See ‘Multimedia key’, p. 15.
• To change the profile, press , and select a profile.
• If you have two phone lines (network service), press
to switch between the two lines.
• To open the last dialed numbers list, press .
• To use voice commands, press and hold .
• To start a connection to Services, press and hold .
See ‘Services’, p. 57.
For further shortcuts available in the standby mode, see
‘Active standby mode’, p. 81.
R1114_en.book Page 14 Tuesday, January 24, 2006 2:04 PM

Your Nokia N71
15
FCC DRAFT
Edit text and lists
• To mark an item in a list, scroll to it, and press and
at the same time.
• To mark multiple items in a list, press and hold
while you press or . To end the selection, release
or , then release .
• To select letters and words, press and hold . At the
same time, press or to highlight text.
• To copy the text to clipboard, while still holding ,
select Copy.
• To insert the text into a document, press and hold ,
and select Paste.
Multimedia key
To open the shortcut assigned to the multimedia key, press
and hold . To open a list of multimedia applications,
press . To open the desired application, press , ,
or . To exit the list without selecting an application,
press .
To change the shortcuts, press , and press . To
change the applications that are shown when you press
, select Top, Left, Middle, and Right and the
application.
Some shortcuts may be fixed, and you are not able to
change them.
Help
Your device has context-sensitive help. When an
application is open, select Options > Help to access help
for the current view.
When you are reading the instructions, to switch between
help and the application that is open in the background,
press and hold .
To open help from the main menu, select Tools > Help.
Select the desired application to view its help topics.
Tutorial
The tutorial gives you information about some of the
features of your device. To access the tutorial in the menu,
press , and select My own > Tutorial and the section
you want to view.
R1114_en.book Page 15 Tuesday, January 24, 2006 2:04 PM

Camera
16
FCC DRAFT
Camera
Your Nokia N71 has
To activate the camera, open the cover, press , and
select Camera. In the viewfinder, you can see the view to
be captured.
The images and video clips are automatically saved in the
Gallery. The camera produce .jpg images. Video clips are
recorded in the 3gpp file format with the .3gp file
extension or in the .mp4 file format (high video quality
mode). See ‘Video settings’, p. 23.
You can send images in a multimedia message as an
e-mail attachment, or by using Bluetooth connectivity.
Tip! You can insert an image into a contact card. See
‘Save names and numbers’, p. 54.
Your Nokia N71 supports an image capture resolution of
up to 1600x1200 pixels using the camera. The image
resolution in these materials may appear different.
Camera display
Camera indicators show the following:
• The device memory ( ) and memory card ( )
indicators (1) show where images are saved.
• The images indicator (2) estimates how many images,
depending on the selected image quality, can fit in the
remaining memory of your device or the memory card.
• The shooting mode indicator (3) shows the active
shooting mode. See ‘Shooting mode’, p. 17.
•Theflashindicator(4)
shows if the flash is set to
Automatic (),On (),
or Off ().
• The self-timer indicator
(5) shows that the
self-timer is activated. See
‘You in the picture—self-
timer’, p. 19.
• The sequence mode
indicator (6) shows that
the sequence mode is
active. See ‘Take time-lapse pictures’, p. 18.
Take pictures
If the camera is in video mode, open the image mode by
selecting Options > Image mode.
Graphic: Screenshot to
show position of the
indicators (to be
numbered).
R1114_en.book Page 16 Tuesday, January 24, 2006 2:04 PM

Camera
17
FCC DRAFT
To zoom in and out, press or . The zoom indicator,
which is displayed on the side of the viewfinder, shows the
zoom level. The quality (resolution) of a zoomed picture is
lower than that of a nonzoomed picture.
To take a picture, press . Do not move the device before
the image is saved. The image is saved automatically in the
Images & Video folder of Gallery. See ‘Gallery’, p. 25.
Saving the captured image may take longer if you change
the zoom, lighting, or color settings.
To select the shooting mode; flash, colour and lighting
settings; or view the Last image before taking a picture,
see ‘Camera setup’, p. 17.
After the image is taken, do any of the following:
• If you do not want to keep the image, select Options >
Delete, or press .
• To send the image Via multimedia, Via e-mail, or Via
Bluetooth, select Options > Send. For more
information, see ‘Messaging’, p. 35 and ‘Bluetooth
connectivity’, p. 70. This option is not available during
an active call.
• To edit the picture, select Options > Edit. See ‘Edit
images’, p. 20.
• To print the picture, select Options > Print. See ‘Image
print’, p. 29.
The camera goes into battery saving mode if you do not
make any key presses for a while. To continue taking
pictures, press
Camera setup
If the viewfinder is active, press or , or select
Options > Open setup.
Press or to choose
the item to be viewed or
adjusted, and press . The
settings available depend on
which camera is in use.
To reactivate the viewfinder,
press Cancel or .
The settings return to the default settings when you close
the Camera.
Shooting mode
The settings of each shooting mode have been set to
match a certain style or environment.
Graphic: Screenshot to
indicate the setup (lower)
part of the screen being
active.
R1114_en.book Page 17 Tuesday, January 24, 2006 2:04 PM

Camera
18
FCC DRAFT
The following shooting
modes are available:
Automatic, User defined,
Portrait, Landscape, Night,
and Sports.
Scroll to the appropriate
shooting mode for taking a
picture, and press .
When taking pictures, the
default shooting mode is
Automatic.
To make your own shooting mode suitable for a certain
environment, select User defined scene. In the user
defined scene you can adjust Based on mode, Flash,
White balance, and Colour tone, and Reset user scene
options. To copy the settings of another scene, select
Based on mode and the desired scene.
If you select the User defined shooting mode, it is set as
the default shooting mode.
Flash
The camera has an LED flashlight for low light conditions.
Keep a safe distance when using the flash. Do not use the
flash on people or animals at close range. Do not cover
the flash while taking a picture.
The following flash modes are available: Automatic, On,
and Off.
Scroll to the desired flash setting and press .
If the flash is set to Off or Automatic during bright
conditions, the flash still emits a low light when an image
is captured. This allows the subject of the picture to see
when the picture is taken. There is no flash effect on the
resultant picture.
White balance
Select the appropriate setting that matches the current
lighting conditions. This allows the camera to reproduce
colors more accurately.
Scroll to the desired setting and press .
Colour tone
Scroll to the desired color effect setting and press .
Last image
To view the last image taken, press .
Take time-lapse pictures
Select Options > Advance sequence to set the camera to
take several pictures in a sequence automatically. You can
set the rate between two frames per second (fast) and one
Graphic: Screenshot to
show landscape scene??
See Gromit.
R1114_en.book Page 18 Tuesday, January 24, 2006 2:04 PM

Camera
19
FCC DRAFT
frame every 15 minutes (slow). The number of pictures is
limited by the amount of memory available.
The pictures are automatically saved in Gallery.
You can also use the
sequence mode with the
Self-timer. See ‘You in the
picture—self-timer’, p. 19.
After taking the pictures, they
are shown in a grid on the
main display. To view a
picture, press to open it.
To return to the sequence
mode viewfinder, select Back.
You in the picture—self-timer
Use the self-timer to delay the taking of a picture so that
you can include yourself in the picture. To set the
self-timer delay, select Options > Self-timer > 10
seconds, 20 seconds or 30 seconds. To activate the
self-timer, select Activate. The self-timer indicator ( )
blinks and the device beeps when the timer is running. The
camera takes the picture after the selected delay has
elapsed. You can also use the Self-timer in the sequence
mode. See ‘Take time-lapse pictures’, p. 18.
Camera settings
To change the main camera settings, select Options >
Settings, and from the following:
Image quality—High 2M - Print (1600x1200 resolution),
Med 0.8M - Email (800x600 resolution) or Low 0.3M -
Multimedia (640x480 resolution). The better the image
quality, the more memory the image uses.
Add to album—Select whether you want to save the
image to a certain album in Gallery. If you select Yes, a list
of available albums opens.
Extended zoom—Select On if you want to achieve
maximum zoom but are prepared to accept a reduction in
image resolution, which may be lower than you have
selected with the Image quality setting. If you want to
limit the zoom range and have less reduction in resolution,
select Off.
Show captured image—Select On to see the captured
image after it is taken, or Off to continue taking pictures
immediately.
Capture tone—Select the tone you want to hear when you
take a picture.
Memory in use—Select where to store your images.
Graphic: Screenshot to
show a grid of pictures in
Gallery.
R1114_en.book Page 19 Tuesday, January 24, 2006 2:04 PM

Camera
20
FCC DRAFT
Edit images
To edit the picture you have just taken, select Options >
Edit. To edit other pictures, select them from Gallery.
Select Options > Apply effect to crop and rotate the
image; adjust the color, compression, and resolution; also,
to add effects, text, clip art, or a frame to the picture.
To manually crop an image, select Options > Apply
effect > Crop > Manual. A rectangle indicating the crop
area is displayed. Scroll to define the top left starting
point for the crop, and select Set. Scroll to the bottom
right of the area to be cropped, and select Crop.
To reduce redness of the eyes in an image, select
Options > Apply effect > Red eye reduction. Move the
cross onto the eye, and press . A loop appears on the
display. Scroll to resize the loop to fit the size of the eye.
Press to reduce the redness.
To add clip art to an image, select Options > Apply
effect > Clip art. Select the item you want to add from
the list, and press . To move, rotate, and change the
size of the item, select Options > Move, Resize, or Rotate.
To add text to an image, select Options > Apply effect >
Text. Enter the text, and select OK. To edit the text, select
Options > Move, Resize, Rotate, or Colour.
Shortcuts in the image editor:
• To view an image in full screen, press . To return to
the normal view, press again.
• To rotate an image clockwise or counterclockwise,
press. and .
• To zoom in or zoom out, press and .
Tips on taking good photographs
Picture quality
Use the appropriate picture quality. The camera has
three picture quality settings. Use High 2M - Print for
large prints up to 25x20 centimeters (10x8 inches), Med
0.8M - Email for e-mail and prints up to 15x10
centimeters (6x4 inches), or Low 0.3M - Multimedia for
use in a multimedia message. The better the image quality,
the more memory the image consumes. The quality of a
zoomed picture is lower than that of a nonzoomed picture.
To change the picture quality, select Options > Settings..
Background
Use a simple background—For portraits and other pictures
with people, avoid having your subject in front of a
cluttered, complex background that may distract attention
from the subject. Move the camera or the subject when
these conditions cannot be met. Move the camera closer to
the object to take clearer portraits.
R1114_en.book Page 20 Tuesday, January 24, 2006 2:04 PM
