Nokia RM-608 User manual

Nokia C1-01/C1–02 User Guide
9223500
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
2
Issue 1.

Contents
Safety 5
Support 7
Get started 8
Insert the SIM card
and battery 8
Keys and parts 9
Switch on or off 10
Charge the battery 10
Antennas 11
Headset 12
Insert a memory
card 13
Remove the microSD
card 14
Connect a USB data
cable 15
Attach the wrist
strap 16
Access codes 16
Keypad lock 18
Use your device
without a SIM card 18
Applications running
in background 19
Calls 19
Make and answer a
call 19
Loudspeaker 20
Dialing shortcuts 20
Write text 21
Text modes 21
Traditional text
input 22
Predictive text
input 22
Navigate the
menus 23
Messaging 24
Text and multimedia
messages 24
Flash messages 27
Nokia Xpress audio
messages 27
2 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Nokia Messaging
Service 28
Voice messages 28
Message settings 29
Contacts 30
Photos 31
Capture images and
record videos 31
View your images
and videos 33
Music 33
Music player 33
FM radio 35
Call log 36
Web or Internet 37
Connect to a web
service 38
Settings 38
Profiles 38
Tones 39
Display 39
Date and time 39
Shortcuts 40
Synchronization and
backup 40
Connectivity 41
Call and phone 44
Accessories 45
Configuration 45
Restore factory
settings 46
Applications 47
Alarm clock 47
Gallery 48
Extras 48
Voice recorder 49
To-do list 50
Operator menu 50
SIM services 50
Green tips 50
Save energy 51
Recycle 51
www.nokia.com/support 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Product and safety
information 52
Index 67
4 www.nokia.com/support
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Safety
Read these simple guidelines. Not following them
may be dangerous or illegal. Read the complete user
guide for further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when cellular phone
use is not allowed or when it may cause
interference or danger, for example, in
aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your
hands free to operate the vehicle while
driving. Your first consideration while
driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect
performance.
English 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

QUALIFIED SERVICE
Only qualified personnel may install or
repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it
dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level,
and do not hold the device near your ear
when the loudspeaker is in use.
6English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Support
When you want to learn more about how to use your
product or you are unsure how your device should
function, go to www.nokia.com/support, or using a
cellular phone, www.nokia.mobi/support.
If this does not resolve your issue, do one of the
following:
•Reboot your device. Switch off the device, and
remove the battery. After about a minute,
replace the battery, and switch on the device.
•Restore the original factory settings.
•Update your device software.
If your issue remains unsolved, contact Nokia for
repair options. Go to www.nokia.com/repair, or in
Latin America, www.nokia-latinoamerica.com/
centrosdeservicio. Before sending your device for
repair, always back up the data in your device.
English 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Get started
Insert the SIM card and battery
The SIM card and its contacts can be easily damaged
by scratches or bending, so be careful when
handling, inserting, or removing the card.
Important: Do not use a mini-UICC SIM card,
also known as a micro-SIM card, a micro-SIM card
with an adapter, or a SIM card that has a mini-UICC
cutout (see figure) in this device. A micro-SIM card is
smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of
incompatible SIM cards may damage the card or the
device, and may corrupt data stored on the card.
1 Place your finger in the recess at the bottom of
the device, and carefully lift and remove the
back cover (1).
8English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

2 If the battery is inserted, lift the battery out (2).
3 Insert the SIM card. Make sure the contact area
of the card is facing down (3, 4).
4 Line up the contacts of the battery and the
battery compartment, and insert the battery (5).
To replace the back cover, direct the top locking
catches toward their slots (6), and press down
until the cover locks into place (7).
Safe removal. Always switch the device off and
disconnect the charger before removing the battery.
Keys and parts
1Headset connector
(3.5 mm)
2Earpiece
3Display
4Selection keys
5Navi™ key (scroll
key)
6Call key
7End/Power key
English 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

8Keypad
9Charger connector
10 Micro USB
connector
11 Loudspeaker
12 Camera lens (Nokia
C1–01 only)
13 Microphone
Switch on or off
Press and hold the power key.
Charge the battery
Your battery has been partially charged at the
factory. If the device indicates a low charge, do the
following:
10 English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge,
disconnect the charger from the device, then
from the wall outlet.
You do not need to charge the battery for a specific
length of time, and you can use the device while it
charges. If the battery is completely without charge,
it may take several minutes before the charging
indicator appears on the display or before any calls
can be made.
Antennas
Your device may have internal and external
antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the
communication quality and may cause a higher
power level during operation and may reduce the
battery life.
English 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Headset
Warning:
When you use the headset, your ability to hear
outside sounds may be affected. Do not use the
headset where it can endanger your safety.
When connecting any external device or any
headset, other than those approved by Nokia for use
with this device, to the Nokia AV Connector, pay
special attention to volume levels.
Do not connect products that create an output signal
as this may cause damage to the device. Do not
connect any voltage source to the Nokia AV
Connector.
12 English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert a memory card
Use only compatible microSD cards approved by
Nokia for use with this device. Nokia uses approved
industry standards for memory cards, but some
brands may not be fully compatible with this device.
Incompatible cards may damage the card and the
device and corrupt data stored on the card.
Your phone supports microSD cards with a capacity
of up to 32 GB.
English 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

A compatible memory card may be supplied with the
device, and may already be inserted in the device. If
not, do the following:
1 Open the back cover.
2 Make sure the contact area of the card is facing
down. Push the card in, until you hear a click.
3 Replace the back cover.
Remove the microSD card
Important: Do not remove the memory card
during an operation when the card is being
accessed. Doing so may damage the memory card
and the device, and corrupt data stored on the card.
You can remove or replace the memory card during
phone operation without switching the device off,
but you need to ensure that no application is
currently accessing the memory card.
14 English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Connect a USB data cable
Connect a compatible USB data cable to the USB
connector. You may need to purchase a USB data
cable separately.
English 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

To modify the USB settings, select Menu >
Settings > Connectivity > USB data cable and the
desired mode.
Attach the wrist strap
Thread the wrist strap, and tighten it.
Nokia C1–01:
Nokia C1–02:
Access codes
The security code helps to protect your device
against unauthorized use. The preset code is 12345.
You can create and change the code, and set the
device to request the code. Keep the code secret and
16 English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

in a safe place separate from your device. If you
forget the code and your device is locked, your
device will require service. Additional charges may
apply, and all the personal data in your device may
be deleted. For more information, contact a Nokia
Care point or your device dealer.
The PIN code supplied with the SIM card protects the
card against unauthorised use. The PIN2 code
supplied with some SIM cards is required to access
certain services. If you enter the PIN or PIN2 code
incorrectly three times in succession, you are asked
for the PUK or PUK2 code. If you do not have them,
contact your service provider.
The module PIN is required to access the
information in the security module of your SIM card.
The signing PIN may be required for the digital
signature. The restriction password is required
when using the call restriction service.
To set how your device uses the access codes and
security settings, select Menu > Settings >
Security.
English 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Keypad lock
To prevent accidental keypresses, select Menu, and
press *within 3.5 seconds to lock the keypad.
To unlock the keypad, select Unlock, and press *
within 1.5 seconds. If the security keyguard is
activated, enter the security code when requested.
To set the keypad to lock automatically after a
defined length of time when the device is not being
used, select Menu > Settings > Phone >
Automatic keyguard > On.
To answer a call when the keypad is locked, press
the call key. When you end or reject a call, the keypad
locks automatically.
When the device or keypad is locked, calls may be
possible to the official emergency number
programmed into your device.
Use your device without a SIM card
Some features of your device may be used without
inserting a SIM card, such as games. Features that
are unavailable in the offline profile cannot be
selected in menus.
18 English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Applications running in background
Leaving applications running in the background
increases the demand on battery power and reduces
the battery life.
Applications that usually run in the background are,
for example, the Radio and Music player
applications.
Calls
Make and answer a call
Make a call
Enter the phone number, including the country and
area code if necessary, and press the call key.
Answer an incoming call
Press the call key.
Reject a call
Press the end key.
Adjust the volume
During a phone call, scroll up or down.
English 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Loudspeaker
If available, you may select Loudsp. or Normal to
use the loudspeaker or the earpiece of the phone
during a call.
Warning:
Continuous exposure to high volume may damage
your hearing. Listen to music at a moderate level,
and do not hold the device near your ear when the
loudspeaker is in use.
Dialing shortcuts
Assign a phone number to a number key
Select Menu > Contacts > More > 1-touch
dialing, scroll to a desired number (2-9), and select
Assign. Enter the desired phone number, or select
Search and a saved contact.
Activate speed dialling
Select Menu > Settings > Call > 1-touch
dialing > On.
20 English
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
