1. Insert the SIM and memory
card
1. Open the SIM card tray: push the tray opener pin
in the tray hole and slide the tray out.
2. If you have a single-SIM phone, put a nano-SIM
card in slot 1 and a memory card in slot 2 on the
tray with the contact areas face down. If you have a
dual-SIM phone, put a nano-SIM card in slot 1 and
either a second SIM or a memory card in slot 2 with
the contact areas face down.
Tip: To find out if your phone can use 2 SIM cards,
see the label on the sales box. If there are 2 IMEI
codes on the label, you have a dual-SIM phone.
3. Slide the tray back in.
Use only original nano-SIM cards. Use of incompati-
ble SIM cards may damage the card or the device,
and may corrupt data stored on the card.
Use only compatible memory cards approved for
use with this device. Incompatible cards may dam-
age the card and the device and corrupt data stored
on the card.
Important: Do not remove the memory card
when an app is using it. Doing so may damage the
memory card and the device and corrupt data
stored on the card.
Both SIM cards are available at the same time when
the device is not being used, but while one SIM card
is active, for example, making a call, the other may
be unavailable.
2. Charge the battery and switch
the phone on
Plug a compatible charger into a wall outlet, and
connect the cable to your phone. Your phone
supports the USB-C cable. You can also charge your
phone from a computer with a USB cable, but it may
take a longer time.
If the battery is completely discharged, it may take
several minutes before the charging indicator is
displayed.
Use only Qi-compatible chargers for wireless
charging.
To switch your phone on, press and hold the power
key until the phone vibrates. The phone guides you
through the setup.
For an online user guide and troubleshooting help,
go to www.nokia.com/mobile-support.
11385947 V1.0
Get Started
Nokia xx
TA-1371 EN-LATAM
3
2
4
7
5
910
11
1
6
8
12
13
14
15
16
17
18
*Google Assistant is not available in certain languages and countries. Where not available, Google
Assistant is replaced by Google Search. Check availability at https://support.google.com/assistant.
1. Sensors
2. NFC area/Wireless charging area
3. Flash
4. Camera
5. Google Assistant/Google Search key*
6. Microphone
7. Emergency key (programmable)
8. Front camera
9. Earpiece/Loudspeaker
10. Light sensor/Proximity sensor
11. SIM and memory card slot
12. Volume keys
13. Power/Lock key, Fingerprint sensor
14. USB connector
15. Strap connector
16. Headset connector
17. Microphone
18. Loudspeaker

Product and safety info
Important: For important info on the safe use of your device and
battery, read the Product and safety info booklet before you take
your device into use.
You can only use your device on the GSM 850, 900, 1800, 1900;
WCDMA 1, 2, 4, 5, 8; LTE:1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 20, 25, 26, 28,
30, 38, 40, 41, 48, 66, 71; 5G NR: n2, n5, n25, n38, n41, n48, n66,
n71, n77, n78 networks.
You need a subscription with a service provider.
Important: 5G might not be supported by your network service
provider or by the service provider you are using when traveling. To
make sure your device works seamlessly when full 5G service is not
available, it is recommended that you change the highest connection
speed from 5G to 4G. To do this, on the home screen, tap Settings >
Network & Internet > Mobile network > Advanced, and switch
Preferred network type to 4G.
For more info, contact your network service provider.
Wet or dusty conditions
This device has been given a rating of IP68 for dust and water
resistance based on tests done in standby mode under controlled
laboratory conditions. This resistance is not a permanent condition,
and may decrease as a result of normal wear.
Water resistance means resistance against cold, clean fresh water
only. Do not expose the device to any other type of liquid, (such as
sea water, soap water, pool water, detergent, acids or solvents,
perfume, adhesive remover, hair dye, lotions, sunscreen or oil). Do
not submerge the device in water. If the device has been exposed to
water, wipe it off with a dry cloth. If it has been exposed to any other
liquid, immediately splash some clean fresh water onto the device.
Carefully wipe the device dry. Do not charge the device or connect
anything if the connectors are dusty, wet, or damp.
Important: Liquid damage is not covered under warranty. To
prevent liquid damage, avoid swimming or bathing with the device,
exposing it to pressurized or high velocity water (such as when
showering, surfing or jet skiing), using the device in a sauna or steam
room, intentionally submerging the device in water, or using the
device outside the suggested temperature ranges or in high humidity
conditions.
Important: Accessories for use with this device are not as water-
resistant as the device itself. For example, chargers should only be
used in dry conditions, never when damp or wet.
Your device has an internal, non-removable, rechargeable battery.
Do not attempt to remove the battery or back cover, as you may
damage the device. To replace the battery, take the device to the
nearest authorised service facility.
Charge your device with the AD-18WE (EU plug) / AD-18WX (UK plug)
/ SACAD18TVL (US plug) / AD-18WA (Australia plug) chargers. HMD
Global may make additional battery or charger models available for
this device. When charger is not included in the sales box, use a USB
PD compatible 18W charger. Charging time can vary depending on
device capability. Some of the accessories mentioned in this user
guide, such as charger, headset, or data cable, may be sold
separately.
Electrical Information of the Charger
The following electrical information corresponds to the above-
mentioned charger models:
Input: 100-240 V, 50-60 Hz, 0,5A
Output: 5V, 3,0A
Charger safety instructions
The charger is suitable to be used only with compatible devices.
The charger should not be used in extremely high or low
temperatures.
Ventilation should not be obstructed by covering the charger with
magazines, blankets, curtains etc.
Open flames, such as candles, should not be placed above the
charger.
The charger and the wall outlet shall be easily accessible at all times.
In case the cable or the plugs are damaged, stop using them.
The charger requires very low maintenance. If you want to clean it,
use a dry cloth or a brush.
Meaning of the symbols:
For internal use only
The charger should not be disposed as unsorted municipal
waste. It should be recycled.
Use only Qi-compatible chargers for wireless charging.
The surface of the device is nickel-free.
Parts of the device are magnetic. Metallic materials may be attracted
to the device. Do not place credit cards or other magnetic stripe
cards near the device for extended periods of time, since the cards
may be damaged.
Note: Pre-installed system software and apps use a significant
part of memory space.
Keep a safe distance when using the flash. Do not use the flash on
people or animals at close range. Do not cover the flash while taking
a photo.
Certification information (SAR)
This mobile device meets guidelines for exposure to radio waves as
set forth by the Federal Communications Commission (FCC). Refer to
the following.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. The guidelines are based on
standards that were developed by independent scientific
organization through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed
to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1,6 W/kg. The tests are performed in
positions and locations (e.g. at the ear and worn on the body) as
required by the FCC for each model. The highest SAR value for this
handset model as reported to the FCC when tested for use at the ear
is 1,43 W/kg, and when worn on the body in a holder or carry case, is
0,96 W/kg.
Body-worn Operation; This device was tested for typical body-worn
operations with the handset kept 1,5 cm from the body. To maintain
compliance with FCC RF exposure requirements, use accessories that
maintain a 1,5 cm separation distance between the user’s body and
the handset. The use of belt clips, holsters and similar accessories
should not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply
with FCC RF exposure requirements, and should be avoided. The FCC
has granted an Equipment Authorization for this handset model with
all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this handset model is on file
with the FCC and can be found under the FCC ID Search section of
www.fcc.gov/oet/ea/ after searching on FCC ID 2AJOTTA-1371.
Additional information on Specific Absorption Rates (SAR) can be
found on the FCC website at www.fcc.gov/general/radio-frequency-
safety-0.
To send data or messages, a good connection to the network is
needed. Sending may be delayed until such a connection is available.
Follow the separation distance instructions until the sending is
finished.
During general use, the SAR values are usually well below the values
stated above. This is because, for purposes of system efficiency and
to minimise interference on the network, the operating power of your
mobile is automatically decreased when full power is not needed for
the call. The lower the power output, the lower the SAR value.
Device models may have different versions and more than one value.
Component and design changes may occur over time and some
changes could affect SAR values.
For more info, go to www.sar-tick.com. Note that mobile devices
may be transmitting even if you are not making a voice call.
Your mobile device is also designed to meet the United States
Federal Communications Commission (FCC) guidelines. FCC ratings
for your device and more information on SAR can be found at http:/
/transition.fcc.gov/oet/rfsafety/sar.html.
The World Health Organization (WHO) has stated that current
scientific information does not indicate the need for any special
precautions when using mobile devices. If you are interested in
reducing your exposure, they recommend you limit your usage or use
a hands-free kit to keep the device away from your head and body.
For more information and explanations and discussions on RF
exposure, go to the WHO website at www.who.int/peh-emf/en.
Copyrights and other notices
FCC notice:
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. For more info, go to www.fcc.gov/engineering-
technology/electromagnetic-compatibility-division/radio-
frequency-safety/faq/rf-safety. Any changes or modifications not
expressly approved by HMD Global could void the user’s authority to
operate this equipment. Note: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
HAC notice:
Your phone is compliant with the FCC Hearing Aid Compatibility
requirements.
The FCC has adopted HAC rules for digital wireless phones. These
rules require certain phones to be tested and rated under the
American National Standard Institute (ANSI) C63.19-2011 hearing aid
compatibility standards. The ANSI standard for hearing aid
compatibility contains two types of ratings:
• M-Ratings: Rating for less radio frequency interference to enable
acoustic coupling with hearing aids.
• T-Ratings: Rating for inductive coupling with hearing aids in
telecoil mode.
Not all phones have been rated. A phone is considered hearing aid
compatible under FCC rules if it is rated M3 or M4 for acoustic
coupling and T3 or T4 for inductive coupling. These ratings are given
on a scale from one to four, where four is the most compatible. Your
phone meets the M3/T3 level rating.
However, hearing aid compatibility ratings don't guarantee that
interference to your hearing aids won't happen. Results will vary,
depending on the level of immunity of your hearing device and the
degree of your hearing loss. If your hearing device happens to be
vulnerable to interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing device is the
best way to evaluate it for your personal needs.
This phone has been tested and rated for use with hearing aids for
some of the wireless technologies that it uses. However, there may
be some newer wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is important to try the
different features of this phone thoroughly and in different
locations, using your hearing aid or cochlear implant, to determine if
you hear any interfering noise. Consult your service provider or the
manufacturer of this phone for information on hearing aid
compatibility. If you have questions about return or exchange
policies, consult your service provider or phone retailer.
Hearing devices may also be rated. Your hearing device manufacturer
or hearing health professional may help you find this rating. For more
information about FCC Hearing Aid Compatibility, please go to http:/
/www.fcc.gov/cgb/dro.
This device has an electronic label for certification information. To
access it, select Settings > System > Certification.
© 2021 HMD Global. HMD Global Oy is the exclusive licensee of the
Nokia brand for phones & tablets. Nokia is a registered trademark of
Nokia Corporation.
Qualcomm Snapdragon is a product of Qualcomm Technologies, Inc.
and/or its subsidiaries. Qualcomm and Snapdragon are trademarks
or registered trademarks of Qualcomm Incorporated. Qualcomm
aptX is a product of Qualcomm Technologies, Inc. and/or its
subsidiaries. Qualcomm is a trademark or registered trademark of
Qualcomm Incorporated. aptX is a trademark or registered
trademark of Qualcomm Technologies International, Ltd.
Android, Google and other related marks and logos are trademarks of
Google LLC.
The 'Qi' symbol is a trademark of the Wireless Power Consortium.
ZEISS and the ZEISS logo are registered trademarks of Carl Zeiss AG
used under license of Carl Zeiss Vision GmbH.
OZO is a trademark of Nokia Technologies Oy.
