Nokia X7 User manual

Nokia X7–00 User Guide
Issue 1.0

Contents
Safety 5
Get started 6
Keys and parts 6
Antenna locations 8
Headset 8
Change the volume of a call, song, or
video 9
Lock or unlock the keys and screen 9
Insert or remove the SIM card 10
Insert or remove the memory card 11
Charging 13
Switch the device on or off 15
Use your device for the first time 16
Copy contacts or pictures from your old
device 16
Nokia account and Nokia's Ovi
services 17
Device set-up 18
Use the in-device user guide 18
Install Nokia Ovi Suite on your PC 18
Basic use 19
Touch screen actions 19
Interactive home screen elements 22
Switch between open applications 23
Write text 24
Display indicators 27
Search in your device and on the
internet 28
Use your device offline 28
Prolong battery life 29
Personalisation 30
Profiles 30
Change your theme 32
Home screen 32
Organise your applications 35
Download a game, application, or
other item 35
Telephone 36
Call a phone number 36
Search for a contact 36
Call a contact 37
Make a conference call 37
Call the numbers you use the most 38
Use your voice to call a contact 39
Make calls over the internet 40
Call the last dialled number 40
Record a phone conversation 41
Turn to silence 41
View your missed calls 41
Call your voice mailbox 42
Divert calls to your voice mailbox or
another phone number 42
Prevent making or receiving calls 42
Allow calls only to certain numbers 43
Video sharing 44
Contacts 45
About Contacts 45
Save phone numbers and mail
addresses 46
Save a number from a received call or
message 46
Contact your most important people
quickly 46
Add a picture for a contact 47
Set a ringing tone for a specific
contact 47
Send your contact information using
My Card 48
Create a contact group 48
Send a message to a group of people 48
Copy contacts from the SIM card to your
device 48
Back up your contacts to Ovi by Nokia 49
Messaging 49
2Contents

About Messaging 49
Send a message 49
Send an audio message 50
Receive messages 50
View a conversation 51
Listen to a text message 52
Change language 52
Mail 53
Mail 53
Internet 56
About the web browser 56
Browse the web 56
Add a bookmark 57
Subscribe to a web feed 57
Access your company intranet 57
Social networks 58
About Social 58
See your friends' status updates in one
view 58
Post your status to social networking
services 59
Link your online friends to their
contact information 59
See your friends' status updates on the
home screen 59
Upload a picture or video to a service 59
Contact a friend from a social
networking service 60
Add an event to your device calendar 60
Camera 61
About Camera 61
Take a picture 61
Save location information to your
pictures and videos 61
Take a picture in the dark 62
Picture tips 62
Record a video 62
Send a picture or video 63
Your pictures and videos 64
About My Videos and My Images 64
View pictures and videos 64
Edit the pictures you have taken 65
Video editor 65
Print a picture you have taken 66
Videos 66
About Videos 66
Play a video 67
Copy your videos between your device
and computer 67
Music and audio 67
Music player 67
About Ovi Music 70
Protected content 70
Record sounds 70
FM radio 71
Maps 73
Navigate to a destination 73
My position 73
Search 77
Favourites 78
Drive and Walk 80
Give feedback on Maps 85
Report incorrect map information 85
Time management 85
Clock 85
Calendar 87
Office 91
Quickoffice 91
Read PDF documents 91
Make a calculation 92
Write notes 92
Translate words from one language to
another 92
Open or create zip files 93
Access your company intranet 93
Contents 3

Connectivity 93
Internet connections 93
Wireless LAN 94
Bluetooth 95
USB data cable 98
VPN connections 100
Close a network connection 100
Store your files on a remote drive 101
Device management 102
Keep your device software and
applications up to date 102
Manage files 103
Increase available memory for more
content 104
Manage applications 105
Synchronise content 106
Copy contacts or pictures between
devices 107
Protect your device 108
Find more help 109
Support 109
Access codes 109
Troubleshooting 110
If your device stops responding 110
Restore original settings 110
If the device memory is full 111
If the message indicator is blinking 111
If a contact appears twice in the
contacts list 111
Unreadable characters while browsing
the web 111
Prepare your device for recycling 112
Nokia original accessories 112
Practical rules about accessories 112
Battery 112
Product and safety information 113
Index 119
4Contents

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The front cover of the device is made of glass. This glass can break if the device
is dropped on a hard surface or receives a substantial impact. If the glass
breaks, do not touch the glass parts of the device or attempt to remove the
broken glass from the device. Stop using the device until the glass is replaced
by qualified service personnel.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near your
ear when the loudspeaker is in use.
Safety 5

Get started
Keys and parts
Top
1Micro-USB connector
2Nokia AV connector (3.5 mm)
3Power/Unlock/Lock key
Front
1Earpiece
2Menu key
6Getstarted

Back
1Camera flash
2Microphones
3Camera lens
Sides
1Memory card slot
2SIM card slot
3Volume/Zoom key
4Camera key
5Loudspeaker
Get started 7

Bottom
1Microphone
Antenna locations
Avoid touching the antenna area unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the communication quality and may cause a
higher power level during operation and may reduce the battery life.
Headset
You can connect a compatible headset or compatible headphones to your device.
8Getstarted

Change the volume of a call, song, or video
Use the volume keys.
You can adjust the volume during a call or when an application is active.
The built-in loudspeaker allows you to speak and listen from a short distance without
having to hold the device to your ear.
Activate or deactivate the loudspeaker during a call
Select or .
Lock or unlock the keys and screen
To avoid accidentally making a call when your device is in your pocket or bag, lock the
keys and screen of your device.
Lock the keys and screen
Press the power key .
Unlock the keys and screen
Press the power key or the menu key, and select Unlock.
Get started 9

Set the keys and screen autolock delay
1 Select Menu > Settings and Phone > Display > Screen/keylock time-out.
2 Define how long your device waits before the screen and keys lock automatically.
Insert or remove the SIM card
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a
micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may damage
the card or the device, and may corrupt data stored on the card.
Do not attach any stickers to your SIM card.
Insert the SIM card
1 Press open the cover of the SIM card slot.
2 Pull out the SIM card holder.
3 Make sure the contact area is facing up, and place the SIM card in the holder.
4 Insert the SIM card holder back into the device.
10 Get started

Remove the SIM card
1 Press open the cover of the SIM card slot.
2 Pull out the SIM card holder.
3 Remove the SIM card.
Insert or remove the memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on the
card.
Do not attach any stickers to your memory card.
Insert the memory card
1 Press open the cover of the memory card slot.
2 Pull out the memory card holder.
Get started 11

3 Make sure the contact area is facing up, and insert the memory card into the holder.
4 Insert the memory card holder back into the device.
Remove the memory card
1 If your device is switched on, first press and hold the power key, and select Remove
memory card.
2 Press open the cover of the memory card slot.
3 Pull out the memory card holder.
4 Remove the memory card.
12 Get started

Charging
About the battery
Your device has an internal, nonremovable, CTIA 1725-certified rechargeable battery.
Use only Nokia approved chargers designated for this device. You can also use a
compatible USB data cable to charge your device.
Do not attempt to remove the battery from the device. Take the device to the nearest
authorised service facility for replacement of the battery.
You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly, and
it may take a long time for charging to start and the device to start functioning.
Only connect your device to products that have a USB-IF logo or have completed the
USB-IF compliance program.
Authorised retail points may also offer a battery replacement service.
When your device is low on power, it goes into power save mode. To deactivate power
save mode, press and hold the power key, and select Deactivate power saving. When
power save mode is activated, you may not be able to modify the settings of certain
applications.
Get started 13

Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it
before you can switch on your device for the first time.
If the device indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging.
If the battery is completely discharged, it may take several minutes before the charging
indicator appears on the display or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Tip: You can also use a compatible USB charger to charge your battery.
14 Get started

Charge the battery over USB
Battery low, but you don't have a charger with you? You can use a compatible USB cable
to connect to a compatible device, such as a computer.
To avoid breaking the charger connector, be careful when connecting or disconnecting
the charger cable.
If connected to a computer, you can synchronise your device while charging.
Charging over USB can take longer to start, and may not work if you connect through a
non-powered USB hub. Your device charges more quickly when connected to a wall
outlet.
Switch the device on or off
Switch on
Press and hold the power key until the device vibrates.
Switch off
Press and hold the power key , and select Switch off!.
Get started 15

Use your device for the first time
Your device guides you through the initial setup when you insert your SIM card and
switch your device on for the first time. To use all of Nokia's Ovi services, create a Nokia
account. You can also copy your contacts and other content from your previous device,
and subscribe to receive helpful tips and tricks.
To create a Nokia account, you need an internet connection. For information about data
transmission charges, contact your service provider. If you can't connect to the internet,
you can create an account later.
Tip: To create and manage your Nokia account on the internet, go to www.ovi.com.
If you already have a Nokia account, sign in.
Tip: Forgotten your password? You can request it to be sent to you in a mail or text
message.
Use the Phone switch application to copy your content, such as:
•Contacts
•Messages
•Pictures and videos
•Personal settings
When you set up your mail account, you can set your inbox to be displayed on your
home screen, so you can easily check your mail.
If you need to make an emergency call during the setup phase, press the menu key.
Copy contacts or pictures from your old device
Want to copy important information from your previous compatible Nokia device and
start using your new device quickly? Use the Phone switch application to copy, for
example, contacts, calendar entries, and pictures to your new device, free of charge.
Select Menu > Applications > Tools > Phone setup and Data transfer.
16 Get started

If your old Nokia device does not have the Phone switch application, your new device
sends it in a message. Open the message in the old device, and follow the instructions.
1 Select the device you want to connect to, and pair the devices. Bluetooth needs to
be activated.
2 If the other device requires a passcode, enter the passcode. The passcode, which
you can define yourself, must be entered in both devices. The passcode in some
devices is fixed. For details, see the user guide of the device.
The passcode is valid only for the current connection.
3 Select the content and OK.
Nokia account and Nokia's Ovi services
When you switch on your device for the first time, you are prompted to create or sign
in to a Nokia account, so you can access Nokia's Ovi services.
With Ovi services, you can:
•See your friends' statuses in different social networking services
•Download games, applications, videos, pictures, themes, and ringtones from Ovi
Store
•Get to where you want to go with free walk and drive navigation
•Back up and manage your contacts in the Ovi internet service
To learn more about Ovi services, go to www.ovi.com.
Get started 17

Device set-up
To define some basic settings for your device, select Menu > Applications > Tools >
Phone setup. With the Phone set-up widget, you can do the following:
•Copy contacts, pictures, and other content from your previous Nokia device
•Personalise your device by changing the ringtone and visual theme
•Set up mail
•Update your device software
Use the in-device user guide
Select Menu > Applications > User guide.
Open the user guide from an application
Select Options > User guide. This is not available for every application.
Search the user guide
When the user guide is open, select Options > Search, and enter a letter or a word in
the search field.
Switch between the user guide and an application
Press and hold the menu key, swipe left or right, and select the desired application.
indicates a link to a web page. Links to related topics may be at the end of
instructions.
Install Nokia Ovi Suite on your PC
With the Nokia Ovi Suite PC application, you can manage content on your device, and
keep it in sync with your computer. You can also update your device with the latest
software, and download maps.
Download the latest version of Nokia Ovi Suite from www.ovi.com/suite to your
computer.
If your computer can't connect to the internet, to install Nokia Ovi Suite from your device
memory:
1 Use a compatible USB data cable to connect your device to your computer.
If you are using Windows XP or Windows Vista on your computer, set the USB mode
of your device to Mass storage. To set the USB mode on your device, select the
notification area in the top right corner, and select > USB > Mass storage.
Your memory card appears as a removable disk on your PC.
18 Install Nokia Ovi Suite on your PC

2 On your computer, select Install Nokia Ovi Suite.
If the installation window does not open automatically, open the installation file
manually. Select Open folder to view files, and double-click
Install_Nokia_Ovi_Suite.exe.
3 Follow the displayed instructions.
4 When the installation is complete, if you are using Windows XP or Windows Vista
on your computer, check that the USB mode of your device is set to Nokia Ovi
Suite.
To learn more about Nokia Ovi Suite, go to www.ovi.com/suite.
To check which operating systems Nokia Ovi Suite supports, go to www.nokia.com/
support.
Basic use
Touch screen actions
To interact with the user interface, tap or tap and hold the touch screen.
Basic use 19

Open an application or other screen element
Tap the application or element.
Access functions quickly
Tap and hold the item. A pop-up menu with available options opens. For example, to
send an image or delete an alarm, tap and hold the image or alarm, and from the pop-
up menu, select the appropriate option.
If you tap and hold the home screen, editing mode is activated.
20 Basic use
