Nokia BH-106 Black User manual

Copyright ©2009 Nokia. All rights reserved.
Nokia Bluetooth Headset BH-106
8
9
2
1
4
5
6
7
3

2 Copyright ©2009 Nokia. All rights reserved.
DECLARATION OF
CONFORMITY
Hereby, NOKIA
CORPORATION declares
that this BH-106 product
is in compliance with the
essential requirements and
other relevant provisions of
Directive 1999/5/EC. A copy
of the Declaration of
Conformity can be found at
http://www.nokia.com/
phones/
declaration_of_conformity/.
© 2009 Nokia. All rights
reserved.
Nokia, Nokia Connecting
People and the Nokia
Original Accessories logo
are trademarks or registered
trademarks of Nokia
Corporation. Nokia tune
is a sound mark of Nokia
Corporation. Other product
and company names
mentioned herein may be
trademarks or tradenames
of their respective owners.
Reproduction, transfer,
distribution, or storage of
part or all of the contents in
this document in any form
without the prior written
permission of Nokia is
prohibited.

Copyright ©2009 Nokia. All rights reserved. 3
Bluetooth is a registered
trademark of Bluetooth
SIG, Inc.
Nokia operates a policy
of ongoing development.
Nokia reserves the right
to make changes and
improvements to any of the
products described in this
document without prior
notice.
To the maximum extent
permitted by applicable law,
under no circumstances
shall Nokia or any of its
licensors be responsible for
any loss of data or income
or any special, incidental,
consequential or indirect
damages howsoever caused.
The contents of this
document are provided
"as is". Except as required
by applicable law, no
warranties of any kind,
either express or implied,
including, but not limited
to, the implied warranties
of merchantability and
fitness for a particular
purpose, are made in relation
to the accuracy, reliability
or contents of this
document. Nokia reserves
the right to revise this
document or withdraw it
at any time without prior
notice.

4 Copyright ©2009 Nokia. All rights reserved.
The availability of particular
products may vary by region.
Please check with your
Nokia dealer for details.
Export Controls
This device may contain
commodities, technology or
software subject to export
laws and regulations from
the US and other countries.
Diversion contrary to law is
prohibited.
Introduction
With the Nokia Bluetooth
Headset BH-106, you can
make and receive calls while
on the move.
Read this user guide carefully
before using the headset.
Also, read the user guide for
the mobile device that you
connect to the headset.
This product may contain
small parts. Keep them out
of the reach of small children.
The surface of this device is
nickel-free.

Copyright ©2009 Nokia. All rights reserved. 5
Bluetooth wireless
technology
Bluetooth wireless
technology allows you to
connect compatible devices
without cables. The headset
and the other device do not
need to be in line of sight,
but they should be within
10 metres (33 feet) of each
other. Connections may be
subject to interference from
obstructions, such as walls,
or other electronic devices.
The headset is compliant
with Bluetooth Specification
2.1 + EDR supporting the
Headset Profile 1.1 and
Hands-Free Profile 1.5. Check
with the manufacturers of
other devices to determine
their compatibility with
this device.
Get started
The headset contains the
following parts shown on
the title page: earpiece (1),
microphone (2), answer/end
key (3), charger connector
(4), plug for fixing the
earpiece cable (5), power key
(6), and indicator light (7).

6 Copyright ©2009 Nokia. All rights reserved.
Before using the headset,
you must charge the battery
and pair the headset with a
compatible device.
Parts of the device are
magnetic. Metallic materials
may be attracted to the
device. Do not place credit
cards or other magnetic
storage media near the
device, because information
stored on them may be
erased.
Charge the battery
Before charging the battery,
carefully read “Battery and
charger information”.
Warning: Use only
chargers approved
by Nokia for use
with this particular model.
The use of any other types
may invalidate any approval
or warranty, and may be
dangerous.
When you disconnect the
power cord of any accessory,
grasp and pull the plug, not
the cord.
1. Connect the charger to a
wall outlet.
2. Connect the charger cable
to the charger connector.
The red indicator light is
displayed during charging.

Copyright ©2009 Nokia. All rights reserved. 7
Charging the battery fully
may take up to 2 hours.
3. When the battery is fully
charged, the green
indicator light is displayed.
Disconnect the charger
from the headset, then
from the wall outlet.
The fully charged battery
has power for up to 5 hours
and 30 minutes of talk time
or up to 120 hours of standby
time.
To check the battery charge
when the headset is not
connected to a charger,
press the power key. If the
indicator light is green, the
charge level is sufficient. If
the light is yellow, you may
need to recharge the battery
soon. If the light is red,
recharge the battery.
When the battery charge is
low, the headset beeps every
5 minutes and the red
indicator light flashes.
Switch on or off
To switch on, press and hold
the power key for about
2 seconds. The headset beeps,
and the green indicator light
is displayed. The headset tries
to connect to the last
connected device.

8 Copyright ©2009 Nokia. All rights reserved.
To switch off, press and hold
the power key for about
2 seconds when the headset
is on. The headset beeps,
and the red indicator light
is briefly displayed. If the
headset is not connected
to a device within about
30 minutes, it switches off
automatically.
Pair and connect the
headset
1. Ensure that your mobile
device is switched on and
the headset is off.
2. Press and hold the power
key (for about 5 seconds)
until the green indicator
light starts to flash quickly.
3. Within about 3 minutes,
activate Bluetooth
connectivity on your
device, and set it to
search for Bluetooth
devices.
4. Select the headset from
the list of found devices.
5. If necessary, enter the
passcode 0000 to pair
and connect the headset
to your device. In some
devices, you may need to
make the connection
separately after pairing.

Copyright ©2009 Nokia. All rights reserved. 9
When the headset is
connected to your device
and is ready for use, the
green indicator light flashes
about every 5 seconds.
Basic use
Wear the headset
Use the clip to attach the
headset to your clothing (8).
To use the headset for
calling, gently push the
earpiece into your ear.
To have the earpiece within
easy reach when you do not
use the headset, insert the
plug that is attached to the
earpiece cable into the
charger connector (9).
Calls
To make a call, use your
mobile device in the normal
way when the headset is
connected to it.
To redial the number you
last called (if your device
supports this feature with
the headset), when no call
is in progress, press the
answer/end key twice.

10 Copyright ©2009 Nokia. All rights reserved.
To activate voice dialling
(if your device supports this
feature with the headset),
when no call is in progress,
press and hold the answer/
end key for about 2 seconds.
Proceed as described in the
user guide of your device.
To answer or end a call,
press the answer/end key.
To reject a call, press this
key twice.
To switch a call from the
headset to a compatible
device, press and hold the
answer/end key for about
2 seconds, or switch off the
headset. To switch the call
back to the headset, press
and hold the answer/end
key for about 2 seconds, or
switch on the headset.
Turn lights on or off
By default, the indicator
lights are on in all situations.
To turn the lights off in some
situations (for example,
during a call or when the
headset is connected to a
device) or back on, press
and hold the power key and
the answer/end key for
about 2 seconds when the
headset is connected to a
device.

Copyright ©2009 Nokia. All rights reserved. 11
Clear settings or reset
To delete the pairings from
the headset when it is
switched off, press and hold
the power key and the
answer/end key (for about
5 seconds) until the red and
green indicator lights start
to alternate.
To reset the headset if it
stops functioning, even
though it is charged,
connect the headset to a
charger while you press and
hold the power key.
Troubleshooting
If you cannot connect the
headset to your compatible
device, check that the
headset is charged, switched
on, and paired with your
device.
Battery and charger information
This device has an internal,
nonremovable,rechargeable
battery. Do not attempt to
remove the battery from
the device as you may
damage the device. This
device is intended for use
when supplied with power

12 Copyright ©2009 Nokia. All rights reserved.
from the following chargers:
AC-3C, AC-4C, AC-5C,
AC-8C+CA-100C, and DC-4.
The battery can be charged
and discharged hundreds of
times, but it will eventually
wear out. Recharge your
battery only with Nokia
approved chargers
designated for this device.
Use of an unapproved
charger may present a risk
of fire, explosion, leakage,
or other hazard.
If a battery is being used for
the first time or if the battery
has not been used for a
prolonged period, it may be
necessary to connect the
charger, then disconnect
and reconnect it to begin
charging the battery. If the
battery is completely
discharged, it may take
several minutes before the
charging indicator light is
displayed.
Unplug the charger from
the electrical plug and the
device when not in use. Do
not leave a fully charged
battery connected to a
charger, since overcharging
may shorten its lifetime. If
left unused, a fully charged
battery will lose its charge
over time.

Copyright ©2009 Nokia. All rights reserved. 13
Always try to keep the
battery between 15°C and
25°C (59°F and 77°F).
Extreme temperatures
reduce the capacity and
lifetime of the battery. A
device with a hot or cold
battery may not work
temporarily. Battery
performance is particularly
limited in temperatures
well below freezing.
Do not dispose of batteries
in a fire as they may
explode. Batteries may also
explode if damaged.
Never use any charger that
is damaged.
Important: Battery
talk and standby
times are estimates
only and depend on network
conditions, features used,
battery age and condition,
temperatures to which
battery is exposed, and
many other factors. The
amount of time a device is
used for calls will affect its
standby time. Likewise, the
amount of time that the
device is turned on and in
the standby mode will
affect its talk time.

14 Copyright ©2009 Nokia. All rights reserved.
Care and maintenance
Your device is a product of
superior design and
craftsmanship and should
be treated with care. The
following suggestions will
help you protect your
warranty coverage.
• Keep the device dry.
Precipitation, humidity,
and all types of liquids or
moisture can contain
minerals that will corrode
electronic circuits. If your
device does get wet, allow
it to dry completely.
• Do not use or store the
device in dusty, dirty areas.
Its moving parts and
electronic components
can be damaged.
• Do not store the device in
hot areas. High
temperatures can shorten
the life of electronic
devices, damage batteries,
and warp or melt certain
plastics.
• Do not store the device in
cold areas. When the
device returns to its
normal temperature,
moisture can form inside
the device and damage
electronic circuit boards.

Copyright ©2009 Nokia. All rights reserved. 15
• Do not attempt to open
the device.
• Do not drop, knock, or
shake the device. Rough
handling can break
internal circuit boards
and fine mechanics.
• Do not use harsh
chemicals, cleaning
solvents, or strong
detergents to clean the
device.
• Do not paint the device.
Paint can clog the moving
parts and prevent proper
operation.
These suggestions apply
equally to your device,
charger, or any accessory.
If any device is not working
properly, take it to the
nearest authorised service
facility for service.
Recycle
The crossed-out
wheeled-bin symbol
on your product, battery,
literature, or packaging
reminds you that all
electrical and electronic
products, batteries, and
accumulators must be
taken to separate collection
at the end of their working

16 Copyright ©2009 Nokia. All rights reserved.
life. This requirement applies
in the European Union. Do
not dispose of these products
as unsorted municipal waste.
For more environmental
information, see the product
Eco-Declarations at
www.nokia.com/environment.
Always return your used
electronic products,
batteries, and packaging
materials to a dedicated
collection point. This way
you help prevent
uncontrolled waste disposal
and promote the recycling
of materials. More detailed
information is available
from the product retailer,
local waste authorities,
national producer
responsibility organisations,
or your local Nokia
representative. Check how
to recycle your Nokia
products at
www.nokia.com/werecycle,
or if browsing on a mobile
device, www.nokia.mobi/
werecycle.
