Nokia BH-505 User manual

Nokia Bluetooth Stereo Headset
BH-505
Issue 3.0
1
2
3
4
67
8
9
5

11
10

ENGLISH
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this BH-505 product is in compliance with
the essential requirements and other
relevant provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2009-2011 Nokia. All rights reserved.
Nokia, Nokia Connecting People and the
Nokia Original Accessories logo are
trademarks or registered trademarks of
Nokia Corporation. Nokia tune is a sound
mark of Nokia Corporation. Other product
and company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in this
document in any form without the prior
written permission of Nokia is prohibited.
Nokia operates a policy of continuous
development. Nokia reserves the right to
make changes and improvements to any of
the products described in this document
without prior notice.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
To the maximum extent permitted by
applicable law, under no circumstances shall
Nokia or any of its licensors be responsible
for any loss of data or income or any special,
incidental, consequential or indirect
damages howsoever caused.
The contents of this document are provided
"as is". Except as required by applicable law,
no warranties of any kind, either express or
implied, including, but not limited to, the
implied warranties of merchantability and
fitness for a particular purpose, are made in
relation to the accuracy, reliability or
contents of this document. Nokia reserves
the right to revise this document or
withdraw it at any time without prior notice.
The availability of particular products may
vary by region. Please check with your Nokia
dealer for details. This device may contain
commodities, technology or software
subject to export laws and regulations from
the US and other countries. Diversion
contrary to law is prohibited.

ENGLISH
Introduction
With the Nokia Bluetooth Stereo
Headset BH-505, you can make and
answer calls hands-free with your
compatible mobile device. You can
also listen to music from a compatible
music player.
Read this user guide carefully before
using the headset. Also, read the user
guide for the device that you connect
to the headset.
This product may contain small parts.
Keep them out of the reach of small
children.
Note: The surface of this
device does not contain
nickel in the platings. The
surface of this device
contains stainless steel.
Bluetooth wireless technology
Bluetooth wireless technology allows
you to connect compatible devices
without cables. The headset and the
other device do not need to be in line
of sight, but they should be within 10
metres (33 feet) of each other.
Connections may be subject to
interference from obstructions, such
as walls, or other electronic devices.
The headset is compliant with the
Bluetooth Specification 2.1 + EDR
supporting the following profiles:
Headset Profile 1.1, Hands-Free
Profile (HFP) 1.5, Advanced Audio
Distribution Profile (A2DP) 1.2, and
Audio Video Remote Control Profile
1.0. Check with the manufacturers of
other devices to determine their
compatibility with this device.

ENGLISH
Get started
The headset contains the following
parts shown on the title page:
indicator light (1), cover of the
charger connector (2), power key (3),
answer/end key (4), earplugs (5),
volume key (6), rewind/fast-forward
key (7), microphone (8), and play/
pause key (9).
Before using the headset, you must
charge the battery and pair the
headset with a compatible device.
Parts of the device are magnetic.
Metallic materials may be attracted to
the device. Do not place credit cards
or other magnetic storage media near
the device, because information
stored on them may be erased.
Charge the battery
Before charging the battery, carefully
read “Battery and charger
information”.
Warning: Use only chargers
approved by Nokia for use
with this particular model.
The use of any other types
may invalidate any approval
or warranty, and may be
dangerous. Use of
unapproved chargers may
present a risk of fire,
explosion, or other hazard.
When you disconnect the
power cord of any accessory, grasp
and pull the plug, not the cord.
1. Connect the charger to a wall
outlet.
2. Lift the cover of the charger
connector from the edge, and
connect the charger cable to the
connector. The red indicator light is
displayed during charging.
Charging the battery fully may take
up to 2 hours.

ENGLISH
3. When the battery is fully charged,
the green indicator light is
displayed. Disconnect the charger
from the headset, then from the
wall outlet. Press the cover on the
charger connector.
The fully charged battery has power
for up to 12 hours of talk time, up to
375 hours of standby time, or up to 10
hours of music playing time.
To check the battery charge when the
headset is not connected to a charger,
press the power key when the headset
is connected to a mobile device. If the
indicator light is green, the charge
level is sufficient. If the light is yellow,
you may need to recharge the battery
soon. If the light is red, recharge the
battery.
When the battery charge is low, the
headset beeps every 5 minutes and
the red indicator light flashes.
Switch on or off
To switch on, press and hold the power
key for about 5 seconds. The headset
beeps, and the green indicator light
flashes slowly while the headset tries
to connect to a last used device that
supports the HFP Bluetooth profile.
When the headset is connected to a
device and is ready for use, the blue
indicator light flashes slowly. If the
headset has not been paired with a
device, it automatically enters pairing
mode.
To switch off, press and hold the
power key for about 2 seconds. The
headset beeps, and the red indicator
light is briefly displayed. If the headset
is not connected to a device within
about 30 minutes, it switches off
automatically.

ENGLISH
Pair and connect the headset
Before using the headset, you must
pair and connect it to a compatible
device.
If your mobile device supports the
A2DP Bluetooth profile and has a
music player feature, you can use the
device to also play music through the
headset.
If your mobile device does not support
the A2DP profile, you can separately
pair the headset with the mobile
device and a music player that
supports this profile. If you have
paired and connected the headset to
your mobile device, disconnect the
headset from it before pairing the
headset with the music player.
To pair and connect the headset to
your device if the device supports the
Near Field Communication (NFC)
feature, activate the feature, and use
your device to touch the area shown
in figure 10 at the start of this guide.
For details on NFC, see the user guide
of your device.
To pair and connect the headset to
your device if the device does not
support NFC:
1. Ensure that your mobile device or
music player is switched on and
the headset is off.
2. If the headset has not been
previously paired with a device,
switch on the headset. The headset
enters pairing mode, and the blue
indicator light starts to flash
quickly.
If the headset has been previously
paired with a device, ensure that
the headset is switched off, and
press and hold the power key (for
about 8 seconds) until the blue
indicator light starts to flash
quickly.

ENGLISH
3. Within about 3 minutes, activate
the Bluetooth feature on your
device, and set it to search for
Bluetooth devices. For details, see
the user guide of your device.
4. Select the headset from the list of
found devices.
5. If necessary, enter the passcode
0000 to pair and connect the
headset to your device. If your
device does not have a keypad, it
may use this passcode by default.
In some devices, you may need to
make the connection separately
after pairing.
When the headset is connected to
your device and is ready for use, the
blue indicator light flashes slowly.
You can pair the headset with up to
eight devices but connect it to only
one device supporting the HFP profile
and another device supporting the
A2DP profile at a time.
To manually connect the headset to a
last used device that supports the HFP
profile (for example, after connection
loss), switch the headset off and on, or
press and hold the answer/end key for
about 2 seconds. To manually connect
the headset to a last used device that
supports the A2DP profile, press the
play/pause key.
You may be able to set your device so
that the headset connects to it
automatically. To activate this feature
in a Nokia device, change the paired
device settings in the Bluetooth menu.

ENGLISH
Basic use
Change the earplugs
The headset may be provided with
different sized earplugs and earpads.
Select the earplugs or earpads that fit
the best and are the most comfortable
for your ears.
To change the current earplugs, pull
them from the earpieces, and push the
new earplugs or earpads into place.
Wear the headset
Place the headset behind your head so
that the speaker pads rest comfortably
on your ears (11).
Place the speaker pad that has the
play/pause key on the left ear and the
pad that has the answer/end key on
the right ear.
Gently insert the earplugs into your
ears.
Warning: When you use the
headset, your ability to hear
outside sounds may be
affected. Do not use the
headset where it can
endanger your safety.
Adjust the volume
To adjust the headset volume, slide
the volume key up or down when the
headset is connected to a device. To
adjust the volume quickly, slide and
hold the key.
You can also adjust the headset
volume on the connected A2DP device
if it supports this feature.
Calls
To make a call, use your mobile device
in the normal way when the headset is
connected to it.

ENGLISH
To redial the number you last called (if
your mobile device supports this
feature with the headset), when no
call is in progress, press the answer/
end key twice.
To activate voice dialling (if your
mobile device supports this feature
with the headset), when no call is in
progress, press and hold the answer/
end key for about 2 seconds. Proceed
as described in the user guide of the
mobile device.
To answer or end a call, press the
answer/end key. To reject a call, press
this key twice.
To mute or unmute the microphone
during a call, press the play/pause key.
The headset beeps.
To switch a call from the headset to a
compatible mobile device, press and
hold the answer/end key for about 2
seconds, or switch off the headset. To
switch the call back to the headset,
press and hold the answer/end key for
about 2 seconds, or switch on the
headset.
Listen to music
To listen to music, connect the
headset to a compatible music player
that supports the A2DP Bluetooth
profile.
The available music functions depend
on your music player.
If you receive or make a call while
listening to music, the music is paused
until you end the call.
Warning: Continuous
exposure to high volume may
damage your hearing. Listen
to music at a moderate level.
To play a song, select it in the music
player, and press the play/pause key.
To pause or resume playing, press the
play/pause key. To stop playing, press
and hold this key.

ENGLISH
To select the next song during
playback, slide the rewind/fast-
forward key up. To select the previous
song, slide this key down twice. To
scroll through the current song
quickly, slide and hold the key.
Clear settings or reset
To clear the volume and pairing
settings from the headset, press and
hold the power key and the answer/
end key (for about 5 seconds) until the
red and green indicator lights start to
alternate. After the settings are
cleared, the headset enters pairing
mode.
To reset the headset if it stops
functioning, even though it is charged,
connect the headset to a charger
while you press and hold the power
key.
Troubleshooting
If you cannot connect the headset to
your compatible device, check that
the headset is charged, switched on,
and paired with the device.
Battery and charger information
This device has an internal,
nonremovable, rechargeable battery. Do
not attempt to remove the battery from
the device as you may damage the
device. This device is intended for use
when supplied with power from the
following chargers: AC-3, AC-4, AC-15
and DC-4. The exact charger model
number may vary depending on the type
of plug. The plug variant is identified by
one of the following: E, EB, X, AR, U, A,C,
K, or UB. The battery can be charged and
discharged hundreds of times, but it will
eventually wear out. Recharge your
battery only with Nokia approved
chargers designated for this device.

ENGLISH
If a battery is being used for the first time
or if the battery has not been used for a
prolonged period, it may be necessary to
connect the charger, then disconnect and
reconnect it to begin charging the
battery. If the battery is completely
discharged, it may take several minutes
before the charging indicator light is
displayed.
Unplug the charger from the electrical
plug and the device when not in use. Do
not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime. If
left unused, a fully charged battery will
lose its charge over time.
Always try to keep the battery between
15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and
lifetime of the battery. A device with a
hot or cold battery may not work
temporarily. Battery performance is
particularly limited in temperatures well
below freezing.
Do not dispose of batteries in a fire as
they may explode. Dispose of batteries
according to local regulations. Please
recycle when possible. Do not dispose as
household waste.
Never use any charger that is damaged.
Operating times are estimates only.
Actual performance depends on many
factors such as device settings selected,
device features being used (or running in
the background), battery condition and
ambient temperature.
Taking care of your device
Your device is a product of superior
design and craftsmanship and should be
treated with care. The following
suggestions will help you protect your
warranty coverage.

ENGLISH
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If your
device does get wet, allow it to dry
completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in high or cold
temperature. High temperatures can
shorten the life of electronic devices,
damage batteries, and warp or melt
certain plastics. When the device
warms to its normal temperature
from a cold temperature, moisture
can form inside the device and
damage electronic circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals, cleaning
solvents, or strong detergents to
clean the device. Only use a soft,
clean, dry cloth to clean the surface of
the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
These suggestions apply equally to your
device, charger, or any accessory.
Recycle
Always return your used electronic
products, batteries, and packaging
materials to dedicated collection points.
This way you help prevent uncontrolled
waste disposal and promote the recycling
of materials. Check product
environmental information and how to
recycle your Nokia products at
www.nokia.com/werecycle, or
nokia.mobi/werecycle.

ENGLISH
The crossed-out wheeled-bin
symbol on your product, battery,
literature, or packaging reminds
you that all electrical and
electronic products, batteries,
and accumulators must be taken
to separate collection at the end
of their working life. This
requirement applies in the
European Union. Do not dispose
of these products as unsorted
municipal waste. For more
environmental information, see
the product Eco-Declarations at
www.nokia.com/environment.
