Nokia BH-201 User manual

Nokia Bluetooth Headset BH-201
Issue1
12
9
10 11
13
8
7
6
5
4
3
2
1
9201029_BH-201_1_en.fm Page 1 Thursday, January 25, 2007 4:15 PM

2
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares
that this HS-52W product is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A copy
of the Declaration of Conformity can be
found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution, or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited.
Nokia and Nokia Connecting People are
registered trademarks of Nokia
Corporation. Other product and company
names mentioned herein may be
trademarks or tradenames of their
respective owners.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any
of the products described in this
document without prior notice.
Under no circumstances shall Nokia be
responsible for any loss of data or income
or any special, incidental, consequential
or indirect damages howsoever caused.
The contents of this document are
provided "as is". Except as required by
applicable law, no warranties of any kind,
either express or implied, including, but
not limited to, the implied warranties of
merchantability and fitness for a
particular purpose, are made in relation
to the accuracy, reliability or contents of
this document. Nokia reserves the right
to revise this document or withdraw it at
any time without prior notice.
The availability of particular products
may vary by region. Please check with
your Nokia dealer for details.
Unauthorized changes or modifications
to this device may void the user's
authority to operate the equipment.
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and
other countries. Diversion contrary to law
is prohibited.
0434
9201029_BH-201_1_en.fm Page 2 Thursday, January 25, 2007 4:15 PM

3
Introduction
The Nokia Bluetooth Headset BH-
201 allows you to make and receive
calls while on the move. You can
use the headset with compatible
phones that support Bluetooth
wireless technology.
Read this user guide carefully
before using the headset. Also read
the user guide for your phone,
which provides important safety
and maintenance information.
Keep all accessories and
enhancements out of the reach of
small children.
Bluetooth wireless
technology
Bluetooth wireless technology
allows you to connect compatible
devices without cables. The phone
and the headset do not need to be
in line of sight, but they should be
within 10 meters (30 feet) of each
other. Connections may be subject
to interference from obstructions,
such as walls, or other electronic
devices.
The headset complies with the
Bluetooth Specification 2.0 + EDR
that supports the Headset Profile
1.1 and Hands-Free Profile 1.5.
Check with the manufacturers of
other devices to determine their
compatibility with this headset.
There may be restrictions on using
Bluetooth technology in some
locations. Check with your local
authorities or service provider.
9201029_BH-201_1_en.fm Page Thursday, January 25, 2007 4:15 PM

4
Get started
The headset contains the following
parts shown on the title page:
earpiece wheel (1), charger
connector (2), indicator light (3),
microphone (4), power key (5),
volume key (6), strap lock (7), and
answer/end key (8).
Before using the headset, you must
charge the battery and pair the
headset with a compatible phone.
Parts of the headset are magnetic.
Metallic materials may be attracted to
the headset. Do not place credit cards
or other magnetic storage media near
the headset, because information
stored on them may be erased.
Chargers
Check the model number of any
charger before using it with this
headset. The headset is intended for
use with the AC-3, AC-4, and DC-4
chargers.
Warning: Use only
chargers approved by
Nokia for use with this
particular headset. The use of any
other types may invalidate any
approval or warranty and may be
dangerous.
For availability of approved
enhancements, please check with your
dealer. When you disconnect the
power cord of any enhancement,
grasp and pull the plug, not the cord.
Charge the battery
The headset has an internal,
nonremovable, rechargeable
battery. Do not attempt to remove
the battery from the headset, as
you may damage the headset.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to
the charger connector on the
headset. The red indicator light
9201029_BH-201_1_en.fm Page 4 Thursday, January 25, 2007 4:15 PM

5
is on while charging. It may take
a while before charging starts. If
charging does not start, connect
the charger again and retry.
Charging the battery fully may
take up to 2 hours.
3. When the battery is fully
charged, the red indicator light
turns off. Disconnect the
charger from the headset and
the wall outlet.
The fully charged battery has power
for up to 5 hours and 30 minutes of
talk-time or up to 150 hours of
standby time. However, the talk and
standby times may vary when the
headset is used with different
mobile phones or other compatible
Bluetooth devices, usage settings,
usage styles, and environments.
When battery power is low, the
headset sounds a series of beeps,
and the red indicator light starts to
flash.
Switch the headset on or off
To switch on, press and hold the
power key until the green indicator
light starts to flash.
To switch off, press and hold the
power key until the red indicator
light is displayed briefly.
Pair the headset
1. Switch on your phone and the
headset.
2. Activate the Bluetooth feature
on the phone, and set the phone
to search for Bluetooth devices.
3. Select the headset from the list
of found devices.
4. Enter the Bluetooth passcode
0000 to pair and connect the
headset to your phone. In some
phones you may need to make
the connection separately after
pairing. You only need to pair
the headset with your phone
once.
9201029_BH-201_1_en.fm Page 5 Thursday, January 25, 2007 4:15 PM

6
If the pairing is successful, the
headset beeps and appears in the
phone menu where you can view
the currently paired Bluetooth
devices.
Basic use
Place the headset on your ear
The adjustable earpiece wheel helps
you keep the headset securely in
the ear. Rotate the earpiece wheel
into the most suitable and
comfortable position for your
ear (10).
For example, if you use the headset
on the right ear, you may need to
rotate the wheel to the right for the
best fit.
Insert the earpiece into your ear in
a secure and comfortable position,
and point the headset toward your
mouth (11).
Wear the headset
You can wear the headset on your
neck using the supplied strap. To fix
the headset to the strap, attach the
shorter part of the strap (with the
lock) to the headset (12), and
attach the longer part to the lock
(13). To release the strap, pull it
from the lock.
Change the earbud
The headset may be supplied with
earbuds in different sizes. To
change the earbud, pull the current
earbud from the headset (9), and
push the new earbud into place,
with the wider end first.
Call handling
To make a call, use your phone in
the normal way when the headset
is connected to your phone.
9201029_BH-201_1_en.fm Page 6 Thursday, January 25, 2007 4:15 PM

7
If your phone supports last number
redialing with the headset, press
the answer/end key twice briefly
when no call is in progress.
If your phone supports voice dialing
with the headset, press and hold
the answer/end key when no call in
progress, and proceed as described
in the user guide of your phone.
To answer or end a call, press the
answer/end key. To reject an
incoming call, press the answer/end
key twice.
To switch the call between the
headset and a compatible phone,
press and hold the answer/end key.
To adjust the headset volume, press
the volume key up or down.
Clear the settings or reset the
headset
To clear the settings, press and hold
the power key and the answer/end
key over 10 seconds.
To reset the headset if it does not
function properly, although it is
charged, plug the headset into a
charger, and press the power key
and the answer/end key at the
same time.
Battery information
Your headset is powered by a
rechargeable battery. The battery can
be charged and discharged hundreds
of times, but it will eventually wear
out. Recharge your battery only with
Nokia approved chargers designated
for this headset.
Unplug the charger from the electrical
plug and the headset when not in use.
Do not leave a fully charged battery
connected to a charger, since
overcharging may shorten its lifetime.
If left unused, a fully charged battery
will lose its charge over time.
9201029_BH-201_1_en.fm Page 7 Thursday, January 25, 2007 4:15 PM

8
Never use any charger that is
damaged.
Leaving the headset in hot or cold
places, such as in a closed car in
summer or winter conditions, will
reduce the capacity and lifetime of the
battery. Always try to keep the battery
between 15°C and 25°C (59°F and
77°F). A headset with a hot or cold
battery may not work temporarily,
even when the battery is fully charged.
Battery performance is particularly
limited in temperatures well below
freezing.
Do not dispose of batteries in a fire as
they may explode. Batteries may also
explode if damaged. Dispose of
batteries according to local
regulations. Please recycle when
possible. Do not dispose as household
waste.
Care and maintenance
Your device is a product of superior
design and craftsmanship and should
be treated with care. The following
suggestions will help you protect your
warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that
will corrode electronic circuits. If
your device does get wet, allow it
to dry completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can be
damaged.
• Do not store the device in hot
areas. High temperatures can
shorten the life of electronic
devices, damage batteries, and
warp or melt certain plastics.
• Do not store the device in cold
areas. When the device returns to
its normal temperature, moisture
can form inside the device and
damage electronic circuit boards.
• Do not attempt to open the device.
9201029_BH-201_1_en.fm Page 8 Thursday, January 25, 2007 4:15 PM

9
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals,
cleaning solvents, or strong
detergents to clean the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
All of the above suggestions apply
equally to your device, battery,
charger, or any enhancement. If any
device is not working properly, take it
to the nearest authorized service
facility for service.
9201029_BH-201_1_en.fm Page 9 Thursday, January 25, 2007 4:15 PM
