Nokia BH-602 User manual

Nokia Bluetooth Headset
BH-602 User Guide
9203998
Issue 1 EN

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this HS-91W product is
in compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of the Declaration of
Conformity can be found at http://www.nokia.com/phones/
declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the
contents in this document in any form without the prior written
permission of Nokia is prohibited.
Nokia and Nokia Connecting People are registered trademarks of
Nokia Corporation. Other product and company names mentioned
herein may be trademarks or tradenames of their respective owners.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Nokia operates a policy of ongoing development. Nokia reserves the
right to make changes and improvements to any of the products
described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of
data or income or any special, incidental, consequential or indirect
damages howsoever caused.
0434

The contents of this document are provided "as is". Except as
required by applicable law, no warranties of any kind, either express
or implied, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose, are made in
relation to the accuracy, reliability or contents of this document.
Nokia reserves the right to revise this document or withdraw it at
any time without prior notice.
The availability of particular products may vary by region. Please
check with the Nokia dealer nearest to you.
Unauthorized changes or modifications to this device may void the
user's authority to operate the equipment.
Export Controls
This device may contain commodities, technology or software
subject to export laws and regulations from the US and other
countries. Diversion contrary to law is prohibited.
9203998 / Issue 1 EN

Contents
4
Contents
1. Introduction .............................................................. 5
Bluetooth wireless technology............................................................... 6
2. Get started................................................................. 8
Overview....................................................................................................... 8
Chargers........................................................................................................ 9
Charge the battery.................................................................................. 10
Switch the headset on or off............................................................... 11
Pair the headset....................................................................................... 12
Disconnect the headset..................................................................... 13
Reconnect the headset...................................................................... 13
Troubleshooting....................................................................................... 14
3. Basic use .................................................................. 15
Place the headset on the ear............................................................... 15
Call handling ............................................................................................ 16
Adjust the headset volume................................................................... 18
Mute or unmute the microphone....................................................... 18
Switch the call between headset and mobile device ................... 18
Turn off indicator light.......................................................................... 19
Clear settings or reset............................................................................ 19
4. Battery information ................................................ 21
Care and maintenance ................................................ 23

Introduction
5
1. Introduction
With the Nokia Bluetooth Headset BH-602 you can make
and receive calls while on the move and use your mobile
device hands free. You can use the headset with compatible
devices that support Bluetooth wireless technology.
Read this user guide carefully before using the headset. Also
read the user guide for your mobile device, which provides
important safety and maintenance information. Keep the
headset and its accessories out of reach of small children.

Introduction
6
■Bluetooth wireless technology
Bluetooth wireless technology
allows you to connect compatible
devices without cables. A
Bluetooth connection does not
require that the mobile device and
the headset be in line of sight, but
the maximum distance between
the devices is 10 meters (33 feet).
The closer the mobile device and the headset are to each
other, the better is the performance. The optimal operating
range is shown in dark grey in the picture. The connection is
subject to interference from distance and obstructions
(shown in light grey) or other electronic devices.
The headset is compliant with the Bluetooth Specification
2.0 + EDR supporting the following profiles: Headset Profile
1.1 and Hands-Free Profile 1.5. Check with the
manufacturers of other devices to determine their
compatibility with this device.
<10m

Introduction
7
There may be restrictions on using Bluetooth technology in
some locations. Check with your local authorities or service
provider.

Get started
8
2. Get started
■Overview
The headset contains the following parts: earloop (1),
volume key (2), charger connector (3), answer/end key (4),
indicator light (5), earpiece (6), power key (7), and
microphone (8).
Before you can start using the headset, you must charge the
battery and pair the headset with a compatible device.
+
1
2
3
4
8
6
7
5

Get started
9
Parts of the headset are magnetic. Metallic materials may
be attracted to the headset. Do not place credit cards or
other magnetic storage media near the headset, because
information stored on them may be erased.
■Chargers
Check the model number of any charger before using it with
this headset. The headset is intended for use with the AC-3,
AC-4, and DC-4 chargers.
Warning: Use only chargers approved by Nokia for
use with this particular enhancement. The use of
any other types may invalidate any approval or
warranty, and may be dangerous.
When you disconnect the power cord of any enhancement,
grasp and pull the plug, not the cord.

Get started
10
■Charge the battery
The headset has an internal, nonremovable, rechargeable
battery. Do not attempt to remove the battery from the
headset, as you may damage the headset.
1. Connect the charger to a wall outlet.
2. Connect the charger cable to the charger connector. The
indicator light is red while charging. It may take a while
before charging starts. If charging does not start,
disconnect the charger, plug it in again, and retry.
Charging the battery for 15 minutes provides about
5 hours of talk time with the AC-4 charger. Charging
the battery fully may take up to 45 minutes with the
AC-4 charger.
3. When the battery is fully charged, the indicator light
turns green. Disconnect the charger from the headset
and the wall outlet.
The fully charged battery has power for up to 11 hours of
talk time or up to 300 hours of standby time. However, the
talk and standby times may vary with different compatible

Get started
11
Bluetooth devices, usage settings, usage styles, and
environments.
To check the battery charge when the headset is not
connected to a charger, briefly press the power key. When
the indicator light is green (displayed for about 3 seconds),
the charge level is sufficient. When the light is yellow, you
may need to recharge the battery soon. When the light is
red, recharge the battery.
When battery power is low, the headset beeps at regular
intervals, and the indicator light slowly flashes red.
■Switch the headset on or off
To switch on, press and hold the power key until the headset
beeps and the green indicator light is displayed. When the
headset tries to connect to a paired device, the indicator
light slowly flashes green. When the headset is connected
to a paired device and is ready for use, the indicator light
slowly flashes blue. If the headset has not been previously
paired with a device, it automatically enters the pairing
mode (see “Pair the headset,” p. 12).

Get started
12
To switch off, press and hold the power key until the
headset beeps and the red indicator light flashes once.
■Pair the headset
1. Ensure that your mobile device is switched on.
2. To pair the headset if it has not been previously paired
with a device, switch on the headset. The headset enters
the pairing mode, and the indicator light flashes blue
quickly.
To pair the headset if it has been previously paired with
another device, ensure that the headset is switched off,
and press and hold the power key until the indicator
light starts to flash blue quickly.
3. Activate the Bluetooth feature on the mobile device,
and set it to search for Bluetooth devices. See the user
guide of your device for instructions.
4. Select the headset from the list of found devices.
5. Enter the passcode 0000 to pair and connect the
headset to your device. In some mobile devices, you may

Get started
13
need to make the connection separately after pairing.
See the user guide of your device for details. You only
need to pair the headset with your device once.
If pairing is successful, the headset appears in the menu of
the mobile device where you can view the currently paired
Bluetooth devices.
Disconnect the headset
To disconnect the headset from your mobile device, switch
off the headset, or disconnect it in the Bluetooth menu of
your device.
You do not need to delete pairing with the headset to
disconnect it.
Reconnect the headset
To connect the headset to your mobile device, switch on the
headset, and make the connection in the Bluetooth menu of
your device, or press and hold the answer/end key for about
2 to 3 seconds until you hear a short beep.

Get started
14
In your device, you may be able to allow the headset to
connect to it automatically when the headset is switched
on. To do this in Nokia devices, change your paired device
settings in the Bluetooth menu.
■Troubleshooting
If you cannot connect the headset to your mobile device, do
as follows:
• Ensure that the headset is charged, switched on, and
paired with your device.
• Ensure that the Bluetooth feature is activated on your
device.
• Ensure that the headset is within 10 meters (33 feet) of
your device and that there are no obstructions between
the headset and the device, such as walls, or other
electronic devices.

Basic use
15
3. Basic use
■Place the headset on the ear
The headset is provided with an earloop that you can use for
a better fit on your ear.
Slide the earloop over your ear (1), and gently plug the
earpiece into your ear. Push or pull the earloop to set its
length. Set the headset so that it points toward your mouth
(2).
12

Basic use
16
To use the headset on the left ear, rotate the earloop so that
the loop is to the left of the Nokia logo (3).
■Call handling
To make a call, use your mobile device in the normal way
when the headset is connected to it.
If your device supports last number redialing with the
headset, press the answer/end key twice.
If your device supports voice dialing with the headset, press
and hold the answer/end key until the mobile device starts
3

Basic use
17
voice dialing, and proceed as described in the user guide of
the device. Voice dialing cannot be used during a call.
To answer a call, press the answer/end key, or use the keys
of the mobile device. When you receive a call, the indicator
light flashes blue quickly, and you hear a ringing tone
through the headset.
To reject an incoming call, press the answer/end key twice,
or use the keys of the mobile device.
To end a call, press the answer/end key, or use the keys of
the mobile device.
To answer a waiting call and put the current call on hold,
press and hold the answer/end key. To answer a waiting call
and end the current call, press the answer/end key briefly.
To reject a waiting call, press the answer/end key twice. To
switch between the active call and the call on hold, press
and hold the answer/end key. To end the active call and
make the call on hold active, press the answer/end key. To
use these features, your mobile device must support the
Bluetooth Hands-Free profile 1.5, and call waiting must be
set to on in your device. Call waiting is a network service.

Basic use
18
■Adjust the headset volume
The headset automatically adjusts the volume according to
ambient noise. To set the minimum volume, press the
volume key up to increase or down to decrease the volume,
or use the keys of the mobile device. To adjust the volume
quickly, press and hold the volume key in the desired
direction.
■Mute or unmute the microphone
To mute or unmute the microphone during a call, press the
middle of the volume key.
■Switch the call between headset and
mobile device
To switch the call from the headset to the connected mobile
device, press and hold the power key for about 2 to 3
seconds (the headset switches off), or use the respective
function in your device. To switch the call back to the

Basic use
19
headset, switch on the headset, or press and hold the
answer/end key (when the headset is on).
■Turn off indicator light
To turn the indicator light off or on, briefly press the power
key and the answer/end key at the same time when no call
is in progress.
When the indicator light is off, it is not shown when the
headset is connected to a device, when you handle calls, or
when the microphone is muted. When you switch on the
headset, the indicator light is enabled.
■Clear settings or reset
To clear all the pairing settings from the headset, press and
hold the power key and the answer/end key until the
headset beeps and the indicator light alternates red and
green.
To reset the headset if it stops functioning, although it is
charged, plug the charger into the headset, and briefly press

Basic use
20
the power key and the answer/end key at the same time. The
headset switches off. To use the headset, reconnect it to
your mobile device. The reset does not clear the headset
settings.
