Nokia BH-101 User manual

Nokia Bluetooth Headset BH-101
Issue 1
89
12
2
3
5
6
4
1
7
10
11

2
2
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares
that this HS-94W product is in
compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC. A
copy of the Declaration of Conformity
can be found at http://www.nokia.com/
phones/declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Nokia and Nokia Connecting People are
registered trademarks of Nokia
Corporation. Other product and
company names mentioned herein may
be trademarks or tradenames of their
respective owners.
Reproduction, transfer, distribution, or
storage of part or all of the contents in
this document in any form without the
prior written permission of Nokia is
prohibited.
Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Nokia operates a policy of ongoing
development. Nokia reserves the right to
make changes and improvements to any
of the products described in this
document without prior notice.
To the maximum extent permitted by
applicable law, under no circumstances
shall Nokia or any of its licensors be
responsible for any loss of data or
income or any special, incidental,
consequential or indirect damages
howsoever caused.
The contents of this document are
provided "as is". Except as required by
applicable law, no warranties of any
kind, either express or implied,
including, but not limited to, the implied
warranties of merchantability and
fitness for a particular purpose, are
made in relation to the accuracy,
reliability or contents of this document.
Nokia reserves the right to revise this
document or withdraw it at any time
without prior notice.
The availability of particular products
may vary by region. Please check with
your Nokia dealer for details.
© 2007 Nokia. All rights reserved.

3
Export Controls
This device may contain commodities,
technology or software subject to export
laws and regulations from the US and
other countries. Diversion contrary to
law is prohibited.
Introduction
The Nokia Bluetooth Headset BH-
101 allows you to make and
receive calls while on the move.
You can use the headset with
compatible phones that support
Bluetooth wireless technology.
Read this user guide carefully
before using the headset. Also,
read the user guide for your phone,
which provides important safety
and maintenance information.
Keep the headset out of the reach
of small children.
Bluetooth wireless
technology
Bluetooth wireless technology
allows you to connect compatible
devices without cables. The phone
and the headset do not need to be
in line of sight, but they should be
within 10 metres (33 feet) of each
other. Connections may be subject
to interference from obstructions,
such as walls, or other electronic
devices.
The headset complies with the
Bluetooth Specification 2.0 + EDR
that supports the Headset Profile
1.1 and Hands-Free Profile 1.5.
Check with the manufacturers of
other devices to determine their
compatibility with this device.
© 2007 Nokia. All rights reserved.

4
4
Get started
The headset contains the
following parts shown on the title
page: earloop (1), charger
connector (2), earpiece (3), volume
keys (4), indicator light (5),
multifunction key (6), and
microphone (7).
Before using the headset, you
must charge the battery and pair
the headset with a compatible
phone.
Parts of the device are magnetic.
Metallic materials may be attracted
to the device. Do not place credit
cards or other magnetic storage
media near the device, because
information stored on them may be
erased.
Chargers
This device is intended for use when
supplied with power from the
following chargers: AC-3, AC-4, and
DC-4.
Warning: Use only
chargers approved by
Nokia for use with this
particular enhancement. The use of
any other types may invalidate any
approval or warranty, and may be
dangerous.
When you disconnect the power cord
of any enhancement, grasp and pull
the plug, not the cord.
Charge the battery
Before charging the battery,
carefully read “Battery
information”.
1. Connect the charger to a wall
outlet.
2. Connect the charger cable to
the charger connector (10). The
indicator light is red during
© 2007 Nokia. All rights reserved.

5
charging. It may take a while
before charging starts.
Charging the battery fully may
take up to 2 hours.
3. When the battery is fully
charged, the indicator light
turns green. Disconnect the
charger from the headset and
the wall outlet.
The fully charged battery has
power for up to 8 hours of talk
time or up to 180 hours of standby
time. However, the talk and
standby times may vary with
different compatible Bluetooth
devices, usage settings, usage
styles, and environments.
When battery power is low, the
headset beeps once every minute
and the red indicator light flashes
slowly.
Switch on or off
To switch on, press and hold the
multifunction key for about 5
seconds. The headset beeps, and
the green indicator light starts to
flash. The headset tries to connect
to a paired device.
To switch off, press and hold the
multifunction key (for about 5
seconds) until the headset beeps
and the red indicator light flashes
once.
Pair the headset
1. Ensure that your phone is
switched on and the headset is
switched off.
2. Press and hold the
multifunction key (for about 8
seconds) until the green
indicator light starts to flash
quickly.
© 2007 Nokia. All rights reserved.

6
6
3. Activate the Bluetooth feature
on the phone, and set the
phone to search for Bluetooth
devices.
4. Select the headset from the list
of found devices.
5. Enter the passcode 0000 to
pair and connect the headset to
your phone. In some phones,
you may need to make the
connection separately after
pairing. You only need to pair
the headset with your phone
once.
If the pairing is successful, the
headset appears in the phone
menu where you can view the
currently paired Bluetooth
devices.
When the headset is connected to
your phone and is ready for use,
the green indicator light flashes
slowly.
Basic use
Place the headset on the ear
The headset is ready to be used on
the right ear. Slide the earloop
over your ear (11), and gently push
the earpiece into your ear. You can
bend the earloop to make it fit the
shape of your ear. Point the
headset towards your mouth (12).
To use the headset on the left ear,
detach the earloop (8). flip it, and
attach it so that the loop is to the
left of the “Nokia“ logo (9).
© 2007 Nokia. All rights reserved.

7
Call handling
To make a call, use your phone in
the normal way when the headset
is connected to your phone.
If your phone supports last
number redialling with the
headset, press the multifunction
key twice while no call is in
progress.
If your phone supports voice
dialling with the headset, press
and hold the multifunction key for
about 2 to 3 seconds until the
phone start voice dialling, and
proceed as described in the user
guide of the phone. Voice dialling
cannot be used during a call.
To answer or end a call, press the
multifunction key. To reject an
incoming call, press this key twice.
To adjust the headset volume
during a call, press either volume
key.
To switch the call between the
headset and a compatible phone,
press and hold the multifunction
key for about 2 to 3 seconds.
Clear settings or reset
To delete the pairings from the
headset, switch on the headset,
and press and hold the
multifunction key and the volume
up key for about 5 seconds until
the indicator light alternates
between red and green.
To reset the headset if it stops
functioning, although it is
charged, press and hold the
multifunction key, and plug the
headset into a charger.
Troubleshooting
If you cannot connect the headset
to your compatible phone, check
that the headset is charged,
© 2007 Nokia. All rights reserved.

8
8
switched on, and paired with your
phone.
Battery information
Your device is powered by a
rechargeable battery. The battery can
be charged and discharged hundreds
of times, but it will eventually wear
out. Recharge your battery only with
Nokia approved chargers designated
for this device. Use of an unapproved
charger may present a risk of fire,
explosion, leakage, or other hazard.
If a battery is being used for the first
time or if the battery has not been
used for a prolonged period, it may be
necessary to connect the charger,
then disconnect and reconnect it to
begin charging the battery. If the
battery is completely discharged, it
may take several minutes before the
charging indicator light is displayed.
Unplug the charger from the
electrical plug and the device when
not in use. Do not leave a fully
charged battery connected to a
charger, since overcharging may
shorten its lifetime. If left unused, a
fully charged battery will lose its
charge over time.
Always try to keep the battery
between 15°C and 25°C (59°F and
77°F). Extreme temperatures reduce
the capacity and lifetime of the
battery. A device with a hot or cold
battery may not work temporarily.
Battery performance is particularly
limited in temperatures well below
freezing.
Do not dispose of batteries in a fire as
they may explode. Batteries may also
explode if damaged.
© 2007 Nokia. All rights reserved.

9
Never use any charger that is
damaged.
Care and maintenance
Your device is a product of superior
design and craftsmanship and should
be treated with care. The following
suggestions will help you protect
your warranty coverage.
• Keep the device dry. Precipitation,
humidity, and all types of liquids
or moisture can contain minerals
that will corrode electronic
circuits. If your device does get
wet, allow it to dry completely.
• Do not use or store the device in
dusty, dirty areas. Its moving parts
and electronic components can
be damaged.
• Do not store the device in hot
areas. High temperatures can
shorten the life of electronic
devices, damage batteries, and
warp or melt certain plastics.
• Do not store the device in cold
areas. When the device returns to
its normal temperature, moisture
can form inside the device and
damage electronic circuit boards.
• Do not attempt to open the
device.
• Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards and fine
mechanics.
• Do not use harsh chemicals,
cleaning solvents, or strong
detergents to clean the device.
• Do not paint the device. Paint can
clog the moving parts and prevent
proper operation.
© 2007 Nokia. All rights reserved.

10
10
If the product is not working properly,
take it to the nearest authorised
service facility for service.
