Nokia 7368 ISAM ONT BGW320-505 User manual

Nokia ONT
BGW320-505
BGW320-505 Product Guide
3FE-47753-AAAA-TCZZA
Issue 3
June 2022
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.

Legal notice
Nokia is committed to diversity and inclusion. We are continuously reviewing our customer documentation and consulting with standards
bodies to ensure that terminology is inclusive and aligned with the industry. Our future customer documentation will be updated accordingly.
This document includes Nokia proprietary and confidential information, which may not be distributed or disclosed to any third parties without
the prior written consent of Nokia.
This document is intended for use by Nokia’s customers (“You”/”Your”) in connection with a product purchased or licensed from any
company within Nokia Group of Companies. Use this document as agreed. You agree to notify Nokia of any errors you may find in this
document; however, should you elect to use this document for any purpose(s) for which it is not intended, You understand and warrant that
any determinations You may make or actions You may take will be based upon Your independent judgment and analysis of the content of
this document.
Nokia reserves the right to make changes to this document without notice. At all times, the controlling version is the one available on
Nokia’s site.
No part of this document may be modified.
NO WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY WARRANTY OF
AVAILABILITY, ACCURACY, RELIABILITY, TITLE, NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, IS MADE IN RELATION TO THE CONTENT OF THIS DOCUMENT. IN NO EVENT WILL NOKIA BE LIABLE FOR ANY
DAMAGES, INCLUDING BUT NOT LIMITED TO SPECIAL, DIRECT, INDIRECT, INCIDENTAL OR CONSEQUENTIAL OR ANY LOSSES,
SUCH AS BUT NOT LIMITED TO LOSS OF PROFIT, REVENUE, BUSINESS INTERRUPTION, BUSINESS OPPORTUNITY OR DATA
THAT MAY ARISE FROM THE USE OF THIS DOCUMENT OR THE INFORMATION IN IT, EVEN IN THE CASE OF ERRORS IN OR
OMISSIONS FROM THIS DOCUMENT OR ITS CONTENT.
Copyright and trademark: Nokia is a registered trademark of Nokia Corporation. Other product names mentioned in this document may be
trademarks of their respective owners.
© 2022 Nokia.
BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
2 Issue 3

Contents
About this document............................................................................................................................................5
1 What’s new....................................................................................................................................................11
1.1 Overview ...........................................................................................................................................11
1.2 What’s new in BBD Release 22.02 ...................................................................................................11
2 ANSI ONT safety guidelines........................................................................................................................13
2.1 Safety instructions.............................................................................................................................13
2.2 Safety standards compliance ............................................................................................................14
2.3 Electrical safety guidelines................................................................................................................15
2.4 ESD safety guidelines .......................................................................................................................16
2.5 Laser safety guidelines .....................................................................................................................16
3 BGW320-505 unit data sheet.......................................................................................................................19
3.1 Overview ...........................................................................................................................................19
3.2 BGW320-505 part numbers and identification ..................................................................................19
3.3 BGW320-505 general description .....................................................................................................20
3.4 BGW320-505 software and installation feature support....................................................................26
3.5 BGW320-505 interfaces and interface capacity................................................................................27
3.6 BGW320-505 service LED ................................................................................................................29
3.7 BGW320-505 detailed specifications ................................................................................................30
3.8 BGW320-505 GEM ports and T-CONTs............................................................................................31
3.9 BGW320-505 standards compliance ................................................................................................31
3.10 BGW320-505 special considerations ................................................................................................32
4 Install or replace a BGW320-505 indoor ONT............................................................................................35
4.1 Overview ...........................................................................................................................................35
4.2 Prerequisites .....................................................................................................................................35
4.3 Safety information .............................................................................................................................35
4.4 Install a BGW320-505 indoor ONT ...................................................................................................36
4.5 Replace a BGW320-505 indoor ONT................................................................................................39
Contents BGW320-505
June 2022
Issue 3 3
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

Contents BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
4 Issue 3

About this document
Purpose
This documentation set provides information about safety, features and functionality, ordering,
hardware installation and maintenance, and software installation procedures of this ONT for the
current release.
Intended audience
This documentation set is intended for planners, administrators, operators, and maintenance
personnel involved in installing, upgrading, or maintaining the ONTs.
The reader must be familiar with general telecommunications principles.
Safety information
For your safety, this document contains safety statements. Safety statements are given at points
where risks of damage to personnel, equipment, and operation may exist. Failure to follow the
directions in a safety statement may result in serious consequences.
Safety Information Examples
DANGER
Hazard
Danger indicates that the described activity or situation may result in serious personal injury or
death; for example, high voltage or electric shock hazards.
WARNING
Equipment Damage
Warning indicates that the described activity or situation may, or will, cause equipment damage or
serious performance problems.
CAUTION
Service Disruption
Caution indicates that the described activity or situation may, or will, cause service interruption.
Note:A note provides information that is, or may be, of special interest.
Acronyms and initialisms
The expansions and optional descriptions of most acronyms and initialisms appear in the glossary
About this document BGW320-505
June 2022
Issue 3 5
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

Nokia quality processes
Nokia’s ONT manufacturing, testing, and inspecting practices are in compliance with TL 9000
requirements. These requirements are documented in the Fixed Networks Quality Manual 3FQ-
30146-6000-QRZZA.
The quality practices adequately ensure that technical requirements and customer end-point
requirements are met. The customer or its representatives may be allowed to perform on-site
quality surveillance audits, as agreed upon during contract negotiations.
Documents
Documents are available using ALED or OLCS.
To download a ZIP file package of the customer documentation
1
Navigate to http://customer.nokia.com/s/ and enter your user name and password. If you are a
new user and require access to this service, please contact your Nokia sales representative.
2
Select Products.
3
Type your product name in the Find and select a product field and click the search icon.
Select a product.
4
Click Downloads: ALED to go to the Electronic Delivery: Downloads page.
5
Select Documentation from the list.
6
Select a release from the list.
7
Follow the on-screen directions to download the file.
END OF STEPS
To access individual documents
Individual PDFs of customer documents are also accessible through the Nokia Support Portal
website.
About this document BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
6 Issue 3

1
Navigate to http://customer.nokia.com/s/ and enter your user name and password. If you are a
new user and require access to this service, please contact your Nokia sales representative.
2
Select Products.
3
Type your product name in the Find and select a product field and click the search icon.
Select a product.
4
Click Documentation: Doc Center to go to the product page in the Doc Center.
5
Select a release from the Release list and click SEARCH.
6
Click on the PDF icon to open or save the file.
END OF STEPS
Procedures with options or substeps
When there are options in a procedure, they are identified by letters. When there are required
substeps in a procedure, they are identified by roman numerals.
Example of options in a procedure
At Step 1, you can choose option a or b. At Step 2, you must do what the step indicates.
1
This step offers two options. You must choose one of the following:
a. This is one option.
b. This is another option.
2
You must perform this step.
END OF STEPS
Example of required substeps in a procedure
At Step 1, you must perform a series of substeps within a step. At Step 2, you must do what the
step indicates.
About this document BGW320-505
June 2022
Issue 3 7
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

1
This step has a series of substeps that you must perform to complete the step. You must
perform the following substeps:
a. This is the first substep.
b. This is the second substep.
c. This is the third substep.
2
You must perform this step.
END OF STEPS
Multiple PDF document search
You can use Adobe Reader Release 6.0 and later to search multiple PDF files for a common term.
Adobe Reader displays the results in a single display panel. The results are grouped by PDF file,
and you can expand the entry for each file.
Note:The PDF files in which you search must be in the same folder.
To search multiple PDF files for a common term
1
Open Adobe Acrobat Reader.
2
Choose Edit→Search from the Acrobat Reader main menu. The Search PDF panel displays.
3
Enter the search criteria.
4
Select All PDF Documents In.
5
Select the folder in which to search using the drop-down menu.
6
Click Search.
Acrobat Reader displays the search results. You can expand the entries for each document by
clicking on the + symbol.
END OF STEPS
About this document BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
8 Issue 3

Technical support
For details, refer to the Nokia Support portal (https://customer.nokia.com/support/s/).
For ordering information, contact your Nokia sales representative.
How to comment
To comment on this document, go to the Online Comment Form (https://documentation.nokia.com/
comments/) or e-mail your comments to the Comments Hotline (mailto:[email protected]).
About this document BGW320-505
June 2022
Issue 3 9
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

About this document BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
10 Issue 3

1 What’s new
1.1 Overview
1.1.1 Purpose
This chapter provides the details of features and other documentation changes updated in the
product guide in each release.
1.1.2 Contents
1.1 Overview 11
1.2 What’s new in BBD Release 22.02 11
1.2 What’s new in BBD Release 22.02
Table 1-1, “What’s new in BBD Release 22.02” (p. 11) lists the new features and enhancements
added to the BGW320-505 product guide in Issue 3.
Table 1-1 What’s new in BBD Release 22.02
Feature/enhancement Description See
New features/enhancements
BGW320-505 pluggable optics supply
details for customer specific variants.
Added the ordering kit part number (3FE
46901 AC) for pluggable optics.
Table 3-3, “BGW320-505 pluggable optics”
(p. 20)
What’s new
Overview BGW320-505
June 2022
Issue 3 11
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

What’s new
What’s new in BBD Release 22.02 BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
12 Issue 3

2 ANSI ONT safety guidelines
This chapter provides information about the mandatory regulations that govern the installation and
operation of the optical network terminals or units (ONTs or ONUs) in the North American or ANSI
market.
2.1 Safety instructions
This section describes the safety instructions that are provided in the ONT customer documentation
and on the equipment.
2.1.1 Safety instruction boxes in customer documentation
The safety instruction boxes are provided in the ONT customer documentation. Observe the
instructions to meet safety requirements.
The following is an example of the Danger box.
DANGER
Hazard
Possibility of personal injury.
The Danger box indicates that the described activity or situation may pose a threat to personal
safety. It calls attention to a situation or procedure which, if not correctly performed or adhered to,
may result in death or serious physical harm.
Do not proceed beyond a Danger box until the indicated conditions are fully understood and met.
The following is an example of the Warning box.
WARNING
Equipment Damage
Possibility of equipment damage.
Possibility of data loss.
The Warning box indicates that the described activity or situation may, or will, cause equipment
damage, loss of data, or serious performance problems. It identifies a possible equipment-
damaging situation or provides essential information to avoid the degradation of system operations
or data.
Do not proceed beyond a warning until the indicated conditions are fully understood and met.
The following is an example of the Caution box.
ANSI ONT safety guidelines
Safety instructions BGW320-505
June 2022
Issue 3 13
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

CAUTION
Service Disruption
Possibility of service interruption.
Service interruption.
The Caution box indicates that the described activity or situation may, or will, cause service
interruption.
Do not proceed beyond a caution until the indicated conditions are fully understood and met.
The following is an example of the Note box.
Note: Information of special interest.
The Note box provides information that assists the personnel working with ONTs. It does not
provide safety-related instructions.
2.1.2 Safety-related labels
The ONT equipment is labeled with specific safety compliance information and instructions that are
related to a variant of the ONT. Observe the instructions on the safety labels.
The following table provides examples of the text in the various ONT safety labels.
Table 2-1 Safety labels
Description Label text
CE marking There are various CE symbols for CE compliance.
2.2 Safety standards compliance
This section describes the ONT compliance with North American safety standards.
WARNING
Equipment Damage
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
2.2.1 EMC, EMI, and ESD standards compliance
The ONT equipment complies with the following requirements:
• Federal Communications Commission (FCC) CFR 47, Part 15, Subpart B, Subpart C, and
Subpart E, Class A requirements for OLT equipment
• EN 61000-4-4 Testing and measurement techniques - Electrical fast transient/burst immunity test
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
ANSI ONT safety guidelines
Safety standards compliance BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
14 Issue 3

against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
needed.
• Consult the dealer or an experienced radio/TV technician for help.
2.2.2 Equipment safety standard compliance
The ONT equipment complies with the requirements of UL60950-1 and Indoor ONTs to Information
Technology Equipment (ITE).
2.2.3 Environmental standards compliance
The ONT equipment complies with the following standards:
• SPS-1019_Reliability_Env_Mech v2_5_REL_07-17-17 Section 6 Environmental Requirements
2.2.4 Resistibility requirements compliance
The ONT equipment complies with the requirements of ITU Recommendation K.21 for resistibility of
telecommunication equipment installed in customer premises to overvoltage and overcurrents.
2.3 Electrical safety guidelines
This section provides the electrical safety guidelines for the ONT equipment.
Note: The ONTs comply with the U.S. National Electrical Code. However, local electrical
authorities have jurisdiction when there are differences between the local and U.S. standards.
2.3.1 Power supplies
The use of any non-Nokia approved power supplies or power adapters is not supported or
endorsed by Nokia. Such use will void any warranty or support contract with Nokia. Such use
greatly increases the danger of damage to equipment or property.
2.3.2 Cabling
The following are the guidelines regarding cables used for the ONT equipment:
• Use only cables approved by the relevant national electrical code.
• The ONTs have been evaluated for use with external POTS wiring without primary protection
that may not exceed 140 ft (43 m) in reach. However, the power cable must not exceed 100 ft
(31 m).
ANSI ONT safety guidelines
Electrical safety guidelines BGW320-505
June 2022
Issue 3 15
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

2.3.3 Protective earth
Earthing and bonding of the ONTs must comply with the requirements of NEC article 250 or local
electrical codes.
2.4 ESD safety guidelines
The ONT equipment is sensitive to ESD. While the BGW320-505 product is designed to operate
per specifications, the product might be installed in a location which exceeds them. Do not install
the BGW320-505 in an area with high humidity or where there is high chance of ESD.
CAUTION
Service Disruption
This equipment is ESD sensitive. End users should not attempt to open the BGW320-505
enclosure.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure limits as set forth for an uncontrolled
environment. This equipment should be installed and operated maintaining a minimum distance of
54 cm (21.25 inches) between the device and your body.
During installation and maintenance, service personnel must wear wrist straps to prevent damage
caused by ESD.
Nokia recommends that you prepare the site before you install the ONT equipment. In addition, you
must control relative humidity, use static dissipating material for furniture or flooring, and restrict the
use of air conditioning.
2.5 Laser safety guidelines
Observe the following instructions when you perform installation, operations, and maintenance
tasks on the ONT equipment.
Only qualified service personnel who are extremely familiar with laser radiation hazards should
install or remove the fiber optic cables and units in this system.
DANGER
Hazard
There may be invisible laser radiation at the fiber optic cable when the cable is removed from the
connector. Avoid direct exposure to the laser beam.
Observe the following danger for laser hazard. Eyes can be damaged when they are exposed to a
laser beam. Take necessary precautions before you plug in the optical modules.
ANSI ONT safety guidelines
ESD safety guidelines BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
16 Issue 3

DANGER
Hazard
Possibility of equipment damage. Risk of eye damage by laser radiation.
2.5.1 Normal laser operation
In normal operation, fiber cable laser radiation is always off until it receives signal from the line
terminal card.
Eyes can be damaged when they exposed to a laser beam. Operating personnel must observe the
instructions on the laser explanatory label before plugging in the optical module.
DANGER
Hazard
Risk of eye damage by laser radiation.
2.5.2 Location class
Use cable supports and guides to protect the receptacles from strain.
ANSI ONT safety guidelines
Laser safety guidelines BGW320-505
June 2022
Issue 3 17
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

ANSI ONT safety guidelines
Laser safety guidelines BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
18 Issue 3

3 BGW320-505 unit data sheet
3.1 Overview
3.1.1 Purpose
3.1.2 Contents
3.1 Overview 19
3.2 BGW320-505 part numbers and identification 19
3.3 BGW320-505 general description 20
3.4 BGW320-505 software and installation feature support 26
3.5 BGW320-505 interfaces and interface capacity 27
3.6 BGW320-505 service LED 29
3.7 BGW320-505 detailed specifications 30
3.8 BGW320-505 GEM ports and T-CONTs 31
3.9 BGW320-505 standards compliance 31
3.10 BGW320-505 special considerations 32
3.2 BGW320-505 part numbers and identification
Table 3-1, “Identification of BGW320-505 indoor ONT” (p. 19) provides part numbers and
identification information for the BGW320-505 indoor ONT.
Table 3-1 Identification of BGW320-505 indoor ONT
Ordering kit
part number
Provisioning
number
Description CLEI CPR ECI/
Bar
code
3FE 48263 AA
(Customer-
specific variant)
3FE 47753 AA Package P ONT unit with one RJ-14 dual voice port,
three 1000/100/10 BaseT Ethernet interfaces, and one
5G/2.5G/1G/100M Ethernet port, all four as LAN ports
and one 1G/100M/10M WAN Ethernet port.
This ONT also supports 802.11b/g/n/ac tri-band Wi-Fi: 5
GHz low-band, 5 GHz high-band, and 2.4 GHz radios.
This ONT has one USB 2.0 port with a Type A connector
and has an SFP cage supporting pluggable SFP+ optical
modules.
BVMG400BRA — 474079
BGW320-505 unit data sheet
Overview BGW320-505
June 2022
Issue 3 19
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA

Table 3-1 Identification of BGW320-505 indoor ONT (continued)
Ordering kit
part number
Provisioning
number
Description CLEI CPR ECI/
Bar
code
3FE 48263 AB
(Customer-
specific variant)
3FE 47753 AB Package P ONT unit with one RJ-14 dual voice port,
three 1000/100/10 BaseT Ethernet interfaces, and one
5G/2.5G/1G/100M Ethernet port, all four as LAN ports
and one 1G/100M/10M WAN Ethernet port.
This ONT also supports 802.11b/g/n/ac tri-band Wi-Fi: 5
GHz low-band, 5 GHz high-band, and 2.4 GHz radios.
This ONT has one USB 2.0 port with a Type A connector
and has an SFP cage supporting pluggable SFP+ optical
modules.
Comes with a 2-pin AC/DC U.S. power adapter with AC
cable.
BVMGX10BRA — 475267
Table 3-2, “Supported power adapters” (p. 20) provides information on supported power adapters.
Table 3-2 Supported power adapters
Part number Description
1AF 32246 AA Power supply unit, Delta EPS48R0-16, US Plug, 2-Pin, 12V, 4A, L6, Surge 6KV.
Includes DC power cord. Included with ONT.
1AF 32246 BA Power supply unit, Delta EPS48R1-16, US Plug, 2-Pin, 12V, 4A, L6, Surge 6KV.
Includes DC power cord. Included with ONT.
Table 3-3, “BGW320-505 pluggable optics” (p. 20) provides optics ordering information for
BGW320-505 ONTs. These pluggable optics modules can be ordered separately.
Table 3-3 BGW320-505 pluggable optics
Part number Type Description
3FE 46899 AB GPON SFP+ GPON optical module, SC/APC, Industrial-Temp
3FE 46900 AB Alt-Optic GPON SFP+ Alt-Optic GPON optical module, SC/APC, Industrial-Temp
3FE 46901 AC XGS PON SFP+ XGS 10G GPON optical module, SC/APC, Industrial-Temp
3.3 BGW320-505 general description
BGW320-505 ONTs are designed to cater to business and residential customer requirements. The
ONT offers data and video services to the subscriber.
When used with an appropriate pluggable SFP+ PON module in the ONT’s SFP cage, the
BGW320-505 indoor ONT provides the subscriber interface for the network by terminating the PON
interface and converting it to user interfaces that directly connect to subscriber devices.
The ONT is compatible with all existing subscriber equipment, including analog phones with rotary
dial capability, cordless phones, modems, fax machines, and caller ID boxes (Type I, Type II, and
Type III).
BGW320-505 unit data sheet
BGW320-505 general description BGW320-505
© 2022 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3FE-47753-AAAA-TCZZA
June 2022
20 Issue 3
