Nokia NSW-6 Series Guide

PAMS Technical Documentation
NSW-6 Series Transceivers
Issue 1 12/99 Nokia Mobile Phones Ltd.
Service Tools

NSW-6
Service Tools PAMS Technical Documentation
Page 2 Issue 1 12/99
Nokia Mobile Phones Ltd.
AMENDMENT RECORD SHEET
Amendment
Number Date Inserted By Comments
12/99 OJuntune

NSW-6
Service Tools
PAMS Technical Documentation
Page 3
Issue 1 12/99 Nokia Mobile Phones Ltd.
CONTENTS
Page No
Service Junction box JBU-8 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module Jig JBS-25 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Tool AAX-1 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Adapter BDS-6 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flash Adapter FLA-9 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flash Loading Adapter FLA-5 (Sales Pack) 9. . . . . . . . . . . . . . . . .
Flash Prommer FPS-4S (Sales Pack) 10. . . . . . . . . . . . . . . . . . . . .
Security Box TDF-4 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Audio Box JBA-6 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D15-D15 Cable AXS-5 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DC Cable PCC-1B 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DC Cable SCB-3 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MBUS Cable DAU-9S 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Cable PCS-1 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Modular Service Cable XMS-3 15. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Cable XRC-2 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Antenna Removal Tool ART-5 16. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SW Security Device PKD-1 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dongle/Flash Device FLS-2D (Sales Pack) 18. . . . . . . . . . . . . . . .

NSW-6
Service Tools PAMS Technical Documentation
Page 4 Issue 1 12/99
Nokia Mobile Phones Ltd.
Service Junction box JBU-8
Service Junction Box JBU-8 has been designed for service use:
- To make connection between transceiver to FLA-5 for flash loading.
- To enable functional tests, making the connection from transceiver to
test devices.
- To generate accurate 4,1V and 8.4V voltage for transceiver.
- To generate accurate 500mA current to charging current calibration.
- To generate 10ms IBI-pulse to BTMP-line
Service Junction Box JBU-8 is only forGo/NoGo testing.
Product Code
Service Junction Box JBU-8: 0770186
View of JBU-8

NSW-6
Service Tools
PAMS Technical Documentation
Page 5
Issue 1 12/99 Nokia Mobile Phones Ltd.
Module Jig JBS-25
The purpose of the JBS-25 module service jig is to provide a method of
applying voltage from an external power supply when the phone engine is
out of its mechanics.
The engine module of NSW-6 products can be tested with JBS-25.
The jig contains four connector pcbs, keyboard module and assembly
parts.
Module Jig JBS-25: 0770185
Note: The nominal supply voltage for the JBS-25 is +4.1V.
The supply voltage must not exceed +5.0 V
The purpose of the JBS-25 module service jig is to provide a method of
applying voltage from an external power supply when the phone engine is
out of its mechanics.

NSW-6
Service Tools PAMS Technical Documentation
Page 6 Issue 1 12/99
Nokia Mobile Phones Ltd.
Service Tool AAX-1
The function of the AAX-1 is to provide galvanic contact for RF
measurements.
Product code
Service Tool AAX-1: 0770200
View of AAX-1

NSW-6
Service Tools
PAMS Technical Documentation
Page 7
Issue 1 12/99 Nokia Mobile Phones Ltd.
Battery Adapter BDS-6
The Battery Adapter BDS-6 is used along with an external battery capacity
meter to check battery capacity.
Note that Li-ion batteries have an internal protection circuit to prevent
deep discharge.
Product Code
Battery Adapter BDS-6: 0750121
View of BDS-6

NSW-6
Service Tools PAMS Technical Documentation
Page 8 Issue 1 12/99
Nokia Mobile Phones Ltd.
Flash Adapter FLA-9
Flash Adapter FLA-9 is used in modifying the contents of the phone Flash
memory, e.g.warranty data transfer.
Product Code
Flash Adapter FLA-9: 0770187
View of FLA-9

NSW-6
Service Tools
PAMS Technical Documentation
Page 9
Issue 1 12/99 Nokia Mobile Phones Ltd.
Flash Loading Adapter FLA-5 (Sales Pack)
The Flash Loading Adapter FLA-5 is used with the Flash Adapter FLA-9
and Service Cable XMS-3. Power is supplied to the FLA-5 from the Flash
Security Box TDF-4 via the DC cable PCC-1B, (The PCC-1B cable can be
replaced with a Travel Charger ACH-6), and is connected to the Flash
Prommer FPS-4S with the cable AXS-5.
The sales pack includes:
- Flash Loader Adapter FLA-5 0770085
- Service cable SCH-5 0730098
- D15 - D15 Cable AXS-5 0730091
- Installation software for FPS-4 8400041
Product Code
Flash Loading Adapter FLA-5: 0080178
View of FLA-5

NSW-6
Service Tools PAMS Technical Documentation
Page 10 Issue 1 12/99
Nokia Mobile Phones Ltd.
Flash Prommer FPS-4S (Sales Pack)
The Flash Prommer FPS-4S is used to update the main software of the
phone. Updating is done by first loading the new MCU software from the
PC to the flash prommer, and then loading the new SW from the prommer
to the phone. When updating more than one phone in succession, the
MCU software only needs to be loaded to the prommer once.
The sales pack includes:
- Charger ACL-3E 0680015
- Printer Cable 0730029
- D9 - D9 Cable AXS-4 0730090
- Installation software for FPS-4 8400041
Product Code
Flash Prommer FPS-4S: 0085095
View of FPS-4S

NSW-6
Service Tools
PAMS Technical Documentation
Page 11
Issue 1 12/99 Nokia Mobile Phones Ltd.
Security Box TDF-4
The Security Box TDF-4 is required for updating MCU software, and infra
red testing.
Note: TDF-4 is delivered in de-activated mode. Fill in the enclosed
Activation Request Form, and fax to NMP Salo to get the
activation code
Product Code
Security Box TDF-4: 0770106
View of TDF-4

NSW-6
Service Tools PAMS Technical Documentation
Page 12 Issue 1 12/99
Nokia Mobile Phones Ltd.
Service Audio Box JBA-6
The Service Audio Box JBA-6 is used between the phone or JBS-25 and
test equipment.
Product Code
Service Audio Box JBA-6: 0770184
View of JBA-6

NSW-6
Service Tools
PAMS Technical Documentation
Page 13
Issue 1 12/99 Nokia Mobile Phones Ltd.
D15-D15 Cable AXS-5
The D15-D15 Cable AXS-5 is used to connect two 15 pin D connectors.
e.g. between FLA-5 and FPS-4S.
Product Code
D15-D15 Cable AXS-5: 0730091
View of AXS-5
DC Cable PCC-1B
The DC Cable PCC-1B is used e.g. to connect FLA-5 and TDF-4.
Product Code
DC Cable PCC-1B: 0770053
View of PCC-1

NSW-6
Service Tools PAMS Technical Documentation
Page 14 Issue 1 12/99
Nokia Mobile Phones Ltd.
DC Cable SCB-3
The DC Cable SCB-3 is used to connect the Service Box to the charger
connection Vin of the phone when doing the charger calibration service
procedure.
Product Code
DC Cable SCB-3: 0730114
View of SCB-3
MBUS Cable DAU-9S
The MBUS Cable DAU-9S has a modular connector, and is used with the
JBS-25.
Product Code
MBUS Cable DAU-9S: 0730108
View of DAU-9S

NSW-6
Service Tools
PAMS Technical Documentation
Page 15
Issue 1 12/99 Nokia Mobile Phones Ltd.
Power Cable PCS-1
The Power Cable PCS-1 is used to connect the module jigs JBS-25 and
JBU-8 to an external power supply.
Product Code
Power Cable PCS-1: 0730012
View of PCS-1
Modular Service Cable XMS-3
XMS-3 is a modular cable for flashing and warranty transfer.
Product code
Service Cable XMS-3: 0730174
View of XMS-3

NSW-6
Service Tools PAMS Technical Documentation
Page 16 Issue 1 12/99
Nokia Mobile Phones Ltd.
Service Cable XRC-2
XRC-2 is a modular cable with N connector for RF measurements.
Product code
Service Cable XRC-2: 0730180
View of XRC-2
Antenna Removal Tool ART-5
ART-5 is the antenna removal tool.
Product code
Antenna Removal Tool ART-5: 0774232
Views of ART-5

NSW-6
Service Tools
PAMS Technical Documentation
Page 17
Issue 1 12/99 Nokia Mobile Phones Ltd.
SW Security Device PKD-1
SW security device is a piece of hardware enabling the use of the service
software when connected to the parallel (LPT) port of the PC. Whitout the
dongle present it is not possible to use the service software. Printer or any
such device can be connected to the PC through the dongle if needed.
Caution: Make sure thet you have switched off the PC and the printer
before making connections!
Caution: Do not connected the PKD-1 to the serial port. You may
damage your PKD-1!
Product Code
SW Security Device PKD-1: 0750018
View of SW Security Device

NSW-6
Service Tools PAMS Technical Documentation
Page 18 Issue 1 12/99
Nokia Mobile Phones Ltd.
Dongle/Flash Device FLS-2D (Sales Pack)
FLS-2D is a dongle and flash device incorporated into one package,
developed specifically for POS use.
Product Code
Sales Pack -APAC 0081290
Sales Pack - Europe/Africa 0081291
View of FLS-2D
Sales Pack Contents
ÁÁÁÁÁ
ÁÁÁÁÁ
Part No.
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Description
ÁÁÁÁÁ
ÁÁÁÁÁ
0750142
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
FLS-2D Flash Device.
ÁÁÁÁÁ
ÁÁÁÁÁ
0730163
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
AXS-4U Cable.
ÁÁÁÁÁ
ÁÁÁÁÁ
0770177
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Disk- Installation package,16bit Dongle Drivers.
ÁÁÁÁÁ
ÁÁÁÁÁ
0770176
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Disk - Installation package, 32bit Dongle Drivers.
ÁÁÁÁÁ
ÁÁÁÁÁ
0774120
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Disk - Installation package for the FLE-5 Drivers.
ÁÁÁÁÁ
ÁÁÁÁÁ
0774123
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Disk - Remote Update Application Installation Package.
ÁÁÁÁÁ
ÁÁÁÁÁ
0275405
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Installation and User Guide
ÁÁÁÁÁ
ÁÁÁÁÁ
0275404
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
ÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁÁ
Registration Request Form
Note: in addition to this Sales Pack, a Service Cable will be required to connect the
FLS-2D to the Product/Phone to be flashed, e.g. XMS-3, and a software package to run
the flashing process.
The picture overleaf shows how to connect the FLS-2 device and
associated cables to the PC and Product/Phone.

NSW-6
Service Tools
PAMS Technical Documentation
Page 19
Issue 1 12/99 Nokia Mobile Phones Ltd.
FLS-2D Connection Diagram
1.
5.
3.
2. 4.
Laptop PC
1 Flash Battery Adapter FLA-9 0770184
2 POS Flash Adapter FLS-2D 0750130
(Connected to parallel port)
3 Modular Cable XMS-3 0730174
4 D9-D9 Cable AXS-4U 0730090
5 Travel Charger ACP-8U 0271610

NSW-6
Service Tools PAMS Technical Documentation
Page 20 Issue 1 12/99
Nokia Mobile Phones Ltd.
This page intentionally left blank.
