Nordic Propeye OY1110 User manual

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
Product manual
version
1.
0
January 24, 2023
[email protected]

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
Table of contents
1 Disclaimer ..................................................................................................................... 3
1.1 Technical support .................................................................................................. 3
2 Warnings ....................................................................................................................... 4
3 Environmental ............................................................................................................... 5
4 Product Description ...................................................................................................... 6
5 Installation and activation ............................................................................................. 7
5.1 LoRaWAN Configuration ....................................................................................... 8
5.2 Sensor states and state check .............................................................................. 8
6 Specification ............................................................................................................... 11
7 Product life length ....................................................................................................... 12
8 Security ....................................................................................................................... 12
9 Protocol ....................................................................................................................... 12
9.1 LoRaWAN standard commands .......................................................................... 12
9.2 Unsolicited uplink status commands ................................................................... 13
9.3 Periodic measurement reports ............................................................................ 13
9.4 Downlink commands and queries ........................................................................ 15
9.5 Commands .......................................................................................................... 17
9.6 Uplink query response ......................................................................................... 19

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
1 Disclaimer
This document represents information on products at the time of publication and is subject
to change without prior notice due to product improvements or other reasons. Nordic
Propeye makes no warranties based on the accuracy or completeness of the contents of
this document and reserves the right to make changes to specifications and product
descriptions at any time without notice. Nordic Propeye reserves all rights to this document
and the information contained herein.
1.1 Technical support
Please visit www.nordicpropeye.com for additional information, or contact
[email protected]
EC DECLARATION OF CONFORMITY
certify that the design and manufacturing of this product
WIRELESS TEMPERATURE SENSOR /
FUNK-TEMPERATURSENSOR /
TRÅDLÖS TEMPERATUR SENSOR /
TRÅDØS TEMPERATUR SENSOR /
DRAADLOZE TEMPERATUURSENSOR
OY1110 EU868
conforms to the following directives and standards
The Radio Equipment Directive (2014/53/EU),
EN 300 220-1 V2.4.1, EN 300220-2 V2.4.1,
EN 301 489-1 V1.9.2, EN 301 489-3 V2.1.1,
EN 60950-1:2006+A11+A1+A12+A2
EN 62479:2010
RoHS Directive 2011/65/EU
This product was CE marked in year -18
2018-12-01 ___________________
Managing Director Stefan Lindgren

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
2 Warnings
The following safety precautions must be observed during all phases of the operation,
usage, service or repair of this Nordic Propeye product.
• Read the product manual.
• Do not modify the product.
• The product should not be exposed to extreme heat or open flame.
• The device must not be exposed to harsh chemical agents or solvents.
• The labelling of the product may not be changed, removed or made unrecognizable.

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
3 Environmental
This symbol on the product or on its packaging indicates that this product must not be
disposed of with your other household waste. Instead, it is your responsibility to dispose of
your waste by taking it to a collection point designated for the recycling of electrical and
electronic appliances. Separate collection and recycling of your waste at the time of
disposal will contribute to conserving natural resources and guarantee recycling that
respects the environment and human health. For further information concerning your
nearest recycling center, please contact your nearest local authority/town hall offices, your
household waste collection company or the shop where you bought the product.

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
4 Product Description
Figure 1: OY1110 Temperature and humidity sensor
The OY1110 LoRaWAN Temperature and humidity sensor is designed to measure
temperature and humidity in indoor environments. The sensor is intended for climate
control, energy optimization, and damage preventions in attics and basements. It is
optimized for reliable and secure measurements with more than 10 years life length.
The standard measurement and reporting interval is 15 minutes, other reporting intervals
can be configured over the air.

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
5 Installation and activation
The sensor consists of a bottom piece, to be mounted on the wall, and a top piece with the
active parts.
Figure 2: Mounting information
The bottom piece is mounted on the wall with the “UP” arrow upwards. It can be mounted
either with screws or adhesive tape.
Figure 3: Push button and LED
The top piece contains all active components. The unit is shipped in sleep mode, i.e. with
all functions, including radio, deactivated. The sensor is activated by pressing the push
button for 3 seconds until the red LED makes two short flashes, make sure to not hold
Note “UP”

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
longer than 5 seconds. When the device has successfully joined the LoRaWAN network
there will be a long (2s) flash.
5.1 LoRaWAN Configuration
Configuration on the network server is done with
AppEUI: 70-B3-D5-D7-2F-F8-16-00 (a.k.a. JoinEUI)
It is possible to order a batch of devices configured with a customer unique AppEUI from
the Nordic Propeye OUI range.
The device is configured with device unique DevEUI and AppKey
The device is default configured for OTA provisioning. Contact the Nordic Propeye team
for ABP configuration. The device follows the LoRaWAN standard related Join
configuration parameters, such as RX1 and RX2 windows, RX2 downlink frequency etc.
The default setting is ADR enabled.
5.2 Sensor states and state check
The sensor has four states: Initial, Joining, Configure and Operational state.

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
Figure 4: Device states
To check the device state, press the button and hold it pressed until the red LED starts
flashing after 0.5s.
State
Description
LED response
Initial
Low power state during transport. Radio not active.
1 short flash (0.5 sec)
Joining
Trying to join a LoRaWAN network. The device will
remain in this state until successfully joined a LoRaWAN
network
2 short flash (0.5 sec)
Configure
Enables quick over-the-air configuration, by polling
server after configuration commands during 2 minutes.
This is done by sending uplink status command (0x20).
1 long flash (2 sec)
Operational
Joined to a LoRaWAN network, measures temperature
and humidity periodically, and sends measurement
reports toward a LoRAWAN network.
1 long flash (2 sec)

Product manual, version 1.0, January 24, 2023, www.nordicpropeye.com
OY1110 LoRaWAN® Temperature and humidity
sensor
5.2.1 Re-join functionality
The device supervises its connectivity to the network, by monitoring that periodic downlink
messages are received.
The device tries to re-join the network if it has not heard anything from the network for 288
uplinks (3 days @ 15-minute message interval). The device requests and normally gets a
downlink ever 64th uplink due to the ADRAckReq functionality.
