NordicTrack CEX22522 User manual

USER'S MANUAL
CAUTION
Read all precautions and in-
structions in this manual before
using this equipment. Keep this
manual for future reference.
Model No. CEX22522
Model No. CEX25022
Serial No.
The serial number is found in the
location shown below. Write the
serial number in the space above.
QUESTIONS?
At FreeMotion Fitness,we’re
committed to providing complete
customer satisfaction. For assis-
tance, call Customer Care toll-
free at:
1-800-201-2109
Mon.–Fri., 8 a.m.–5 p.m. MST
Serial
Number
Decal

SECTION 1 Important Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
How to Assemble the Recumbent Bike . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
How to Set Up the Recumbent Bike . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
How to Upgrade the Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SECTION 2 How to Use the Basic Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
How to Use the Workout TV Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
SECTION 3 Maintenance and Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
SECTION 4 Exercise Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SECTION 5 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Part List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Exploded Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
How to Order Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
TABLE OF CONTENTS
1
NordicTrack is a registered trademark of ICON IP, Inc.

3
1. It is the responsibility of the owner to ensure
that all users of the recumbent bike are
adequately informed of all warnings and
precautions.
2. Operate the recumbent bike only as described
in this manual.
3. Do not operate the recumbent bike until it is
properly assembled (see HOW TO ASSEMBLE
THE RECUMBENT BIKE on page 5).
4. Keep the recumbent bike indoors, away from
moisture and dust. Do not place the recum-
bent bike in a garage or covered patio or near
water.
5. Place the recumbent bike on a level surface.
To protect the floor or carpet from damage,
place a mat beneath the recumbent bike.
6. Regularly inspect and tighten all parts of the
recumbent bike.
7. Keep children under the age of 12 and pets
away from the recumbent bike at all times.
8. The recumbent bike should not be used by
persons weighing more than 350 pounds.
9. Always wear appropriate exercise clothes and
athletic shoes when operating the recumbent
bike. Do not wear loose clothes that could be-
come caught on the recumbent bike.
10. Do not modify the power cord or use an
adapter to connect the power cord to an im-
proper receptical. Keep the power cord away
from heated surfaces. Do not use an extension
cord.
11. Keep your back straight when using the re-
cumbent bike; do not arch your back.
12. If you feel pain or dizziness while exercising,
stop immediately and cool down.
13. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
WARNING:To reduce the risk of serious injury, read the following important precautions
and information before operating the recumbent bike.
IMPORTANT PRECAUTIONS
WARNING:Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS

4
Congratulations for selecting the revolutionary Nordic-
Track®9600 recumbent bike. The NordicTrack 9600
recumbent bike offers an impressive array of features
tomake your workouts more effective and enjoyable.
For your benefit, read this manual carefully before
using the NordicTrack 9600 recumbent bike.If you
have questions after reading this manual, please call
Customer Care toll-free at 1-800-201-2109, Monday
through Friday, 8 a.m. until 5 p.m. Mountain Time
(excluding holidays). To help us assist you, please
note your product model number and serial number
before calling. The model number of your recumbent
bike is CEX22522 or CEX25022. The serial number
can be found on a decal attached to the recumbent
bike (see the front cover of this manual for the location
of the decal).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Handlebar
CD/Accessory Tray
Console
Leveling Foot
BEFORE YOU BEGIN
Handgrip Pulse Sensor
Water Bottle Holder*
*No water bottle is included
FRONT
REAR
Backrest
Seat
Wheel
Pedal/Strap
Seat Latch
RIGHT SIDE

5
Assembly requires two persons. Set the recumbent bike in a cleared area and remove all packing materials. Do
not dispose of the packing materials until assembly is completed. Assembly can be completed using the
included tools.
Use the drawings below to identify the small parts used in assembly. The number in parenthesis below each
drawing refers to the key number of the part. The second number refers to the quantity needed for assembly.
HOW TO ASSEMBLE THE RECUMBENT BIKE
1. Push the excess console wiring down into the
Frame (1). Attach the Handlebar (3) to the Frame
with four 3/8” x 1/2” Button Screws (74). Make sure
that the wiring is not pinched between the
Handlebar and the Frame.
3
Console
Wires
1
74
74
1
2. Attach the Seat Back (10) to the Seat Carriage (5)
with four 1/4” x 3/4” Socket Screws (64).
1/4” x 3/4” Button
Screw (67)–4 3/8” x 3/4” Button
Screw (81)–2 3/8” x 1 1/4” Button
Screw (76)–4
1/4” x 3/4” Socket
Screw (64)–4 3/8” x 1/2” Button
Screw (74)–4
2
10
5
64

6
3. Attach the Seat Handlebar (6) to the Seat Carriage
(5) with four 3/8” x 1 1/4” Button Screws (76) and
two 3/8” x 3/4” Button Screws (81). Next, insert the
Pulse Plug (78) into the pulse jack near the top of
the Right Side Shield (8).
5
81
6
876
78
3
4. Attach the Seat (9) to the Seat Carriage (5) with
four 1/4” x 3/4” Button Screws (67). Insert the four
1/2” Round Endcaps (80) into the indicated holes in
the Seat Handlebar (6).
4
9
5
67 67
67
680

7
HOW TO MOVE AND LEVEL THE RECUMBENT
BIKE
Before moving the recumbent bike, make sure
that the power cord is unplugged. Note: If a CATV
cable is connected to the recumbent bike, it may be
necessary to disconnect the cable if the recumbent
bike will be moved far.
Due to the size and weight of the recumbent bike,
moving it requires two persons. While one person
lifts the indicated end, firmly hold the handlebar and
tip the recumbent bike forward until it rolls on the
front wheels. Carefully move the recumbent bike to
the desired location and then lower it back to the
level position. CAUTION: To reduce the risk of in-
jury, use extreme caution while moving the re-
cumbent bike. Do not attempt to move the re-
cumbent bike over uneven surfaces.
If the recumbent bike rocks slightly during use, turn
the leveling feet under the rear of the frame until the
rocking motion is eliminated.
HOW TO ADJUST THE SEAT
To adjust the seat, lift the seat latch, slide the seat
forward or backward to the desired position, and then
push the seat latch back down.
HOW TO CONNECT THE POWER CORD
If the recumbent bike has a Basic console, it can be used with or
without the included power cord. Ifthe recumbent bike has a
Workout TV console, the power cord must be used for the TV to be
operated.
To use the power cord, first plug one end of the power cord into the
jack on the front of the recumbent bike. Plug the other end of the
power cord into an appropriate outlet that is properly installed in ac-
cordance with all local codes and ordinances.
Seat
Latch
HOW TO SET UPTHE RECUMBENT BIKE
Lift
Here
Wheels
Handlebar
Power
Cord
Jack
Leveling
Feet

8
HOW TO CONNECT A CATV CABLE
Ifyour recumbent bike has a Workout TV console, a CATV cable
must be connected to the recumbent bike for cable TV stations to
beviewed.
Locate the cable jack on the front of the recumbent bike. Connect
the CATV cable to the cable jack.
Asatellite receiver, VCR, or DVD player can also be connected to
the recumbent bike. Connect a CATV cable from the coaxial output
on your equipment (usually labeled TV OUT or RF OUT) to the
cable jack. Note: Audio/video equipment without coaxial outputs
(some satellite receivers and DVD players) will require an RF modulator to operate with the recumbent bike. RF
modulators and external CATV cables are not available from FreeMotion Fitness, but are available at electronics
stores. See the owner's manual included with the equipment you wish to connect to see whether an RF modula-
tor is needed.
Cable Jack
Your recumbent bike has been pre-configured to operate with a Basic console and a Workout TV console (see
the drawings below). To learn about the features of the Basic console, see page 9. For information about the
state-of-the-art Workout TV console, see page 23.
To upgrade your console and expand the capabilities of your recumbent bike whenever you choose,
simply contact your local FreeMotion Fitness Sales Representative or call FreeMotion Fitness toll-free at
1-877-363-8449.
HOW TO UPGRADE THE CONSOLE
Basic
Console Workout TV
Console

FEATURES OF THE CONSOLE
The Basic console offers an impressive array of fea-
tures to help you get the most from your exercise.
When the manual mode of the console is selected, the
resistance of the pedals can be changed with a touch
of a button. As you exercise, the console will provide
continuous exercise feedback. You can even measure
your heart rate using the built-in pulse sensor.
A variety of preset workout programs is also offered.
Each program automatically controls the resistance of
the pedals as it guides you through an effective workout.
In addition, the console offers three pulse programs
that adjust the resistance of the pedals to keep your
heart rate near target levels during your workouts, and
aunique fitness test program that measures your VO2
max level. Note: The pulse programs and the fitness
test program require the use of a Polar®-compatible
chest pulse sensor (not included).
To use the QUICK START mode of the console,
follow the steps beginning on page 10. To use a
preset program,see pages 12 to 16. To use a pulse
program, see page 17. To use the fitness test pro-
gram, see page 19. To use the maintenance mode,
see page 20.
Main Display
9
Matrix
HOW TO USE THE BASIC CONSOLE
Note: If there is a
sheet of clear
plastic on the
console, remove
the clear plastic.

10
HOW TO USE THE QUICK START MODE
Plug in the power cord or begin pedaling to
activate the console.
Ifthe recumbent bike has a Basic console, it can
beused with or without the included power cord.
To use the power cord, see HOW TO CON-
NECT THE POWER CORD on page 7. To use
the recumbent bike without the power cord,
begin pedaling at a cadence of about 20 revolu-
tions per minute (RPM) or faster. After a moment,
the console displays will light and a series of
tones will sound. While you pedal, power will be
supplied by a generator; remember to continue
pedaling while using the recumbent bike.
If the recumbent bike has a Workout TV con-
sole, the power cord must be used for the TV
to be operated.
Select the QUICK START mode.
When the power is turned on, the QUICK START
mode will be selected. If you have already se-
lected a program, select the QUICK START mode
again by repeatedly pressing the PROGRAM
SELECT button until the words “QUICK START”
appear in the main display.
Afew seconds after the QUICK START mode is
selected, the words “QUICK START” will begin to
scroll across the main display.
Press the START button and begin pedaling.
When the button is pressed, the console will begin
displaying exercise data.
Change the resistance of the pedals as desired.
As you pedal, change
the resistance of the
pedals by pressing the
RESISTANCE + and –
buttons. To change the
resistance quickly,
press the QUICK RESISTANCE buttons. There
are twenty resistance levels, from level 0.5 to
level 10.
Follow your progress with the matrix and the
main display.
The matrix—When the QUICK START mode is
selected, the matrix will show a graph of the resis-
tance levels that you select. The flashing column
shows the current resistance level. Every thirty
seconds, all columns will move one position to the
left. As you increase or decrease the resistance,
additional indicators will light or darken in the
flashing column (and in all columns to the right).
Note: The matrix shows relative resistance levels.
As you increase or decrease the resistance, the lit
indicators in all columns may shift upward or
downward so that the highest indicators are al-
ways shown in the matrix.
The main display—The main display will show
the following information:
Resistance—The left
end of the main display
will show the resistance
level of the pedals.
Pace/Time—When the
Quick Start mode is se-
lected, this section of the
main display will show
your pedaling pace (in
minutes per mile )and
the elapsed time. The display will change from one
number to the other every few seconds. Note: Any
time that the resistance level changes, the display
will show your pedaling pace.
Note: When a preset program or a pulse program
is selected, the display will show your pedaling
pace, the time remaining in the program, and the
time remaining in the current segment of the pro-
gram. During the fitness test program, the display
will show the elapsed time.
5
4
3
2
1
Flashing Column

Distance—This section
of the main display will
show the distance that
you have pedaled, in
miles or kilometers.
Calories/Watts—This
section of the main dis-
play will show the ap-
proximate number of
Calories you have
burned and your power
output in watts. The display will change from one
number to the other every few seconds.
Note: If you enter your weight into the console, the
console will measure your Calorie expenditure
more accurately. To enter your weight, press the
ENTER AGE/WT. button. The words “ENTER
WEIGHT” and the current weight setting will scroll
across the main display. To enter your weight,
press the + and – buttons beside the ENTER
AGE/WT. button. When your weight is shown,
press the ENTER AGE/WT. button again.
Pulse/% Max—When
you use the handgrip
pulse sensor or a
Polar®-compatible chest
pulse sensor (not in-
cluded), this section of
the main display will show your heart rate (see
step 6). When a pulse program is selected, the
display will show your heart rate and the corre-
sponding
percentage of your estimated maximum
heart rate (see step 5 on page 17 for an explana-
tion of your estimated maximum heart rate). The
display will change from one number to the other
every few seconds.
Speed/RPM—The right
end of the main display
will show your pedaling
speed, in miles per hour
or kilometers per hour,
and your pedaling ca-
dence, in revolutions per minute. The display will
change from one number to the other every few
seconds.
To reset the main display at any time, press the
CLEAR button.
Measure your pulse if desired.
Ifthere are thin
sheets of plastic
on the metal con-
tacts on the hand-
grip pulse sensor,
peel off the plas-
tic. To measure
your pulse, hold the
contacts; your
thumbs must be
resting on the inner
contacts, and your
fingers must be touching the outer contacts.
Avoid moving your hands.
When your pulse is detected, the PULSE indicator
above the main display will light, and then your
heart rate will be shown. For the most accurate
heart rate reading, hold the contacts for at
least 15 seconds without moving your hands.
If your heart rate is not shown, make sure that
your hands are positioned as described. Be care-
ful not to move your hands excessively or to
squeeze the contacts too tightly. For optimal per-
formance, clean the contacts using a soft cloth;
never use alcohol, abrasives, or chemicals.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
If the power cord is being used, the words
“PUSH ANY BUTTON TO START A NEW
WORKOUT” will begin to scroll across the main
display if the pedals are not moved for a few min-
utes. Unplug the power cord when the recumbent
bike is not in use.
If the power cord is not being used, the console
will automatically turn off if the pedals are not
moved for several seconds.
7
6
11
Contacts

12
HOW TO USE THE TIMED WORKOUT PROGRAM
The TIMED WORKOUT program will count down the
time remaining in your workout as you control the
resistance of the pedals.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select the TIMED WORKOUT program.
To select the TIMED WORKOUT program, repeat-
edly press the PROGRAM SELECT button until
the words “TIMED WORKOUT” appear in the main
display.
Afew seconds after the program is selected, the
name of the program and the total program time
will begin to scroll across the main display. Note:
The program can be set to last for 20, 30, 40, 50,
or 60 minutes. See step 8 on page 20.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The TIMED WORKOUT program is divided into
30-second segments. During the program,the
matrix will show your progress and the resistance
levels that you select. The flashing column repre-
sents the current
segment of the
program. The
number of lit indi-
cators in the flash-
ing column shows
the resistance
level for the cur-
rent segment. At
the end of each segment, a series of tones will
sound, the time will flash in the main display, and
the flashing column of the matrix will move one po-
sition to the right.
During the program, change the resistance of the
pedals as desired by pressing the RESISTANCE
+and – buttons or the QUICK RESISTANCE but-
tons. As you increase or decrease the resistance,
additional indicators will light or darken in the
flashing column (and in all columns to the right).
Note: The matrix shows
relative resistance levels.
As you increase or decrease the resistance, the lit
indicators in the columns may shift upward or
downward so that the highest indicators are al-
ways shown in the matrix.
After you have completed the first three minutes of
the program, the flashing column will no longer
move to the right at the end of each segment.
Instead, all columns of indicators will move one
position to the left at the end of each segment.
When only 12 minutes remain in the program, the
flashing column will again move one position to the
right at the end of each segment, until the program
is completed.
Follow your progress with the main display.
See step 5 on page 10.
Measure your pulse if desired.
See step 6 on page 11.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
6
5
4
3
2
1
Flashing Column

13
HOW TO USE THE RANDOM HILLS PROGRAM
The RANDOM HILLS program will automatically
change the resistance of the pedals during your work-
out. Each time the program is selected, the resistance
settings of the program will be different.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select the RANDOM HILLS program.
To select the RANDOM HILLS program, repeat-
edly press the PROGRAM SELECT button until
the words “RANDOM HILLS” appear in the main
display.
Afew seconds after the program is selected, the
name of the program and the total program time
will begin to scroll across the main display. Note:
To select a different RANDOM HILLS program,
simply press the CLEAR button. The program can
be set to last for 20, 30, 40, 50, or 60 minutes.
See step 8 on page 20.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The program is divided into 30-second segments.
One resistance level is programmed for each seg-
ment. (The same resistance level may be pro-
grammed for two or more consecutive segments.)
During the pro-
gram, the matrix
will show your
progress and the
resistance settings
of the program.
The flashing col-
umn represents
the current segment of the program. The number
of lit indicators in the flashing column shows the
resistance setting for the current segment. At the
end of each segment, a series of tones will sound,
the time will flash in the main display, and the
flashing column of the matrix will move one posi-
tion to the right. The resistance of the pedals will
then automatically change if a different resistance
level is programmed for the next segment. Note:
The matrix shows
relative resistance levels. The lit
indicators in the columns may shift upward or
downward so that the highest indicators are al-
ways shown in the matrix.
During the program, you can change the resis-
tance of the pedals if desired by pressing the RE-
SISTANCE + and – buttons or the QUICK RESIS-
TANCE buttons. However, when the current seg-
ment ends, the resistance will automatically
change if a different resistance level is pro-
grammed for the next segment. Note: The pro-
gram begins with a two-minute warm-up period
and ends with a two-minute cool-down period.
During these periods, the resistance level cannot
be changed.
After you have completed the first three minutes of
the program, the flashing column will no longer
move to the right at the end of each segment.
Instead, all columns of indicators will move one
position to the left at the end of each segment.
When only 12 minutes remain in the program, the
flashing column will again move one position to the
right at the end of each segment, until the program
is completed.
Follow your progress with the main display.
See step 5 on page 10.
Measure your pulse if desired.
See step 6 on page 11.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
6
5
4
3
2
1
Flashing Column

14
HOW TO USE THE WATTS WORKOUT PROGRAM
The WATTS WORKOUT program will automatically
change the resistance of the pedals to keep your
power output near a target level during your workout.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select the WATTS WORKOUT program.
To select the WATTS WORKOUT program, re-
peatedly press the PROGRAM SELECT button
until the words “WATTS WORKOUT” appear in the
main display.
Afew seconds after the program is selected, the
name of the program and the total program time
will begin to scroll across the main display. Note:
The program can be set to last for 20, 30, 40, 50,
or 60 minutes. See step 8 on page 20.
Press the START button and enter a target
watts setting for the program.
When the button is pressed, the words “ENTER
TARGET WATTS” and the current target watts
setting will scroll across the main display. If you
wish to change the target watts setting for the pro-
gram, press the + and – buttons beside the
ENTER AGE/WT. button. The target watts setting
can be changed in increments of 10 watts.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The program is divided into 30-second segments.
The same target watts level is programmed for all
segments. During
the program, the
matrix will show
your progress. The
flashing column
represents the cur-
rent segment of
the program. At
the end of each
segment, a series of tones will sound, the time will
flash in the main display, and the flashing column
of the matrix will move one position to the right.
During the program, the console will compare your
power output to the target watts setting. If your
power output is too far above or below the target
watts setting, the resistance of the pedals will au-
tomatically change to bring your power output
closer to the target watts setting. Note: Pressing
the RESISTANCE + and – buttons during the pro-
gram will change the target watts setting for the
program (see step 3).
After you have completed the first three minutes of
the program, the flashing column will no longer
move to the right at the end of each segment.
Instead, all columns of indicators will move one
position to the left at the end of each segment.
When only 12 minutes remain in the program, the
flashing column will again move one position to the
right at the end of each segment, until the program
is completed.
Follow your progress with the main display.
See step 5 on page 10.
Measure your pulse if desired.
See step 6 on page 11.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
7
6
5
4
3
2
1
Flashing Column

15
HOW TO USE THE CARDIO WORKOUT PROGRAM
The CARDIO WORKOUT program will automatically
change the resistance of the pedals as it guides you
through an effective cardiovascular workout.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select the CARDIO WORKOUT program.
To select the CARDIO WORKOUT program, re-
peatedly press the PROGRAM SELECT button
until the words “CARDIO WORKOUT” appear in
the main display.
Afew seconds after the program is selected, the
name of the program and the total program time
will begin to scroll across the main display. Note:
The program can be set to last for 20, 30, 40, 50,
or 60 minutes. See step 8 on page 20.
Press the START button and enter a maximum
resistance setting for the program.
When the button is pressed, the words “ENTER
WORKOUT LEVEL” and the maximum resistance
setting for the program will scroll across the main
display. If you wish to change the maximum resis-
tance setting, press the + and – buttons beside
the ENTER AGE/WT. button. The maximum resis-
tance setting can be from level 2 to level 10. Note:
Increasing or decreasing the maximum resistance
setting will increase or decrease the intensity level
of the program.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The program is divided into 30-second segments.
One resistance level is programmed for each seg-
ment.
During the pro-
gram, the matrix
will show your
progress and the
resistance settings
of the program.
The flashing col-
umn represents
the current seg-
ment of the program. The number of lit indicators
in the flashing column shows the resistance set-
ting for the current segment. At the end of each
segment, a series of tones will sound, the time will
flash in the main display, and the flashing column
of the matrix will move one position to the right.
The resistance of the pedals will then automati-
cally change if a different resistance level is pro-
grammed for the next segment. Note: The matrix
shows
relative resistance levels. As you increase
or decrease the resistance, the lit indicators in the
columns may shift upward or downward so that
the highest indicators are always shown in the ma-
trix.
After you have completed the first three minutes
of the program, the flashing column will no longer
move to the right at the end of each segment.
Instead, all columns of indicators will move one
position to the left at the end of each segment.
When only 12 minutes remain in the program, the
flashing column will again move one position to
the right at the end of each segment, until the pro-
gram is completed.
Note: Pressing the RESISTANCE + and – buttons
or the QUICK RESISTANCE buttons during the
program will change the maximum resistance set-
ting of the program (see step 3).
Follow your progress with the main display.
See step 5 on page 10.
Measure your pulse if desired.
See step 6 on page 11.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
7
6
5
4
3
2
1
Flashing Column

16
HOW TO USE THE HILLS INTERVAL PROGRAM
The HILLS INTERVAL program will automatically
change the resistance of the pedals to simulate a
series of hills as it guides you through an effective
interval training workout.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select the HILLS INTERVAL program.
To select the HILLS INTERVAL program, repeat-
edly press the PROGRAM SELECT button until
the words “HILLS INTERVAL” appear in the main
display.
Afew seconds after the program is selected, the
name of the program and the total program time
will begin to scroll across the main display. Note:
The program can be set to last for 20, 30, 40, 50,
or 60 minutes. See step 8 on page 20.
Press the START button and enter a maximum
resistance setting for the program.
See step 3 on page 15.
Press the START button and enter the desired
number of hills for the program.
When the button is pressed, the words “NUMBER
OF HILLS” and the number of hills that the pro-
gram will simulate will scroll across the main dis-
play. If you wish to change the number of hills,
press the + and – buttons beside the ENTER
AGE/WT. button. The program can simulate from
2to 10 hills.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The program is divided into 30-second segments.
One resistance level is programmed for each seg-
ment.
During the pro-
gram, the matrix
will show your
progress and the
resistance settings
of the program.
The flashing col-
umn represents
the current seg-
ment of the program. The number of lit indicators
in the flashing column shows the resistance set-
ting for the current segment. At the end of each
segment, a series of tones will sound, the time will
flash in the main display, and the flashing column
of the matrix will move one position to the right.
The resistance of the pedals will then automati-
cally change if a different resistance level is pro-
grammed for the next segment. Note: The matrix
shows
relative resistance levels. As you increase
or decrease the resistance, the lit indicators in the
columns may shift upward or downward so that
the highest indicators are always shown in the ma-
trix.
After you have completed the first three minutes
of the program, the flashing column will no longer
move to the right at the end of each segment.
Instead, all columns of indicators will move one
position to the left at the end of each segment.
When only 12 minutes remain in the program, the
flashing column will again move one position to
the right at the end of each segment, until the pro-
gram is completed.
Note: Pressing the RESISTANCE + and – buttons
or the QUICK RESISTANCE buttons during the
program will change the maximum resistance set-
ting for the program (see step 3).
Follow your progress with the main display.
See step 5 on page 10.
Measure your pulse if desired.
See step 6 on page 11.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
8
7
6
5
4
3
2
1
Flashing Column

HOW TO USE THE PULSE PROGRAMS
The three pulse programs automatically control the
resistance of the pedals to keep your heart rate near
atarget level while you exercise.
Put on a Polar®-compatible chest pulse sensor
(not included).
You must wear a chest pulse sensor to use a
pulse program. See the instructions included with
your chest pulse sensor.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select one of the three pulse programs.
To select a pulse program, repeatedly press the
PROGRAM SELECT button until the words “CAR-
DIO PULSE,” “ENDURANCE PULSE,” or “MAN-
UAL PULSE” appear in the main display. Note:
The CARDIO PULSE program will keep your
heart rate near 65% of your estimated maximum
heart rate (see step 5 at the right for an explana-
tion of estimated maximum heart rate). The EN-
DURANCE PULSE program will keep your heart
rate near 80% of your estimated maximum heart
rate. The MANUAL PULSE program will keep
your heart rate near a percentage that you select.
Afew seconds after the program is selected, the
name of the program and the total program time
will begin to scroll across the main display.
Note: During pulse
programs, the ma-
trix will show a
moving graphic
that represents
your heart rate.
Each time a heart-
beat is detected,
an additional peak will appear in the graphic.
Press the START button and enter your age.
When the button is pressed, the words “ENTER
AGE” and the current age setting will appear in
the main display. To enter your age, press the +
and – buttons beside the ENTER AGE/WT. but-
ton.
If you have selected the CARDIO PULSE pro-
gram or the ENDURANCE PULSE program, go
to step 6. If you have selected the MANUAL
PULSE program, go to step 5.
Press the START button and enter a target
heart rate setting.
When the button is pressed, the words “ENTER
PERCENT” and the current target heart rate set-
ting for the program will appear in the main dis-
play. The target heart rate setting represents a
percentage of your estimated maximum heart
rate
.Note: Your estimated maximum heart rate is
determined by subtracting your age from 220. For
example, if you are 30 years old, your estimated
maximum heart rate is 190 beats per minute (220
–30 = 190). Therefore, if you are 30 years old, a
target heart rate setting of 65% is equal to 123
beats per minute (65% of 190 is 123).
If desired, you can change the target heart rate
setting by pressing the + and – buttons beside the
ENTER AGE/WT. button. The target heart rate
setting can be from 50% to 85% of your estimated
maximum heart rate.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The program is divided into 30-second segments.
One target heart rate setting is programmed for
each segment. (If the MANUAL PULSE program
is selected, the same target heart rate setting is
programmed for all segments.)
At the end of each segment, a series of tones will
sound, and then the resistance of the pedals will
automatically increase or decrease, if necessary, to
bring your heart rate closer to the target heart rate
setting for the next segment. The program will con-
tinue in this way until the main display shows that
no time remains in the program.
6
5
4
3
2
1
17

18
During the program, you can change the resis-
tance of the pedals, if desired, by pressing the
RESISTANCE + and – buttons or the QUICK RE-
SISTANCE buttons. However, when the current
segment ends, the resistance will automatically in-
crease or decrease, if needed, to bring your heart
rate closer to the target heart rate setting for the
next segment. Note: Each pulse program begins
with a two-minute warm-up period and ends with a
two-minute cool-down period. During these peri-
ods, the resistance level cannot be changed.
If your pulse is not detected during the program,
the letters “PLS” will flash in the main display, and
the resistance of the pedals may automatically de-
crease. If this occurs, see the instructions included
with your chest pulse sensor.
Follow your progress with the main display.
See step 5 on page 10.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
8
7

19
HOW TO USE THE FITNESS TEST PROGRAM
The FITNESS TEST program measures your VO2 max
level. For the best results, the program should be used
atatime when your energy level is high; the program
should not be used if you have already exercised dur-
ing the day. Follow the steps below to use the program.
Put on a Polar®-compatible chest pulse sensor
(not included).
You must wear a chest pulse sensor to use the
FITNESS TEST program. See the instructions in-
cluded with your chest pulse sensor.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Select the FITNESS TEST program.
To select the FITNESS TEST program, press the
PROGRAM SELECT button repeatedly until the
words “FITNESS TEST” appear in the main dis-
play.
Afew seconds after the program is selected, the
name of the program will begin to scroll across the
main display.
Note: During the
FITNESS TEST
program, the ma-
trix will show a
moving graphic
that represents
your heart rate.
Each time a heart-
beat is detected, an additional peak will appear in
the graphic.
Press the START button and enter your age.
When the button is pressed, the words “ENTER
AGE” and the current age setting will appear in
the main display. To enter your age, press the +
and – buttons beside the ENTER AGE/WT. button.
Press the START button and enter your
weight.
When the button is pressed, the words “ENTER
WEIGHT” and the current weight setting will scroll
across the main display. To enter your weight,
press the + and – buttons beside the ENTER
AGE/WT. button.
Press the START button and begin pedaling to
start the program.
When the button is pressed, the console will begin
displaying exercise data.
The FITNESS TEST program is divided into three-
minute segments. During the program, the con-
sole will automatically control the resistance of the
pedals and prompt you to pedal at a cadence of
50 revolutions per minute (RPM). If you pedal
more than 5 RPM faster or slower than 50 RPM, a
tone will sound and the words, “PLEASE PEDAL
AT 50 RPM” will scroll across the main display.
When the first three-minute segment of the pro-
gram is completed, a tone will sound and the sec-
ond segment will begin. The program will continue
until the console has measured your VO2 max
level. Your VO2 max level will then begin to scroll
across the main display.
Note: The RESISTANCE + and – buttons and the
QUICK RESISTANCE buttons will not function
while the FITNESS TEST program is selected. If
your pulse is not detected during the program, the
letters “PLS” will flash in the main display. If your
pulse is not detected at the end of any segment,
the program will end and the main display will
show a VO2 max level of 000.
Follow your progress with the main display.
See step 5 on page 10.
When you are finished using the recumbent
bike, the console will automatically enter an
idle mode or turn off.
See step 7 on page 11.
8
7
6
5
4
3
2
1

20
HOW TO USE THE MAINTENANCE MODE
The console features a maintenance mode that allows
you to access information and to view and change de-
fault settings. Follow the steps below to use the main-
tenance mode.
Plug in the power cord or begin pedaling to
activate the console.
See step 1 on page 10.
Hold down the CLEAR button and the ENTER
AGE/WT. button simultaneously for a few sec-
onds to select the maintenance mode.
When the maintenance mode is selected, the
words MAINTENANCE MODE will appear in the
main display.
Press the ENTER AGE/WT. button and select a
language for the main display.
The main display can display text in English, UK
English, Spanish, Italian, German, or French. To
change the language, press the + and – buttons
beside the ENTER AGE/WT. button.
Press the ENTER AGE/WT. button again and
select the desired system of measurement.
The console can display data using the standard
system (miles and pounds) or the metric system
(kilometers and kilograms). To change the system
of measurement, press the + and – buttons be-
side the ENTER AGE/WT. button.
Press the ENTER AGE/WT. button again and
view the service time.
The console will show the total number of hours
that the recumbent bike has been used since the
service time was reset. To reset the service time,
press the CLEAR button.
Press the ENTER AGE/WT. button again and
view the service distance.
The console will show the total distance pedaled
on the recumbent bike since the service distance
was reset. To reset the service distance, press
the CLEAR button.
Press the ENTER AGE/WT. button again and
set the delay time for the idle mode.
If the power cord is used with the recumbent bike,
and if the pedals are stationary for several min-
utes, the console will enter an idle mode and the
words “PUSH ANY BUTTON TO START A NEW
WORKOUT” will begin to scroll across the main
display. To set the number of minutes before the
console will enter the idle mode, press the + and –
buttons beside the ENTER AGE/WT. button. The
delay time can be from 1 to 15 minutes.
Press the ENTER AGE/WT. button again and
set the program time for the programs.
The programs (except for the FITNESS TEST
program) can be set to last for 20, 30, 40, 50, or
60 minutes. To change the length of time, press
the + and – buttons beside the ENTER AGE/WT.
button.
If the recumbent bike has a Basic console, go
to step 12. If the recumbent bike has a
Workout TV console, go to step 9.
Press the ENTER AGE/WT. button again and
choose a connection setting for the TV.
To prevent the TV from being used, press the +
and – buttons beside the ENTER AGE/WT. button
until the words “TV DISABLED” appear in the
main display.
To make the TV available for use, press the + and
–buttons beside the ENTER AGE/WT. button to
select one of the following connection settings: TV
NTSC AIR, TV NTSC CABLE, TV NTSC HRC
CABLE, TV NTSC IRC CABLE, TV PAL I AIR, TV
PAL I CABLE, TV PAL B/G AIR, TV PAL B/G
CABLE, TV NTSC J AIR, or TV NTSC J CABLE.
Note: For help selecting the correct setting,
see page 22.
If you have disabled the TV, go to step 12. If
you have enabled the TV, go to step 10.
9
8
7
6
5
4
3
2
1
