Nortel Meridian Meridian 1 User manual

Upgrade system installation Upgrading to Meridian 1 system options
Meridian 1
Upgrade system installation through X11
release 21
Upgrading to Meridian 1 system options
Document Number: 553-3001-250
Document Release: Standard 14.00
Date: August 1996
Year Publish FCC TM
© 1990, 1996
All rights reserved
Printed in the United States of America
Information is subject to change without notice. Northern Telecom reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant. This equipment has been tested
and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules, and the
radio interference regulations of Industry Canada. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their own expense.
SL-1 and Meridian 1 are trademarks of Northern Telecom.

iii
Upgrade system installation Upgrading to Meridian 1 system options
Revision history
January 29, 1990 Standard, release 1.0.
February 28, 1990 Standard, release 2.0.
January 15, 1991 Standard, release 3.0.
December 1, 1991 Standard, release 4.0.
Release 5.0 omitted.
April 5, 1993 Standard, release 6.0 (mislabeled as release 2.0). Reissued to include
upgrades to option 81.
August 1, 1993 Standard, release 7.0 (mislabeled as release 3.0).
January 21, 1994 Standard, release 8.0.
April 1, 1994 Standard, release 9.0.
December 1994 Standard, release 10.0. This document is reissued to include information on
the Small systems Multi-Disk Unit (SMDU), the NTND01CA 12MB ICM
card and Option 51C. Changes to technical content are noted by revision bars
in the margins.

iv
553-3001-250 Standard 14.00 August 1996
December 1994 Standard, release 11.0. Reissued for technical content.
July 1995 Standard, release 12.00. Includes new information on release 21 and
option 81C. Changes to technical content are noted by revision bars in the
margins, except in the option 81 and 81C sections where changes were
extensive and revision bars were not used.
December 1995 Standard, release 13.00. This document is reissued to include information on
the NT9D19 Call Processor Card. Changes to technical content are noted by
revision bars in the margins.
August 1996 Standard, release 14.00. This document is updated to include information on
the NT9D19 Call Processor Card for the option 51C and option 61C and new
memory requirements for systems upgrading to X11 release 22 software.
Changes to technical content are noted by revision bars in the margins.

v
Upgrade system installation 553-3001-250
Contents
General information . . . . . . . . . . . . . . . . . . . . . . 1-1
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
SL-1 A, M, S, and MS system upgrades . . . . . . 2-1
Upgrading A, M, S, and MS systems to option 51C . . . . . . . . . . . . 2-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Installing the connector housings . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Converting the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Turning on the power and configuring the system . . . . . . . . . . . 2-18
Upgrading A, M, S, and MS systems to option 61C . . . . . . . . . . . . 2-22
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Installing the connector housings . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Converting the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Turning on the power and configuring the system . . . . . . . . . . . 2-38
SL-1 L, LE, and N system upgrades . . . . . . . . . 3-1
Upgrading L, LE, and N systems to option 61C . . . . . . . . . . . . . . . 3-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Installing the connector housings . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Converting the SL-1 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10

vi Contents
553-3001-250 Standard 14.00 August 1996
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Turning on the power and configuring the system . . . . . . . . . . . 3-19
SL-1 ST and STE system upgrades . . . . . . . . . 4-1
Upgrading an ST system to an STE system . . . . . . . . . . . . . . . . . . . 4-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 4-4
Upgrading ST and STE systems to option 51C . . . . . . . . . . . . . . . . 4-48
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-54
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 4-55
Installing option 51C hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 4-58
Turning on the power and configuring the system . . . . . . . . . . . 4-60
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-72
Upgrading ST and STE systems to option 61C . . . . . . . . . . . . . . . . 4-73
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-73
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-78
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 4-81
Converting the SL-1 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 4-95
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-96
Turning on the power and configuring the system . . . . . . . . . . . 4-97
SL-1 RT system upgrades . . . . . . . . . . . . . . . . . 5-1
Upgrading an RT system to X11 release 21 . . . . . . . . . . . . . . . . . . 5-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 5-6
Upgrading an RT system to option 61C . . . . . . . . . . . . . . . . . . . . . 5-43
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-44
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-49
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 5-52
Converting the SL-1 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 5-62
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-64
Turning on the power and configuring the system . . . . . . . . . . . 5-66

Contents vii
Upgrade system installation Upgrading to Meridian 1 system options
SL-1 NT system upgrades . . . . . . . . . . . . . . . . . 6-1
Upgrading an NT system to X11 release 21 . . . . . . . . . . . . . . . . . . 6-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Upgrading an NT system to option 61C . . . . . . . . . . . . . . . . . . . . . . 6-69
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-70
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-75
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 6-78
Installing the connector housings . . . . . . . . . . . . . . . . . . . . . . . . 6-103
Converting the SL-1 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 6-104
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-106
Turning on the power and configuring the system . . . . . . . . . . . 6-108
SL-1 XT system upgrade . . . . . . . . . . . . . . . . . . 7-1
Upgrading an XT system to X11 release 21 . . . . . . . . . . . . . . . . . . 7-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Meridian 1 option 21 upgrades . . . . . . . . . . . . . 8-1
Upgrading option 21A to option 21E . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Installing option 21 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14
Upgrading option 21 to option 21E . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-34
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 8-36
Upgrading option 21/21E module to option 51C . . . . . . . . . . . . . . . 8-58
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-58
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-64
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 8-65
Installing option 51C hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 8-69
Turning on the power and configuring the system . . . . . . . . . . . 8-71

viii Contents
553-3001-250 Standard 14.00 August 1996
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-83
Upgrading option 21/21E card cage to option 51C . . . . . . . . . . . . . 8-84
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-84
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-88
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 8-90
Removing and installing the card cage . . . . . . . . . . . . . . . . . . . . 8-94
Upgrading the hardware and converting the database . . . . . . . . 8-106
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-108
Upgrading option 21/21E to option 61C . . . . . . . . . . . . . . . . . . . . . 8-112
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-112
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-118
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 8-121
Converting the SL-1 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . 8-126
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-127
Turning on the power and configuring the system . . . . . . . . . . . 8-128
Meridian 1 option 51 upgrades . . . . . . . . . . . . . 9-1
Upgrading option 51 to X11 release 21 . . . . . . . . . . . . . . . . . . . . . . 9-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 9-5
Upgrading option 51 to option 51C . . . . . . . . . . . . . . . . . . . . . . . . . 9-26
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-27
Terminal and modem connections . . . . . . . . . . . . . . . . . . . . . . . 9-29
Module backplane connections . . . . . . . . . . . . . . . . . . . . . . . . . . 9-30
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-32
Removing and installing the card cage . . . . . . . . . . . . . . . . . . . . 9-34
Upgrading the hardware and converting the database . . . . . . . . 9-46
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-48
Upgrading option 51 to option 61C . . . . . . . . . . . . . . . . . . . . . . . . . 9-51
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-51
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-57
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 9-60
Converting the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-65
Installing external cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-66
Turning on the power and configuring the system . . . . . . . . . . . 9-67

Contents ix
Upgrade system installation Upgrading to Meridian 1 system options
Upgrading option 51C to option 61C . . . . . . . . . . . . . . . . . . . . . . . . 9-77
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-77
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-83
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 9-86
Transferring call processing and installing intermodule cables . 9-90
Meridian 1 option 61 upgrades . . . . . . . . . . . . . 10-1
Upgrading option 61 to X11 release 21 . . . . . . . . . . . . . . . . . . . . . . 10-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 10-4
Upgrading option 61 to option 61C . . . . . . . . . . . . . . . . . . . . . . . . . 10-30
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-31
Terminal and modem connections . . . . . . . . . . . . . . . . . . . . . . . . 10-32
Module backplane connections . . . . . . . . . . . . . . . . . . . . . . . . . . 10-33
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-35
Installing the card cage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-37
Upgrading Core 0 and converting the customer database . . . . . . 10-53
Upgrading Core 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-60
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-63
Meridian 1 option 71 upgrade . . . . . . . . . . . . . . 11-1
Upgrading option 71 to X11 release 21 . . . . . . . . . . . . . . . . . . . . . . 11-1
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-3
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . . 11-4
Upgrades to Meridian 1 option 81 . . . . . . . . . . . 12-1
Terminal and modem connections . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Module backplane connections . . . . . . . . . . . . . . . . . . . . . . . . . . 12-2
Upgrading option 61C to option 81 . . . . . . . . . . . . . . . . . . . . . . . . . 12-5
Equipment required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-6
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-6
Installing option 81 hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-11
Performing a data dump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Splitting the CPUs on the option 61C . . . . . . . . . . . . . . . . . . . . . 12-13

xContents
553-3001-250 Standard 14.00 August 1996
Converting the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-15
Upgrading Core 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-27
Completing the Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-30
Option 71 card cage upgrade to option 81 . . . . . . . . . . . . . . . . . . . . 12-34
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-37
Upgrading CPU 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-48
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 12-66
Upgrading CPU 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-76
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-90
XT and option 71 Core module upgrade to option 81 . . . . . . . . . . . 12-92
Upgrade planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-96
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-100
Installing cables and connector housings . . . . . . . . . . . . . . . . . . 12-105
Preparing the Core Module column(s) . . . . . . . . . . . . . . . . . . . . 12-122
Transferring call processing to CPU 0 . . . . . . . . . . . . . . . . . . . . 12-136
Upgrading CPU 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-139
Transferring call processing to Core 1 . . . . . . . . . . . . . . . . . . . . 12-147
Upgrading CPU 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-149
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-154
XT Core and Network Module upgrade to option 81 . . . . . . . . . . . 12-163
Upgrade planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-166
Upgrade preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-168
Core and Network Module installation . . . . . . . . . . . . . . . . . . . . 12-170
Converting the customer database . . . . . . . . . . . . . . . . . . . . . . . 12-172
Installing external cables and connector housings . . . . . . . . . . . 12-185
Transferring service to the option 81 . . . . . . . . . . . . . . . . . . . . . 12-195
Completing the upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-199
System monitor upgrade installation . . . . . . . . 13-1
System monitoring in NT/XT systems and
QCA60-type cabinets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-3
System monitoring in ST and RT systems . . . . . . . . . . . . . . . . . . . . 13-10
Configuration 1—ST system with QCA136 and PE Module . . . 13-13
Configuration 2—ST system with QCA136 and CE/PE Module 13-17
Configuration 3—ST/RT system with QCA137 and CE/PE Module 13-24

Contents xi
Upgrade system installation Upgrading to Meridian 1 system options
Configuration 4—ST system with QCA136, QCA137, and PE Module
13-28
Configuration 5—ST system with QCA136, QCA137, and CE/PE
Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-33
Configuration 6—RT system with QCA147 and PE Module . . . 13-42
Configuration 7—RT system with QCA147 and CE/PE Module 13-46
Configuration 8—RT system with QCA147, QCA137, and PE Module
13-51
Configuration 9—RT system with QCA147, QCA137, and CE/PE
Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-57
Configuration 10—RT system with two QCA137s and CE/PE Module
13-64
Configuration 11—RT system with QCA147, two QCA137s, and PE
Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-69
Configuration 12—RT system with QCA147, two QCA137s, and CE/PE
Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-75
Ground package installation . . . . . . . . . . . . . . . 14-1
Installing Ground Package P0677580 . . . . . . . . . . . . . . . . . . . . . . . 14-1
Installing Ground Package P0677587 . . . . . . . . . . . . . . . . . . . . . . . 14-4
Installing Ground Package P0677588 . . . . . . . . . . . . . . . . . . . . . . . 14-7
Network hybrid installation . . . . . . . . . . . . . . . . 15-1
Removing the BTUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-2
Installing the Network Hybrids . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-4
Using the Extraction Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-7
Appendix A: Core Module upgrades
using NTND33BB/BC/BD Cable Kits . . . . . . . . . A-1
Installing NTND33Bx cable kits . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Labelling cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Assembling and mounting connector housings . . . . . . . . . . . . . . . . A-12
Preparing the Core Module columns . . . . . . . . . . . . . . . . . . . . . . . . A-17
Connecting intercabinet cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-24

xii Contents
553-3001-250 Standard 14.00 August 1996
Appendix B: Terminal and modem connections B-1
Options 51C, 61C, 81, and 81C terminal and modem connections B-8
Configuring an A0638930 Motorola 28.8 Data/Fax Modem . . . B-17
Configuring an A0381391 UDS FastTalk modem . . . . . . . . . . . B-20
Connecting a modem to an SDI port . . . . . . . . . . . . . . . . . . . . . . B-22
Connecting a modem to a switch box and CPSI and SDI ports . B-24
Appendix C: Troubleshooting . . . . . . . . . . . . . . C-1
Troubleshooting procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1

1-1
Upgrade system installation Upgrading to Meridian 1 system options
2
General information
1
This document describes how to upgrade SL-1 and Meridian 1 systems
running on hardware and software prior to X11 release 21. When upgrading
a system to X11 release 21, in addition to this document, refer to the
following documents:
— Meridian 1 system installation procedures (553-3001-210)
— Software conversion procedures (553-2001-320)
— Upgrade engineering (553-3001-150)
— Circuit card installation and testing (553-3001-211)
— Disk drive upgrade procedures (553-3001-251)
— X11 input/output guide (553-3001-400)
— X11 features and services (553-3001-305)
Please note that the NTPs contain 2 sections relating to hardware upgrades.
These two sections are Upgrade system installation to X11 release 22
(553-3001-258) and Upgrade system installation (553-3001-250).
— Upgrade system installation to X11 release 22 (553-3001-258) defines
theproceduresforsystemsupgradingtooption51C,61Cand81C,where
the existing system is on release 18 or later. This NTP may reference the
upgrade procedures in Upgrade system installation (553-3001-250).
— Upgrade system installation (553-3001-250) documents hardware
upgrades to release 21 and is used as a reference.

1-2 General information
553-3001-250 Standard 14.00 August 1996
Tools
Table 1-1 lists the tools that you will need for upgrading a Northern Telecom
system. Special tools required in a procedure are listed in that procedure.
Table 1-1
List of recommended tools
Digital Multimeter (DMM)
Pliers, needlenose
Pliers, standard
Screwdriver, 3/16" flat blade
Screwdriver, #2 Phillips
Wire cutters
Electrical insulation tape
5/16" socket wrench
Electric drill and drill bits
Hammer and sheet metal center punch
1/4" socket wrench
3/8" socket wrench
1/4" nut driver
7/16" socket driver

2-1
Upgrade system installation Upgrading to Meridian 1 system options
44
SL-1 A, M, S, and MS system upgrades
2
This chapter covers these upgrades:
— SL-1 A, M, S, or MS system to option 51C X11 release 21, below
— SL-1 A, M, S, or MS system to option 61C X11 release 21, page 2-22
Upgrading A, M, S, and MS systems to option 51C
To upgrade an SL-1 A, M, S, or MS system to an option 51C, you must
upgradeboththehardwareandthesoftware.Upgradingthe hardware consists
of the following:
— removing the common equipment (CE) from the SL-1 cabinet
— installing a Meridian 1 option 51C column next to the SL-1 cabinet
— installing new connector housings on the SL-1 cabinet
— cabling the cabinet to the option 51C column
Upgrading the software consists of the following:
— If you choose to have the customer database converted, you must send it
to Northern Telecom for conversion; contact your Northern Telecom
representative to arrange for this. Alternatively, you can reenter the
database on the option 51C after the upgrade is complete.

2-2 SL-1 A, M, S, and MS system upgrades
553-3001-250 Standard 14.00 August 1996
Equipment required
Tables 2-1 and 2-2 list the items required to upgrade an AC- or DC-powered
system to an X11 release 22 Meridian 1 option 51C. Some configurations
may require items not included in the tables. All required items must be
identified and on hand before the upgrade can start.
Letters at the end of a part number represent the minimum vintage equipment
that can be used in the upgrade; only equipment of that vintage or later can be
used. Refer to Product compatibility (553-3001-156) for equipment
compatibility information.
Network cables are required to connect peripheral shelves in the cabinet to
network cards in the column. The number of cables required depends on the
number of network cards installed. These are the cables:
— NT8D86AC cables that connect the network card and the peripheral
buffer card to the I/O panel
— NT9J96 cables that connect the I/O panel in the Core/Network module to
the cabinet I/O panel
An NT8D01 Controller card is provided to support the intelligent peripheral
cards in the new IPE module. If analog peripheral cards are used in the IPE
module, one NT8D21 Ringing Generator must be installed.

SL-1 A, M, S, and MS system upgrades 2-3
Upgrade system installation Upgrading to Meridian 1 system options
Table 2-1
Hardware requirements for an AC-powered option 51C (Part 1 of 2)
Qty Part number Description
1NT1R91AA Modem Kit
1 NT5D20AA I/O Processor and Core Multi Drive Unit
1 NT5D21AA Core/Network module, AC
1 NT6D65AA Core to Network Interface card (CNI)
1 NT9D19AA 48 MB Call Processor card (CP)
1 NT7D00AA Top Cap, AC
1 NT8D01BC Controller-Four card
1 NT8D04BA Superloop Network card
1 NT8D06AA Peripheral Equipment Power Supply, AC
1 NT8D17FA Conference/TDS card
1 NT8D22AC System Monitor
1 NT8D27BB Pedestal, AC
1 NT8D29AB Common Equipment Power Supply, AC
1 NT8D37BA Intelligent Peripheral Equipment module, AC
2 NT8D41AA Dual-Port SDI Paddle Board
1 NT8D46AG System Monitor to SDI Paddle Board Cable
(34 in.)
1 NT8D46BH System Monitor to MDF Cable (32 ft.)
1 NT8D52AB Pedestal Blower Unit, AC

2-4 SL-1 A, M, S, and MS system upgrades
553-3001-250 Standard 14.00 August 1996
1 NT8D53BB Power Distribution Unit, AC
2 NT8D80AZ CPU Interface Cable (5 ft.)
3 NT8D84AA SDI Paddle Board to I/O Cable (18 in.)
1 NT8D91AE Network to Controller Cable (8 ft.)
1 NTND13BC IOP to IOP SCSI cable (6 ft.)
4 NTND21AA Module Side Cover
1 QPC43R Peripheral Signaling card (PS)
1 QPC441F Three-Port Extender card (3PE)
1 QPC471H Clock Controller
Note 1: One NT8D21AA Ringing Generator, AC, must be added for each IPE
module in which analog-type peripheral cards are to be used.
Note 2: A superloop network card, an IPE module, and a power supply and cable
are included in the upgrade package to provide replacement card slot availability for
the existing IPE cards contained in the unused NT8D11 module.
Table 2-1
Hardware requirements for an AC-powered option 51C (Part 2 of 2)
Qty Part number Description

SL-1 A, M, S, and MS system upgrades 2-5
Upgrade system installation Upgrading to Meridian 1 system options
Table 2-2
Hardware requirements for a DC-powered option 51C (Part 1 of 2)
Qty Part number Description
1NT1R91AA Modem Kit
1 NT5D20AA I/O Processor and Core Multi Drive Unit
1 NT5D21DA Core/Network module, DC
1 NT6D40AB Peripheral Equipment Power Supply, DC
1 NT6D41AB Common Equipment Power Supply, DC
1 NT6D65AA Core to Network Interface card (CNI)
1 NT9D19AA 48 MB Call Processor card (CP)
1 NT7D00BA Top Cap, AC
1 NT7D09CA Pedestal, DC
1 NT7D10CA System Monitor Panel
1 NT7D67CB Power Distribution Unit, DC
1 NT8D01BC Controller-Four card
1 NT8D04BA Superloop Network card
1 NT8D17FA Conference/TDS card
1 NT8D22AC System Monitor
1 NT8D37EC Intelligent Peripheral Equipment module, AC
2 NT8D41AA Dual-Port SDI Paddle Board
1 NT8D46AG System Monitor to SDI Paddle Board Cable
(34 in.)

2-6 SL-1 A, M, S, and MS system upgrades
553-3001-250 Standard 14.00 August 1996
1 NT8D46BH System Monitor to MDF Cable (32 ft.)
1 NT8D52DD Pedestal Blower Unit, DC
3 NT8D84AA SDI Paddle Board to I/O Cable (18 in.)
1 NT8D91AE Network to Controller Cable (8 ft.)
2 NT8D99AB CPU to Network Cable (2 ft.)
4 NTND21AA Module Side Cover
1 QPC43R Peripheral Signaling card (PS)
1 QPC471H Clock Controller
1 QPC441F Three-Port Extender card (3PE)
Note 1: One NT6D42CC Ringing Generator, DC, must be added for each IPE
module in which analog-type peripheral cards are to be used.
Note 2: A superloop network card, an IPE module, and a power supply and cable
are included in the upgrade package to provide replacement card slot availability for
the existing IPE cards contained in the unused NT8D11 module.
Table 2-2
Hardware requirements for a DC-powered option 51C (Part 2 of 2)
Qty Part number Description

SL-1 A, M, S, and MS system upgrades 2-7
Upgrade system installation Upgrading to Meridian 1 system options
Upgrade preparation
Some preparation is required before the conversion of the SL-1 hardware and
software begins. You must first do the following:
— Inventory all equipment required for the upgrade.
— Provideappropriate power and ground fortheincreasedelectricalload of
the option 51C.
— Install the option 51C hardware.
— Back up the customer database to disk by doing a data dump.
Power and ground
Clean power and a good ground are prerequisites to any switch upgrade.
Refer to Upgrade engineering (553-3001-150) to verify that sufficient power
is available for the new equipment. Follow the procedures outlined in
Meridian 1 system installation procedures (553-3001-210) to install new
power equipment and to provide a good ground for the equipment.
Installing option 51C hardware
The option 51C equipment is preconfigured at the factory according to your
requirements. The equipment includes the pedestal, Core/Network modules,
IPE module, cards, and top cap. Cards such as MDUs and power supplies are
shipped in separate packages to prevent damage to the cards.
Figure 2-1 shows the option 51C common equipment and intelligent
peripheral equipment modules and cards installed in their typical card slots.
To install the option 51C at your site, first follow the procedures in
Meridian 1 system installation procedures (553-3001-210) and then continue
with the procedures in this chapter.
Also install any external cables that can be installed at this time without
interrupting service (see “Installing external cables” on page 2-15).
