Nortel Norstar M7100 User manual

© 2000 Nortel Networks
P0908511 Issue 03
Enterprise Edge
M7100
Quick Reference Guide

Page 1 Enterprise Edge M7100 Quick Reference Guide
Your Enterprise Edge M7100 telephone
Using Button Inquiry Check what is programmed on your memory button.
1. Release all calls or lines with dial tone.
2. Press ƒ•‚.
3. Press the button that you want to check.
4. Read the display.
5. Press ƒwhen finished.
Adjusting the display
contrast 1. Press ƒ•‡.
2. Press ⁄to ·for the level you want; the higher the number
the higher the level.
Selecting a ring type and
volume level 1. Press ĥfl.
2. Press ⁄, ¤, ‹or ›to hear the different ring types.
3. While the telephone is ringing, press √to adjust
the volume level.
4. Press ƒto store the ring.
Adjusting the handset or
telephone speaker volume 1. Press √when using the handset or the speaker.
Display
shows the time, date, call information, and guides you.
Feature button
starts or ends a feature.
Release button
cancels active calls
Hold button
Dial pad
Volume control
Memory button
is programmable to store a feature or to
automatically dial internal or external
number.

Page 2 Enterprise Edge M7100 Quick Reference Guide
Making and answering calls
Answering calls 1. When your telephone rings, lift your handset.
You are immediately connected to the call.
Making external calls Depending upon the dialling mode programmed for your
telephone, you may be able to dial your call before lifting your
handset.
1. Pick up the handset.
2. Dial ‚(your system’s exchange line access code or a line
pool access code).
3. Dial the external telephone number.
Making internal calls 1. Pick up the handset.
2. Dial the internal number.
Note: Extension numbers and the exchange line access code
are supplied by your System Administrator.
Making or answering a
second call The M7100 telephone allows you to have two calls active at the same time.
You can switch between calls using ˙.
To answer a second call while on another call
1. Press ˙to put the first call on hold.
The second call automatically comes onto the line.
To hold a call and make a second call
1. Press ˙to put the first call on hold.
2. Dial the telephone number for the second call.
To return to the first call
1. Press ˙again to return to the first call on hold.
The second call is automatically put on hold.
˙To hold a call
1. Press ˙.
2. Press ˙again to return to the call on hold.
Check the display for confirmation or additional information.
Note: If you have difficulty selecting a line on your M7100
telephone, ask your System Administrator to check your
telephone's programming. Your telephone must be assigned to
use an exchange line or line pool.

Page 3 Enterprise Edge M7100 Quick Reference Guide
Programming the memory button
Remember: Press ƒ•‚ to check a memory or
line button.
Programming the memory
button External Autodial
1. If you are on a call or a line with dial tone, press ˙or
®.
2. Press ƒ•⁄.
3. Dial the external number.
4. Press ˙to store the number.
5. Label your new button.
Internal Autodial
1. If you are on a call or a line with dial tone, press ˙or
®.
2. Press ƒ•¤.
3. Dial the extension number.
4. Label your new button.
Features
1. If you are on a call or a line with dial tone, press ˙or
®.
2. Press ƒ•‹.
3. Press ƒand the feature code.
4. Label your new button.
Erasing the memory button
1. If you are on a call or a line with dial tone, press ˙or
®.
2. Press ƒ•⁄.
3. Press ˙to erase the button.
Notice This telephone now conforms to the latest standards in
relation to the positioning of Q and Z on the number keys. The
Q appears on key number 7 and the Z appears on key
number 9.
About the
memory button The memory button can store a
telephone number or feature code to
give you one touch dialling or feature
activation. You can change the
memory button by programming it
with a new number or feature code.
Memory button

Page 4 Enterprise Edge M7100 Quick Reference Guide
Setting up the telephone
Connecting the cords ATTENTION Before attempting
to carry out any work on the
telephone, ensure that the line
cord is unplugged from the wall
socket.
To remove any of the cords,
squeeze the release latch on the
plug and gently pull the plug
from the socket.
Connect the handset cord to the
jack labelled with the telephone
icon and route the cord as
shown.
Route the line cord through the
stand and connect the cord to
the telephone jack that is
marked with the jack icon.
Attach the stand using the slots
on the back of the telephone.
Once the above work is
complete, plug the line cord back
into its wall socket.
Connect to jack
from distribution block
Connect to receiver

Page 5 Enterprise Edge M7100 Quick Reference Guide P0908511 Issue 03
Setting up the telephone
Mounting the
telephone on
the wall
