Nortel Norstar M7208 Parts list manual

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○
M7208
Telephone
User Card

2
Your Norstar M7208 telephone
Display
shows the time, date, call information and guides you
while using Norstar* features.
Indicators
appear beside active lines and features.
Feature button
starts or ends a feature.
Release button
cancels active calls.
Hold button
Dial pad
Volume control
Memory and line buttons
are buttons with indicators for one
touch dialing, feature operation or line
access.
* Meridian and Norstar are trademarks of Northern Telecom.
Button Inquiry Confirm that your memory and line buttons have the correct snap-on caps by
checking their programming.
1. Release all calls and open lines with dial tone.
2. Press ƒ•‚ .
3. Press the button you want to check.
4. Read the display.
5. Press ƒ when finished.
1. Press ƒ•‡ .
2. Press a number on the dial pad for the contrast level you want, the higher
the number the higher the contrast level.
1. Press ĥfl .
2. Press ⁄ , ¤ , ‹ or › ␣ to hear the different types of rings.
3. While the telephone is ringing, press √ to adjust the volume.
4. Press ƒ to store the ring.
1. Press √ when using the receiver or the speaker.
Selecting a Ring
Type and volume
level
Adjusting receiver or
telephone speaker
volume
Adjusting display
contrast
softer louder
softer louder
Important: All M7208 telephones Release 16 (REL 16) and higher comply with the Americans with Disabilities Act
(ADA). See the label on the bottom of the telephone for the Release marking.

3
Making calls
About line buttons Norstar systems can have different types of line buttons. Match the line
buttons on your telephone with the ones below for instructions on how to use
them.
Internal calls using Intercom buttons
1. Pick up the receiver.
2. If º appears beside an Intercom
button, then dial.
OR
Press an Intercom button without
º , then dial.
External calls using numbered Line
buttons
1. Pick up the receiver.
2. When º appears beside a
numbered Line button, then dial.
OR
Press a numbered Line button
without º , then dial.
Note: Internal numbers are supplied by your System Coordinator.
External calls using extension
buttons
1. Pick up the receiver.
2. When º appears beside the
extension button, dial ·
(or your system's external line
access code) and the number.
Internal calls using extension
buttons
1. Pick up the receiver.
2. When º appears beside an
extension button, then dial.
Holding Calls
1. Press ˙ .␣ The º flashes beside the line on hold.
2. Press the line button with the flashing º to return to the call.
Check the display for confirmation or additional information.
Automatic hold
Calls are put on hold automatically when you switch from one line to another.
This button operates the telephone's built-in microphone and speaker in place
of the receiver. Your System Coordinator can program Handsfree to your
telephone.
Making calls
1. Press © instead of picking up the receiver.
Switching between Handsfree and handset
1. Press © and replace the handset to switch to Handsfree.
2. Pick up the receiver to switch back.
Using Mute
1. Press © to turn the microphone OFF.
2. Press © ␣ again to turn the microphone ON.
1. Press a line button without º , then dial your call.
2. When answered, pick up the receiver, or press © .
3. If the call is not answered, or the line is busy, press ® .
∫
Line 1
∆
∫
4321
˙
©
Dialing without
lifting the handset

4P0749848 Issue 02 Printed in Canada
Programming memory buttons
About memory
buttons
Remember: Press ƒ•‚ to check a memory or line button.
External autodial
1. If you are on a call or an open line with dial tone, press ˙ ␣
or ® .
2. Press ƒ•⁄ .
3. Press a memory button.
4. Dial the external number.
5. Press ˙ ␣ to store the number.
6. Label your new button.
Internal autodial
1. If you are on a call or an open line with dial tone, press ˙ ␣
or ® .
2. Press ƒ•¤ .
3. Press a memory button.
4. Dial the internal number.
5. Label your new button.
Features
1. If you are on a call or an open line with dial tone, press ˙ ␣
or ® .
2. Press ƒ•‹ .
3. Press a memory button.
4. Press ƒ and the feature code.
5. Label your new button.
Erasing memory buttons
1. If you are on a call or an open line with dial tone, press ˙ ␣
or ® .
2. Press ƒ•⁄ .
3. Press the memory button you want to erase.
4. Press ˙ ␣ to erase the button.
Programming
memory buttons
Memory buttons are the buttons
with indicators other than line or
Handsfree buttons. Memory
buttons store telephone numbers
or feature codes to give you one
touch dialing or feature activation.
You can change what a memory
button does by just programming
it with a new number or feature.
You cannot program a line or
Handsfree button.
